Minimizing the Number of Matching Queries for Object Retrieval

12/18/2014
by   Johannes Niedermayer, et al.
Universität München
0

To increase the computational efficiency of interest-point based object retrieval, researchers have put remarkable research efforts into improving the efficiency of kNN-based feature matching, pursuing to match thousands of features against a database within fractions of a second. However, due to the high-dimensional nature of image features that reduces the effectivity of index structures (curse of dimensionality), due to the vast amount of features stored in image databases (images are often represented by up to several thousand features), this ultimate goal demanded to trade query runtimes for query precision. In this paper we address an approach complementary to indexing in order to improve the runtimes of retrieval by querying only the most promising keypoint descriptors, as this affects matching runtimes linearly and can therefore lead to increased efficiency. As this reduction of kNN queries reduces the number of tentative correspondences, a loss of query precision is minimized by an additional image-level correspondence generation stage with a computational performance independent of the underlying indexing structure. We evaluate such an adaption of the standard recognition pipeline on a variety of datasets using both SIFT and state-of-the-art binary descriptors. Our results suggest that decreasing the number of queried descriptors does not necessarily imply a reduction in the result quality as long as alternative ways of increasing query recall (by thoroughly selecting k) and MAP (using image-level correspondence generation) are considered.

READ FULL TEXT VIEW PDF
POST COMMENT

Comments

There are no comments yet.

Authors

page 1

page 2

page 3

page 4

07/07/2021

Partial 3D Object Retrieval using Local Binary QUICCI Descriptors and Dissimilarity Tree Indexing

A complete pipeline is presented for accurate and efficient partial 3D o...
11/16/2016

Efficient Diffusion on Region Manifolds: Recovering Small Objects with Compact CNN Representations

Query expansion is a popular method to improve the quality of image retr...
01/03/2019

Local Area Transform for Cross-Modality Correspondence Matching and Deep Scene Recognition

Establishing correspondences is a fundamental task in variety of image p...
03/13/2019

Towards Accurate Camera Geopositioning by Image Matching

In this work, we present a camera geopositioning system based on matchin...
10/31/2018

Query Adaptive Late Fusion for Image Retrieval

Feature fusion is a commonly used strategy in image retrieval tasks, whi...
03/07/2018

Fast in-database cross-matching of high-cadence, high-density source lists with an up-to-date sky model

Coming high-cadence wide-field optical telescopes will image hundreds of...
03/26/2020

Compact Deep Aggregation for Set Retrieval

The objective of this work is to learn a compact embedding of a set of d...
This week in AI

Get the week's most popular data science and artificial intelligence research sent straight to your inbox every Saturday.

1 Introduction

While the development of the SIFT-Descriptor [22] made effective object retrieval on a large scale feasible, its initial use of nearest neighbor queries lead to slow runtimes even on relatively small data sets. In 2003, the invention of the Bag of Visual Words (BoVW) technique [35]

aimed at solving this issue by roughly approximating the matching step using quantization, initiating a whole new area of research. However soon the limitations of this rough approximation became obvious, enforcing the development of more accurate techniques for assigning query vectors to database features. Whilst initial approaches aiming at increasing the accuracy of the matching step such as soft assignment

[29] were relatively close to the BoVW approach, the focus in recent years turned back more and more to approximate NN queries [20, 8, 2, 25] due to their possible gain in matching accuracy [17]: NN queries provide an accurate ranking of the matching candidates and a measure of proximity between feature vectors and query vectors. This additional information can be exploited for weighting the scores of image matches, increasing retrieval accuracy considerably [17].

Current research on

NN processing in the image retrieval community focuses on maximizing accuracy, on minimizing the memory footprint of index structure and feature vectors, and on minimizing processing time. In recent years such techniques have received a vast amount of interest even in the most prestigious conferences addressing image retrieval

[20, 8, 2, 18, 25]. As a result, a remarkable leap in performance has been achieved concerning efficient and effective NN query processing. However, with the vast amount of features that have to be matched during recognition (up to a few thousand), even very fast NN indexing techniques that can provide approximate query results in under ten milliseconds (e.g. [20]), would yield recognition runtimes of many seconds.

We argue that the use of NN queries for object recognition in large-scale systems cannot be achieved by developing efficient indexing techniques alone. The problem of efficiency has to be approached from different research directions as well, such as the number of NN queries posed on the system, as reducing the number of

NN queries linearly decreases the runtime of the matching step. In this paper we aim at addressing this problem. We evaluate an alternative recognition pipeline that ranks features extracted from the query image by assessing their matchability. Then, the most promising features in this ranking are matched against the database using traditional

NN queries. However, despite gaining efficiency, the enforced reduction of NN queries causes a reduction of feature matches, decreasing the quality of the query result. While recall can be increased by increasing , to increase Mean Average Precision (MAP) we propose to expand matches on the image level: Given a single seed feature match in a candidate image, this match is expanded by comparing its spatially neighboring keypoints. The idea of this additional step is to push load from the matching step (with complexity mostly determined by the underlying index structure) to an additional step that only has to consider the features stored in an image pair. The resulting enriched set of matches can then be processed equivalently to techniques based on BoVW, e.g. by using query expansion [5] or geometric verification [28].

This work stands in contrast to research in the area of BoVW-based retrieval: Research involving the BoVW pipeline often assumes that the matching step is relatively cheap, especially if approximate cluster assignment techniques such as hierarchical -means [24] or approximate -means [28] are used. Therefore such research focused on increasing Mean Average Precision (MAP) at a large number of query features. In contrast, this paper aims at maximizing MAP for a small number of processed features. This different optimization criterion is especially of interest as techniques that do not lead to significant gains in performance at a high number of features (where convergence to the maximum possible MAP has already been achieved by other techniques) can lead to a remarkably higher MAP when only a low number of features is queried.

The contribution of this paper is to provide a simple and extensible pipeline for large-scale object retrieval based on NN queries with all of the following properties:

  • Reduction of the number of keypoints queried

    by a general keypoint ranking scheme in order to reduce matching times. The pipeline is not bound to a specific keypoint selection technique as long as keypoints can be ranked by their estimated quality.

  • Acceleration of the pipeline by state-of-the art index structures such as (Locally Optimized) Product quantization [18] or Multi-Index-Hashing[25].

  • Geometric Match Expansion to relieve the index structure and to increase query MAP.

  • The use of many nearest neighbors () to increase the number of seed hypotheses and therefore query recall.

  • Consideration of distances between features during score generation to allow accurate scoring of image features by their similarity.

