From Robotic Process Automation to Intelligent Process Automation: Emerging Trends

07/27/2020 ∙ by Tathagata Chakraborti, et al. ∙ 30

In this survey, we study how recent advances in machine intelligence are disrupting the world of business processes. Over the last decade, there has been steady progress towards the automation of business processes under the umbrella of “robotic process automation” (RPA). However, we are currently at an inflection point in this evolution, as a new paradigm called “Intelligent Process Automation” (IPA) emerges, bringing machine learning (ML) and artificial intelligence (AI) technologies to bear in order to improve business process outcomes. The purpose of this paper is to provide a survey of this emerging theme and identify key open research challenges at the intersection of AI and business processes. We hope that this emerging theme will spark engaging conversations at the RPA Forum.

READ FULL TEXT VIEW PDF
POST COMMENT

Comments

There are no comments yet.

Authors

page 1

page 2

page 3

page 4

This week in AI

Get the week's most popular data science and artificial intelligence research sent straight to your inbox every Saturday.

1 Introduction

Business processes are an integral part of every industry, such as government, insurance, banking and healthcare. Examples of such processes include automobile insurance claims processing, handling prescription drug orders and patient case management. The business process management (BPM) industry is expected to approach $16 billion by 2023 [43]. With recent advances in machine learning and artificial intelligence (AI), the automation of steps in a business process – which came to be known as Robotic Process Automation (RPA) – is undergoing a radical transformation. The industries that are most eager to adopt automation are transportation, manufacturing, packaging and shipping, customer service, finance, and healthcare [19].

As noted in “The Transformation of RPA to IPA: Intelligent Process Automation” [63]: The convergence of AI, automation and customer data has now seen the emergence of a new class of tools, known as intelligent process automation (IPA). This view is also echoed in market outlook reports from industry leaders, including PwC’s recent analysis of rising trends in RPA in the financial sector [32] and the 2020 AI predictions from IBM research [55] outlining the potential of AI-fueled automation to transform how people work. Recently AAAI, one of the leading AI conferences, also hosted the first workshop on Intelligent Process Automation [25]. In this survey, we explore this nascent field of inquiry at the intersection of AI and business process automation in greater detail. We begin first with some background on BPM and RPA.

2 Business Processes

A business process is a collection of connected tasks that once completely executed delivers a service or product to a client or accomplishes an organizational goal within an enterprise [65]. A mortgage loan application (shown in Fig. 1) is a common example of a business process where the process flow is the set of linked loan application tasks such as collecting client related data (e.g. verifying employment, requesting credit report), performing a title search, receiving the title report and so on. The goal of this process is to approve or reject a loan application once all the required tasks are fully executed. The process is expressed in the business process model and notation (BPMN) graphical notation [22]. Circles denote events, activities are denoted by rounded-corner rectangles and diamonds depict gateways that allow paths to conditionally merge or diverge.

Figure 1: Example of a mortgage loan application process.

2.1 Business Process Management

Business Process Management (BPM) is a multi-disciplinary field that supports the management of business processes with some combination of modeling, automation, execution, control, measurement and optimization. BPM involves business activity flows (workflows), systems, and people such as employees, customers and partners within and beyond the enterprise boundaries.

Business processes in reality have a wide scope from the traditional rigid processes (modeled and running under the supervision of a strict workflow management system) to completely ad-hoc unstructured flows driven by humans over e-mail, chat and phone. Traditional BPM systems, at one end of this spectrum, demand a process model that can be completely defined in advance and typically include restrictions such as rigid control flow and context tunneling [39]. Case management is closer to the other end of this spectrum: a case consists of people, documents, and tasks [64]. Flexible ordering of task execution is enabled through Event-Condition-Action rules as well as the ability for a user to add new (ad-hoc) tasks. A task itself may be defined as a fully structured workflow, making case management a hybrid model.

2.2 Business Process Automation

Businesses seek to support growth while maintaining low costs by automating repetitive and time consuming tasks, especially seeking to eliminate costly and error-prone manual steps. Business Process Automation (BPA) seeks to improve the efficiency of business processes in terms of cost, resources and investment through automating the management of relevant information and data, the time spent by team members, and the execution logic.

RPA is an emerging technology in BPA that creates software robots that perform tasks previously done by humans. RPAs are one form of BPA implementation that is specifically focused on repetitive workflows. The overall goal of RPA is to provide the shortest route to automation by introducing a user interface automation layer rather than interacting deeply with the application code, system or database that are behind those applications.

