Twin-GAN -- Unpaired Cross-Domain Image Translation with Weight-Sharing GANs

08/26/2018
by   Jerry Li, et al.
Google
0

We present a framework for translating unlabeled images from one domain into analog images in another domain. We employ a progressively growing skip-connected encoder-generator structure and train it with a GAN loss for realistic output, a cycle consistency loss for maintaining same-domain translation identity, and a semantic consistency loss that encourages the network to keep the input semantic features in the output. We apply our framework on the task of translating face images, and show that it is capable of learning semantic mappings for face images with no supervised one-to-one image mapping.

READ FULL TEXT VIEW PDF
POST COMMENT

Comments

There are no comments yet.

Authors

11/07/2016

Unsupervised Cross-Domain Image Generation

We study the problem of transferring a sample in one domain to an analog...
07/12/2018

Sem-GAN: Semantically-Consistent Image-to-Image Translation

Unpaired image-to-image translation is the problem of mapping an image i...
04/23/2020

An Asymetric Cycle-Consistency Loss for Dealing with Many-to-One Mappings in Image Translation: A Study on Thigh MR Scans

Generative adversarial networks using a cycle-consistency loss facilitat...
04/08/2017

DualGAN: Unsupervised Dual Learning for Image-to-Image Translation

Conditional Generative Adversarial Networks (GANs) for cross-domain imag...
03/27/2021

H-GAN: the power of GANs in your Hands

We present HandGAN (H-GAN), a cycle-consistent adversarial learning appr...
10/15/2018

Refacing: reconstructing anonymized facial features using GANs

Anonymization of medical images is necessary for protecting the identity...
This week in AI

Get the week's most popular data science and artificial intelligence research sent straight to your inbox every Saturday.

1 Introduction

The ability of a human to transfer scenes of what they see to a painting has long existed since the cradle of civilization. The earliest cave paintings that we know of is not a photo-realistic representation, but rather an abstract depiction of hunting scenes. Yet when it comes to developing an algorithm that mimics such ability, we are still limited in what we can achieve.

Recent development in neural networks has greatly improved the generalization ability of image domain transfer algorithms, in which two parallel lines of development prevails: using Neural Style Transfer

gatys2015neural and using Generative Adversarial Networks(GAN)goodfellow2014generative .

Neural Style Transfer defines a content loss that captures the semantic information loss in transferred image, and a style loss often defined as the statistical correlation (e.g. a Gramian matrix) among the extracted features. It utilizes a trained object detection network such as VGG19simonyan2014very

for feature extraction. As a result, style transfer gives less satisfactory results when the target domain contains object representations not seen by the pretrained object detection network

zhang2017style . Furthermore, due to the content loss being defined as the L2 difference in convolutional layers of object detection network, Style Transfer based methods fails to fundamentally change the object layout when applied to domain transfer and often relies on the objects in the content and style images having similar spacial proportions in the first place. When semantic objects fails to align, e.g. body proportions in paintings are different from those in real life, style transfer leads to less desirable results.

On the other hand, GAN has shown more promising results when provided paired data belonging to the two domains of interest. Previous works such as isola2017image and zhang2017style all show promising results when paired datasets are available or can be generated. However such datasets are often expensive to obtain.

Current works on unpaired cross-domain image translation tasks, including but not limited to taigman2016unsupervised ; yoo2016pixel ; zhu2017unpaired ; choi2017stargan ; royer2017xgan , usually rely on the "shared latent space" assumption. That is, given two related domains S and T, for item , there exists a unique item where s and t shares the same latent encoding z. However, this assumption may not always hold for all datasets and forcing such assumption on the system may result in model collapse or unrealistic-looking outputs, especially for domains that are vastly different in appearance.

To address the issues mentioned above, we introduce the Twin-GAN network and demonstrates its usage on the task of translating unpaired unlabeled face images.

2 Related Work

2.1 Domain Transfer through Style Transfer

Conditional Style Transfer

By using conditional instance normalization, which learns a separate set of parameters and in the instance normalization layers for each style , dumoulin2017learned expanded on the Neural Style Transfer methods with a single network capable of mix-and-matching 32 styles. Future works such as huang2017arbitrary further improved on the idea by adaptively computing and based on the input style image and proposed real-time arbitrary style transfer using a feed-forward network.