We further provide a thorough evaluation of this pipeline on a variety of well-known datasets, including Oxford5k, Oxford105k, Paris 6k, and INRIA Holidays, provide insights into advantages and disadvantages of the approach, and show that such match expansion techniques can lead to performance improvements. We also evaluate the effect of in relation to the number of keypoints queried on the systems performance, and the pipeline’s behaviour on different feature descriptors including real-valued (SIFT) and binary (BinBoost) features.

This paper is organized as follows. Section 2 formally defines the problem addressed in this paper. We then review related work in Section 3. In Section 4 we describe our solution to reducing the number of NN queries during retrieval. Section 5 evaluates our solution on different feature types and datasets. Section 6 concludes this work.

2 Problem Definition

Let denote a database of images . Images are represented by a list of interest points and their corresponding feature vectors, i.e. with for affine-variant interest point descriptors and for affine-invariant descriptors, with a (real-valued or binary) feature vector, the coordinate of the interest point in the image, its scale, its rotation, its response, and for affine-invariant descriptors the parameters of the ellipse describing its affine shape, see [27].

Given a query image containing an object , we would like to retrieve all images containing object . This is usually achieved by a combination of feature matching and scoring. During feature matching, we retrieve tuples of similar feature vectors , denoting that feature of the query is visually similar to the features . This matching problem can for example be solved using the BoVW approach. In recent years however, as mentioned in the introduction, there has been a shift away from BoVW towards more accurate, however less efficient NN queries, leading to where retrieves the tuples from the database whose feature vectors are closest to the query feature vector given a pre-defined distance function, e.g Euclidean distance. Now let , with a subset of the query features. The score of database image is computed as . The most trivial solution would be to increase the score of image by one for each tentative match, resulting in . More sophisticated scoring approaches for NN-based image retrieval can be found e.g. in [17].

Accurate NN queries are, even after astonishing research efforts in the last years, still relatively expensive. For example, running a 100NN-query on 100 million binary features using Multi-Index Hashing [26] would take about 100ms, summing up to 100 seconds in a scenario where 1000 features are queried to retrieve a single image111Note that the number of features extracted from an image is often even larger, see the dataset statistics in our experimental evaluation. SIFT features are generally queried approximately, runtimes vary significantly with recall and are often between 8ms/query and 53 ms/query for a billion SIFT features at a recall below 0.5 [20]. Generally, achieving good recall over 0.5 for 1NN queries with such techniques is very expensive. We are not aware of recall evaluations of these techniques for although it was shown in [17] that a larger can notably boost recognition performance. Based on these observations we argue that in addition to indexing efficiency, other possibilities must be considered to reduce the complexity of the feature matching phase. Generally, to achieve this complexity reduction, different approaches are reasonable:

  • Reduce the dimensionality

    of feature vectors. One well-known approach would be to apply PCA to SIFT features and drop the dimensions with least variance. Another more desirable option would be to directly extract lower-dimensional features.

  • Reduce the cost

    of distance functions, for example by binarization

    [36, 19, 39, 13, 12] or by extracting binary features [37, 31] and using the Hamming distance.

  • Reduce the accuracy of a matching query. This has been widely used in the past, e.g BoVW [35] can be seen as an extreme case.

  • Reduce the cost for querying. A variety of (exact) indexing techniques have been proposed, e.g. Multi-index-hashing [25] for binary features.

  • Reduce the number of NN queries, e.g. [11, 10, 21, 3].

In this paper we focus on the last approach: Let a database of images, represented by sets of features describing the neighborhood around interest points, be given. Let denote the upper bound on the number of matching queries, constraining the number of NN queries. The goal of this research is to develop a retrieval algorithm that returns a list of images ranked by their visual similarity to the query. We aim at modifying the image recognition pipeline such that a given performance measure (in our case MAP) is maximized for a given .

The problem setting is similar to BoVW-based approaches, however in such a context it is usually assumed that . In this paper we address the opposite case where .

3 Related Work

This section, addressing related research, follows the organization of the image processing pipeline used in Section 4.

Keypoint reduction. In order to reduce the number of extracted features that have to be matched, [11] aimed at predicting the matchability of features by interpreting the problem as a classification task. Keypoint reduction can also be achieved by employing the Adaptive Non-Maxima suppression (ANMS) from Brown et al. [3]. Their approach aims at finding interest points that are sufficiently distributed across the whole image and is computationally relatively inexpensive. Hajebi and Zhang [10] propose to keep track of the distribution of scores during query processing and stop the investigation of further features as soon as the score difference between the best-scored image and the average score becomes large enough. Other approaches to rank features are based on visual attention [21]. In contrast to us, the authors query all features of higher scale levels to build a coarse-grained (32x32) top-down attention map and combine it with a bottom-up saliency map. Then, in an iterative fashion, the features in the most promising cells of these attention maps are queried. The authors perform some kind of geometric verification, but no match expansion.

NN indexing. As exact NN query processing on high-dimensional features often cannot significantly decrease runtimes compared to a linear scan due to the curse of dimensionality, indexing research in the image community concentrates on approximate nearest neighbor search. Some well-known approximate indexing techniques used in image retrieval are forests of randomized D-trees[34, 23] and the Means-tree [24, 23]. These techniques however suffer either from high storage complexity if the database descriptors are needed for refinement, or low-quality distance approximations. Recent research in NN indexing aims at providing low runtime and storage complexity while providing accurate distance approximations at the same time. One group of these techniques is based on the Product Quantization approach from Jegou et al. [18], a quantization-based approximate indexing technique distantly related to the BoVW paradigm. Recent extensions of this approach include [2, 8, 20]. Another group of techniques aiming at efficient indexing is built on the idea of generating distance-preserving binary codes from real-valued features, sometimes referred to as binarization. Recently developed binarization techniques include the approach from [36], Random Maximum Margin Hashing [19], Scalar Quantization [39], Spherical Hashing [13]

and k-means hashing

[12]. In contrast to binarization techniques, binary keypoint descriptors such as BinBoost and ORB [37, 31] can avoid the indirection of extracting real-valued (e.g. SIFT) features first and then binarizing them. Nearest Neighbor queries on databases of binary features can be speeded up by employing (approximate) LSH-based techniques [14] or exact indexing [25] and are relatively fast due to them employing the Hamming distance instead of the Euclidean distance.

