The k-Centre Selection Problem for Multidimensional Necklaces

08/04/2021 ∙ by Duncan Adamson, et al. ∙ 0

This paper introduces the natural generalisation of necklaces to the multidimensional setting – multidimensional necklaces. One-dimensional necklaces are known as cyclic words, two-dimensional necklaces correspond to toroidal codes, and necklaces of dimension three can represent periodic motives in crystals. Our central results are two approximation algorithms for the k-Centre selection problem, where the task is to find k uniformly spaced objects within a set of necklaces. We show that it is NP-hard to verify a solution to this problem even in the one dimensional setting. This strong negative result is complimented with two polynomial-time approximation algorithms. In one dimension we provide a 1 + f(k,N) approximation algorithm where f(k,N) = (log_q(k N))/(N-log_q(kN)) - (log^2_q(kN))/(2N(N-log_q(kN))). For two dimensions we give a 1 + g(k,N) approximation algorithm where g(k,N) = (log_q(k N))/(N-log_q(kN)) - (log^2_q(k))/(2N(N-log_q(kN))). In both cases N is the size of the necklaces and q the size of the alphabet. Alongside our results for these new problems, we also provide the first polynomial time algorithms for counting, generating, ranking and unranking multidimensional necklaces.

READ FULL TEXT VIEW PDF
POST COMMENT

Comments

There are no comments yet.

Authors

page 1

page 2

page 3

page 4

This week in AI

Get the week's most popular data science and artificial intelligence research sent straight to your inbox every Saturday.

1 Introduction

The problem of finding uniformly spaced points (centres) in a metric space is well known as the -centre selection problem. Finding centres is important in many contexts: facility location and distribution, representative samples for state space exploration or identification of cluster centres. So far, the problem has been intensively studied for finite and explicitly given inputs like the -centre problem for graphs [Algorithmica2020], grids [Zhang11] or strings [CPM2004, JACM2002].

In graph theory, the objective of the -centre problem is to find a set of vertices, in a given undirected (weighted) graph , for which the maximal distance from any vertex to its nearest centre in is minimised .

In the area of stringology finding -centres within a set of words can be seen as a problem in a complete weighted graph. Thus, vertices are words and the distance between words depends on their closeness such as the Hamming distance or overlap/Jaccard coefficients for contextual similarity. However, the configuration space of many algebraic and combinatorial structures cannot be explicitly given due to the exponential growth and infeasibility of listing/enumerating the space. So the solutions for centre-selection problem on graphs, or explicitly given finite set of strings, is impractical to apply directly on these objects.

In this paper we introduce a fundamental class of combinatorial objects, multidimensional necklaces, generalising the classical combinatorial necklaces, and we study -centre selection problem for these objects. Multidimensional words in automata theory literature are known as picture-languages and they are a well-studied generalisation of one-dimensional languages to two dimensions [Annexstein1997, Bozapalidis2006, Giammarresi1997, Latteux1997, Matz1997, Stromoney1972]. The level of complexity to deal with such objects moves even higher if we consider natural classes of words which are equivalent under translation symmetry, known as necklaces [Codes_automata, Graham1994].

One-dimensional necklaces are known as cyclic words, i.e. strings over a finite alphabet, which are equivalent under the cyclic shift operation. One-dimensional necklaces also closely related to Lyndon words, i.e., aperiodic necklaces. For both one-dimensional necklaces and Lyndon words efficient algorithms for generation, ranking and unranking have been discovered only recently [Kociumaka2014, Kopparty2016, Sawada2017]. Two-dimensional necklaces correspond to toroidal codes, which have recently attracted attention in the combinatorics on words community in the context of bioinformatic applications [Anselmo2019].

Periodic motives in crystals is another example to illustrate the application of necklaces up to dimension three, e.g. see representation of in Figure 1. The methods for effective exploration of a configuration space of crystal structures and a search for potentially stable materials, see EMMA [Collins17, Dyer13], FUSE [FUSE2018], AIRSS [AIRSS], require procedures for selecting equally spaced seeding configurations in contrast to purely random initial positions. The solution to -centre problem on combinatorial necklaces can be used to build representative sample in discrete configuration space of crystalline materials [SOFSEM2020, CSP2020] and speed up in silico predictions of novel materials, known to be one of the major scientific challenges of our time. The substantial gap of knowledge in solving -centre problem for implicitly represented objects and applications in computational chemistry motivate the study of -centre selection problem for multidimensional necklaces.

Figure 1: The crystal of (left) and its 3D (middle) and 1D (right) necklace representations.