Image Analogy through Patch Matching

liao2017visual

propose a structure-preserving image analogy framework based on patch matching method. Given two structurally similar images, it extracts the semantic features using an object detection network. For each feature vector at one position, it finds a matching feature from the style image lying within the same fixed sized patch. The image is then reconstructed using the matched features from the style image. The effect is impressive, yet its application is greatly limited by its requirement on the input images – the images must be spatially and structurally similar since features can only come from a vicinity determined by the perspective field of the network and the patch size. Nonetheless, it is powerful for some use cases and can achieve state-of-the-art results, e.g. in harmonic photoshopping of paintings

luan2018deep .

2.2 Domain Transfer through Generative Adversarial Networks

The Generative Adversarial Networkgoodfellow2014generative frameworks synthesizes data points of a given distribution using two competing neural networks playing a minimax game. The Generator takes a noise vector sampled from a random distribution and synthesizes data points and the Discriminator tells apart real data points from the generated ones.

Supervised Image Translation

isola2017image

propose a conditional GAN framework called "pix2pix" for image translation task using a paired dataset. In order to make preserving details in the output image much easier, it uses U-Net, which adds skip connection between layer

in the encoder and layer in the decoder where is the total number of layers. isola2017image

is applied on numerous tasks such as sketch to photo, image colorization, and aerial photo to map. Similarly,

zhang2017style use a conditional GAN with Residual UNetronneberger2015u framework supplemented with embeddings from VGG19simonyan2014very for sketch colorization task. Both show that conditional GAN and UNet are effective when paired data are readily available or can be generated.

Unsupervised Domain Transfer

For an unsupervised domain transfer task where paired datasets are unavailable but labeled data is available for the source domain, DTNtaigman2016unsupervised transfers images in the source domain to the target domain while retaining their labeled features. It contains a pretrained feature extractor and a generator on top of . The DTN is trained using a GAN loss for realistic output, a feature consistency loss for preserving key features after translation, and an identity loss for making sure the network acts as an identity mapping function when supplied with inputs sampled from the target domain. DTN’s need for a pretrained feature extractor implies that the result will be limited by the quality and quantity of the labeled features.

Unsupervised Image Translation

In liu2017unsupervised the GAN-VAE based UNIT framework was introduced to handle the domain transfer task on an unpaired unlabeled dataset. It made the cycle-consistency hypothesis where for a pair of corresponding images from two domains, there exists a shared latent embedding where one-to-one mapping exists for and

., the GAN-VAE based UNIT framework uses this hypothesis to learn a pair of encoders mapping images from two different domains into the same latent space and a pair of generators conditioned on the latent encoding to translate the embedded image back into the two domain space. Specifically, the latent space is constrained to a Gaussian distribution by the VAE framework and weights are shared in the higher-level(deeper) layers of the encoders and decoders. It showed promising results in domain transfer tasks such as day/night scenes, canine breeds, feline breeds, and face attribute translation.

Similarly, zhu2017unpaired proposed the CycleGAN framework for unpaired image translation that relies on a GAN loss and a cycle consistency loss term defined as . This is similar to the shared latent embedding assumption without specifying the latent embedding distribution. The CycleGAN framework showed some success when applied to a range of classic image translation tasks. Some of its failure cases include over-recognizing objects and not being able to change the shape of the object during translation (e.g. outputting an apple-shaped orange).

Finally, choi2017stargan introduced a multi-domain transfer framework and applied it on face synthesis using labeled facial features. royer2017xgan trained an adversarial auto-encoder using cycle-consistency, reconstruction loss, GAN loss, and a novel teacher loss where knowledge is distilled from a pretrained teacher to the network. It showed some success on two all-frontal face dataset: the VGG-Face and the Cartoon Set.

3 Method

3.1 Objective

Given unpaired samples from two domains and depicting the same underlying semantic object, we would like to learn two functions, that transforms source domain items to the target domain , and that does the opposite. Following past literaturestaigman2016unsupervised ; zhu2017unpaired ; choi2017stargan ; royer2017xgan , our TwinGAN architecture uses two encoders, and , two generators and , and two Discriminators and for domain and respectively, such that and .