NN-based Matching. NN-based matching techniques have a long history in the context of Image retrieval. One of the most famous techniques using such approaches is Lowe’s SIFT recognition pipeline [22]. Lowe retrieved, for each query feature, the two nearest neighbors from the database and accepted a feature as match if its distance ratio between 1NN and 2NN was above a given threshold. Jégou et al. [17] evaluated NN-based matching based on local features, especially SIFT. They proposed a voting scheme optimized for NN-based retrieval. This adaptive criterion basically scores matches relative to the distance of the -th match. Furthermore, the authors analyzed normalization methods for the resulting votes in order to reduce the negative effect of favouring images with many features over those with only a few. They did however not consider reducing the number of query features. Qin et al. [30] proposed a normalization scheme for SIFT-features that locally reweights their Euclidean distance, optimizing the separability of matching and non-matching features. Based on this normalization, the authors developed a new similarity function and scoring scheme based on thresholding rather than NN query processing.

Match Expansion. As our technique aims at reducing the number of NN queries during the matching step, the generation of a sufficient number of match hypotheses has to be achieved in a different fashion. We do so by applying a flood-filling approach using

NN matches as seed points. Match expansion has received quite some attention in the computer vision community

[33, 32, 35, 7, 9, 6], and will most likely become more relevant again with the use of NN-based matching techniques. One of the first technique in this area of research has been proposed by Schmid and Mohr [33]

. They used the spatial neighbors of match candidates to increase the distinctiveness of features. They also considered the consistency of gradient angles between these features to reject false-positive matches, however they did not consider the combination of their approach with feature reduction. Sivic and Zisserman adapted the technique for Video Google

[35]. We however do not reject matches based on this technique but rather increase the score of a given image by considering neighboring features. Our work is also inspired by [32], where the authors used a region-growing approach for establishing correspondences in the context of multi-view matching. After establishing a set of initial matches in a traditional index-supported manner, an affine transformation is estimated that guides search of additional matches in a local neighborhood of the seed match. The authors, however, did not use this technique for reducing the number of queries in the matching step, but rather to increase the result quality. Ferrari et al. [7] developed another related technique in order to achieve high invariance to perspective distortion and non-rigid transformation; it further allowed to perform an accurate segmentation of objects during recognition. Their approach builds a dense grid of features over the image; in contrast we use the initially provided keypoints and descriptors that are stored in the database nonetheless, reducing computational overhead. A recent work related to this approach includes [6]. Guo and Cao [9] proposed to use Delaunay triangulation to improve geometric verification. Wu et al. [38] proposed to enrich visual words by their surrounding visual words, generating scores not only by the weight of a visual word, but also the neighboring features; the authors however did not consider keypoint reduction. Geometric min-Hashing [4], based on the BoVW-paradigm, considers neighboring features as well, however in the context of hashing. The approach aims at increasing precision at the cost of recall, by dropping features that do not share a similar neighborhood. However, if we reduce the number of matching queries, one of the main concerns is recall, such that our approach aims at increasing MAP without negatively affecting recall.

4 Pipeline

The general retrieval pipeline from this paper follows the one used in the past for BoVW-based image retrieval, but in order to incorporate NN queries and reduce the number of query features we applied some changes. In this section, we first provide a theoretic overview over the pipeline. Then, as implementing the pipeline in such a naive way would lead to unacceptable overhead in terms of memory and computational resources, we provide practical considerations about its implementation in a real-world setup.

4.1 Theory

We split our pipeline into the stages of feature detection and extraction, feature ranking, feature matching, match expansion, scoring, and re-ranking. The pipeline was designed with extensibility in mind such that each stage, e.g. keypoint reduction and match expansion, can be easily exchanged by different techniques.

1) Feature Extraction.

During feature extraction, given the query image, we extract the set of keypoints and descriptors. Possible features include floating point features such as SIFT [22] or binary features such as BinBoost and ORB [37, 31]. The cardinality of depends on the used feature extractors and can range up to several thousand features.

2) Feature Ranking.

The next stage, feature ranking, is based on the idea that some features in an image contain more information than others. For example, vegetation usually provides less information about a specific object contained in the image than the features of the object itself. We aim at ordering the extracted features by a given quality measure, as we would like to query the most promising features first, i.e. the features with the highest chance of providing good match hypotheses. There exist several techniques for feature ranking, and we will fall back to these instead of developing a new approach. The only criterion such a technique needs to fulfill in order to be integrated into the recognition pipeline is that it returns a quality score for each query feature. A simple baseline is a random ranking. Features can also be ranked by their response or size. More sophisticated techniques include Adaptive Non-Maximal Suppression [3]

and the use of decision trees involving additional training

[11], which has however neither been adapted to binary features nor to NN-based matching, yet. The result of this feature ranking step is a feature list, ordered such that the most promising features appear first.

3) Feature Matching.

The next step, feature matching, aims at finding match hypotheses for the highest ranked features found during the last step. For each of the first features in the ranking, a NN query is posed on the database. The selection of the parameter of the NN query is important for maximizing the quality of the query result [17]. On the one hand side, a large decreases the quality of the query result, as this introduces a high number of erroneous correspondences which have to be filtered out during a verification step later in the pipeline. On the other hand, a small also reduces the retrieval quality as many high-quality hypotheses are left unconsidered. Basically, can be seen as a way to tweak recall at a given number of query features, as the number of images returned by the query is at most . As a result, especially if a very small number of NN queries is used for correspondence generation, it is possible that an even larger increases effectiveness, as it allows for finding more initial correspondences (however of lower quality). We refer to Section 5 for an experimental analysis of this problem. The feature matching stage provides a list of tentative matches (tuples) .

4) Match expansion.

The match expansion phase is tightly interleaved with the match generation phase. In our scenario where we want to pose a very small number of

NN queries on the system, we face the problem that even if we find some correspondences between the query and a database image, their number will be relatively low, increasing the probability that a good match is outranked by an image containing common random matches only. To resolve this problem, we shift the load of correspondence generation from the matching stage –that employs

NN queries– to an intermediate stage that avoids such queries. Match expansion aims at reducing the runtimes of generating additional matches, which usually depend on the underlying index structure, to runtimes depending on the features stored in a single image pair. When employing exhaustive search with product quantization for indexing, match expansion therefore avoids additional linear scans over the feature database; as non-exhaustive variants of product quantization only consider a fraction of features in the database, the gain of match expansion in this case depends on the desired recall of the index structure.

It is however important to realize that, while such a match expansion can find additional hypotheses for candidate images, i.e. increase MAP, it cannot retrieve any new candidates, i.e. increase recall. This stage therefore aims at compensating for the loss in MAP due to querying less features.

Figure 1: Generation of additional match hypotheses.

