The supervised hierarchical Dirichlet process

12/17/2014 ∙ by Andrew M. Dai, et al. ∙ Google 0

We propose the supervised hierarchical Dirichlet process (sHDP), a nonparametric generative model for the joint distribution of a group of observations and a response variable directly associated with that whole group. We compare the sHDP with another leading method for regression on grouped data, the supervised latent Dirichlet allocation (sLDA) model. We evaluate our method on two real-world classification problems and two real-world regression problems. Bayesian nonparametric regression models based on the Dirichlet process, such as the Dirichlet process-generalised linear models (DP-GLM) have previously been explored; these models allow flexibility in modelling nonlinear relationships. However, until now, Hierarchical Dirichlet Process (HDP) mixtures have not seen significant use in supervised problems with grouped data since a straightforward application of the HDP on the grouped data results in learnt clusters that are not predictive of the responses. The sHDP solves this problem by allowing for clusters to be learnt jointly from the group structure and from the label assigned to each group.



There are no comments yet.


page 10

This week in AI

Get the week's most popular data science and artificial intelligence research sent straight to your inbox every Saturday.

1 Introduction

Bayesian nonparametric models allow the number of model parameters that are utilised to grow as more data is observed. In this way the structure of the model can adapt to the data. A Dirichlet process (DP) mixture model [1] is a popular type of nonparametric model that has an infinite number of clusters. DP mixtures are trained in an unsupervised manner and are frequently used for problems that require model adaptation to different data sizes or where more and more new components are likely to be represented in the data as the data size increases.

In this paper, we describe a new nonparametric supervised model for grouped data that utilises topics, where topics are distributions over data items that are shared across groups. We analyse the performance of the model using experiments on both regression and classification tasks. The problems of regression and classification are ubiquitous and related; both involve labelled examples. Each example takes the form of pair consisting of a predictor, also known as input, covariate or independent variable, and a response, also known as output or dependent variable. The set of examples is then used as data to inform models that predict the responses for test examples where the response is unknown.

Topic models such as latent Dirichlet allocation (LDA) [2] are unsupervised models of grouped data, where the topics are distributions that are shared across the groups. A typical example of such data is the text in the documents of a corpus. In this context, each group is a document, and the topics are distributions over a vocabulary of terms (e.g. words). The topic distributions are shared across a number of the documents. Each topic can be thought of as a group of semantically related words, and inferred topics shed light on the common themes that run through the documents. Topic modes of this form are mixed-membership models since each document consists of a mixture of topics in different proportions. Topic models have been successful in analysing collections of documents, including abstracts from citation databases [3] and newsgroup corpora. They can also be used for a wide range of applications including data exploration, authorship modelling [4] and information retrieval. The latent topics that are learnt are particularly important when modelling large document collections as they can reduce the dimension of the data.

Recently, attention has turned to these models as ways of performing regression and classification on collections of documents, where each document possesses an associated response. The response can be categorical, continuous, ordered or of some other type. For example, the response could be a sentiment rating. A simple approach to the problem of modelling document responses is to use topic models as a dimensionality reduction method and then to regress on the resulting lower dimensional dataset. A set of topics is learnt for the corpus using a topic model while ignoring the document responses. Then the document responses are regressed on the empirical topic distribution for each document. However, this approach performs poorly in contrast to directly regressing on the empirical word distribution for each document [5]. The topics that are learnt also often have no relation to the responses that need to be predicted. As a result, the words that cause positive responses and those that cause negative responses end up being assigned to the same topic. This difficulty has spurred interest in supervised topic models that can learn topics that are both good models of document contents and are good predictors for document responses.

Supervised topic models (sLDA) [5] are an extension of latent Dirichlet allocation (LDA) [2]

. Topics that are learnt are more useful for predicting a document’s response than those obtained in unsupervised LDA. This is because the learnt topics are oriented around terms that are predictive of document responses. For example, in sentiment analysis tasks, the topics learnt consist of terms that cause the document to have positive or negative sentiment. Similarly, for financial news, the topics consist of terms that have positive or negative effects in the market. In contrast, unsupervised LDA learns topics that are in line with the general theme of the documents, but are often unrelated to the document responses.

Blei and McAuliffe [5]

found that the predictions made by sLDA for the responses of an unseen test set were better than the predictions made using the unsupervised topics inferred by LDA. However, they found that the sLDA model only performed slightly better than LASSO regression on the empirical distribution of words for each document.

Although supervised topic models perform well, they are limited as the number of topics in the model must be fixed in advance. This can lead to overfitting in sLDA when there are too many topics and regression parameters in the model so that topics are relatively specific and do not generalise well to unseen observations. Underfitting is the opposite case when there are too few topics and regression parameters in the model so unrelated observations are assigned together to the same topic. Another characteristic is the relative contribution of the supervised and unsupervised components to the model. In a fixed parametric setting it can be that one or the other (typically the unsupervised part) of these signals may dominate the likelihood, which determines the topic features. In a nonparametric setting, any dominant individual signal is captured by a set of components, leaving the remaining joint topic and supervised signal to be captured by as many additional components as are relevant.

A number of methods can be used to choose the number of topics, including cross-validation and model comparison techniques; however, these are slow as the algorithm has to be restarted a number of times and choosing the ideal number of topics from the runs can be difficult. Bayesian nonparametric methods have emerged as a good way to extend these models naturally to handle a flexible number of topics.

The nonparametric supervised HDP (sHDP) model is presented in this paper. The sHDP model is a generative supervised model that has an infinite number of topics (or clusters) that can be used to predict a document response. The sHDP model is a nonparametric extension of the supervised topic model (sLDA) [5]. The main contribution of the model is that it overcomes the issue of choosing the fixed number of topics that is necessary for sLDA. The fact that the model has an infinite number of topics also reduces the problems of underfitting and overfitting. The sHDP can also be considered a supervised extension of the HDP mixture model described in Section 3.1. In this paper, we show that sHDP performs better than sLDA on one dataset or comparable to sLDA with the best performing number of topics (chosen post-hoc) on two out of three other datasets (see e.g. Figure 2).