2.3 Performance Measures

Performance measurement in business processes is the first step for analyzing and monitoring the process health and progress for process automation. Identifying the right measures for process performance is extremely important. Performance of a process measures how well the process is doing with respect to chosen indicators. Examples of such performance indicators can be time to execute a task, cost per task in terms of employee head count or number of approved loans [46]. Numerous authors have proposed a fixed number of category classes for indicators in order to provide a structure. The majority of authors, including [58], proposed a process-oriented view of the indicators which resulted in four groups of performance indicators: quality, time, costs, and flexibility. As [1] indicates, better processes contribute to meeting the strategic objectives of an organization. Therefore, we specifically call out another association with respect to existing groups of indicators that focuses on the impact of all the indicators towards the business goals. Such indicators can be, for example, analyzing the process performance indicators with respect to profit and revenue of the organization.

In practice, most business process owners focus on productivity measures related to time and cost. The challenge with flexibility and quality measures is that they are difficult to standardize, optimize, implement and generalize. It is common to use indicators related to a process’s utilization and assignment of resources, such as repeated tasks or time to execute a task. Resources are usually aligned with the length of the task to avoid bottlenecks in the process. However, shortening the time of task execution or lowering the cost of resources does not necessarily yield better business outcomes. Therefore, it is important to consider methods for measuring process performance that can assess the impact of indicators on business goals and outcomes.

Adopting the right measures is crucial to the success of BPA. They would then be used to evaluate the performance of RPAs and other automation solutions, allowing business users to assess the effectiveness and return on investment of these solutions. Furthermore, these measures can be used by the RPAs themselves to iteratively improve their performance using machine learning models.

2.4 Digital Transformation of Business Processes

While the use of automation has been gaining traction across many industries, its incorporation into business processes poses several challenges. Automation capabilities such as RPAs can provide transformational benefits, however, it is unclear where their use can provide the highest value. Tools and analytic approaches for identifying high value automation opportunities in a process are still nascent. As we discussed previously in Section 1, recent innovations in machine intelligence stand to disrupt this field through the digital transformation of business processes. Throughout the rest of this paper, we will take the reader along this journey, starting from the state of the art in RPAs, through the vision and promise of IPAs, to the major challenges to be overcome to reach this goal. Finally, we will conclude with a quick overview of a recently concluded workshop on this topic.

3 State of the Art: Robotic Process Automation

RPA operates on the user interface of software tools and automates mouse and keyboard interactions to remove repetitive, labor intensive tasks. This minimizes human error due to mental lapses resulting from boredom or exhaustion. RPA’s outside-in approach avoided the overhead of changing the internals of legacy software and as a result, its adoption rate has been increasing, leading to its multi-billion dollar valuation. Among academic contributions to the field, we distinguish between three approaches to building RPAs.

The first approach learns to automate tasks by example or demonstration. RPAs either observe humans perform the tasks or process the behavior logs of the software. One example of this approach is if-then-else rule deduction from behavior logs; the form-to-rule approach consisted of identifying the tasks in the logs as humans perform actions on forms and then deduced the rules from the IO data [18]. Another example is [35] which provided the input-output examples from which the RPA can extract the underlying rule or program based on the inductive program synthesis paradigm. Miltner et al. [47] detected repetitive edits to text documents by keeping track of a graph of edits and suggested automation rules by adopting a greedy algorithm that finds short explanations of users’ edits. All these algorithms rely on humans in the loop. This is one of the more popular approaches to RPAs. However, it does not generalize well to new applications due to the highly specific design of logs and user interfaces.

The second approach learns tasks from step-by-step natural language text descriptions of the process. Leopold et al. [38]

learned process activities from text documents using supervised machine learning, namely feature extraction using WordNet and support vector machine training (a quadratic optimization approach that finds the optimal separator of activities). Han et al.

[24]

adopted a deep learning approach, long short-term memory recurrent neural networks specifically, to learn the relationship between activities in a business process from text documents describing business processes. This approach also relied on humans in the loop, although in an indirect fashion, since the text documents that describe the processes were written by humans. Since it does not require the existence of an embodied business process (i.e. through a UI), it can be more difficult to learn the rules that should be automated.

The third approach learns from the task as defined by an environment with its reward function or some input/output examples. Often referred to as RPA 2.0, this approach seeks to eliminate human-dependent training. It relies on adopting reinforcement learning algorithms on the rewards to RPAs and train them to achieve better performance. This approach is the least mature to date but will lead to generalizable RPAs that approach intelligent automation.