Match expansion exploits the keypoint information of the seed matches that provide scale, rotation, and possibly affine information. These properties can be used to identify spatially close keypoints, adapting the ideas of [32, 7, 4, 38]; we will use a modified version of [33] for expanding matches. Given that a match hypothesis is correct, not only the corresponding feature pair should match, but also its spatial neighborhood, as an object is usually not only described by a single but rather by multiple keypoints. The similarity of a match’s neighborhood is evaluated using the procedure visualized in Figure 1. The figure shows an initial seed match, i.e. a NN of a query feature, and keypoints surrounding the seed match. The scale of each keypoint is represented by the keypoint’s size, and the gradient direction is represented by a line anchored in the keypoint’s center. The top row of this figure visualizes the features of the query image, while the bottom row visualizes the image features of a tentative match.

Starting point is an initial correspondence pair established by NN-search in feature space, see Figure 1 a). In a first step, features in a given spatial range are retrieved in the image for and in Image for , see Figure 1 b); the spatial range is visualized by a dotted circle. Given the constant , the spatial range is given by for the query feature and for the matching database feature, achieving scale invariance. Spatially close keypoints with a significantly different scale (determined by the scale ratio threshold ) than their reference feature are discarded (see the small features in the figure) similar to [4], resulting in two sets of features and . These remaining features are rotation-normalized using the reference keypoint’s gradient orientation information and , rotating the set of keypoints and their corresponding gradient orientations, see Figure 1 c). Then the two lists of keypoints are traversed in parallel. If the rotation-normalized angle to the reference feature, the rotation-normalized gradient angle , and the feature-space distance of two features are within a predefined threshold (, , and respectively) and the ratio of their scale-normalized spatial distance is within given bounds , the corresponding features are accepted as a matching pair (see Figure 1 d)). The remaining features are discarded. Note that, while the complexity of this step is in the worst case, it can be reduced by an efficient sweep-line implementation that sorts features by their angle and traverses both lists in parallel.

This technique of finding neighboring keypoints assumes that two images are only distorted by similarity transforms. To mitigate the effects of non-similarity or even (small) non-rigid distortions, a recursive procedure (in our case with a maximum recursion depth of 2) can be chosen that performs the same procedure on each of the resulting pairs. Moreover, by choosing the Mahalanobis distance using the affinity matrices of the seed pair ( and respectively) instead of Euclidean distances for finding spatially neighboring keypoints, the process can be extended to affine-invariant features. This technique returns features within an elliptical region around the seed points, reducing performance loss from affine distortions.

Result of the expansion phase is an extended list of match hypotheses.

5) Scoring.

Scoring is again tightly interleaved with match generation. In this phase, based on the expanded list of matches, a score is computed for every database image. In the simplest case, each hypothesis pair votes with a score of one for a given database image. This however, has shown to have a relatively low performance [17], as for example images containing many features would have higher scores than images containing only a few features. For this purpose, more sophisticated scoring techniques have been developed. We will adapt some of the techniques from [17], weighting scores based on the distance of the candidate feature to the query feature and the number of features in the image. For each matched feature from image its score is increased by with the NN distance of the seed feature, and the distance between the seed feature and its tentative match in the candidate image, i.e. features generated during match expansion are assigned the same score as their seed match. This score is similar to the scores from [17], however we have added additional square root weighting which further increased effectiveness of these scores. For scoring we implemented a simple burst removal [16] scheme after match expansion that allows only for one correspondence per query feature.

6) Re-Ranking.

After building match hypotheses and scoring, the ranked list can be processed equivalently to BoVW-based approaches. Further steps can include geometric verification or query expansion techniques [5]. As these techniques are complementary to the remaining pipeline we will not further consider them in this chapter.

4.2 Practical Considerations

To enable efficient query processing using the pipeline summarized previously, three conditions must be fulfilled. First, it must be possible to efficiently retrieve the NN features of a query feature and their corresponding keypoints from the database. Second, to enable match expansion, it must be possible to compute, given two keypoints, the distance of their corresponding feature vectors. Third, also concerning match expansion, it must be possible to pose a range query on all keypoints from a given image, retrieving spatially close keypoints. In the most basic case, the image database used for query processing can be seen of a list of tuples containing feature and keypoint information. The features in the list are ordered by their corresponding image to allow efficient match expansion. However, in order to enable usability of this approach in a practical setup, special care has to be taken concerning computational and memory efficiency and the thorough selection of parameters; we will address solutions for these challenges in the following section. Computational efficiency can be achieved using indexing techniques such as Product Quantization or Multi-Index Hashing, while the memory footprint of the image database can be reduced by compressing the feature vectors used during match expansion. Finally, the selection of parameters can be achieved using appropriate optimization techniques.

4.2.1 Indexing

In order to improve the performance of of the pipeline in real-world applications, fast (approximate) indexing techniques optimized for high-dimensional data

[20, 8, 2, 25, 18] can be employed. In this research we focused on (Locally Optimized) Product Quantization for real-valued features and Multi-Index Hashing for binary features; we will summarize these techniques in the following paragraphs for the sake of completeness.

Product Quantization.

Approximate nearest neighbor search based on Product Quantization, initially proposed by Jégou et al. [18] and further optimized e.g. in [20, 8, 2], is an elegant solution for indexing high-dimensional real-valued features. During a training phase, features in the database are clustered using -means and the database features are assigned to their closest cluster mean, partitioning the set of vectors into distinct cells, similar to Locality-Sensitive Hashing [14]. Then, for each feature vector, the residual to its corresponding cluster mean is computed and the resulting residuals are product quantized. Product quantization is achieved by splitting a vector into a small number of subvectors (e.g. 8) and quantizing each of these subvectors separately using a relatively small codebook of e.g. 256 centroids. Instead of storing the residuals themselves, only the cluster id of the closest residual is stored in the index for each subvector, resulting in a reduction in memory complexity. With product quantization using 8 subvectors of 256 cluster centers, a SIFT vector could be compressed from 128 bytes to 8 bytes, resulting in a compression of nearly 95%. The index itself consists mostly of a list of outer clusters and for each of these clusters an inverted list storing, for each feature assigned to this cluster mean, its list of quantized subvectors.

During query evaluation, the query is first assigned to the closest outer cluster mean (or possibly the closest means in the case of multi-assignment). Then the inverted lists of these means are scanned, and a distance approximation is computed for each of the database vectors stored in this list: As vectors are represented as a list of their closest subvector-centroids, a distance approximation can be generated by summing the squared distances of the corresponding centroids which can be sped up with the use of look-up tables. The resulting distance approximations are then used to rank the feature vectors. In the past, a variety of improvements of this approach have been proposed, for example the Inverted Multi-Index [2], Optimized Product Quantization [8], and Locally Optimized Product Quantization (LOPQ) [20]. For our experiments we will use the most recent of these approaches, namely LOPQ.