The rest of the paper is organised as follows. Section 2 sets the problem and the form of the data for the models proposed in this paper. Then in Section 3

, we briefly review some existing work on tackling the supervised learning problem with nonparametric models and also approaches specifically for grouped data, and goes on in Section

3.2 to give an introduction to generalised linear models, and review the sLDA model (Section 3.3), both of which are important in the later parts of the paper. We then introduce the supervised HDP model in Section 4. Section 5 describes the inference algorithms that are used to sample from the posterior of the new model. Finally, Section 6 covers experiments with this model on real-world datasets consisting of both binary and continuous responses and compares the new model to existing models.

2 Problem description

In this section we outline the structure of the problems for which this work is relevant. First, we assume that there is a set of data points divided into groups. Second, to reduce complexity, we should be willing to assume a bag of words representation can be used for each group, which amounts to assuming exchangeability among the observations within a group. Each group consists of both a variable number of data points , which are the predictors, and a single response . Given a set of training examples with predictors and associated responses, the task is to predict the responses on a separate test set of predictors. In the case of document modelling, is the number of documents in the corpus, each word uses one-of- encoding where is the size of the vocabulary of the corpus. is the response for the document, such as a rating or a category. In the rest of this paper, the problem and models will be described in terms of documents and words, but all the models can also be used on other kinds of grouped data.

3 Background

In this section we outline previous work and other methods that will be used in this paper. Many of these approaches utilise Bayesian nonparametric models to gain more flexibility than parametric models.

Due to their flexibility, there has been interest in supervised nonparametric models, such as the regression models of Gaussian processes (GPs) [6]

and Bayesian regression trees. Dirichlet processes have also been adapted for supervised problems. An example of this is the Dirichlet process multinomial logit model (dpMNL)


. In this generative model, the relationship between the covariates and responses are modelled jointly using Dirchlet process mixtures. Although within each cluster the relationship is assumed to be linear, an overall nonlinear relationship occurs when the model has more than one cluster. A multinomial logit is used to model the responses conditionally on the covariates within each cluster. Thus, the regression parameters of the logit model are different for each cluster. The predicted responses are conditional on the parameters and the covariates. The dpMNL model was tested on protein fold classification, and compared with existing methods based on neural networks and support vector machines. The results showed that the dpMNL model performed significantly better.

The dpMNL has been extended to model additional response types with DP mixtures of generalised linear models (DP-GLM) [8]. Whereas the dpMNL only explicitly models discrete responses, the DP-GLM can generatively model both continuous and discrete responses using different generalised linear models. Again, the regression coefficients of the generalised linear models are different for each cluster. Priors are also placed on the coefficients, resulting in a regularised model for the response. The model was shown to have weak consistency by Hannah et al. [8], and the performance was shown to be comparable to a Gaussian process model.

Neither the dpMNL nor the DP-GLM has, to our knowledge, been applied to the problem of predicting the responses of groups of observations. The supervised topic model (sLDA) is one approach to tackling this prediction problem for grouped data (e.g. documents). sLDA learns topics that are able to model the document responses more accurately. The sLDA model has, however, limited flexibility since the number of latent topics must be fixed in advance leaving it at risk of overfitting or underfitting. There has also been work on other methods of learning the regression coefficients or other response types such as DMR [9], MedLDA [10] and labeled LDA [11], however, these models still have a fixed number of topics.

Hierarchical Dirichlet process (HDP) mixture models, described in Section 3.1, are a type of Bayesian nonparametric model that can be used instead of LDA for topic modelling. They are commonly used as the nonparametric analog to LDA, allowing for flexible topic modelling without being restricted to a fixed number of topics. Though inference is more complex, Gibbs sampling and variational Bayes techniques can still be applied. Until now, HDP mixtures have not seen significant use in supervised problems and suffer the same problems as unsupervised LDA in that the topics learnt are not necessarily predictive of the responses. The sHDP model we present in this paper extends the HDP mixture model to learn topics that are good predictors of document responses.

3.1 Hierarchical DPs

A Dirichlet process (DP) [1, 12]

is a stochastic process that can be thought of as a probability distribution on the space of probability measures. The name of the process accurately describes the fact that the DP results in finite-dimensional Dirichlet marginal distributions, similar to the Gaussian process that has Gaussian distributed finite-dimensional marginal distributions. DPs are commonly used as a prior on the space of probability measures, which give wider support and so improved flexibility over using traditional parametric families as priors. In addition, DPs also have tractable posteriors so making them important in Bayesian nonparametric problems. A DP is defined in terms of a base measure and a concentration parameter. Each draw from the DP is itself a measure. Since there is a positive probability of drawing a previously drawn value, the draws are discrete with probability

. This makes them very useful for clustering in DP mixtures.

The HDP [13] is a hierarchical extension to DPs. The hierarchical structure provides an elegant way of sharing parameters. This process defines a set of probability measures for pre-specified groups of data and a global probability measure . The global measure is distributed as


where is the base probability measure and is the concentration parameter.

The random measures for each group are conditionally independent given the global measure


where is a concentration parameter. The distribution varies around by an amount controlled by and the distribution in group varies around by an amount controlled by . This can be seen as adding another level of smoothing on top of DP mixture models. Let be i.i.d. variables distributed to and each of these variables is a parameter that corresponds to an observation , the likelihood of these observations being


where is the distribution of given . This prior results in a DP being associated with each group in the model where the DPs are conditionally independent given their parent and the parameters drawn in the parent node are shared among the descendant groups. This structure can be extended to multiple levels.

The HDP requires that the data be in a pre-defined nested structure. The HDP model has been used in information retrieval tasks and used in relation with traditional TF-IDF measures [14] for measuring the score of documents in relation to a query. There are variants of HDP that model topics for documents where there is no predefined hierarchical structure (see e.g. [15]).