A critical component to the success of RPAs is identifying the opportunities for automation to add RPAs in the right place and maximize their potential. Bosco et al. [8] presented a method to analyze user interaction logs in order to discover routines that are fully deterministic and therefore amenable to automate via RPAs. Klingeberg et al. [20] used process mining to assess the automation opportunities for RPAs with a requirement for processes to be standardized, repeatable and scaleable. Leno et al. [37] proposed a vision for robotic process mining, an approach to achieve end-to-end automation of mining RPA-amenable tasks from logs and generate RPA scripts from these logs to perform the tasks. In practice, these automation opportunities are usually identified manually by subject matter experts comparing potential automation rates. Even though the research in RPA shows promising methods and guidance for assessing automation opportunities, there is still minimal insights on how this could be efficiently automated and implemented in practice at scale.

Figure 2: Traditional RPA is focused on building individual bots that automate a repetitive human task. The scope of IPA is broader addressing the coordination between humans and multiple bots, and encompassing the entire lifecycle of the process including identifying automation opportunities and continuously retraining the bots based on monitored performance.

4 The Vision: Intelligent Process Automation

RPA has enabled integration of systems that otherwise would not have been integrated and eased the workload of business process workers automating repetitive and routine tasks (e.g., copying data from one system to another). Beyond automating simple repetitive tasks, IPA achieves more complex automation by using AI to minimize human-dependent training and automating more complex tasks that entail decision making. The IPA vision builds on traditional RPA technologies, while going a step further to automate complex tasks which require decision making, insights and analysis or the composition, coordination, and collaboration of multiple IPA solutions (outside the scope of RPAs as shown in Fig. 2). While current efforts are a step in the right directions, IPA still falls short of achieving that promise because of the reasons discussed in this section.

4.1 Automation Opportunities

Implementing an RPA requires a costly manual analysis of the tasks performed by the users either by observing their behavior, which does not scale when there are hundreds of processes, or through careful analysis of process-related documentation, which can be outdated. Finding opportunities to automate tasks that are more complex than routine repeatable tasks requires the use of structured and unstructured data from process logs. There have been several research efforts to identify candidate tasks for automation [38, 30] from textual descriptions, but they focus on particular business domains (e.g generating utility bills) and are still not implemented at scale. Identifying automatable tasks only solves part of the problem. The results should also be augmented with a recommendation of possible IPA templates or AI models that are suitable to automate these tasks, as in [36].

4.2 High Cost to Build and Maintain

Unlike RPAs whose overall potential results in a significant increase in turnaround time and cost savings of up to 30% [33], there is a higher cost associated with developing IPAs. To build the next generation of IPAs requires data preparation (identifying relevant data, and cleaning and transforming it) and feature engineering (extracting appropriate features), before building and validating the AI capabilities. Similarly, there is a higher cost associated with maintaining IPAs in comparison with RPAs. In addition to the deployed code, the AI capabilities within have a lifecycle of their own.

The AI models must be retrained in response to changes in the business process (control flow drifts) or changes in the data (data drifts). These higher costs require larger return on investment for IPAs to be suitable. Some ways to mitigate the cost required to build and maintain IPAs include decreasing the effort to develop them, enabling them to be reused for different types of processes, or using them to replace/augment different customer tasks.

4.3 Low Adoption

Adopting IPAs comes with an added risk of monetary or reputation loss. For example, data used for training may be manipulated or contain implicit racial, gender, or ideological biases [67]. In addition, business users are risk-averse and do not implicitly trust AI models. Mitigating the risk of deploying the AI models requires staged deployment techniques such as canary deployments, bandit services, and A/B testing [49]. Increasing business users’ trust will require a variety of solutions including maintaining action provenance for audits and providing explanations for any automated IPA decisions.

4.4 Beyond a Single IPA

IPA research currently focuses on non-routine tasks. Handling more complex tasks will require the composition of multiple IPAs, as well as the collaboration and coordination of these IPAs. To achieve this, new frameworks need to be developed that enable IPA cooperation. Previous research efforts to use multi-agent systems in BPM [52, 12] need to be adjusted and revised for IPAs. Frameworks must now take into account the diversity of automation tasks and domains, and the fact that RPAs can be created by different developers without shared development guidelines. Maintaining compatibility between RPA and business process versions as each co-evolves is also crucial. Finally, a unified interface such as a conversational system may also be required to facilitate the interaction among IPAs and end users [57].