Multi-Index-Hashing.

While Product Quantization has been developed to support efficient query processing on real-valued and high-dimensional feature vectors such as SIFT, Multi-Index Hashing (MIH) [25] has been specifically designed for binary features, such as ORB or BinBoost[37, 31]. It is based on the idea of Locality-Sensitive Hashing [14], however in contrast to this approach it aims at exact query processing. The idea behind MIH is, similar to Product Quantization, to split a binary vector into a set of subvectors. Each of these subvectors is indexed in a dedicated hash table with the subvectors’ binary value directly representing the id of its hash cell: A single cell of the index contains all database vectors that contain a given subvector.

During query processing, the query is split into subvectors as well. These subvectors provide the hash cells that have to be looked up in order to find vectors with similar values. Bit-flipping the query subvectors and retrieving the corresponding hash cells allows retrieving features with similar, but not equivalent subvectors. To allow exact NN processing, Norouzi et al. developed a retrieval strategy that enumerates all relevant bit-flip operations to retrieve an exact query result. In our experimental evaluation, we will use this index structure in combination with BinBoost[37] features to evaluate the pipeline from Section 4.1 on binary features.

4.2.2 Match Expansion

Concerning the expansion of initial matches we face two challenges. First, we have to find the best parameters for the expansion step. Second, memory consumption has to be minimized in order to store features in main memory and hence speed up query processing.

Parameter Selection. Unfortunately it is a tedious task to determine the thresholds of the flood-filling procedure for match expansion, namely , , , and , by hand. This problem can be solved by utilizing Nelder-Mead Simplex-Downhill optimization: After selecting the distance multiplier and the maximum scale change ratio by considering runtime constraints, the remaining thresholds are automatically determined by the Simplex-Downhill approach. Optimization of these parameters should be conducted on a training dataset different from the test set in order to avoid overfitting.

Vector Compression. For compressing real-valued feature vectors, we consider Product Quantization as well. In contrast to Product Quantization based indexing based on LOPQ, however, we do not product quantize residual vectors, but rather the vectors themselves, as otherwise vectors belonging to different cells in the outer quantizer could not be compared efficiently. For compression, we split each feature vector in a set of subquantizers and for each of these subquantizers build a codebook of centroids. The distance between feature vectors can then easily be approximated as the sum of squared distances between the closest subquantizer centroids followed by a square root operation. As distances between cluster centroids can be stored in a lookup table of size , distance computations reduce to table look-ups and a single square root operation.

5 Experiments

5.1 Experimental Setup

Datasets. We evaluated the modified recognition pipeline on four datasets. The Oxford5k (O5k) building dataset [28] consists of 5063 images of common tourist landmarks in Oxford. The authors of the benchmark also provide a set of 55 queries including rectangular query regions and ground truth files listing, for each query, the images that contain at least parts of the query. Ground truth files are split into three categories: good, ok and junk. Good and ok files are considered for computing the Mean Average Precision (MAP) of the query. Junk images are neither scored as true hit nor as false hit and simply discarded for computing the MAP. We also included Oxford105k (O105k) in our evaluation which consists of the Oxford5k dataset in combination with about 100k distractor images [28] that do not contain images related to the query. The Paris6k (P6k) dataset [29], conceptually similar to the Oxford dataset, consists of 6412 images of common landmarks in Paris, and has the same structure as the Oxford dataset. As a third dataset we used the INRIA Holidays (Hol) dataset [15] which consists of 1491 images including 500 queries and their corresponding ground truth. In contrast to the Oxford and Paris dataset, Holidays contains more natural scenes and a lower number of result images for each query. Images of the Holidays dataset were scaled down to a maximum side length of 1024 before feature extraction.

Feature Extraction and Indexing. We used two different feature extraction techniques: a rotation-variant version of SIFT using affine invariant keypoints222https://github.com/perdoch/hesaff/ made available by the authors of [27] and, as an instance of state-of-the-art binary descriptors, the BinBoost descriptor which is also publicly available [37]. We decided to include binary features in our evaluation as we see them as another mean of decreasing query complexity, however we will concentrate on SIFT features in our evaluation.

Dataset Extractor Features
O5k BinBoost 10,640,081 2101.5
O105k BinBoost 195,068,373 1855.4
O5k SIFT (Hess.-Aff.) 13,516,675 2669.7
O105k SIFT (Hess.-Aff.) 253,761,866 2413.7
P6k SIFT (Hess.-Aff.) 16,073,531 2506.8
Hol SIFT (Hess.-Aff.) 4,596,567 3082.9
Table 1: Database Statistics

Concerning Hessian-affine SIFT, scale was separated from the affinity matrices according to [27], however for expanding matches we used the square root of this scale which roughly corresponds to the radius of the image patch used for SIFT extraction. The parameters of the feature extraction stage have been left at the default parameters. SIFT features are 128-dimensional real-valued vectors. These vectors were square-root weighted similar to RootSift[1], however without normalization. The weighted features were then indexed using LOPQ in combination with a multi-index [20]. We use a vocabulary of size for the inverted lists, and 8 subquantizers for vector quantization, each subquantizer with a vocabulary of size of 256 clusters. The corresponding source code has been kindly provided by the authors333http://image.ntua.gr/iva/research/lopq/. To compress the feature vectors for the expansion phase, we again used 8 subquantizers consisting of 256 clusters, reducing storage overhead of feature vectors to 6.25% of their uncompressed memory footprint. Codebooks for the Oxford and Holidays datasets were trained on Paris6k, and for Paris6k code books where trained on Oxford5k. During query processing, we applied a simple means of burst removal [16], scoring each query feature once even if it had more than one match.

Extractor Train
SIFT P6k 6 0.8 26.2 24.3 0.49
SIFT O5k 6 0.8 26.9 18.9 0.56
BinBoost P6k 4 0.8 73 21.1 26.0 0.46
Table 2: Parameters for Match Expansion

BinBoost descriptors, i.e. 256-dimensional binary vectors, can be queried rather efficiently using exact indexing techniques optimized for binary feature vectors, e.g. [25]. We have used a publicly available implementation of their index during our experimental evaluation. We applied burst removal when querying these features as well.

An overview of the extracted features can be found in Table 1. Note that the number of query features was different to the number of database features on Oxford5k, Oxford105k and Paris6k due to the bounding boxes provided by the dataset authors, and for several queries the number of query features was less than 1000. The average number of features available over all queries was 1371.4 (BinBoost, ) and 1452.8 (SIFT Hessian-Affine, ) for queries on Oxford.