3.2 Architecture

Progressive GAN

We follow the current state of the art in image generation and adapts the PGGAN structurekarras2017progressive . In order to improve the stability of GAN training, to speed up training process, and to output images with higher resolution, PGGAN progressively grows the generator and discriminator together and alternates between growing stages and reinforcement stages. During the growing stage, the input from a lower resolution is linearly combined with a higher resolution. The linear factor grows from 0 to 1 as training progresses, allowing the network to gradually adjust to the higher resolution as well as any new variables added. During the reinforcement stage, any unused layer for lower dimension are discarded as the grown network does more training. Our discriminator is trained progressively as well.

Encoder and UNet

In an encoder-decoder structure using convolutional neural networks, the input is progressively down-sampled in the encoder and up-sampled in the decoder. For image translation task, some details and spatial information may be lost in the down-sampling process. UNet

ronneberger2015u is commonly used in image translation tasksisola2017image ; zhang2017style where details of the input image can be preserved in the output through the skip connection. We adapt such structure and our encoder mirrors the PGGAN generator structure – growing as the generator grows to a higher resolution. The skip connection connects the encoding layers right before down-sampling with generator layers right after up-sampling. For details on the network structure please see 4.

Domain-adaptive Batch Renormalization

Previous work such as dumoulin2017learned , de2017modulating , and miyato2018spectral have shown that by using a different set of normalization parameters , one can train a generative network to output visually different images of the same object. Inspired by their discovery, we capture the style difference in the two domains and by using two sets of batch renormalizationioffe2017batch parameters – one for each domain. The motivation behind such design is as follows: Since both encoders are trying to encode the same semantic object represented in a different style, by sharing weights in all but the normalization layers, we encourage them to use the same latent encoding to represent the two visually different domains. Thus, different from prior worksliu2017unsupervised ; zhu2017unpaired ; choi2017stargan ; royer2017xgan which share parameters only in the higher layers, we choose to share the weights for all

layers except the batch renormalization layers and we use the same weight-sharing strategy for our two generators as well. This is the key to our TwinGAN model that enable us to capture shared semantic information and to train the network with fewer parameters. Due to the small batch size used at higher resolutions, we found empirically that batch renormalization performs better than batch normalization during inference.

3.3 Optimization

We use three sets of losses to train our framework. The adversarial loss ensures that the output images is indistinguishable from sampled images from the given domains. The reconstruction loss enforces that the encoder-generator actually captures information in the input image and is able to reproduce the input. The cycle consistency ensures that the input and output image contains the same features.

Adversarial Loss

Given Input domain and output domain , the objective for image translation using vanilla GAN is formulated as

To boost the stability of GAN, we add the DRAGANkodali2017convergence objective function to our adversarial loss:

The adversarial objective is thus:

Cycle Consistency Loss

We follow previous workszhu2017unpaired royer2017xgan and use a cycle consistency loss to encourage that the network acts as an identity operation for mapping images back to their own domains.

Optionally a discriminator can also be applied on the output and . Empirically we found that it leads to slightly better performance and less blurry output, but is by no means required.

Semantic Consistency Loss

We would like the translated image to have the same semantic features as the input image. That is, the encoder should extract the same high level features for both input and output image regardless of their domains. Since cycle consistency already covers the semantic consistency for input and output from the same domain, here we focus on cross-domain semantic consistency. Similar to previous works royer2017xgan , we formulate the semantic consistency loss as follows:

We note that it is generally not true that there exists a strictly one-to-one mapping between two domains. For example cat faces lack facial muscle to have as many expressions as we humans do, and forcing a one-to-one mapping between the two domains at the pixel level (e.g. using a loss such as in taigman2016unsupervised ) leads to mismatches. Therefore we choose to apply the loss only on the embeddings, which encode semantic information that is shared across domains. Thus, features unique to only one of the two domains are encouraged to be captured in the adaptive normalization parameters.

Overall Loss

Our overall loss function is defined as:

Here the

s are hyperparameters that control the weight on each of the objectives.