5 Research Opportunities

This section highlights research from the BPM and AI literature to achieve the IPA vision in Section 4, and outlines opportunities for future research.

5.1 Business Process Automation

The BPM literature offers a variety of AI solutions to cluster process traces [50, 51] for better process discovery, predict business outcomes [9, 34], and provide decision support [42]. Deep learning models, including those in the NLP domain have also been applied [62, 16]. Recent efforts attempt to discover automatable routines from user interaction logs [8]. Unfortunately, due to the reasons mentioned above, very little of these innovations have been applied and adopted by enterprises [13], and those adopted are limited to narrow domains such as customer service, enterprise risk, and compliance [66]. Solutions need to take into account the structure of these highly regulated domains that require paper trails of all transactions and must adhere to privacy and security laws.

5.2 Composition and Synthesis

An area of AI that is readily applicable to business processes is automated planning, which concerns itself with generating sequential courses of actions or plans from its declarative components and thus provides a powerful framework for sequential decision making in a BPM system. [44] provides an overview of existing work and challenges at the intersection of planning and BPM. Perhaps the most important (and natural) among them is the specification and synthesis of business processes in the form of planning problems [54]: the planner composes workflows on demand automatically based on the components specified by the process author or workflow designer.

A particular area of interest here is that of the composition of automated services for the optimization of a business process [15, 5, 10]. This work is motivated by research on “web service composition” [53]. We refer to [56] for a comprehensive summary of work in this area, while [61, 60] provides an overview of many of the challenges involved.

5.3 Risk Management

Another key application of planning to business process management is in the prediction of how different process components will evolve over time, thereby anticipating possible risks. Generative model-based approaches such as planning are uniquely situated to do this, finding applications in the robustification and adaptation of processes to failures [28], validation, verification, and monitoring of processes [14], and so on. A particular useful tool towards achieving this is referred to as top-k and diverse planning [31] where a set of solutions are computed instead of a single one thereby allowing one to anticipate likely ways a process may evolve. Such approaches have found many applications111http://ibm.biz/ai-scenario-planning in enterprise risk management and scenario planning recently.

5.4 Chatbots

Reducing the need for direct human involvement with the business process is one of the main goals of automation. There is a very strong trend of automating people-driven processes to chatbot interactions throughout the industry [23]. According to Gartner 222https://www.gartner.com/imagesrv/summits/docs/na/customer-360/C360_2011_brochure_FINAL.pdf

, by 2020 customers will manage 85% of their relationship with the enterprise without interacting with humans. Conversational interfaces apply not only to customer facing businesses but also to employee services such as help-desk and support bots which have been deployed within almost all enterprises. The focus has also expanded to carrying out a business process with a conversational agent

[41], or automating tasks such as placing orders, paying and following up invoices, repetitive data base queries, external service inquiries and automatic analytics and reporting.

Chatbots bring ease of access to all these applications in one interactive mode. The natural language interaction helps democratize access to data, automation, and analytics for a broader range of business users enabling faster adaptation by users and greater personalization  [69]. Chat interactions also serve as a rich source of data to mine for additional automation candidates, closing the loop on bringing intelligence into process automation.

5.5 Explainability

Introducing AI into mission-critical business applications can be a risky endeavor. The software engineering community has developed formal methods to verify the correctness of programs in critical systems [68], but these techniques are not applicable to learned AI models. Approaches to improve the interpretability and explainability of AI models are a more promising avenue [2]. For example, knowing why a model recommended denying a loan to an applicant is important to ensure adherence to anti-discrimination regulations [21]. These approaches, however, need to be expanded along at least two dimensions. First, existing interpretability techniques such as perturbation-based methods or interpretable proxy models [2] need to be augmented with domain knowledge of the business process, including the control flow semantics, decision rules, and business objects, thereby leading to more complete and accurate explanations [27]. Second, the explanations need to be targeted at non-technical subject matter experts. Statistical measures of feature importance or Shapley values are useful to data scientists but do not give actionable insights to a loan officer or process owner. The explanations need to be tailored to the business user, including using the business domain vocabulary and concepts as well as taking into account the context of the user’s needs and preexisting knowledge.

Paper Topics from the Survey Comments
[17] Performance Measures,
Synthesis
This paper attempts to provide a formal framework to facilitate end user programming of IPAs so that they can be synthesized and evaluated in a principled manner.
[4] RPA –> IPA
transformation
The authors here echo the message of this survey in terms of the transformation of RPAs into IPAs, and provide a classification of existing RPA tools towards this end.
[24] Process Mining

This paper focuses on automated discovery of process components from textual descriptions. The authors use ordered neurons LSTMs with special process-level language models to capture process information.