The code was written in C++ using OpenCV. Runtime experiments were conducted on an off-the-shelf Linux Machine with i7-3770@3.40GHz CPU and 32GB of main memory without parallelization. During our experimental evaluation we concentrate on analyzing the effectiveness of the approaches in terms of Mean Average Precision (MAP); we also provide numbers on the performance of the evaluated approaches concerning the runtime of the scoring, querying and ranking stages.

Parameters. The parameters for query processing were set as follows. First, range multiplier , maximum scale change , , and were set by hand with computational efficiency in mind, as a lower number of features considered during expansion reduces the cost of this step. Given these manually set parameters, the remaining parameters of the expansion phase, i.e. feature distance threshold , angular threshold , gradient angle threshold and spatial distance ratio were set to the outcome of a Nelder-Mead Downhill-Simplex optimization maximizing MAP; initialization was performed with reasonable seed values. Minimization was done on the Paris6k dataset (with LOPQ and quantization code books trained on Paris6k as well) for the Oxford5k, Oxford105k and Holidays datasets. For the Paris6k dataset, we optimized these parameters on the Oxford5k dataset. The parameters were selected for each of the descriptor types (SIFT and BinBoost) using ANMS ranking at , number of keypoints , recursively descending into every expanded match. The resulting parameters were reused for the remaining ranking approaches, different , and the non-recursive approach. An overview over the selected parameters is shown in Table 2.

We varied each of the optimized parameters by separately on Oxford 5k (ANMS ranking with match expansion) to get insights into their effect on MAP. The maximum deviation resulted from decreasing the feature distance threshold, which lead to a decrease in MAP of , indicating that while there is an impact of the optimized parameters on the performance of match expansion, there is still a range of relatively “good” parameters.

5.2 Experiments

We evaluated the algorithm’s performance by varying and as these parameters affect the number of initial seed points that are expanded later. As a baseline for our experiments we implemented a scoring scheme based on [17] that considers the distances between features and the number of features in the image for score computation.

Appr. 50 100 500 1000
RND .616 .698 .810 .827
RESP .557 .640 .787 .822
ANMS .676 .727 .825 .836
RND+ME .679 .749 .829 .838
ANMS+ME .741 .780 .843 .844
RND+MER .686 .752 .826 .832
ANMS+MER .752 .786 .837 .838
Table 3: SIFT, Oxford5k, k=100
Appr. 50 100 500 1000
RND .566 .652 .770 .786
RESP .519 .594 .743 .775
ANMS .578 .668 .783 .794
RND+ME .629 .699 .781 .789
ANMS+ME .648 .723 .793 .796
Table 4: SIFT, Paris6k, k=100

Keypoint Ranking. In our first experiment (see Table 3 and Table 6) we wanted to evaluate the performance difference in MAP when querying a low number of features (i.e. 50, 100, 500 and 1000 keypoints) with different keypoint ranking techniques, providing a baseline for further experiments. The simplest ranking (RND) takes random features from the extracted keypoints; we averaged this approach over 5 runs to get accurate results. Furthermore we evaluated a ranking based on keypoint responses (RESP), and a more sophisticated approach called Adaptive Non-Maximal Suppression [3] (ANMS) that aims at distributing keypoints relatively uniformly over the image. As expected, considering only few keypoints significantly reduces the MAP of all approaches. The MAP of the response-based ranking is worse or similar to the random baseline: for SIFT, the response decreases performance compared to the random approach, while for BinBoost (that is based on SURF Keypoints) results are sometimes slightly better than the random baseline. The ANMS ranking increases the MAP for all approaches. Note that the gain resulting from using ANMS is rather astonishing for the Oxford5k dataset; we can easily gain 0.03 (=100) to 0.06 (=50) points in MAP without significant computational overhead if the number of features queried is relatively low. Similar observations hold for Holidays (Table 5) but considering Paris6k (Table 4), the gain resulting from using ANMS instead of a random ranking is lower. Our results with BinBoost (Table 6) on Oxford5k indicate that ANMS without match expansion can increase performance by over 0.07 points in MAP (=50), however its performance is generally lower than SIFT, even if SIFT vectors are quantized as in our case; the memory overhead (8 bytes) for quantized SIFT vectors is actually lower than for BinBoost (32 bytes) features.

Appr. 50 100 500 1000
RND .600 .662 .765 .792
RESP .571 .630 .735 .770
ANMS .642 .696 .779 .803
RND+ME .646 .702 .764 .770
ANMS+ME .699 .734 .780 .781
Table 5: SIFT, Holidays, k=10
Appr. 50 100 500 1000
RND .390 .462 .586 .616
RESP .389 .461 .600 .625
ANMS .461 .508 .614 .620
RND+ME .469 .529 .625 .638
ANMS+ME .542 .588 .648 .644
RND+MER .481 .539 .626 .634
ANMS+MER .551 .591 .648 .640
Table 6: BinBoost, Oxford5k, k=100

Match expansion. Our second experiment aims at evaluating the gain in MAP that can be achieved for a low number of NN queries when additional hypotheses are generated by match expansion (ME) and the same approach in its recursive version (MER). Affine-invariant SIFT (ANMS+ME, =50) achieves about 90% of the random baseline (RND, =1000) at 50 keypoints on Oxford5k, where the baseline only achieves 75%. At the same time the results at 1000 keypoints are similar for all approaches, showing that match expansion does not considerably affect MAP if a high number of keypoints is queried. This substantiates our statement made in the introduction: if a small number of features is queried, techniques that do not achieve significant performance gain for a high number of features can achieve considerable gain in performance. Results are similar for Holidays (88% for ANMS+ME@ vs. 76% for the random Baseline) while for Paris6k the gain of match expansion is lower (82% vs 72% for the random baseline). Further note that MAP for ANMS+ME decreases slower with decreasing than without expansion (-0.003 (ANMS+ME) vs. -0.011 (ANMS) for on Paris6k). Results for Oxford105k are shown in Table 7.

Using BinBoost (Table 6 and Table 8) the results are similar. The combination of ANMS ranking and match expansion at 100 keypoints performs similar to the random baseline at 500 keypoints, which is especially interesting as the exact indexing techniques used for BinBoost already lead to a relatively high runtime.

While there is some gain for recursively descending (MER) into matches, this additional step does not significantly improve the performance with both SIFT and BinBoost, while being computationally much more expensive. Therefore we will concentrate on ME in the following. ANMS+ME on Oxford using SIFT accepted about 16500 matches per query image (, ), in contrast to the approximately 8800 tentative correspondences (less than due to burst removal) that have been generated using NN matching alone (ANMS).

