1 Introduction

Deep neural networks have obtained excellent performance for many applications. However, one of the known shortcomings of these systems is that they can be overly confident when presented with images (and classes) which were not present in the training set. Therefore, a desirable property of these systems would be the capacity to not produce an answer if an input sample belongs to an unknown class, that is, a class for which it has not been trained. The field of research which is dedicated to this goal is called out-of-distribution detection [Hendrycks and Gimpel(2017), Liang et al.(2018)Liang, Li, and Srikant, Lee et al.(2018)Lee, Lee, Lee, and Shin]. Performing out-of-distribution detection is important not only to avoid classification errors but also as the first step towards lifelong learning systems [Chen and Liu(2016)]. Such systems would detect out-of-distribution samples in order to later update the model accordingly [Kirkpatrick et al.(2017)Kirkpatrick, Pascanu, Rabinowitz, Veness, Desjardins, Rusu, Milan, Quan, Ramalho, Grabska-Barwinska, et al., Liu et al.(2018)Liu, Masana, Herranz, Van de Weijer, Lopez, and Bagdanov].

The problem of out-of-distribution detection has also been called one-class classification, novelty and anomaly detection [Pimentel et al.(2014)Pimentel, Clifton, Clifton, and Tarassenko]

. More recently, associated to deep neural network classifiers, some works refer to it as open-set recognition

[Bendale and Boult(2016)]. In this paper, we distinguish two cases of out-of-distribution which we believe are quite different: we propose to term as novelty an image from a class different from those contained in a dataset from which to train, but that bears some resemblance to them, for instance because it shows the same kind of object from untrained points of view. This is a very important problem in many computer vision applications. For example, imagine a system that classifies traffic signs on-board a car and takes automatic decisions accordingly. It can happen that it finds a class of local traffic signs which was not included in the training set, and this must be detected to avoid taking wrong decisions. We reserve the word anomaly for completely unrelated samples, like different type of objects, images from another unrelated dataset, or background patches in the case of traffic sign classification. This is also relevant from the point of view of commercial applications. In fact, most previous works focus on anomaly detection. Novelty detection remains rather unexplored. To the best of our knowledge only [Schultheiss et al.(2017)Schultheiss, Käding, Freytag, and Denzler] and [Liang et al.(2018)Liang, Li, and Srikant] perform some intra-dataset out-of-distribution detection experiments. The three previous works closest to ours [Hendrycks and Gimpel(2017), Liang et al.(2018)Liang, Li, and Srikant, Lee et al.(2018)Lee, Lee, Lee, and Shin]

, revolve around one idea: given a discriminative neural network model, use the output probabilities to take the decision of seen/unseen class. These networks are optimized to distinguish between the classes present in the training set, and are not required to explicitly model the marginal data distribution. As a consequence, at testing time the system cannot assess the probability of the presented data, complicating the assessment of novelty cases.

Here we explore a completely different approach: to learn an embedding where one can use Euclidean distance as a measure of “out-of-distributioness”. We propose a loss that learns an embedding where samples from the same in–distribution class form clusters, well separated from the space of other in–distribution classes and also from out-of-distribution samples. The contributions to the problem of out-of-distribution detection presented in this paper are the following. First, the use of metric learning for out-of-distribution detection, instead of doing it on the basis of the cross-entropy loss and corresponding softmax scores. Second, we distinguish between novelty and anomaly detection and show that research should focus on the more challenging problem of novelty detection. Third, we obtain comparable or better results than state-of-the-art in both anomaly and novelty detection. Last, in addition to the experiments with benchmark datasets in order to compare with previous works, we address also a real-world classification problem, traffic sign recognition, for which we obtain good detection and accuracy results.

2 Related work

Our paper is related to anomaly detection in its different meanings. Also to open-set recognition, as one of the most important applications of out-of-distribution detection. And finally to metric learning, the base of our approach. In the following we briefly review the most related works in each of these areas. Out-of-distribution detection should not be confused with another desirable property of machine learning systems, namely the reject option, that is, the ability to decide not to classify an input if the confidence on any of the labels is too weak (see for example

[Geifman and El-Yaniv(2017)] and references therein). The difference is that in the latter case it is assumed that the sample does belong to some class present during training.

Anomaly and novelty detection.  Also known as out-of-distribution detection, it aims at identifying inputs that are completely different from or unknown to the original data distribution used for training [Pimentel et al.(2014)Pimentel, Clifton, Clifton, and Tarassenko]. In [Bodesheim et al.(2013)Bodesheim, Freytag, Rodner, Kemmler, and Denzler]

, they perform novelty detection by learning a distance in an embedding. It proposes a Kernel Null Foley-Sammon transform that aims at projecting all the samples of each in-distribution class into a single point in a certain space. Consequently, novelty detection can be performed by thresholding the distance of a test sample to the nearest of the collapsed class representations. However, they employ handcrafted features, thus optimizing only the transform parameters and not the representation, like in the presently dominating paradigm of deep learning.

Although Deep Neural Networks (DNNs) have established as state-of-the-art on many computer vision classification and detection tasks, overconfidence in the probability score of such networks is a common problem. DNNs capable of detecting lots of objects with fine accuracy can still be fooled by predicting new never-seen objects with high confidence. This problem can be defined by the ability of the network to decide if a new test sample belongs to the in-distribution (i.e. from a class or from the data used to train the classifier) or to an out-of-distribution.

In [Hendrycks and Gimpel(2017)], they show that DNNs trained on MNIST [LeCun et al.(1998)LeCun, Bottou, Bengio, and Haffner] images can frequently produce high confidence guesses (+90%) on random noise images. They propose a baseline for evaluation of out-of-distribution detection methods and show that there is room for future research to improve that baseline. Their baseline assumes that out-of-distribution samples will have a more distributed confidence among the different classes than an in-distribution sample. Recently, in [Liang et al.(2018)Liang, Li, and Srikant] the authors propose ODIN, a simple method applied to DNNs that uses a softmax layer for classification and does not need the network to be retrained. The key idea is to use temperature scaling and input pre-processing, which consists on introducing small perturbations in the direction of the gradients for the input images.