Main Contributions: Our contribution is twofold. Firstly, we introduce the -centre problem for necklaces and develop approximation algorithms for it. Secondly, we derive efficient procedures for foundational operations on multidimensional necklaces. These operations are used by our algorithms, and are of independent interest.

For the -centre problem, we introduce the overlap distance for necklaces. Using this, we provide both negative and positive results for the problem. On the negative side we prove that it is NP-hard to evaluate the quality of a solution for the problem even for 1-dimensional necklaces. Although this is does not resolve the complexity of -centre problem, it is a strong indication that the problem is hard. On the positive side, we design two polynomial-time algorithms that achieve approximation. In the 1-dimensional case this is , and for the multidimensional case it is where is the size of a necklace and the size of the alphabet. Our analysis for both algorithms relies on technical Lemma 2, providing an upper bound on the distance between necklaces and the nearest sample based on the number of subwords which we cover with at least one sample. Our first algorithm works when the input includes a de Bruijn sequences of logarithmic size relative to the number of necklaces; these can be efficiently computed for one-dimensional necklaces, while no algorithm is known for higher dimensions. Our second algorithm bypasses this limitation using new operations on multidimensional necklaces like counting and ranking that we establish in Section 5.

Our second set of results contains the generalisation of several fundamental results from one-dimensional necklaces to the multidimensional setting. This theme focuses on -dimensional necklaces defined over a given set of dimensions and an alphabet . Throughout the paper we use to denote . Our results include the first formal definition of multidimensional necklaces, along with the algorithms to:

  • Count the number of necklaces of dimensions over the alphabet in polynomial time.

  • Generate the set of all necklaces of dimensions over the alphabet in at most time per necklace.

  • Rank a necklace in the set of all necklaces of dimensions over the alphabet in time.

  • Unrank the necklace of dimensions over the alphabet in time.

The remainder of this paper is organised as follows. Section 2 provides definitions and notation used throughout the paper. Section 3 gives the general results about the -centre problem on necklaces, including both hardness results and bounds on the optimal solutions. Section 4 provides two approximation algorithms for this problem in one and dimensional cases. Finally, Section 5 is devoted to the foundational results for multidimensional necklaces.

2 Preliminaries

We denote by the set of integers from to inclusive and by the set of integers from to inclusive. Let be a linearly ordered finite alphabet such that . We denote by the set of all words over and by the set of all words in of length . The notation is used to clearly denote that the variable is a word. The length of a word is denoted by . We use to denote the symbol of , where . The concatenation of words and , denoted , returns the word . We extend the ordering from to in the usual lexicographic manner. Formally, let be a pair of words, where . We say if and only if there exists an where and . For a given set of words the rank of with respect to is the number of words in that are smaller than .

The translation of a word by , denoted , returns the word . A word is equivalent to under translation if for some . The power of a word , denoted , is equal to concatenations of . A word is periodic if there is some word and an integer such that . The smallest such is called the period of . A word is aperiodic if it is not periodic.

A necklace, also called a cyclic word, is the equivalence class of words under the translation operation. For notation, a word is written as when treated as a necklace. Given a necklace , the canonical representative is the lexicographically smallest element of the set of words in the equivalence class . A cyclic subword of the word , denoted , is the word such that for all . Here and in the future we tacitly assume that is equivalent to . Since we consider only cyclic subwords in the paper, we omit “cyclic” in the future. If , then is a prefix and is a suffix. A prefix or suffix of is proper if its length is smaller than .

Multidimensional Words and Necklaces

A -dimensional word over is an array of

-dimensions given by a vector

of elements from . For notation, given a vector where every , is used to denote the set . Similarly is used to denote the set . Let be the dimensions of . Given a vector of dimensions , is used to denote the set of all words of dimensions over . Let for a dimension vector . For a -dimensional word , the notation is used to refer to the symbol at position in the array. Given 2 -dimensional words such that and , the concatenation is performed along the last coordinate, returning the word of dimensions such that if and if .

A multidimensional cyclic subword of of dimensions is denoted . As in the one-dimensional case, a subword is defined by a starting position in the original word and set of dimensions defining the size of the subword. The subword starting at position with dimensions is the word such that for all of the form , where . Such a subword we denote by . One important class of subwords are what we call slices, an example of which is given in Figure 2. The slice of , denoted by , is the subword of dimensions starting at position of . In the 2D case, the slice corresponds to the row of a word. We use to denote . A prefix of length for a multidimensional word is the first slices of in order. A suffix of length for a multidimensional word is the last slices of in order. In the two-dimensional case, the prefix and suffix of length corresponds to the first and last rows respectively.

Figure 2: Example of a 2-dimensional word of size over a binary alphabet: the 4 slices of ; the canonical form of ; and three translations of .