3.1.1 Similarity to LDA

With the appropriate base measure, the HDP can be thought of as the infinite analogue of LDA. In the HDP, the base probability measure allows for a countably infinite number of multinomial draws and so an infinite number of topics. This allows the number of topics to grow or shrink according to the data. This solves the problem of finding the best number of topics in LDA and reduces the problems of overfitting or underfitting due to a fixed number of topics.

3.2 Generalised linear models

Often when a response is not an unconstrained continuous variable, it is transformed into one and a normal linear model is used for it. However, this may not always be appropriate. A generalised linear model (GLM) [16]

expands the flexibility of linear regression by being capable of analysing data where either there may not be a linear relation between the covariates

and the response or where a Gaussian assumption for is inappropriate. Given parameters , and covariates , a generalised linear model is specified by a linear predictor which we denote in this section by , a link function that relates the linear predictor to the mean of the response and a probability distribution from the exponential family that gives the distribution of the response with mean . In this paper, we only consider canonical link functions though others can be used when needed. The canonical link function is a choice of link function such that is the natural parameter in the exponential family distribution. The distribution of the response may also be an exponential dispersion family that has an additional dispersion parameter denoted as . We denote this as ExpFam. The generalised linear model for response takes the form


where the log-normaliser.

Different forms of responses can be modelled using different choices of and . In particular, there is a Gaussian distribution on ,


when and . This is a normal linear model with a mean of

and variance of



is binary, a binomial distribution can be used with the number of trials

, so that is distributed as


which uses the canonical logit link function and the binomial distribution for

. This choice of distribution and link function results in a logistic regression model.

3.3 The supervised topic model

The supervised topic model (sLDA) [5] is an extension of LDA to supervised problems. It partially overcomes the problem that the topics that are learnt cannot be controlled in the LDA model. The learnt topics in LDA act to reduce the dimension of the data but may not be predictive of a document’s response as they will correspond to the general themes of the corpus. sLDA overcomes this problem by jointly learning topics and their regression coefficients for the document responses. The response for a document is predicted by averaging over the empirical topic allocations for a document.

The generative process for each document is the following. Let be the fixed number of topics, the number of words in document , the topics where each is a distribution over the vocabulary, a parameter for topic proportions, and and the response parameters.

  1. Draw topic proportions .

  2. For each word (enumerated by )

    1. Draw a topic assignment .

    2. Draw a word .

  3. Draw the document response where .

This implements a GLM for the document responses: ExpFam is a distribution from the exponential family, is the link function and is the dispersion parameter for the distribution. The linear predictor in the GLM model for the response is where are the empirical frequencies of the topics in the document and are the regression coefficients. Exchangeability of the topic assignments imply posterior parameter symmetries in the GLM model, were a full Bayesian solution obtained. However if we are constrained to a MAP inferential setting there is no possibility of parameter symmetry and so there is symmetry breaking of the exchangeability of topic assignments. The inference process used must be sensitive to this broken symmetry. An inference process that considers the generation process for the document contents first enables consistent topic labels to be determined. Then the document’s response is chosen conditional on those contents, and hence on topic labels that have a consistent meaning. An alternative to this is to choose a model where is regressed on the topic proportions for the document,

. However, this may result in some topics being estimated that just explain the response variables while other topics only explain the document words.

In the sLDA model, the parameters , , and are treated as constants to be estimated. Approximate maximum-likelihood estimation is then performed with a variational expectation-maximisation (EM) method, similar to that for LDA. Collapsed Gibbs sampling can also be used for inferring the topics jointly as in LDA.

The models we propose in this paper solve the issue sLDA has of requiring the number of topics to be fixed from the start. This can result in overfitting or underfitting if the number of topics is unsuitable for the dataset. Though the number of topics can be chosen based on a training set, the process can be difficult and time consuming.

4 The supervised HDP (sHDP) model

The supervised HDP (sHDP) model proposed in this paper can automatically learn the necessary number of topics to model the responses of documents on training data. It is a Bayesian nonparametric model so that a potentially infinite number of latent clusters can be used for prediction. The sHDP model extends the HDP mixture model to learn clusters that align with document responses. The relationship between the data points and the responses is modelled with a generalised linear model on the clusters to which the data points in a document have been allocated. A regression coefficient is associated with each cluster, and the document’s response is regressed on the mean of these coefficients.

In the sHDP model, unlike sLDA, the number of topics does not need to be fixed in advance. This is beneficial in supervised problems since it is unclear how many latent topics will be necessary to model the data and the response conditional on the document. The response is modelled by a generalised linear model (GLM) conditioned on the topics that have been assigned to the observations in the document. Since the number of instantiated topics can vary and each topic has a regression coefficient, the number of instantiated regression coefficients also varies given the current number of instantiated topics. In the generative process, a regression coefficient is sampled for each topic in addition to sampling a distribution over the vocabulary. In effect, a product base measure is used for the topics where one component is a prior over the vocabulary and the other is a prior for the regression coefficient. This treats the regression coefficients as random variables, whereas in sLDA, the regression coefficients are treated as constants. This modelling of the regression coefficients results in a regularised regression model for the response variables. Each topic can also be assigned a vector of regression coefficients for categorical responses.

The model is thus


where is the linear predictor for the GLM, is its link function and is the dispersion parameter for the exponential family distribution. ranges over each document, ranges over each observation in that document, denotes the concentration parameter for the corpus-level DP and denotes the concentration parameter for the document-level DP. The base measure consists of a measure for the regression parameters and another measure for the topic parameters . is the corpus-level random measure that acts as the base measure for the document-level random measure .