[45] Process Automation Authors here focus on automation of the procure to pay process (P2P) by means of similarity measures learned from recordings of a case worker’s manual workflow.
[29] Modalities The authors here explore a stochastic model of spatial demand in a commercial store in order to optimize produce placement. Approaches based on deep q-learning techniques provided promising results.
[59] Modalities This paper utilizes an R-NET with modified attention to translate instructions in English to navigational plans, providing useful insights on the representation of graphs with known landmarks and natural language annotations.
[6] Process Mining,
Modalities

This paper explores how an agent can be taught the rules of a game (process) interactively using a combination of demonstration, active learning, and game theory.

[11] Process Mining,
Synthesis
Authors here attempt to learn data analysis widgets from SQL query logs and optimize the resultant interface using Monte Carlo tree search methods.
[57] Chatbots, BPA,
Modalities
As discussed in the survey, this paper explores a multi-agent framework that allows the integration of conversation components in a single interface for the end user.
[26] Modalities, RPA –> IPA
transformation
This paper explores a natural language interface to IPAs to bring down the expertise level required to manage IPAs using semantic parsing techniques.
[10] Chatbots, Explainability
Composition / Synthesis
This work also focuses on the end user programming in how complex business processes with conversational components can be specified declaratively for automated synthesis and easy debugging.
[40] Modalities,
Process Mining
Authors here again highlight the use of natural language as a means of training IPAs but specifically highlight the effectiveness of a multi-model approach using natural language and GUIs.
[36] Process Mining This paper revisits the process mining theme and attempts to learn routines where a user transforms data from one form (spreadsheet or web) to another, by using logs of interactions on a GUI.
[48] Chatbots,
BPA

Authors here re-emphasize the usefulness of a conversation interface for business process automation, this time using the assistant to augment unstructured resources with additional training data in order to aid in transfer learning.

Table 1: A summary of the International Workshop on Intelligent Process Automation (IPA) at AAAI 2020 (NYC, Feb 2020).

5.6 Modalities

We posit that business process data should be considered a new modality in machine learning, similar to image, text, audio, or video. At the very least, it should be treated as a multi-modal domain [7]. A non-exhaustive list of the different types of data embodied in a business process includes the control flow (graph structure), the execution of a process trace (sequence of events), the metadata associated with an event (multi-dimension set of attributes), references to unstructured documents (images or text), interactions between participants (both graph and time series representations), and the social networks (also graphs).

Many existing techniques exploit one or more of these data structures to extract insights or build predictive models [50, 51, 42, 62, 16]. We believe that a more principled approach to unify these different sub-modalities of business processes will accelerate research in this area. Reifying business process data as a distinct modality opens up a number of research questions for the machine learning community including developing novel techniques for representation learning, explainability, and transfer learning for this new modality.

6 Closing Remarks: State of the Art in IPA

So far, we have discussed the promise of IPAs and AI challenges towards realizing that promise. We will now conclude with a brief summary of the recently concluded (inaugural) international workshop on Intelligent Process Automation (IPA-20) [25] at AAAI 2020. To the best of our knowledge, this is the first workshop of its kind at one of the major AI conferences, and it perfectly reflects the current excitement around business process automation and artificial intelligence. Thus, it is worthwhile to explore the proceedings of the workshop for the latest areas of interest in this field.

Table 1 summarizes the papers presented at IPA-20. It is particularly interesting to observe recurring themes in the papers from topics discussed so far in this survey. Popular topics revolve around process mining and automation (particularly from natural language), automated synthesis and composition of processes for end user programming, conversational interfaces to business processes, and the need to deal with multi-modal inputs. Multiple keynote speakers also touched on the importance of synthesis from examples and natural language understanding in business process automation.

While these topics covered in the proceedings of IPA-20 largely validate the research agenda laid out in the survey so far, it also reveals how much exciting work still needs to be done for the digital transformation of RPAs to IPAs. Most importantly, this transformation cannot be successful without the effective synergy across the BPM community [3] and the AI crowd at conferences like AAAI [25], which has largely remained separate in spite of the growing overlap in their interests. We hope that this survey can act as a springboard for the exchange of ideas across the two communities and motivates exciting research opportunities going forward, combining the power of AI and the real-world complexities, challenges, and scale of business process automation problems.