Note that we also evaluated the effect of a re-ranking stage, weak geometric consistency (WGC) [15] with 32 angular and 16 scale bins, on match expansion using BinBoost. Both pipelines, with and without match expansion were positively affected by WGC, gaining about 0.04 (ANMS and ANMS+ME) points in MAP at , indicating that WGC is complementary to match expansion. We further observed that WGC did not have a large effect with a low number of features (0.013 with ANMS and 0.006 with ANMS+ME at ) involved both with and without match expansion.

Appr. 50 100 500 1000
ANMS .489 .554 .710 .748
ANMS+ME .584 .630 .753 .775
Table 7: SIFT, Oxford 105k, k=100
Appr. 50 100 500 1000
ANMS .369 .412 .527 .558
ANMS+ME .445 .477 .576 .590
Table 8: BinBoost, Oxford 105k, k=100

Value of . Not only the number of queried keypoints can be used to increase the number of seed hypotheses and therefore the matching quality, but also . While increasing comes at a lower query cost, it also produces hypotheses of lower quality. However, as it is well known for example in the context of NN classification, reasonable values for can increase the query performance. In this experiment we evaluate the effect of if the number of features to be queried is fixed to a given number. For a large number of keypoints, a very high value of adds a lot of false positives such that the MAP decreases [17]. On the other hand, if is too small, only a small amount of correct hypotheses is found [17]. We reproduced this result with the ANMS ranker at 1000 keypoints (see Figure 2), as here the MAP at is highest compared to or .

What happens when we decrease the number of keypoints? As shown in Figure 2, if a large number of keypoints is queried (), then for all of the evaluated approaches a value of performed better than . So match expansion does not greatly affect the optimal value of in this case. However, if only very few keypoints are used for query processing (e.g. ), a large performed better with match expansion. Without this additional step, performance decreased for large (however at a larger than at a higher number of keypoints queried), most likely because the additional noise introduced could not be out-weighted by the higher number of correct matches. This leads us to the following results: The best way to increase query performance, which is well known, is to increase the number of keypoints queried. In order to increase query performance however, it is possible to decrease the number of keypoints queried. In this case, some of the performance loss resulting from a lower number of keypoints can be compensated by a large in combination with match expansion (and, at a lower degree, even without expanding matches).

Figure 2: Performance for varying (Hessian-affine SIFT). Straight lines show the performance for 10 keypoints, dashed lines for 1000 keypoints. Equivalent approaches have equivalent colors.

Runtime. The cost of the evaluated keypoint ranking approaches is negligible for the random and response based ones, as these just have to sort the query features, and about 7ms (SIFT) and 5ms (BinBoost) for the ANMS ranker. For Hessian-affine SIFT on Oxford5k, scoring times (including ME) were about 6ms for processing all results of a single NN query (, ), and therefore slightly lower than the runtimes of running a single NN query which took about 7ms, at the possible gain of adding additional matches and a rough geometric check. The feature quantization needed for match expansion took about 45ms for all features in a query image. For BinBoost features (including ME), the match expansion and scoring took less than 4ms for processing a single NN result. Runtimes increase with , as more correspondences have to be expanded. The overall runtime for Hessian-Affine SIFT at 100 keypoints (ANMS+ME) was about 1.34s (, ), while for binary features it was higher (15s), as for this we used an exact, though state-of-the-art, indexing technique.

Setting runtimes in relation to MAP, it is possible to beat an RND ranker considering 100 keypoints with ANMS+ME considering 50 keypoints at a slightly lower runtime 0.69s vs 0.75s and a higher MAP (see Table 3, 0.741 vs. 0.698). For the holidays dataset runtimes of the random approach (RND) were about 0.9s (, ) and for ANMS+ME it was only approximately 0.6s (, ) at a higher MAP. The most time-consuming operation during match expansion is the search of spatially close features. Therefore we think that the runtimes of match expansion can be reduced significantly by optimizing this matching step, e.g. by ordering features in a d-tree which can be realized without additional space overhead. This would also help on the Paris6k dataset where runtimes of the random approach (RND) were about 0.8s (, ) and for ANMS+ME approximately 0.7s (, ) at similar MAP. Runtimes have been measured using only a single core. As each keypoint is queried separately and match expansion is also achieved on a per-keypoint basis, query processing can be easily extended to a multi-core setting.

For Oxford105k the runtime for match expansion was similar to Oxford5k: A single NN query took slightly less than 8ms and expansion took about 7ms.

Comparison to the State of the Art. While the primary goal of this research is not to increase the effectiveness of object recognition but rather to reduce the number of features queried, let us still compare the results from this paper to the state of the art in order to get insights into its performance. We will compare to [30], as the authors were using the same Hessian-Affine SIFT features as we do and a similar recognition pipeline involving Product Quantization. On the Oxford5k dataset the authors of [30] achieved 0.78 points in MAP using 8 subquantizers for indexing features using Product Quantization, i.e. a setting close to our scenario. This corresponds to the performance we could achieve when querying 100 keypoints. However, using the pipeline from this chapter requires a larger memory footprint; if we consider techniques with a memory footprint closer to ours, [30] was able to achieve 0.83 points in MAP by approximating features more accurately using 32 bytes per feature. On Paris6k, using 8 subquantizers, [30] achieved a MAP of 0.74, which is slightly better than the performance of ANMS+ME at 100 keypoints (at a higher memory footprint, performance of [30] was 0.76). Concerning Oxford105k, a larger number of features (about 300) is needed to achieve performance comparable to the state of the art (0.728 [30]). Finally note that the performance of our baseline is lower for Holidays than the state of the art performance of ( respectively) from [30]; this might be due to a different quantization training set or related to their similarity measure, which is however complementary to our approach and can be easily integrated into our pipeline.

6 Conclusion

In this paper we evaluated an alternative pipeline for decreasing the runtimes of object recognition when NN queries are used for the generation of tentative correspondences instead of Bags of Visual Words. While the reduction of query features can have negative effects on query performance, especially if the unmodified standard recognition pipeline is used, some simple modifications in the pipeline aiming at feature ranking and match expansion can already produce good results at only a fraction of NN queries. Some challenges however, remain. First, more techniques for feature ranking will have to be investigated that provide good results for any type of keypoint descriptor and extractor. Additionally, improvements in the match expansion stage should aim at increasing efficiency and effectiveness. Due to the simple structure of the pipeline used in this paper, these improvements can be easily integrated.