In [Lee et al.(2018)Lee, Lee, Lee, and Shin]

they diverge from the other threshold-based methods by proposing a new training method. They add two loss terms that force the out-of-distribution samples to be less confident and improve the in-distribution samples respectively. In both these works, trained DNNs follow a typical softmax cross-entropy classification loss, where each dimension on the output embedding is assigned to measure the correlation with a specific class from that task. Other than previous work which focuses on networks trained with the cross-entropy, our work studies out-of-distribution for networks which are optimized for metric learning. These networks do not have the normalization problem which is introduced by the softmax layer, and are therefore expected to provide better estimates of out-of-distribution data. One last work is still worth to mention in the context of DNNs. In

[Schultheiss et al.(2017)Schultheiss, Käding, Freytag, and Denzler]

the authors propose to discern between seen and unseen classes through the dimensions of certain layer activations which have extreme values. They achieve a good accuracy on ImageNet but only when the number of selected classes is very small.

Open Set Recognition.  It shares with out-of-distribution detection the goal of discriminating samples from two different distributions. But it places the emphasis on how to apply it to improve the classifier capabilities, so that it can still perform well when the input may contain samples not belonging to any of those in the training set. One of the first works is [Scheirer et al.(2013)Scheirer, de Rezende Rocha, Sapkota, and Boult]

, which formalized the problem as one of (open) risk minimization in the context of large margin classifiers, producing what they called a one-versus-set Support Vector Machine. More recently, a method to adapt deep neural networks to handle open set recognition has been proposed in

[Bendale and Boult(2016)]. The key idea is to replace the conventional softmax layer in a network by a so called openmax layer. It takes the activations (being

the number of classes) of the penultimate layer of the network and estimates the probability for each training class, like in softmax, plus that of not being a sample of the training data. This later is done by fitting a Weilbull density function to the distance between the mean activation value for each class and those of the training samples. We see thus that distance between last layer activations or features play a key role. This is coincident with our method, only that features in their case are learned through a loss function similar to cross-entropy whereas we explicitly will learn a distance such that in-distribution samples cluster around one center per class and out-of-distribution samples are pushed away from all these centers.

Metric Learning.  Several computer vision tasks such as retrieval, matching, verification, even multi-class classification, share the need of being able to measure the similarity between pairs of images. Deriving such a measure from data samples is known as metric learning [Kulis(2013)]. Two often cited seminal works on this subject through neural networks are [Chopra et al.(2005)Chopra, Hadsell, and LeCun, Hadsell et al.(2006)Hadsell, Chopra, and LeCun], where the Siamese architecture was proposed for this purpose. Differently from classification networks, the goal is to learn rather than a representation amenable for classification, one for measuring how similar two instances are in terms of the Euclidean distance. Another popular architecture is triplet networks [Hoffer and Ailon(2015)]. For both of them many authors have realized that mining the samples of the training set in order to find out difficult or challenging pairs or triplets is important in order to converge faster or to better minima [Schroff et al.(2015)Schroff, Kalenichenko, and Philbin, Song et al.(2016)Song, Xiang, Jegelka, and Savarese, Sohn(2016)]. Like them, we have also resorted to a mining strategy in order to obtain good results in the task of out-of-distribution detection.

3 Metric Learning for Out-of-Distribution

Most recent works on out-of-distribution detection are based on supervisely trained neural networks which optimize the cross-entropy loss. In these cases the network output has a direct correspondence with the solution of the task, namely a probability for each class. However, the representation of the output vector is forced to always sum up to one. This means that when the network is shown an input which is not part of the training distribution, it will still give probabilities to the nearest classes so that they sum up to one. This phenomena has led to the known problem of neural networks being too overconfident about content that they have never seen [Hendrycks and Gimpel(2017)].

Several works have focused on improving the accuracy of the confidence estimate of methods based on the cross entropy; adapting them in such a way that they would yield lower confidences for out-of-distribution [Hendrycks and Gimpel(2017), Liang et al.(2018)Liang, Li, and Srikant, Lee et al.(2018)Lee, Lee, Lee, and Shin]. We hypothesize that the problem of the overconfident network predictions is inherent to the used cross-entropy, and therefore propose to study another class of network objectives, namely those used for metric learning. In metric learning methods, we minimize an objective which encourages images with the same label to be close and images with different labels to be at least some margin apart in an embedding space. These networks do not apply a softmax layer, and therefore are not forced to divide images which are out-of-distribution over the known classes.

3.1 Metric Learning

For applications such as image retrieval, images are represented by an embedding in some feature space. Images can be ordered (or classified) according to the distance to other images in that embedding space. It has been shown that using metric learning methods to improve the embeddings could significantly improve their performance

[Guillaumin et al.(2009)Guillaumin, Verbeek, and Schmid]. The theory of metric learning was extended to deep neural networks by Chopra et al. [Chopra et al.(2005)Chopra, Hadsell, and LeCun]. They proposed to pass images through two parallel network branches which share the weights (also called a Siamese network). A loss considers both embeddings, and adapts the embedding in such a way that similar classes are close and dissimilar classes are far in that embedding space.

Traditionally these networks have been trained with contrastive loss [Hadsell et al.(2006)Hadsell, Chopra, and LeCun], which is formulated as:


where is the distance between the embeddings of images and computed by network with weights . The label indicates that the two images are from the same class, and is used for images from different classes. The loss therefore minimizes the distance between images of the same class, and increases the distance of images of different classes until this distance surpasses the margin . Several other losses have been proposed for Siamese networks [Hoffer and Ailon(2015), Wang et al.(2014)Wang, Leung, Rosenberg, Wang, Philbin, Chen, Wu, et al., Schroff et al.(2015)Schroff, Kalenichenko, and Philbin, Wang et al.(2017)Wang, Zhou, Wen, Liu, and Lin, Song et al.(2016)Song, Xiang, Jegelka, and Savarese] but in this paper we will evaluate results with the contrastive loss to provide a simple baseline on which to improve.