Source Image
CycleGAN
UNIT
MUNIT1
MUNIT2
TwinGAN(ours)
Table 1: Examples of unsupervised image translation from human to anime characters using various network structures. CycleGAN, UNIT, MUNIT are all trained to 64x64 resolution using the default settings from the official implementations. CycleGAN was trained for 465k iterations, UNIT for 940k iterations, and MUNIT for 650k iterations. MUNIT1 and MUNIT2 uses the same network but different style embeddings. Notice that CycleGAN suffers from unable to move the eye position after translation, which looks unnatural on the target domain. UNIT failed to converge, while MUNIT suffers from inconsistent semantic correspondence between original and translated images.

4 Experiments

We first compare our framework with other recent image translation architectures on the real-to-anime face translation task. We then study the benefits of cycle consistency loss and the semantic consistency loss. We show some use cases of a trained encoder and study its training process. Lastly, we show the generalization power of our framework on the human-to-cat face task.

4.1 Real-to-Anime Face Translation

We train out network on two datasets: CelebA liu2015deep dataset with 202599 celebrity face images and the "Getchu" datasetjin2017towards containing 26752 anime character face images with clean background. During training, we randomly crop the images to of their original size. In addition, we follow szegedy2017inception and randomly flip the images and adjust the contrast, hue, brightness, and saturation levels.

Regarding the hyperparameters in our framework, we set (the hyperparameters are not fine-tuned due to limit on computing resources). Following karras2017progressive , we use Adamkingma2014adam with , and . We did not spend much effort on finding the optimal set of hyperparameters.

We start with a resolution of and gradually grows to . We use a batch size of 8 for resolutions up to 64, and reduce that to 4 for 128 and 2 for 256 resolution. We show the discriminator 600k images for each stage of training. Different from karras2017progressive , we find that DRAGAN has a shorter training time compared to variations of WGANarjovsky2017wasserstein ; gulrajani2017improved and provides more stable training for image translation task. We used pixel-wise feature vector normalization but not equalized learning ratekarras2017progressive .

We compare our result with the same dataset trained with CycleGANzhu2017unpaired , UNITliu2017unsupervised , and the most recent MUNIThuang2018multimodal . In 1, We found that our model outperforms all three in our experiments.

4.2 Extra loss terms

Model 16 32 64 128 Average
No 65.58 24.03 28.37 35.19 38.29
No 40.15 11.60 9.75 12.01 18.38
No UNet 82.89 24.78 17.54 16.54 35.44
With Style Embedding 26.85 10.87 9.89 13.06 15.16
No Style Embedding 29.23 9.21 10.51 10.41 14.84
Table 2: Sliced Wasserstein Score

We study the merits of the cycle loss, the semantic consistency loss, the style embedding, and the UNet. Because all requires extra computation during training, the extra training time spent must be justified by the better result they bring. We measure those benefits both quantitatively using Sliced Wasserstein Score proposed in karras2017progressive .

In our experiments, we observed that having UNet encourages the network to find more local correspondences. Without UNet, the network failed to preserve correspondence between semantic parts and there were common error patterns such as the face direction becoming mirrored after translation – which is technically allowed by all our loss terms but is judged as being unnatural by human. Note that similar error patterns are observed in our experiment with MUNIT 1, which does not use UNet.

Adding cycle loss and semantic consistency loss both resulted in higher Sliced Wasserstein Score and better output. Adding Style embedding increased the Sliced Wasserstein Score by a little, but it gave the user the ability to control some features such as hair color and eye color. However we argue that those features should perhaps belong to the content and the style embeddings failed to catch the more subtle yet important style information, such as eye-to-face ratio, texture of the hair, etc., that varies from painter to painter. We thus made the style embedding optional and did not use that for the final results.

4.3 Human to cat face translation

Source Image
TwinGAN
Table 3: Human to Cat Translation

In order to show the general applicability of our model, here we show our results on the task of translating human faces to cat faces. For human face we collected 200k images from the CelebA dataset. We extracted around 10k cat faces from the CAT datasetzhang2008cat by cropping the cat faces using the eye and ear positionsalexia2018deep . The network, the CelebA dataset, and training setup is the same as in 4.1.

4.4 Learned Cross-domain Image Embeddings

We want verify that meaningful semantic information shared across domains can indeed be extracted using our TwinGAN. For each domain, we use the corresponding encoder to extract the latent embeddings. For each image in domain , we find the nearest neighbors in domain by calculating the cosine distances between the flattened embeddings. As shown in 1, we found that meaningful correlations, including hair style, facing direction, sex, and clothing, can be established between the latent embeddings from the two domains.