Due to the clustering property of the DP, some data points will share the same parameters , which can be represented as those data points being assigned to the same topic. The prior density for the regression parameters is typically . For topic modelling, the documents consist of words, and the prior density for the cluster parameters is , where is the parameter for a symmetric Dirichlet distribution. is the likelihood of given the observations . In a topic modelling problem,

. When coupled with its conjugate prior, the Dirichlet distribution, the topic parameters

can be integrated out, allowing for collapsed Gibbs inference to be performed by just keeping track of the word to topic allocations and the regression coefficients for the topics. The GLM model for the responses allows the responses to be continuous, ordinal, categorical and other types depending on the form of the GLM. If the base measure for the coefficients is chosen to be Gaussian, the maximum a posteriori (MAP) solution for the coefficients is similar to the solution for penalised regression. A graphical model is shown in Figure 1.

Fig. 1: The supervised HDP model where the observed variables are the words denoting word in document and the document label .

The generative process for the full model is:

  1. Draw (from their prior distributions) the concentration parameters for the global DPs . Likewise, draw the concentration parameters for the lower-level DPs from their priors.

  2. Draw a global distribution over topics and their regression coefficients .

  3. Now for each document ,

    1. Draw a distribution over topics .

    2. For each word ,

      1. Draw a topic .

      2. Draw a word .

    3. Draw a response for the document where .

The sHDP learns topics that both model document contents well and are predictive of document responses without the need to choose a fixed number of topics beforehand. This structured approach to supervision allows the model to be easily extended to incorporate additional information from documents to aid in predicting the response such as the authors of a document or the research group which authored a document, which can be inferred through the grouped author-topic model [17]. For example, there is the problem of predicting the venue where a paper is published by learning the venues where the research group has previously published. Another example could be the problem of predicting a set of keywords or categories for a paper by learning which categories have previously been picked by the research group for those topics. Allowing for the topics to be supervised can also give more control over the types of topics that are learnt by the sHDP in case the unsupervised topics are not interesting for a particular task. Finally, the sHDP model allows for unlabelled data to be used as part of the training set in semi-supervised problems. This allows supervised topics to be learnt that take into account the content of unlabelled documents so that the topics can better model the entire corpus instead of just the labelled documents.

5 Inference

Since posterior inference is intractable in DP-based models, approximations must be used. Collapsed Gibbs sampling is the most common technique used to sample from the posteriors of these models, and it can also be applied to the model described in this paper. For topic modelling problems, the Dirichlet base measure for each topic, which is a distribution over the vocabulary, is conjugate to the multinomial likelihood for the words. This enables the topic parameters to be integrated out. Thus at each iteration and based on the Chinese restaurant process, collapsed Gibbs sampling can be used to sample the topic allocations. The regression coefficients can then be sampled from their posteriors in some cases such as for a Gaussian response and can be approximated in other cases. The following sections describe inference in the proposed sHDP model.

5.1 The sHDP model

Since the base measure for the topic regression coefficients will not in general be conjugate to the response model, the non-conjugate auxiliary variable sampling algorithm (alg. 8) described by Neal [18] is used to sample the topic allocations, where indicates that word is allocated to topic . The main difference from inference for the HDP mixture model is in sampling the topic allocation variable and the topic regression coefficients. The conditional distribution for the topic allocation has an additional term for the conditional likelihood of the topic parameters given the document response. Gibbs sampling proceeds as below.

  1. For each document ,

    1. Let denote the number of words in document allocated to topic , and let a superscript for a variable denote the terms excluding the th term. For each word , sample the topic allocation using enumerate


      where , , is the distribution of the word given the other words allocated to topic and is the probability of the word in an empty topic.

      If a new topic is sampled during one of the steps above, then draw , set the new weight and set the new to . The value corresponds to the weight of the new atom that is instantiated from the Dirichlet process. Also, set to the value of .


    2. Sample , where ranges over the topics, by generating uniformly distributed random variables between 0 and 1 and setting


      where is the indicator function.

  2. Sample from



For a continuous response assuming ,


and for a binomial response where ,


During prediction, the posterior of is needed over the test documents. This is calculated by removing the terms that depend on the response from the conditional distributions so that inference on the test documents is identical to unsupervised sHDP. The posterior for the test samples can be sampled by replacing (13) with


and sampling the allocations and counts for the test documents.

5.2 Parameter posteriors and prediction

The topic regression coefficients are sampled after each round of sampling the topic assignments. We also performed experiments where the topic assignments were sampled for several rounds in between sampling the regression coefficients but this made little difference to prediction performance. The topic coefficients can be updated for sHDP by regressing only on the topics that are allocated to at least one observation. We will describe cases for a Gaussian and binary response in this section, though other models for the response can be used too.

5.2.1 Gaussian model

In the Gaussian model, we place a Gaussian prior on the regression coefficients. The model response can be rewritten as


where is a length- vector of document responses, is a matrix of cluster to document allocation counts, is a vector of regression parameters for each topic and are the residuals. Let be the matrix where row is the empirical topic distribution for document . Since only a finite number of topics have non-zero counts in the corpus, the columns in that have zero counts and their corresponding entries can be ignored, so making posterior computation tractable.

The posterior distribution for the parameters is then a Gaussian distribution.


where is the prior variance for the concentration parameters and I

denotes the identity matrix.

For prediction, topics are sampled for test documents as in (18). The empirical topic distribution is sampled over a number of iterations with any topics that are instantiated or any topics that are removed during this period ignored. The remaining empirical topic distributions for each document are averaged and used to calculate the expectation of the response.

For the sHDP model, this is calculated as


5.2.2 Binomial model

For the logistic regression GLM model, the likelihood is


The gradient is then



is the logistic sigmoid function,


We place a Gaussian prior distribution on the regression coefficients, however since there is no conjugate prior, the posterior distribution is not available in closed form. To sample from the exact posterior for the coefficients, the Gibbs sampling method presented by Groenewald and Mokgatlhe [19] and used in topic models by Mimno et al. [20] can be used. However, we found that this method took numerous iterations to converge for a given topic assignment due to the high number of coefficients. As a result, in our results, we instead sample from an approximation to the posterior. A common approximation to use is the Laplace approximation, which involves sampling from a Gaussian centred at the MAP estimate of the parameters with a covariance matrix that is the Hessian of the unnormalized log posterior. The limited-memory BFGS algorithm can be used to find the MAP estimate of the parameters [21].