3.2 Out-of-Distribution Mining (ODM)

In the previous section, we considered that during training only examples of in-distribution data are provided. However, some methods consider the availability of some out-of-distribution data during training [Lee et al.(2018)Lee, Lee, Lee, and Shin]. This is often a realistic assumption since it is relatively easy to obtain data from other datasets or create out-of-distribution examples, such as samples generated with Gaussian noise. However, it has to be noted that the out-of-distribution data is used unlabeled, and is of a different distribution from the out-of-distribution used at testing. The objective is to help the network be less confident about what it does not know. Therefore, noise or even unlabeled data can be used to strengthen the knowledge boundaries of the network.

We propose to adapt the contrastive loss to incorporate the out-of-distribution data:


where we have introduced a label which is zero when both images are from the out-of-distribution and one otherwise. This loss is similar to Eq. 1, but with the difference that in case of a pair of images where one is an out-of-distribution image (, ) they are encouraged to be at least distance apart. Note that we do not enforce the out-of-distribution images to be close, since when the pair does not contribute to the loss. It is important to make sure that there are no pairs of out-of-distribution samples so that they are not treated as a single new class and forced to be grouped into a single cluster.

In practice, we have not implemented a two-branches Siamese network but followed recent works [Ustinova and Lempitsky(2016), Liu et al.(2017)Liu, van de Weijer, and Bagdanov]

which devise a more efficient approach to minimize losses traditionally computed with Siamese networks. The idea is to sample a minibatch of images which we forward through a single branch until the embedding layer. We then sample pairs from them in the loss layer and backpropagate the gradient. This allows the network to be defined with only one copy of the weights instead of having two branches with shared weights. At the same time, computing the pairs after the embedding also allows to use any subgroup of possible pairs among all the images from the minibatch. When computing the pairs we make sure that pairs of out-of-distribution samples are not used. As a result

will never be and we can in practice directly apply Eq. 1 instead of Eq. 2.

3.3 Anomaly and Novelty detection

In this paper we distinguish between two categories of out-of-distribution data:

Novelty:  samples that share some common space with the trained distribution, which are usually concepts or classes which the network could include when expanding its knowledge. If you train a network specialized in different dog breeds, an example would be a new dog breed that was not in the training set. Furthermore, if the classes are more complex, some novelty out-of-distribution could be new viewpoints or modifications of an existing learned class. Anomaly:  samples that are not related with the trained distribution. In this category we could include background images, Gaussian noise, or unrelated classes to the trained distribution (i.e. SVHN would be a meaningful anomaly for CIFAR-10). Since anomalies are further from the in-distribution than novelties these are expected to be easier to detect.

To further illustrate the difference between novelties and anomalies consider the following experiment. We train a LeNet on the classes 2, 6 and 7 from the MNIST dataset [LeCun et al.(1998)LeCun, Bottou, Bengio, and Haffner] under the same setup for both cross-entropy (CE) and contrastive (ML) losses. We also train it with our proposed method which introduces out-of-distribution mining during training (ODM). We use classes 0, 3, 4, and 8 as those seen out-of-distribution samples during training. Then, we visualize the embeddings for different out-of-distribution cases from closer to further resemblance to the train set : 1) similar numbers 5, 9 and 1 as novelty, 2) SVHN [Netzer et al.(2011)Netzer, Wang, Coates, Bissacco, Wu, and Ng] and CIFAR-10 [Krizhevsky and Hinton(2009)] as anomalies with a meaning, and 3) the simpler Gaussian noise anomalies.

In Figure 1 we show the 3-dimensional output embedding spaces for CE, ML and ODM in rows 1, 2 and 3 respectively. As expected, the CE space is bounded inside the shown triangle, since the three dimensions of the output (the number of classes) have to always sum up to 1. For SVHN, CE correctly assigns low confidence for all classes. However, for CIFAR-10, Gaussian noise and Novelty it increasingly is more confident about the probability of an out-of-distribution image to be classified as an in-distribution one. In the case of ML, all anomalies seem to be more separated from the in-distributions for each class, and only the Novelty is still too close to the cluster centers. With the introduction of out-of-distribution samples during training, ODM shows how out-of-distribution images are kept away from the in-distribution, allowing the network to be confident about what it is capable of classifying and what not. We provide quantitative performance results for this experiment in the Supplementary Material.

In conclusion, this experiment shows that there is a difference between novel and anomaly out-of-distribution samples for both cross-entropy and metric learning approaches, stressing that those have to be approached differently. Furthermore, the overconfidence of the cross-entropy methods is more clear on novelty detection cases, and among the anomaly cases, the Gaussian noise seems to be the one with more overconfident cases. In those cases, a metric learning approach presents more benefits when doing out-of-distribution detection. It allows for the output embedding space to be more representative of the learned classes around the class centers, and naturally has the ability to give low scores to unseen data. Finally, when some out-of-distribution samples are shown during training, the network is more capable of adapting the embedding space to be more separable against anomaly data.

Figure 1: Embedding spaces for CE, ML and ODM (rows respectively) being tested on in-dist 2, 6, 7 of MNIST (red, blue, purple), and out-dist 5, 9, 1 of MNIST (green), SVHN (yellow), CIFAR-10 (orange), and Gaussian noise (grey). Best viewed in color.