Figure 1: Human Portraits and their nearest neighbors in the Anime portraits domain, which are ranked from left to right the most to the least similar.

5 Conclusion and Future Work

We proposed the Twin-GAN framework that performs cross-domain image translation on unlabeled unpaired data. We demonstrated its use case on human-to-anime and human-to-cat face translation tasks. We showed that TwinGAN is capable of extracting common semantic information across the two domains while encoding the unique information in the adaptive normalization parameters.

Despite the success, there are still a lot of room for improvements. The process of selecting features to translate is not controllable in our current framework. Furthermore, when applied to even more diverse datasets involving changing point-of-view and reasoning about the 3d environment, our framework does poorly. We experimented with applying TwinGAN on image translation from the game of Minecraft to real street views – our network collapsed at even low resolution. We hope to address these issues in future works.

Acknowledgments

This work is not an official Google supported project and is developed solely by the author. We’d like to thank Alan Tian, Yanghua Jin, and Minjun Li for their inspirations. We’d like to thank all the creators of art works and fan-arts, without whom this research will not be possible.

References

6 Supplimentary materials

6.1 Network Structure

Encoder Act. Output shape Input image - 3 x 256 x 256 Conv 1x1 LReLU 16 x 256 x 256 Conv 3x3 LReLU 16 x 256 x 256 Conv 3x3 LReLU 16 x 256 x 256 Downsample - 32 x 128 x 128 Conv 3x3 LReLU 32 x 128 x 128 Conv 3x3 LReLU 64 x 128 x 128 Downsample - 64 x 64 x 64 Conv 3x3 LReLU 64 x 64 x 64 Conv 3x3 LReLU 128 x 64 x 64 Downsample - 128 x 32 x 32 Conv 3x3 LReLU 128 x 32 x 32 Conv 3x3 LReLU 256 x 32 x 32 Downsample - 256 x 16 x 16 Conv 3x3 LReLU 256 x 16 x 16 Conv 3x3 LReLU 256 x 16 x 16 Downsample - 256 x 8 x 8 Conv 3x3 LReLU 256 x 8 x 8 Conv 3x3 LReLU 256 x 8 x 8 Downsample - 256 x 4 x 4 Discriminator Act. Output shape Input image - 3 x 256 x 256 Encoder structure - 256 x 4 x 4 Minibatch stddev - 257 x 4 x 4 Conv 3x3 LReLU 256 x 4 x 4 Conv 4x4 LReLU 256 x 1 x 1 Fully-connected linear 1 x 1 x 1 Generator Act. Output shape Latent Embedding - 256 x 4 x 4 Conv 3x3 LReLU 256 x 4 x 4 Upsample - 256 x 8 x 8 Concat. UNet - 512 x 8 x 8 Conv 3x3 LReLU 256 x 8 x 8 Conv 3x3 LReLU 256 x 8 x 8 Upsample - 256 x 16 x 16 Concat. UNet - 512 x 16 x 16 Conv 3x3 LReLU 256 x 16 x 16 Conv 3x3 LReLU 256 x 16 x 16 Upsample - 256 x 32 x 32 Concat. UNet - 512 x 32 x 32 Conv 3x3 LReLU 128 x 32 x 32 Conv 3x3 LReLU 128 x 32 x 32 Upsample - 128 x 64 x 64 Concat. UNet - 256 x 64 x 64 Conv 3x3 LReLU 64 x 64 x 64 Conv 3x3 LReLU 64 x 64 x 64 Upsample - 64 x 128 x 128 Concat. UNet - 128 x 128 x 128 Conv 3x3 LReLU 32 x 128 x 128 Conv 3x3 LReLU 32 x 128 x 128 Upsample - 32 x 256 x 256 Concat. UNet - 64 x 256 x 256 Conv 3x3 LReLU 16 x 256 x 256 Conv 3x3 LReLU 16 x 256 x 256 Conv 1x1 linear 3 x 256 x 256
Table 4: TwinGAN Network Structure. Note that the discriminator borrows the same encoder structure but does not share weights with the encoder. In addition, a domain-adaptive batch renormalization layer is added after each convolution layer