For prediction, topics are sampled for test documents as in (18).

For the sHDP model, the distribution of the response is given by


For simplicity, we also consider using the MAP estimate of the parameters directly. In many cases we find there is not a significant performance benefit of using parameter sampling over using the MAP solution directly.

A sampling step of the supervised HDP algorithm that samples the regression coefficients (the sampled model) is shown below in pseudocode. To initialize, words are randomly allocated to topics so is set randomly, is set to the maximum value of , and are sampled from (14) and (15) respectively.

Input: Corpus with documents, a response for each document and words in document . Old model parameters .
Output: New model parameters: .
for  do
     for  do
         Sample from (13)
     end for
     for  do
         Sample from (14)
     end for
end for
Sample from (15).
if  is distributed as a Gaussian then
     Sample the regression parameters from (20).
end if
if  is distributed as a binomial then
     Find the MAP value of the regression parameters by using L-BFGS to solve (23).
     Sample where is the Hessian of the unnormalized log posterior.
end if

6 Experiments

We conducted experiments on four real-world datasets. First, we considered the classification problem of determining the effect of financial newswires on the direction of change of the closing prices of a set of stocks. Second, we focused on the classification problem of determining whether movie review sentences are positive or negative. Third, we addressed the regression problem of predicting a rating for a full movie review and fourth, the regression problem of predicting the popularity of a document. The datasets were preprocessed to keep the terms with the highest total TF-IDF score. TF-IDF is a measure of how important a term is for a document in a corpus. The score is calculated as where tf is the frequency of the term in the document, is the number of documents and is the number of documents where the term occurs. This is summed across all the documents for each term, and the highest scoring terms are kept.

The newswire classification dataset consists of a set of real-world newswires extracted from Reuters about the stocks in the S&P 500 on different days over a year up to May 2011. The newswires were labelled with the companies that were mentioned in the wire. These labels were used so that only newswires whose stocks on days that had more than an 8% positive change or 3% negative change from the previous day were considered. These cutoffs were chosen so that the number of declining stocks were similar to the number of rising ones, and to ignore minor changes of prices due to other factors. This resulted in a dataset of 1,518 documents and a vocabulary of 1,895.

The review snippet classification dataset [22] consists of reviews from the Rotten Tomatoes website with reviews that were marked as fresh labelled as positive reviews and reviews that were marked as rotten labelled as negative reviews. The dataset contains 5,331 positive snippets with the same number of negative ones and a vocabulary of 4,310.

The review snippet regression dataset [22] consists of reviews written by four film critics where the writer additionally assigned a rating to his or her review. The ratings were normalised to be between 0 and 1. Any terms that appeared in more than 25% of the documents were removed as were any terms that appeared fewer than 5 times. Only the remaining top 2,179 terms by TF-IDF score were then kept. The ratings for each document were preprocessed to normalise the scores by applying a log transform. There was a total of 5,005 documents.

The document popularity regression dataset is a dataset of submission descriptions from the Digg website with the associated number of votes that each submission received. The number of votes were again normalised by applying a log transform. The dataset consisted of a vocabulary of 4,120 across 3,880 documents.

Experiments were performed with the sHDP model and the sLDA model. Both models were implemented using MCMC methods (collapsed Gibbs sampling in the case of sLDA with the Chang [23] implementation) and predictions were done using an equivalent sample in both instances. For sLDA we also applied a variational approach with the Wang [24] implementation, and the results for sLDA are given for both collapsed Gibbs and variational inference approaches. For sLDA, for collapsed Gibbs sampling, 3000 iterations were used and for variational inference, EM was ran until the relative change in the likelihood bound was less than 0.01%.

The accuracy for classification problems and predictive for regression problems after five-fold cross-validation were calculated. Predictive is defined as


where are the observed responses, with ranging over the documents, is the response predicted by the model and is the mean of the observed responses. This value gives the proportion of variability in the data set that is accounted for by the model and is often used to evaluate the goodness of fit of a model. A value of is obtained when the regression line perfectly fits the data. We present accuracy and predictive results that are calculated on the full set of predictions. We also give indicators of the minimum and maximum difference in performance (across the folds) of each method, relative to the sampled HDP.

In the experiments, the prior standard deviation of the parameters

was tested with three values (, and ) on each fold’s training set by splitting the fold’s training set into a smaller training and validation set and choosing the best value on the validation set. This was also done when choosing the prior standard deviation for sLDA. for the sHDP model was set to on datasets similar to previous experiments with HDP. In the sHDP, the standard prior Gamma() was placed on and and these are sampled during inference. For sHDP, learning took place over iterations with the coefficients being sampled every iteration. For predicting the responses of the test documents, iterations of topic sampling were used to allow the inferred topics to converge. The number of iterations was chosen by looking at the trace plots of the residuals and the regression coefficients, which appeared to converge by that number of iterations. To compare our models, we carried out experiments using sLDA with variable numbers of topics so that performance with sLDA with the best performing number of topics on the test set can also be compared.

We show results for a sHDP inference algorithm that uses the MAP estimate of the regression coefficients (which reduces computation time) during inference and uses a fixed set of coefficients at test time. We also show results for an algorithm that samples from the posterior of those coefficients during training and test time. For the Gaussian model, we sample from the posterior as in Eq. (20). Using a Gibbs sampling method to sample the coefficients of the binomial model took many iterations to converge so we sampled the coefficients from a Laplace approximation. Finally, we also do experiments with a 2-step algorithm in which unsupervised topics for the documents are first learnt as in a HDP model and then a GLM model is trained on top of the learnt topics to predict document labels. In this way, the performance of jointly training the topics and the GLM model can be compared with training the two in separate steps.