4 Results

To assess the performance of the proposed method, we first compare with existing state-of-the-art out-of-distribution detection methods on SVHN [Netzer et al.(2011)Netzer, Wang, Coates, Bissacco, Wu, and Ng] and CIFAR-10 [Krizhevsky and Hinton(2009)] datasets trained on VGGnet [Szegedy et al.(2015)Szegedy, Liu, Jia, Sermanet, Reed, Anguelov, Erhan, Vanhoucke, Rabinovich, et al.] and evaluated with the metrics provided in [Lee et al.(2018)Lee, Lee, Lee, and Shin]. Furthermore, as a more application-based benchmark, we propose to compare cross-entropy based strategies and metric learning strategies on the Tsinghua dataset [Zhu et al.(2016)Zhu, Liang, Zhang, Huang, Li, and Hu] of traffic signs. In this second set of experiments we use our own implementation of the metrics defined in [Liang et al.(2018)Liang, Li, and Srikant]. More about the metrics used can be found in the Supplementary Material.111Code available at:

4.1 Comparison with state-of-the-art

We compare our method with two very recent state-of-the-art methods. One of them uses a confidence classifier and an adversarial generator (CC-AG) [Lee et al.(2018)Lee, Lee, Lee, and Shin] and like ours uses out-of-distribution images during training. The second method is ODIN [Liang et al.(2018)Liang, Li, and Srikant] which does not consider out-of-distribution images during training. In [Lee et al.(2018)Lee, Lee, Lee, and Shin] they compare CC-AG with ODIN [Liang et al.(2018)Liang, Li, and Srikant], and show that they can perform much better in the novelty case but similar for the anomaly cases.

We train each SVHN and CIFAR-10 as the in-distribution datasets while using the other dataset as the seen out-distribution during training. We train on VGGnet, just like [Lee et al.(2018)Lee, Lee, Lee, and Shin], with a contrastive loss of margin 10 and a 25% of (in-dist, out-dist) pairs every two batches. Following the experiments of [Lee et al.(2018)Lee, Lee, Lee, and Shin], we test the resulting networks on the in-distribution test set for classification, and TinyImageNet [Deng et al.(2009)Deng, Dong, Socher, Li, Li, and Fei-Fei], LSUN [Yu et al.(2015)Yu, Zhang, Song, Seff, and Xiao]

and Gaussian noise for out-of-distribution detection. For evaluation we use the proposed metrics from their implementation, namely: true negative rate (TNR) when true positive rate (TPR) is at 95%, detection accuracy, area under the receiver operating characteristic curve (AUROC) and both area under the precision-recall curve for in-distribution (AUPR-in) and out-distribution (AUPR-out).

Table 1 shows the results. For SVHN as the in-distribution results are as expected, with ODIN having lower results due to not using any out-of-distribution during training, and both CC-AG and ODM having near perfect performance. In the case of CIFAR-10 being the in-distribution, the same pattern is repeated for the seen distribution from SVHN. However, for the unseen out-distributions, CC-AG achieves the lower performance on both TinyImageNet and LSUN datasets, and ODIN the lower for Gaussian noise. Although not always achieving the best performance, ODM is able to compete with the best cases, and is never the worse performer. Gaussian noise seems to be the most difficult case on CIFAR-10, which is a more complex dataset than SVHN. For ODIN, as it is only based on cross-entropy, it becomes to overconfident. In the case of CC-AG and ODM, the low results might be related to Gaussian noise being too different from the out-distribution seen during training.

Finally, it is important to note that metric learning has a lower classification accuracy of the in-distribution. This has already been observed in [Horiguchi et al.(2017)Horiguchi, Ikami, and Aizawa], where features learned by classification networks with typical softmax layers are compared with metric learning based features, with regard to several benchmark datasets. For good classification results our metric learning network should be combined with those of a network trained with cross-entropy. One could also consider a network with two heads, where after some initial shared layers a cross-entropy branch and a metric learning branch are trained in a multi-task setting.

In-dist Out-dist TNR at Detection AUROC AUPR-in AUPR-out
classification 95% TPR Accuracy
CIFAR-10* 47.4/99.9/99.8 78.6/99.9/99.8 62.6/99.9/99.5 71.6/99.9/99.7 91.2/99.4/99.9
SVHN Tiny 49.0/100.0/99.0 79.6/100.0/99.1 64.6/100.0/99.0 72.7/100.0/96.5 91.6/99.4/99.8
93.8/94.2/68.7 LSUN 46.3/100.0/99.4 78.2/100.0/99.5 61.8/100.0/99.3 71.1/100.0/97.8 90.8/99.4/99.8
Gaussian 56.1/100.0/100.0 83.4/100.0/100.0 72.0/100.0/100.0 77.2/100.0/100.0 92.8/99.4/100.0
SVHN* 13.7/99.8/99.8 66.6/99.8/99.7 46.6/99.9/99.9 61.4/99.9/99.9 73.5/99.8/100.0
CIFAR-10 Tiny 13.6/10.1/17.1 62.6/58.9/66.9 39.6/31.8/66.2 58.3/55.3/60.3 71.0/66.1/68.2
80.1/80.6/54.0 LSUN 14.0/10.8/19.6 63.2/60.2/70.9 40.7/34.8/68.4 58.7/56.4/59.5 71.5/68.0/70.7
Gaussian 2.8/3.5/3.0 50.0/50.0/64.2 10.2/14.1/49.8 48.1/49.4/64.1 39.9/47.0/46.7
Table 1: Comparison with the state-of-the-art. All metrics show the methods as ODIN/CC-AG/ODM, red indicates worst performance, bold indicates best, * for seen distribution.

4.2 Tsinghua traffic sign dataset

We evaluate our method on a real application, i.e. traffic sign recognition in the presence of unseen traffic signs (novelty) and not-a-traffic-sign detection (anomaly). We compare our proposed method ODM against ODIN [Liang et al.(2018)Liang, Li, and Srikant], as a cross-entropy based method, on the Tsinghua dataset [Zhu et al.(2016)Zhu, Liang, Zhang, Huang, Li, and Hu]. We divide traffic sign classes into three disjoint partitions : the in-distribution classes, seen out-of-distribution images used for training, and unseen out-of-distribution images used for testing on out-of-distribution detection. Since Tsinghua contains some very similar traffic sign classes which would rarely be learned without each other (i.e. all speed limits, all turning arrows, …), we group those that are too similar in order to build a more reasonable and natural split than just a random one (See Supplementary Material for more on the usual random splits). For the same reason, we also discard classes with less than 10 images as they introduce errors. Therefore, we generate a random split which applies by the mentioned restrictions (see Fig. 2), by taking a 50-20-30% split of the classes for the in-distribution, seen out-distribution and unseen out-distribution respectively.