References

  • [1] R. Arandjelovic and A. Zisserman. Three things everyone should know to improve object retrieval. In Proc. CVPR, pages 2911–2918. IEEE, 2012.
  • [2] A. Babenko and V. S. Lempitsky. The inverted multi-index. In Proc. CVPR, pages 3069–3076, 2012.
  • [3] M. Brown, R. Szeliski, and S. Winder. Multi-image matching using multi-scale oriented patches. In Proc. CVPR, volume 1, pages 510–517. IEEE, 2005.
  • [4] O. Chum, M. Perdoch, and J. Matas. Geometric min-hashing: Finding a (thick) needle in a haystack. In Proc. CVPR, pages 17–24. IEEE, 2009.
  • [5] O. Chum, J. Philbin, J. Sivic, M. Isard, and A. Zisserman. Total recall: Automatic query expansion with a generative feature model for object retrieval. In Proc. ICCV, pages 1–8. IEEE, 2007.
  • [6] C. Cui and K. N. Ngan. Global propagation of affine invariant features for robust matching. TIP, 22(7):2876–2888, 2013.
  • [7] V. Ferrari, T. Tuytelaars, and L. Van Gool. Simultaneous object recognition and segmentation by image exploration. In Proc. ECCV, pages 40–54. Springer, 2004.
  • [8] T. Ge, K. He, Q. Ke, and J. Sun. Optimized product quantization for approximate nearest neighbor search. In Proc. CVPR, pages 2946–2953, 2013.
  • [9] X. Guo and X. Cao. Good match exploration using triangle constraint. Pattern Recognition Letters, 33(7):872–881, 2012.
  • [10] K. Hajebi and H. Zhang. Stopping rules for bag-of-words image search and its application in appearance-based localization. arXiv preprint arXiv:1312.7414, 2013.
  • [11] W. Hartmann, M. Havlena, and K. Schindler. Predicting matchability. In Proc. CVPR, 2014.
  • [12] K. He, F. Wen, and J. Sun. K-means hashing: An affinity-preserving quantization method for learning binary compact codes. In Proc. CVPR, pages 2938–2945, 2013.
  • [13] J.-P. Heo, Y. Lee, J. He, S.-F. Chang, and S.-E. Yoon. Spherical hashing. In Proc. CVPR, pages 2957–2964, 2012.
  • [14] P. Indyk and R. Motwani. Approximate nearest neighbors: Towards removing the curse of dimensionality. In Proc. STOC, pages 604–613, 1998.
  • [15] H. Jegou, M. Douze, and C. Schmid. Hamming embedding and weak geometric consistency for large scale image search. In Proc. ECCV, pages 304–317. Springer, 2008.
  • [16] H. Jégou, M. Douze, and C. Schmid. On the burstiness of visual elements. In Proc. CVPR, pages 1169–1176. IEEE, 2009.
  • [17] H. Jégou, M. Douze, and C. Schmid. Exploiting descriptor distances for precise image search. 2011.
  • [18] H. Jégou, M. Douze, and C. Schmid. Product quantization for nearest neighbor search. IEEE PAMI, 33(1):117–128, 2011.
  • [19] A. Joly and O. Buisson. Random maximum margin hashing. In Proc. CVPR, pages 873–880, 2011.
  • [20] Y. Kalantidis and Y. Avrithis. Locally optimized product quantization for approximate nearest neighbor search. In Proc. CVPR, 2014.
  • [21] S. Lee, K. Kim, J.-Y. Kim, M. Kim, and H.-J. Yoo.

    Familiarity based unified visual attention model for fast and robust object recognition.

    Pattern Recognition, 43(3):1116–1128, 2010.
  • [22] D. G. Lowe. Distinctive image features from scale-invariant keypoints. IJCV, 60(2):91–110, 2004.
  • [23] M. Muja and D. G. Lowe. Fast approximate nearest neighbors with automatic algorithm configuration. In VISAPP (1), pages 331–340, 2009.
  • [24] D. Nistér and H. Stewénius. Scalable recognition with a vocabulary tree. In Proc. CVPR, pages 2161–2168, 2006.
  • [25] M. Norouzi, A. Punjani, and D. J. Fleet. Fast search in hamming space with multi-index hashing. In Proc. CVPR, pages 3108–3115, 2012.
  • [26] M. Norouzi, A. Punjani, and D. J. Fleet. Fast exact search in hamming space with multi-index hashing. CoRR, abs/1307.2982v3, 2014.
  • [27] M. Perd’och, O. Chum, and J. Matas. Efficient representation of local geometry for large scale object retrieval. In Proc. CVPR, pages 9–16. IEEE, 2009.
  • [28] J. Philbin, O. Chum, M. Isard, J. Sivic, and A. Zisserman. Object retrieval with large vocabularies and fast spatial matching. In Proc. CVPR, 2007.
  • [29] J. Philbin, O. Chum, M. Isard, J. Sivic, and A. Zisserman. Lost in quantization: Improving particular object retrieval in large scale image databases. In Proc. CVPR, pages 1–8, 2008.
  • [30] D. Qin, C. Wengert, and L. J. V. Gool. Query adaptive similarity for large scale object retrieval. In Proc. CVPR, pages 1610–1617, 2013.
  • [31] E. Rublee, V. Rabaud, K. Konolige, and G. Bradski. Orb: an efficient alternative to sift or surf. In Proc. ICCV, pages 2564–2571, 2011.
  • [32] F. Schaffalitzky and A. Zisserman. Multi-view matching for unordered image sets, or “how do i organize my holiday snaps?”. In Proc. ECCV, pages 414–431. Springer, 2002.
  • [33] C. Schmid and R. Mohr. Combining greyvalue invariants with local constraints for object recognition. In Proc. CVPR, pages 872–877. IEEE, 1996.
  • [34] C. Silpa-Anan and R. Hartley. Optimised kd-trees for fast image descriptor matching. In Proc. CVPR, pages 1–8. IEEE, 2008.
  • [35] J. Sivic and A. Zisserman. Video google: A text retrieval approach to object matching in videos. In Proc. ICCV, pages 1470–1477, 2003.
  • [36] A. Torralba, R. Fergus, and Y. Weiss. Small codes and large image databases for recognition. In Proc. CVPR, 2008.
  • [37] T. Trzcinski, M. Christoudias, P. Fua, and V. Lepetit. Boosting binary keypoint descriptors. In Proc. CVPR, pages 2874–2881. Ieee, 2013.
  • [38] Z. Wu, Q. Ke, M. Isard, and J. Sun. Bundling features for large scale partial-duplicate web image search. In Proc. CVPR, pages 25–32. IEEE, 2009.
  • [39] W. Zhou, Y. Lu, H. Li, and Q. Tian. Scalar quantization for large scale image search. In Proc. MM, pages 169–178, 2012.