6.1 Results

Figure 2 shows that the supervised HDP (sHDP) model performs significantly better than the sLDA model on the newswire dataset. For almost all models, sLDA inference using Gibbs sampling performs better than with variational EM, so we have not shown the variational EM to avoid clutter. sHDP performs competitively against sLDA with the best performing number of topics (as chosen on the test set) on the remaining datasets except for the movie snippet dataset. In the movie snippet dataset, sLDA outperformed the sHDP across the number of topics. From the results it can be seen that for sLDA, picking the right number of topics is key to getting good performance. Moreover, picking too few topics or too many in some cases can cause big drops in performance. On the other hand, for the sHDP, the model yields good performance without having to pick the number of topics. For sHDP, the results also show that sampling the regression coefficients from their posteriors make little difference to the results compared to using the MAP value of the coefficients. Additionally, the simple alternative of learning the topics unsupervised in a HDP model and then training a GLM model on top (a 2-step supervised approach) performs significantly worse than jointly learning the topics with the sHDP model.

The better performance of sHDP compared to sLDA for the newswire dataset and competitive performance with the other datasets is partly due to the increased flexibility of the model and better mixing during inference as can be seen in Figure 3. The increased flexibility comes from the model having an infinite number of topics to model the documents and responses. The better mixing results from the fact that during inference, clusters can be instantiated or unneeded ones can be removed while sampling. Since newly instantiated clusters are empty, it is easier for words to change topic and be allocated to a new cluster. In contrast, in sLDA each topic almost always has a significant number of words allocated to it, making it difficult for the distribution of a topic to change. This has the effect of smoothing over term contributions for each topic. Thus, the fact that there are more specific topics in the sHDP model helps to improve performance.

From the relatively low accuracy scores and large standard deviations, it can be seen that the labels on the newswire dataset are much harder to predict than on the movie review dataset. The standard deviations for the newswire scores imply that the data is much more noisy since newswires only indirectly influence stock movements. In addition, only closing stock prices are used, which means that it is possible there were changes in the stock price from the general movement of the industry or the market. However, the sHDP is able to pick out these subtle signals whereas sLDA with both types of inference algorithms was unable to.

(a) Newswire
(b) Movie Snippet Classification
(c) Movie Reviews
(d) Document Popularity
Fig. 2: Results for the test datasets after 5-fold cross-validation. Classification results are given for (a) the newswire dataset and (b) the movie snippet dataset. Regression results () for the entire dataset are given for (c) the movie reviews dataset and (d) the document popularity dataset. sLDA Gibbs performance is shown for each number of topics. Variational EM performed as well as or worse than Gibbs sampling and is omitted for space. For sHDP, the performance with MAP parameters, with parameters sampled from their posteriors and with a 2-step supervised approach where an unsupervised HDP model is learnt and a GLM model trained on top of that is shown. The upper and lower bars show the minimum and maximum performance of each method relative to the performance of the sampled sHDP (minimum and maximum taken over the 5 folds). This allows the reader to see whether a method performs better or worse than sampled sHDP across all the folds.

Figure 3 is a Gelman-Rubin-Brooks plot [25] which shows how Gelman and Rubin’s shrink factor [26] changes as the number of iterations changes during inference. The plot of the shrink factor is calculated from 4 parallel MCMC chains from different starting points. We present results for the Gaussian sHDP model and the Gibbs sampled sLDA model with 40 topics. The shrink factor is calculated by comparing the within-chain and between-chain variances for each variable of interest. The factor predicts that the chains have converged if the output from the chains are indistinguishable, which is given by the factor approaching 1. In the plots, the shrink factors for the L2 norm of the regression coefficients and the L2 norm of the residuals for the two models are shown. As can be seen from the plots, the shrink factor for the sLDA model is significantly higher than that of the sHDP model, indicating the sHDP model exhibits better mixing.

Fig. 3: Chain convergence for (TOP) the sHDP model and (BOTTOM) the Gibbs sampled sLDA model with 40 topics. Gelman-Rubin-Brooks plots show how Gelman and Rubin’s shrink factor for the L2 norm of the regression coefficients and the L2 norm of the residuals changes across iterations during inference for the movie regression dataset. This is shown for 4 parallel MCMC chains with different starting values. Values close to 1 indicate convergence. From these graphs it can be seen that the Gibbs sampled sLDA model is slower to mix compared to the sHDP model.

We also conducted experiments by regressing directly on the empirical word distribution for each document with L1 regularized generalized linear models and the GLMNET R package. The regularization parameter was chosen through cross validation on the training set of each fold. The accuracies are for newswire dataset, for the movie snippet dataset, and of for the movie rating dataset and for the document popularity dataset. Hence this approach marginally outperformed both sLDA and sHDP on newswire, movie snippet and movie review datasets, but it is outperformed by the sHDP on the document popularity dataset. Given the large number of available parameters, the model flexibility provides benefits for the L1 GLM, but makes it particularly sensitive to particular word usage. It is therefore understandable that this model does best on the three datasets with more coherent word usage patterns, but is less powerful than a sampled sHDP on document popularity, where the word usage within a topic is more varied. The extra topic structure also enables an understanding of the topic-related dependencies which we expand on in the next section.

6.2 Analysis of strong topics and terms

For the sHDP model, the top positive and negative topics, in terms of their regression coefficients and their most frequent terms for the movie review problem, are shown in Table I. The topics do not generally correspond to themes such as film genre or style. Instead of this, the topics contain many names such as actors and directors. This is because the flexibility of a nonparametric model means that the top positive and negative topics consist of very few terms and are allocated to actors and directors that are consistently reviewed well or poorly. This flexibility results in strong topics that are grouped around consistently performing actors or directors but the topics are less coherent since they are associated with so few documents. Topics that consist of more terms, even if those are strong terms, generally have smaller regression coefficients since the effect of the different terms is averaged over other words in the same topic. Strong terms are spread among the top positive and negative topics, for example, positive topic 5 contains the positive term charming and negative topic 2 contains many negative terms such as unfortunately, worse and problem. Since many of the topics have actor and director names such as Tom Hanks in positive topic 2 and the Coen brothers: Ethan and Joel in positive topic 4, it can be seen that specific actors and directors are associated with consistently better or poorer movie review scores.