Figure 2: In-distribution (left), seen (middle) and unseen(right) out-of-distribution partition classes from the proposed Tsinghua split.

Regarding anomalies, we consider Gaussian noise, but also background patches from the same Tsinghua dataset images. Those patches are generated randomly from the central area of the original full frames to avoid an unbalanced ratio of ground and sky images, which can be semantically richer and more challenging. In a real traffic sign detector application, where detected possible traffic signs are fed to a classifier, this kind of anomalies are more realistic and account for possible detection errors more than Gaussian noise. The global performance of the system can be improved by avoiding that those anomalies reach the classifier and produce an overconfident error.

For this experiment, we learn a 32-dimensional embedding space, training a WRN-28-10 model [Zagoruyko and Komodakis(2016)] with an Adam optimizer at learning rate 0.0001 for 10,000 steps. The same training parameters are used for ODIN since they provided the best combination on the validation set. Table 2 shows the results of the comparison between ODIN, ML and ODM for both seen novelty and anomaly cases. Note that our implementation of the Detection Error metric is fixed to use the FPR at a TPR of 95%, making a value of 2.50 the one of a perfect detector (see Supplementary Material).

In terms of in-distribution classification accuracy, both methods are equivalent. However, the comparison of plain metric learning (Ours-ML) with ODIN shows that learning an embedding can be more suitable for out-of-distribution detection of both novelty and anomalies. Introducing out-distribution samples during training slightly improves all cases. Using anomalies as seen out-of-distribution during training helps the detection of the same kind of anomaly as expected since anomalies will be forced to be further away from the in-distribution in the embedding space. However, in some cases, it can damage the detection of novelty, which would not be guaranteed to be pushed away from the learned classes.

Method In-dist Out-dist FPR at Detection AUROC AUPR-in AUPR-out
accuracy 95% TPR error
ODIN 98.29 Tsinghua (unseen) 8.74 6.87 97.82 96.19 98.92
Background (unseen) 22.42 13.71 96.43 92.13 98.48
Noise (unseen) 0.23 2.61 98.59 98.40 98.76
Ours - ML 98.93 Tsinghua (unseen) 5.23 5.11 98.77 97.38 99.45
Background (unseen) 0.25 2.62 99.35 99.03 99.64
Noise (unseen) 0.07 2.53 99.51 99.25 99.72
Ours - ODM 98.96 Tsinghua (seen) 4.38 4.70 99.01 98.01 99.63
Background (unseen) 0.17 2.60 99.28 98.81 99.67
Noise (unseen) 0.00 2.51 99.69 99.51 99.73
Ours - ODM 98.57 Tsinghua (unseen) 8.65 6.82 97.84 94.40 98.57
Background (seen) 0.01 2.50 99.99 99.94 99.99
Noise (unseen) 0.00 2.50 100.00 99.97 99.99
Ours - ODM 99.00 Tsinghua (unseen) 5.72 5.36 98.50 97.09 99.30
Background (unseen) 1.51 3.25 98.53 97.97 99.20
Noise (seen) 0.00 2.50 100.00 99.93 99.99
Table 2: Comparison between ODIN and our proposed learning strategies on a WRN-28-10 architecture, when using novelty, anomaly (background patches and Gaussian noise) as seen out-of-distribution data as well as not seen out-of-distribution.

5 Conclusions

In this paper, we propose a metric learning approach to improve out-of-distribution detection which performs comparable or better than the state-of-the-art. We show that metric learning provides a better output embedding space to detect data outside the learned distribution than cross-entropy softmax based models. This opens an opportunity to further research on how this embedding space should be learned, with restrictions that could further improve the field. The presented results suggest that out-of-distribution data might not all be seen as a single type of anomaly, but instead a continuous representation between novelty and anomaly data. In that spectrum, anomaly detection is the easier task, giving more focus at the difficulty of novelty detection. Finally, we also propose a new benchmark for out-of-distribution detection on the Tsinghua dataset, as a more realistic scenario for novelty detection.


Marc Masana acknowledges 2018-FI_B1-00198 grant of Generalitat de Catalunya. Idoia Ruiz, Joan Serrat and Antonio Lopez want to acknowledge the Spanish project TIN2017-88709-R (Ministerio de Ciencia, Innovación y Universidades). This work is supported by the EU Project CybSpeed MSCA-RISE-2017-777720. We acknowledge the project TIN2016-79717-R and the CHISTERA project M2CR (PCIN-2015-251) of the Spanish Government. We also acknowledge the CERCA Programme of Generalitat de Catalunya and its ACCIO agency. Finally, we acknowledge the generous support of the NVIDIA GPU donation program.


  • [Bendale and Boult(2016)] A. Bendale and T. E. Boult. Towards open set deep networks. In

    IEEE Conference on Computer Vision and Pattern Recognition (CVPR)

    , pages 1563–1572, 2016.
  • [Bodesheim et al.(2013)Bodesheim, Freytag, Rodner, Kemmler, and Denzler] Paul Bodesheim, Alexander Freytag, Erik Rodner, Michael Kemmler, and Joachim Denzler. Kernel null space methods for novelty detection. In IEEE Conference on Computer Vision and Pattern Recognition (CVPR), pages 3374–3381, 2013.
  • [Chen and Liu(2016)] Zhiyuan Chen and Bing Liu. Lifelong machine learning.