References

  • [1] W. Aalst, M. La Rosa, and F. Santoro (2015-10) Business process management - don’t forget to improve the process!. Business & Information Systems Engineering 58, pp. . External Links: Document Cited by: §2.3.
  • [2] A. Adadi and M. Berrada (2018) Peeking inside the black-box: a survey on explainable artificial intelligence (xai). IEEE Access. Cited by: §5.5.
  • [3] S. Agostinelli, A. Marrella, and M. Mecella (2019) Research challenges for intelligent robotic process automation. In International Conference on Business Process Management, pp. 12–18. Cited by: §6.
  • [4] S. Agostinelli, A. Marrella, and M. Mecella (2020) Towards intelligent robotic process automation for bpmers. In AAAI IPA, Cited by: Table 1.
  • [5] S. S. Araghi (2012) Customizing the composition of web services and beyond. Ph.D. Thesis, U Toronto. Cited by: §5.2.
  • [6] A. Ayub and A. Wagner (2020) A robot that learns connect four using game theory and demonstrations. In AAAI IPA, Cited by: Table 1.
  • [7] T. Baltrusaitis, C. Ahuja, and L. Morency (2019-02) Multimodal machine learning: a survey and taxonomy. IEEE Trans. Pattern Analysis & Machine Intelligence. External Links: ISSN 0162-8828, 2160-9292, 1939-3539, Document Cited by: §5.6.
  • [8] A. Bosco, A. Augusto, M. Dumas, M. La Rosa, and G. Fortino (2019) Discovering automatable routines from user interaction logs. In BPM, Cited by: §3, §5.1.
  • [9] D. Breuker, M. Matzner, P. Delfmann, and J. Becker (2016) Comprehensible predictive models for business processes.. MIS Quarterly. Cited by: §5.1.
  • [10] T. Chakraborti and Y. Khazaeni (2020) D3BA: a tool for optimizing business processes using non-deterministic planning. In AAAI IPA, Cited by: §5.2, Table 1.
  • [11] Y. Chen and E. Wu (2020) Monte carlo tree search for generating interactive data analysis interfaces. In AAAI IPA, Cited by: Table 1.
  • [12] J. A. G. Coria, J. A. Castellanos-Garzón, and J. M. Corchado (2014) Intelligent business processes composition based on multi-agent systems. Expert Systems with Applications 41 (4), pp. 1189–1205. Cited by: §4.4.
  • [13] P. R. Daugherty and H. J. Wilson (2018) Human+ machine: reimagining work in the age of ai. Harvard Business Press. Cited by: §5.1.
  • [14] M. de Leoni, G. Lanciano, and A. Marrella (2018) Aligning Partially-Ordered Process-Execution Traces and Models Using Automated Planning. In ICAPS, Cited by: §5.3.
  • [15] X. Dong, A. Halevy, J. Madhavan, E. Nemes, and J. Zhang (2004) Similarity Search for Web Services. In VLDB, Cited by: §5.2.
  • [16] J. Evermann, J. Rehse, and P. Fettke (2017) Predicting process behaviour using deep learning. Decision Support Systems. Cited by: §5.1, §5.6.
  • [17] D. Ferreira, J. Rozanova, K. Dubba, D. Zhang, and A. Freitas (2020) On the evaluation of intelligence process automation. In AAAI IPA, Cited by: Table 1.
  • [18] J. Gao, S. J. van Zelst, X. Lu, and W. M. van der Aalst (2019) Automated robotic process automation: a self-learning approach. In OTM Confederated International Conferences, Cited by: §3.
  • [19] Gartner (2017) A Future that Works: Automation, Employment, Productivity. McKinsey. Cited by: §1.
  • [20] J. Geyer-Klingeberg, J. Nakladal, F. Baldauf, and F. Veit (2018) Process mining and robotic process automation: a perfect match. In BPM, Cited by: §3.
  • [21] B. Goodman and S. Flaxman (2016) EU regulations on algorithmic decision-making and a “right to explanation”. In ICML workshop on human interpretability in machine learning, Cited by: §5.5.
  • [22] A. Grosskopf, G. Decker, and M. Weske (2009) The process: business process modeling using bpmn. Meghan Kiffer Press. Cited by: §2.
  • [23] S. Han (2019) Business process automation through chatbots implementation: a case study of an it service process at philips. Thesis, TU Delft. Cited by: §5.4.