The terms in the top topics for sHDP seem to correspond to people’s names, such as cameron and miller, with only one topic focusing on terms that intuitively should have a strong contribution to a movie rating. This shows that the topics being learnt are divided into those that correspond to the content of the corpus and those that are more focused on general terms that affect the rating of a movie. The most positive topic and negative topics have no association with film genres and are more concentrated on specific actors, which are more likely to perform consistently.

The top positive and negative topics for the 2-step algorithm in which a GLM model is trained on top of unsupervised topics learnt with a HDP model are shown in Table II. These topics are different in that there are no topics like negative topic 2 from the sHDP model and in general there are much fewer sentiment-related terms in the strong topics. The fact that the regression coefficients are smaller in magnitude also indicates that sentiment or rating-predictive terms are more spread out among the topics meaning that individual topics are less predictive of the rating.

+ Topic 1 (8.3)
+ Topic 2 (6.5)
+ Topic 3 (6.1)
+ Topic 4 (6.1)
+ Topic 5 (5.8)
Topic 1 (-6.2)
Topic 2 (-6.0)
Topic 3 (-5.4)
Topic 4 (-4.1)
Topic 5 (-4.0)
TABLE I: The most positive and negative learnt topics, in terms of their regression coefficients, from the movie review regression dataset with sHDP.
+ Topic 1 (6.0)
+ Topic 2 (4.9)
+ Topic 3 (4.8)
Topic 1 (-5.5)
Topic 2 (-5.3)
Topic 3 (-5.3)
TABLE II: Strongest topics for the movie review regression dataset using the alternative 2-step approach where a supervised GLM model is learnt on top of a set of unsupervised topics from the HDP.

The top positive and negative topics for the newswire dataset and their most frequent terms are given in Table III. These topics are more cohesive than those for the movie review dataset. The top positive topic contains very strong positive terms such as higher, strong, rise and record, which all imply good stock performance. The top negative topic also contains strongly negative terms such as cut, fall, decline and drop, which clearly indicate bad performance. Similarly to the top topics for the movie review dataset, it can be seen that some industries consistently have better or poorer stock performance. For example, negative topic 2 consists of companies such as prudential and metlife along with terms such as insurers and insurance. The negative coefficients indicate that the insurance industry may be performing badly. Positive topic 2 with terms such as defense, military and shareholders indicates that companies involved with the military and defence are associated with rising stock prices.

+ Topic 1 (20.5)
+ Topic 2 (15.9)
+ Topic 3 (15.4)
+ Topic 4 (15.1)
+ Topic 5 (14.7)
Topic 1 (-16.4)
Topic 2 (-11.9)
Topic 3 (-10.8)
Topic 4 (-10.6)
Topic 5 (-10.3)
TABLE III: The most positive and negative learnt topics, in terms of regression coefficients, from the newswires dataset with sHDP.

The sHDP learns strong topics that are assigned to fewer words and indicate trends and tendencies at a finer-grained level, for example, on the level of actors instead of genres. The sHDP model is useful when more specific trends or tendencies are sought and when there is a possibility of overfitting or underfitting due to the number of topics.

7 Conclusions

We have presented a supervised Bayesian nonparametric model that handles grouped data. Each group of data has an associated response such as sentiment ratings or document popularity. The supervised HDP (sHDP) model learns latent topics that are predictive of document responses without having to choose a fixed number of topics, a deficiency in previous models such as supervised LDA (sLDA). In those models, overfitting or underfitting can occur if the number of topics is unsuitable for the dataset. The strongest topics learnt in the sHDP are relatively finer-grained and are associated with fewer topics allowing their effect on the document response to be learnt easily. Regression and classification experiments were performed on real-world datasets and showed that the model performs better than sLDA on the newswire dataset, and only doing worse than sLDA on the movie snippet classification dataset. The experiments also showed that jointly learning the topics and the GLM model produces topics and results that are better than the simple alternative of learning the topics unsupervised in a HDP model and training a regression model on top. Inference in the sHDP remains simple and is an adaptation of that used in the HDP. The flexibility and ease of inference of the sHDP means it has potential uses in many applications. Other inference techniques to improve performance can be explored such as variational inference [27]. While the sHDP does not explicitly handle categorical outcomes, extra regression parameters for each topic can be added to do so.

While sentiment analysis models such as Pang and Lee [22] have a similar goal of predicting document labels, the models we propose in this paper are more general than typical sentiment analysis models and do not require any bootstrap dictionary or labels for the terms. Our models can additionally deal with a wide range of document response types through a generalised linear model and can easily incorporate additional information into its generative process as well as use unlabelled data. The models in this paper are not restricted to textual datasets as they can be used on other kinds of data. For example, topic models have previously been used on extracted image patches or image features by treating the patches or features as words selected from a dictionary of patches [28]. Similarly, the models in this paper can be used to predict the keywords of an image or the theme of an image.