    Synthesis Lectures on Artificial Intelligence and Machine Learning

    , 10(3):1–145, 2016.
  • [Chopra et al.(2005)Chopra, Hadsell, and LeCun] Sumit Chopra, Raia Hadsell, and Yann LeCun. Learning a similarity metric discriminatively, with application to face verification. In IEEE Conference on Computer Vision and Pattern Recognition (CVPR), pages 539–546, 2005.
  • [Davis and Goadrich(2006)] Jesse Davis and Mark Goadrich. The relationship between precision-recall and roc curves. In Proceedings of the 23rd international conference on Machine learning, pages 233–240. ACM, 2006.
  • [Deng et al.(2009)Deng, Dong, Socher, Li, Li, and Fei-Fei] Jia Deng, Wei Dong, Richard Socher, Li-Jia Li, Kai Li, and Li Fei-Fei. Imagenet: A large-scale hierarchical image database. In IEEE Conference on Computer Vision and Pattern Recognition (CVPR), pages 248–255, 2009.
  • [Geifman and El-Yaniv(2017)] Yonatan Geifman and Ran El-Yaniv. Selective classification for deep neural networks. In Advances in Neural Information Processing Systems (NIPS), pages 4885–4894, 2017.
  • [Guillaumin et al.(2009)Guillaumin, Verbeek, and Schmid] Matthieu Guillaumin, Jakob Verbeek, and Cordelia Schmid. Is that you? metric learning approaches for face identification. In Computer Vision, 2009 IEEE 12th international conference on, pages 498–505. IEEE, 2009.
  • [Hadsell et al.(2006)Hadsell, Chopra, and LeCun] Raia Hadsell, Sumit Chopra, and Yann LeCun. Dimensionality reduction by learning an invariant mapping. In IEEE Conference on Computer Vision and Pattern Recognition (CVPR), pages 1735–1742, 2006.
  • [Hendrycks and Gimpel(2017)] Dan Hendrycks and Kevin Gimpel. A baseline for detecting misclassified and out-of-distribution examples in neural networks. In Int. Conference on Learning Representations (ICLR), 2017.
  • [Hoffer and Ailon(2015)] Elad Hoffer and Nir Ailon. Deep metric learning using triplet network. In International Workshop on Similarity-Based Pattern Recognition, pages 84–92. Springer, 2015.
  • [Horiguchi et al.(2017)Horiguchi, Ikami, and Aizawa] Shota Horiguchi, Daiki Ikami, and Kiyoharu Aizawa. Significance of softmax-based features in comparison to distance metric learning-based features. CoRR, abs/1712.10151, 2017.
  • [Kirkpatrick et al.(2017)Kirkpatrick, Pascanu, Rabinowitz, Veness, Desjardins, Rusu, Milan, Quan, Ramalho, Grabska-Barwinska, et al.] James Kirkpatrick, Razvan Pascanu, Neil Rabinowitz, Joel Veness, Guillaume Desjardins, Andrei A Rusu, Kieran Milan, John Quan, Tiago Ramalho, Agnieszka Grabska-Barwinska, et al. Overcoming catastrophic forgetting in neural networks. Proceedings of the national academy of sciences, page 201611835, 2017.
  • [Krizhevsky and Hinton(2009)] Alex Krizhevsky and Geoffrey Hinton. Learning multiple layers of features from tiny images. 2009.
  • [Kulis(2013)] Brian Kulis. Metric learning: A survey. Foundations and Trends in Machine Learning, 5(4):287–364, 2013.
  • [LeCun et al.(1998)LeCun, Bottou, Bengio, and Haffner] Yann LeCun, Léon Bottou, Yoshua Bengio, and Patrick Haffner. Gradient-based learning applied to document recognition. Proceedings of the IEEE, 86(11):2278–2324, 1998.
  • [Lee et al.(2018)Lee, Lee, Lee, and Shin] Kimin Lee, Honglak Lee, Kibok Lee, and Jinwoo Shin. Training confidence-calibrated classifiers for detecting out-of-distribution samples. In Int. Conference on Learning Representations (ICLR), 2018.
  • [Liang et al.(2018)Liang, Li, and Srikant] Shiyu Liang, Yixuan Li, and R. Srikant. Enhancing the reliability of out-of-distribution image detection in neural networks. In Int. Conference on Learning Representations (ICLR), 2018.
  • [Liu et al.(2017)Liu, van de Weijer, and Bagdanov] Xialei Liu, Joost van de Weijer, and Andrew D Bagdanov. Rankiqa: Learning from rankings for no-reference image quality assessment. In International Conference on Computer Vision (ICCV), 2017.
  • [Liu et al.(2018)Liu, Masana, Herranz, Van de Weijer, Lopez, and Bagdanov] Xialei Liu, Marc Masana, Luis Herranz, Joost Van de Weijer, Antonio M Lopez, and Andrew D Bagdanov. Rotate your networks: Better weight consolidation and less catastrophic forgetting. In Proceedings International Conference on Pattern Recognition (ICPR), 2018.
  • [Manning and Schütze(1999)] Christopher D Manning and Hinrich Schütze.

    Foundations of statistical natural language processing

    MIT press, 1999.
  • [Netzer et al.(2011)Netzer, Wang, Coates, Bissacco, Wu, and Ng] Yuval Netzer, Tao Wang, Adam Coates, Alessandro Bissacco, Bo Wu, and Andrew Y Ng. Reading digits in natural images with unsupervised feature learning. In NIPS Workshop on deep learning and unsupervised feature learning, 2011.
  • [Pimentel et al.(2014)Pimentel, Clifton, Clifton, and Tarassenko] Marco A. F. Pimentel, David A. Clifton, Lei A. Clifton, and Lionel Tarassenko. A review of novelty detection. Signal Processing, 99:215–249, 2014.
  • [Scheirer et al.(2013)Scheirer, de Rezende Rocha, Sapkota, and Boult] W. J. Scheirer, A. de Rezende Rocha, A. Sapkota, and T. E. Boult. Toward open set recognition. IEEE Transactions on Pattern Analysis and Machine Intelligence, 35(7):1757–1772, July 2013.
  • [Schroff et al.(2015)Schroff, Kalenichenko, and Philbin] Florian Schroff, Dmitry Kalenichenko, and James Philbin.