  • [24] X. Han, L. Hu, Y. Dang, S. Agarwal, L. Mei, S. Li, and X. Zhou (2020) Automatic business process structure discovery using ordered neurons lstm: a preliminary study. In AAAI IPA, Cited by: §3, Table 1.
  • [25] IPA (2020) Proceedings of the AAAI-20 Workshop on Intelligent Process Automation. AAAI. Cited by: §1, §6, §6.
  • [26] N. Ito, Y. Suzuki, and A. Aizawa (2020) From natural language instructions to complex processes: issues in chaining trigger action rules. In AAAI IPA, Cited by: Table 1.
  • [27] S. T.K. Jan, V. Ishakian, and V. Muthusamy (2020) AI trust in business processes: the need for process-aware explanations. In IAAI Conference, Cited by: §5.5.
  • [28] P. Jarvis, J. Moore, J. Stader, A. Macintosh, A. Casson-du Mont, and P. Chung (1999) Exploiting AI Technologies to Realise Adaptive Workflow Systems. In AAAI Workshop on Agent-Based Systems in the Business Context, Cited by: §5.3.
  • [29] P. Jenkins, H. Wei, J. S. Jenkins, and Z. Li (2020) A probabilistic simulator of spatial demand for product allocation. In AAAI IPA, Cited by: Table 1.
  • [30] A. Jimenez-Ramirez, H. A. Reijers, I. Barba, and C. Del Valle (2019) A method to improve the early stages of the robotic process automation lifecycle. In CAiSE, Cited by: §4.1.
  • [31] M. Katz, S. Sohrabi, and O. Udrea (2020) Top-quality planning: finding practically useful sets of best plans. In AAAI, Cited by: §5.3.
  • [32] I. Kavas (2018) RPA vs IPA: Intelligent Process Automation is the Next Frontier. Ephesoft. Cited by: §1.
  • [33] M. C. Lacity and L. P. Willcocks (2017) A new approach to automating services. MIT Sloan Management Review. Cited by: §4.2.
  • [34] G. Lakshmanan, D. Shamsi, Y. Doganata, M. Unuvar, and R. Khalaf (2015) A markov prediction model for data-driven semi-structured business processes. Springer London Publishing. Cited by: §5.1.
  • [35] V. Le and S. Gulwani (2014) FlashExtract: a framework for data extraction by examples. In Proceedings of the 35th ACM SIGPLAN PLDI, Cited by: §3.
  • [36] V. Leno, M. Dumas, M. La Rosa, F. M. Maggi, and A. Polyvyanyy (2020) Automated discovery of data transformations for robotic process automation. In AAAI IPA, Cited by: §4.1, Table 1.
  • [37] V. Leno, A. Polyvyanyy, M. Dumas, M. La Rosa, and F. M. Maggi (2020) Robotic process mining: vision and challenges. Business & Information Systems Engineering, pp. 1–14. Cited by: §3.
  • [38] H. Leopold, H. van der Aa, and H. A. Reijers (2018) Identifying candidate tasks for robotic process automation in textual process descriptions. In Enterprise, Business-Process and Information Systems Modeling, Cited by: §3, §4.1.
  • [39] F. Leymann and D. Roller (1999) Production workflow: concepts and techniques. Prentice Hall PTR, USA. External Links: ISBN 0130217530 Cited by: §2.1.
  • [40] T. J. Li, M. Radensky, J. Jia, K. Singarajah, T. Mitchell, and B. Myers (2020) Interactive task and concept learning from natural language instructions and gui demonstrations. In AAAI IPA, Cited by: Table 1.
  • [41] A. López, J. Sànchez-Ferreres, J. Carmona, and L. Padró (2019) From process models to chatbots. In CAiSE, Cited by: §5.4.
  • [42] F. Mannhardt, M. De Leoni, H. A. Reijers, and W. M. Van Der Aalst (2016) Decision mining revisited-discovering overlapping rules. In CAiSE, Cited by: §5.1, §5.6.
  • [43] Marketwatch (2019) Business Process Management (BPM) Market 2019: Key Findings, Regional Study, Size, Growth and Global Trends by Forecast to 2023. Cited by: §1.
  • [44] A. Marrella (2017) Automated Planning for Business Process Management. Journal on Data Semantics. Cited by: §5.2.
  • [45] C. K. Maurya, N. Gantayat, S. Dechu, and T. Horvath (2020) Online similarity learning with feedback for invoice line item matching. In AAAI IPA, Cited by: Table 1.
  • [46] J. M. Michael Leyer (2015) Process performance measurement, proceedings of the handbook on business process management 2. Vol. 2nd edition, Springer. Cited by: §2.3.