  • Antoniak [1974] C. E. Antoniak, “Mixtures of Dirichlet processes with applications to Bayesian nonparametric problems,” The Annals of Statistics, vol. 2, no. 6, pp. 1152–1174, 1974.
  • Blei et al. [2003] D. M. Blei, A. Y. Ng, and M. I. Jordan, “Latent Dirichlet Allocation,” J. Mach. Learn. Res., vol. 3, pp. 993–1022, 2003.
  • Griffiths and Steyvers [2004] T. L. Griffiths and M. Steyvers, “Finding scientific topics,” Proceedings of the National Academy of Sciences of the United States of America, vol. 101, no. Suppl 1, pp. 5228–35, 2004.
  • Rosen-Zvi et al. [2004] M. Rosen-Zvi, T. Griffiths, M. Steyvers, and P. Smyth, “The author-topic model for authors and documents,” in

    UAI ’04: Proceedings of the 20th conference on Uncertainty in artificial intelligence

    .   AUAI Press, 2004, pp. 487–494.
  • Blei and McAuliffe [2007] D. M. Blei and J. D. McAuliffe, “Supervised topic models,” in Advances in Neural Information Processing Systems 20, J. C. Platt, D. Koller, Y. Singer, and S. Roweis, Eds., vol. 20, no. 21.   MIT Press, 2007, pp. 1–8.
  • Rasmussen and Williams [2006] C. E. Rasmussen and C. K. I. Williams,

    Gaussian Processes for Machine Learning

    .   Cambridge, Massachusetts: MIT Press, 2006.
  • Shahbaba and Neal [2009] B. Shahbaba and R. M. Neal, “Nonlinear models using Dirichlet process mixtures,” Journal of Machine Learning Research, vol. 10, no. 10(Aug), pp. 1829–1850, 2009.
  • Hannah et al. [2011] L. Hannah, D. Blei, and W. Powell, “Dirichlet process mixtures of generalized linear models,” Journal of Machine Learning Research, vol. 12, 2011.
  • Mimno and McCallum [2008] D. Mimno and A. McCallum, “Topic models conditioned on arbitrary features with Dirichlet-multinomial regression,” in Uncertainty in Artificial Intelligence, 2008.
  • Zhu et al. [2009] J. Zhu, A. Ahmed, and E. P. Xing, “MedLDA: maximum margin supervised topic models for regression and classification,” in Proceedings of the 26th Annual International Conference on Machine Learning.   ACM, 2009, pp. 1257–1264.
  • Ramage et al. [2009] D. Ramage, D. Hall, R. Nallapati, and C. D. Manning, “Labeled LDA: A supervised topic model for credit attribution in multi-labeled corpora,” in

    Proceedings of the 2009 Conference on Empirical Methods in Natural Language Processing

    .   Association for Computational Linguistics, 2009, pp. 248–256.
  • Ferguson [1973] T. S. Ferguson, “A Bayesian analysis of some nonparametric problems,” The Annals of Statistics, vol. 1, no. 2, pp. 209–230, 1973.
  • Teh et al. [2006] Y. W. Teh, M. I. Jordan, M. J. Beal, and D. M. Blei, “Hierarchical Dirichlet processes,” Journal of the American Statistical Association, vol. 101, no. 476, pp. 1566–1581, 2006.
  • Cowans [2004] P. J. Cowans, “Information retrieval using hierarchical Dirichlet processes,” in SIGIR ’04: Proceedings of the 27th annual international ACM SIGIR conference on Research and development in information retrieval.   ACM, 2004, pp. 564–565.
  • Li et al. [2007] W. Li, D. Blei, and A. McCallum, “Nonparametric Bayes pachinko allocation,” in UAI 2007, Proceedings of the Twenty-Third Conference on Uncertainty in Artificial Intelligence, R. Parr and L. C. van der Gaag, Eds.   AUAI Press, 2007.
  • Mccullagh and Nelder [1989] P. Mccullagh and J. Nelder, Generalized Linear Models, 2nd ed., ser. Monographs on Statistics & Applied Probability.   Chapman & Hall/CRC, Aug. 1989.
  • Dai and Storkey [2011] A. M. Dai and A. J. Storkey, “The grouped author-topic model for unsupervised entity resolution,” in Artificial Neural Networks and Machine Learning - ICANN 2011, ser. Lecture Notes in Computer Science, T. Honkela, W. Duch, M. Girolami, and S. Kaski, Eds., vol. 6791.   Springer Berlin Heidelberg, 2011, pp. 241–249.
  • Neal [2000]

    R. M. Neal, “Markov chain sampling methods for Dirichlet process mixture models,”

    Journal of Computational and Graphical Statistics, vol. 9, no. 2, pp. 249–265, 2000.
  • Groenewald and Mokgatlhe [2005] P. C. Groenewald and L. Mokgatlhe, “Bayesian computation for logistic regression,” Computational Statistics & Data Analysis, vol. 48, no. 4, pp. 857 – 868, 2005.
  • Mimno et al. [2008] D. Mimno, H. Wallach, and A. McCallum, “Gibbs sampling for logistic normal topic models with graph-based priors,” in NIPS Workshop on Analyzing Graphs, 2008.
  • Minka [2003] T. P. Minka, “A comparison of numerical optimizers for logistic regression,” Tech. Rep., 2003.
  • Pang and Lee [2005] B. Pang and L. Lee, “Seeing stars: Exploiting class relationships for sentiment categorization with respect to rating scales,” in Proceedings of the 43rd Annual Meeting of the Association for Computational Linguistics (ACL’05), vol. 43, no. 1.   Association for Computational Linguistics, 2005, pp. 115–124.
  • Chang [2012] J. Chang, “R LDA package,” 2012.
  • Wang [2009] C. Wang, “sLDA EM implementation,” 2009.
  • Brooks and Gelman [1998] S. P. Brooks and A. Gelman, “General methods for monitoring convergence of iterative simulations,” Journal of Computational and Graphical Statistics, vol. 7, no. 4, pp. 434–455, Dec. 1998.
  • Gelman and Rubin [1992] A. Gelman and D. B. Rubin, “Inference from iterative simulation using multiple sequences,” Statistical Science, vol. 7, no. 4, pp. 457–472, 1992.
  • Asuncion et al. [2009] A. Asuncion, M. Welling, P. Smyth, and Y. W. Teh, “On smoothing and inference for topic models,” Association for Uncertainty in Artificial Intelligence, no. Ml, pp. 27–34, 2009.
  • Wang et al. [2009] C. Wang, D. M. Blei, and F.-F. Li, “Simultaneous image classification and annotation,” in CVPR.   IEEE, 2009, pp. 1903–1910.