    Facenet: A unified embedding for face recognition and clustering.

    In IEEE Conference on Computer Vision and Pattern Recognition (CVPR), pages 815–823, 2015.
  • [Schultheiss et al.(2017)Schultheiss, Käding, Freytag, and Denzler] Alexander Schultheiss, Christoph Käding, Alexander Freytag, and Joachim Denzler. Finding the unknown: Novelty detection with extreme value signatures of deep neural activations. In Volker Roth and Thomas Vetter, editors, German Conference on Pattern Recognition (GCPR), pages 226–238. Springer, 2017.
  • [Sohn(2016)] Kihyuk Sohn. Improved deep metric learning with multi-class n-pair loss objective. In Advances in Neural Information Processing Systems (NIPS), 2016.
  • [Song et al.(2016)Song, Xiang, Jegelka, and Savarese] Hyun Oh Song, Yu Xiang, Stefanie Jegelka, and Silvio Savarese. Deep metric learning via lifted structured feature embedding. In IEEE Conference on Computer Vision and Pattern Recognition (CVPR), pages 4004–4012, 2016.
  • [Szegedy et al.(2015)Szegedy, Liu, Jia, Sermanet, Reed, Anguelov, Erhan, Vanhoucke, Rabinovich, et al.] Christian Szegedy, Wei Liu, Yangqing Jia, Pierre Sermanet, Scott Reed, Dragomir Anguelov, Dumitru Erhan, Vincent Vanhoucke, Andrew Rabinovich, et al. Going deeper with convolutions. In IEEE Conference on Computer Vision and Pattern Recognition (CVPR), 2015.
  • [Ustinova and Lempitsky(2016)] Evgeniya Ustinova and Victor Lempitsky. Learning deep embeddings with histogram loss. In Advances in Neural Information Processing Systems (NIPS), pages 4170–4178, 2016.
  • [Wang et al.(2017)Wang, Zhou, Wen, Liu, and Lin] Jian Wang, Feng Zhou, Shilei Wen, Xiao Liu, and Yuanqing Lin. Deep metric learning with angular loss. In International Conference on Computer Vision (ICCV), 2017.
  • [Wang et al.(2014)Wang, Leung, Rosenberg, Wang, Philbin, Chen, Wu, et al.] Jiang Wang, Thomas Leung, Chuck Rosenberg, Jinbin Wang, James Philbin, Bo Chen, Ying Wu, et al. Learning fine-grained image similarity with deep ranking. In IEEE Conference on Computer Vision and Pattern Recognition (CVPR), 2014.
  • [Yu et al.(2015)Yu, Zhang, Song, Seff, and Xiao] Fisher Yu, Yinda Zhang, Shuran Song, Ari Seff, and Jianxiong Xiao. Lsun: Construction of a large-scale image dataset using deep learning with humans in the loop. arXiv preprint arXiv:1506.03365, 2015.
  • [Zagoruyko and Komodakis(2016)] Sergey Zagoruyko and Nikos Komodakis. Wide residual networks. In British Machine and Vision Conference (BMVC), 2016.
  • [Zhu et al.(2016)Zhu, Liang, Zhang, Huang, Li, and Hu] Zhe Zhu, Dun Liang, Songhai Zhang, Xiaolei Huang, Baoli Li, and Shimin Hu. Traffic-sign detection and classification in the wild. In IEEE Conference on Computer Vision and Pattern Recognition (CVPR), pages 2110–2118, 2016.

Supplementary Material
Metric Learning for Novelty and Anomaly Detection


A Out-of-Distribution detection metrics

In out-of-distribution detection, comparing different detector approaches cannot be done by measuring only accuracy. The question we want to answer is if a given test sample is from a different distribution than that of the training data. The detector will be using some information from the classifier or embedding space, but the prediction is whether that processed sample is part of the in-distribution or the out-distribution. To measure that, we adopt the metrics proposed in [Liang et al.(2018)Liang, Li, and Srikant]:

  • FPR at 95% TPR is the corresponding False Positive Rate (FPR=FP/(FP+TN)) when the True Positive Rate (TPR=TP/(TP+FN)) is at 95%. It can be interpreted as the misclassification probability of a negative (out-distribution) sample to be predicted as a positive (in-distribution) sample.

  • Detection Error measures the probability of misclassifying a sample when the TPR is at 95%. Assuming that a sample has equal probability of being positive or negative in the test, it is defined as .

where TP, FP, TN, FN correspond to true positives, false positives, true negatives and false negatives respectively. Those two metrics were also changed to TNR at 95% TPR and Detection Accuracy in [Lee et al.(2018)Lee, Lee, Lee, and Shin], which can be calculated by doing from the two metrics above explained respectively. We use the latter metrics only when comparing to other state-of-the-art methods. This is also done because the implementation in both [Liang et al.(2018)Liang, Li, and Srikant, Lee et al.(2018)Lee, Lee, Lee, and Shin] allows for using a TPR which is not at 95% in some cases, meaning that the Detection Error can go below since TPR is not fixed to .

In order to avoid the biases between the likelihood of an in-distribution sample to being more frequent than an out-distribution one, we need threshold independent metrics that measure the trade-off between false negatives and false positives. We adopt the following performance metrics proposed in [Hendrycks and Gimpel(2017)]:

  • AUROC is the Area Under the Receiver Operating Characteristic proposed in [Davis and Goadrich(2006)]. It measures the relation between between TPR and FPR interpreted as the probability of a positive sample being assigned a higher score than a negative sample.

  • AUPR is the Area Under the Precision-Recall curve proposed in [Manning and Schütze(1999)]. It measures the relationship between precision (TP/(TP+FP)) and recall (TP/(TP+FN)) and is more robust when positive and negative classes have different base rates. For this metric we provide both AUPR-in and AUPR-out when treating in-distribution and out-distribution samples as positive, respectively.