  • [47] A. Miltner, S. Gulwani, V. Le, A. Leung, A. Radhakrishna, G. Soares, A. Tiwari, and A. Udupa (2019) On the fly synthesis of edit suggestions. OOPSLA. Cited by: §3.
  • [48] A. Moiseeva, D. Trautmann, and H. Schütze (2020) Multipurpose intelligent process automation via conversational assistant. In AAAI IPA, Cited by: Table 1.
  • [49] V. Muthusamy, A. Slominski, and V. Isahakian (2018) Towards enterprise-ready AI deployments: minimizing the risk of consuming AI models in business applications. In AI4I, Cited by: §4.3.
  • [50] P. Nguyen and et. al (2016) Process trace clustering: a heterogeneous information network approach. In SIAM SDM, Cited by: §5.1, §5.6.
  • [51] P. Nguyen and et. al (2019) SUMMARIZED: efficient framework for analyzing multidimensional process traces under edit-distance constraint. arXiv preprint. Cited by: §5.1, §5.6.
  • [52] T. J. Norman, N. R. Jennings, P. Faratin, and E.H. Mamdani (1996) Designing and implementing a multi-agent architecture for business process management. In International Workshop on Agent Theories, Architectures, and Languages, Cited by: §4.4.
  • [53] M. P. Papazoglou and D. Georgakopoulos (2003) Service-Oriented Computing. Communications of the ACM. Cited by: §5.2.
  • [54] M. D. R-moreno, D. Borrajo, A. Cesta, and A. Oddi (2007) Integrating Planning and Scheduling in Workflow Domains. Expert Systems with Applications. Cited by: §5.2.
  • [55] S. Raghavan (2019) 2020 AI Predictions from IBM Research. IBM Research. Cited by: §1.
  • [56] J. Rao and X. Su (2004) A Survey of Automated Web Service Composition Methods. In Workshop on Semantic Web Services and Web Process Composition, Cited by: §5.2.
  • [57] Y. Rizk, A. Bhandwalder, S. Boag, T. Chakraborti, V. Isahagian, Y. Khazaeni, F. Pollock, and M. Unuvar (2020) A unified conversational assistant framework for business process automation. In AAAI IPA, Cited by: §4.4, Table 1.
  • [58] S. C. Sarin, A. Varadarajan, and L. Wang (2011) A survey of dispatching rules for operational control in wafer fabrication. Production Planning & Control 22 (1), pp. 4–24. External Links: Document, Link, https://doi.org/10.1080/09537287.2010.490014 Cited by: §2.3.
  • [59] A. Shrestha, K. Pugdeethosapol, H. Fang, and Q. Qiu (2020) High-level plan for behavioral robot navigation with natural language directions and r-net. In AAAI IPA, Cited by: Table 1.
  • [60] S. Sohrabi (2010) Customizing the Composition of Actions, Programs, and Web Services with User Preferences. In ISWC, Cited by: §5.2.
  • [61] B. Srivastava and J. Koehler (2003) Web Service Composition – Current Solutions and Open Problems. In ICAPS Workshop on Planning for Web Services, Cited by: §5.2.
  • [62] N. Tax, I. Verenich, M. La Rosa, and M. Dumas (2017) Predictive business process monitoring with lstm neural networks. In CAiSE, Cited by: §5.1, §5.6.
  • [63] D. Tuttle (2019) The Transformation of RPA to IPA: Intelligent Process Automation. CMS Wire. Cited by: §1.
  • [64] M. Weske (2012) Business process management architectures. In Business Process Management, pp. 333–371. Cited by: §2.1.
  • [65] M. Weske (2012) Business process management. Springer. Cited by: §2.
  • [66] H. Wilson, A. Alter, and P. Shukla (2016) Companies are reimagining business processes with algorithms. Harvard Business Review. Cited by: §5.1.
  • [67] M. J. Wolf, K. Miller, and F. S. Grodzinsky (2017) Why we should have seen that coming: comments on microsoft’s tay" experiment," and wider implications. ACM SIGCAS Computers and Society. Cited by: §4.3.
  • [68] J. Woodcock, P. G. Larsen, J. Bicarregui, and J. Fitzgerald (2009) Formal methods: practice and experience. ACM Comput. Surv.. External Links: ISSN 0360-0300, Link, Document Cited by: §5.5.
  • [69] D. Zumstein and S. Hundertmark (2017) CHATBOTS–an interactive technology for personalized communication, transactions and services.. IADIS Int. J. WWW/Internet 15 (1). Cited by: §5.4.