B Quantitative results of the MNIST experiment

In this section we present the quantitative results of the comparison on the MNIST dataset. In this case we allowed a 5-dimensional embedding space for ML so the representation is rich enough to make the discrimination between in-dist and out-dist. For CE, as it is fixed to the number of classes, the embedding space is 3-dimensional. In Table 3 we see that ML performs a better than CE on all cases. ODM almost solves the novelty problem while keeping a similar performance on anomalies as ML. It is noticeable that CE struggles a bit more with Gaussian noise than the other anomalies. In this case, CE still produces highly confident predictions for some of the noise images.

Method In-dist Out-dist FPR at Detection AUROC AUPR-in AUPR-out
accuracy 95% TPR Error
CE 99.70 Novelty 33.76 19.38 92.33 92.73 92.29
Gaussian noise 0.70 2.85 98.85 99.21 98.14
SVHN 0.23 2.60 99.48 98.64 99.91
CIFAR-10 2.86 3.93 98.96 98.02 99.57
Ours - ML 99.54 Novelty 21.05 13.03 94.48 94.02 94.46
Gaussian noise 0.00 1.95 98.54 99.21 95.15
SVHN 0.00 1.74 98.88 98.76 99.61
CIFAR-10 0.01 2.36 98.87 98.93 99.12
Ours - ODM 99.64 Novelty 0.16 1.67 99.95 99.94 99.96
Gaussian noise 0.00 1.76 99.14 99.46 97.66
SVHN 0.00 0.96 99.65 99.41 99.89
CIFAR-10 0.00 1.31 99.54 99.45 99.68
Table 3: Quantitative comparison between cross-entropy and metric learning based methods training on LeNet for MNIST – 2, 6, 7 (In-dist), 0, 3, 4 and 8 (Seen Out-dist) and 5, 9, 1 (Unseen Out-dist Novelty).

C Experimental results on additional Tsinghua splits

Alternatively to the Tsinghua split generated with the restrictions introduced in Section 4.2, we also perform the comparison in a set of 10 random splits without applying any restriction to the partition classes. We still discard the classes with less than 10 images per class. Table 4

shows the average performance for this set of splits with their respective standard deviation. Since the split of the classes is random, this leads to highly similar or mirrored classes to be separated into in-distribution and out-distribution, creating situations that are very difficult to predict correctly. For instance, detecting that a turn-left traffic sign is part of the in-distribution while the turn-right traffic sign is part of the out-distribution, is very difficult in many cases. Therefore, the results from the random splits have a much lower performance, specially for the novelty case.

When comparing the metric learning based methods, ODM improves over ML for the test set that has been seen as out-distribution during training. In general, using novelty data as out-distribution makes an improvement over said test set, as well as for background and noise. However, when using background images to push the out-of-distribution further from the in-distribution class clusters in the embedding space, novelty is almost unaffected. The same happens when noise is used as out-distribution during training. This could be explained by those cases improving the embedding space for data that is initially not so far away from the in-distribution class clusters. This would change the embedding space to push further the anomalies, but would leave the novelty classes, originally much closer to the clusters, almost at the same location.

When introducing out-of-distribution samples, the behaviour on the random splits is the same as for the restricted splits: while introducing novelty helps the detection on all cases, introducing anomaly helps the detection of the same kind of anomaly.

Method In-dist Out-dist FPR at Detection AUROC AUPR-in AUPR-out
accuracy 95% TPR error
ODIN 99.290.05 Tsinghua (unseen) 20.852.28 12.921.14 93.501.05 93.781.93 92.410.73
Background (unseen) 8.396.34 6.703.17 98.061.26 97.023.15 98.790.60
Noise (unseen) 0.030.43 2.530.85 99.670.34 99.600.39 99.740.41
Ours - ML 99.160.16 Tsinghua (unseen) 21.053.25 13.031.62 94.180.92 94.421.12 92.751.08
Background (unseen) 1.911.02 3.450.51 99.140.32 98.790.35 99.400.22
Noise (unseen) 0.300.96 2.650.48 99.270.36 99.090.40 99.430.35
Ours - ODM 99.130.22 Tsinghua (seen) 16.294.53 10.652.26 96.270.86 96.780.93 95.111.15
Background (unseen) 0.391.63 2.710.31 99.500.27 99.300.31 99.660.20
Noise (unseen) 0.011.39 2.510.70 99.590.54 99.510.60 99.690.43
Ours - ODM 99.090.18 Tsinghua (unseen) 20.363.63 12.681.81 93.471.55 93.582.10 92.001.74
Background (seen) 0.010.03 2.510.01 99.970.02 99.920.03 99.980.01
Noise (unseen) 0.000.00 2.500.01 99.990.03 99.970.05 99.990.01
Ours - ODM 99.022.42 Tsinghua (unseen) 20.871.63 12.930.81 93.651.05 94.011.48 92.330.89
Background (unseen) 0.971.19 2.990.60 99.140.19 98.900.23 99.390.19
Noise (seen) 0.000.00 2.500.01 100.000.00 99.980.01 99.991.85
Table 4: Comparison between ODIN and our proposed learning strategies on a WRN-28-10 architecture, when using novelty, anomaly (background patches and Gaussian noise) as seen out-of-distribution data as well as not seen out-of-distribution. The experiments are performed on a set of 10 random splits and the metrics provided are the mean of the metrics on the individual splits its standard deviation.

D Embeddings on Tsinghua

Figure 3 shows the embeddings for ODM (with novelty as seen out-of-distribution) and ML after applying PCA. When using ML, the novelties are not forced to be pushed away from the in-distribution clusters so they share the embedding space in between those same in-distribution clusters. In the case of ODM, the out-of-distribution clusters are more clearly separated from the in-distribution ones.

Figure 3: Embedding spaces after PCA for ODM (left) and ML (right) tested for in-dist (blue shaded) and out-dist (yellow shaded). Results are for TSinghua (first row), background patches (second row) and Gaussian noise (third row). Best viewed in color.
