Signal recognition and background suppression by matched filters and neural networks for Tunka-Rex

12/08/2018

∙

The Tunka Radio Extension (Tunka-Rex) is a digital antenna array, which measures the radio emission of the cosmic-ray air-showers in the frequency band of 30-80 MHz. Tunka-Rex is co-located with TAIGA experiment in Siberia and consists of 63 antennas, 57 of them are in a densely instrumented area of about 1 km2. In the present work we discuss the improvements of the signal reconstruction applied for the Tunka-Rex. At the first stage we implemented matched filtering using averaged signals as template. The simulation study has shown that matched filtering allows one to decrease the threshold of signal detection and increase its purity. However, the maximum performance of matched filtering is achievable only in case of white noise, while in reality the noise is not fully random due to different reasons. To recognize hidden features of the noise and treat them, we decided to use convolutional neural network with autoencoder architecture. Taking the recorded trace as an input, the autoencoder returns denoised trace, i.e. removes all signal-unrelated amplitudes. We present the comparison between standard method of signal reconstruction, matched filtering and autoencoder, and discuss the prospects of application of neural networks for lowering the threshold of digital antenna arrays for cosmic-ray detection.

READ FULL TEXT VIEW PDF

1 Introduction

Tunka-Rex is an antenna array, which measures the radio emission of the air showers produced by cosmic rays with energies above 100 PeV in the frequency band of 30-80 MHz Bezyazeekov:2015rpa . Tunka-Rex requires external trigger and operates jointly with the non-imaging air-Cherenkov light detector Tunka-133 Prosin:2014dxa and the scintillators of Tunka-Grande Budnev:2015cha .

The main background at the Tunka-Rex location is the Galaxy. However there are many sources of non-white and non-stationary background in the Tunka Valley. Due to this we use two different approaches: matched filter with predefined signal template and neural network with optimized convolutional filters.

2 Matched filter and autoencoder for signal reconstruction

In the present work we use 650 000 samples of measured Tunka background and 25 000 CoREAS simulations folded with Tunka-Rex hardware response. We use single polarization ( $v \times B$ ) and following upsampling rates: 64 for matched filter and 16 for neural network. The position of peak is defined with standard method using Hilbert envelope Bezyazeekov:2015rpa .

Matched filter (MF) convolutes template with input trace and the maximum of the convolution defines the position of the peak. Templates are obtained from averaging of many CoREASHuege:2013pro simulations. In the present work we use template with length of 60 ns (see Fig. (1

)). The threshold is defined as 5% probability of false positive. Amplitude is estimated as the function of the square root of cross-correlation. The MF is implemented in Aguer Offline

Abreu:2011pro and tested on the set of simulated events. MF is able to reconstruct pulses with lower amplitudes and features resolution of arrival direction similar to standard method. The distribution of reconstructed events and arrival directions can be seen in Fig. (2).

At the next step we use neural network which called autoencoder (AE). AE based on 1D convolutional layers with rectified linear unit and max pooling after convolution layer. Binary cross-entropy is used as a loss function. For minimization of the loss, all data should be normalized in [0;1] range and baseline always should be put on 0.5 level, what helps the AE to extract features from noise.

Figure 1: From the upper left corner to the bottom right 1) example of MF template, 2) examples of AE performance: correct identification (true positive), no identification (true negative), double identification (true plus false positive).

Structure of AE is defined by the following: depth ( $D$ ) and number of filters per layer ( $N$ ) are free parameters. $i$ -th encoding layer ( $i = 1, . . ., D$ ) is described by the following: $S_{i} = S_{m i n} \times 2^{D - i}$ , $n_{i} = 2^{i + N - 1}$ , where $S_{i}$ is a size of the $i$ -th filter, $n_{i}$ is a number of filters per layer. $D$ and $N$ are free parameters; $S_{m i n} = 16$ is minimal size of layer (correspoding to few ns).

To assess the quality of the networks we have introduced 2 metrics: efficiency: $N_{r e c .} / N_{t o t .}$ , namely fraction of events passed the threshold; and the purity: $N_{h i t} / N_{r e c .}$ , namely fraction of events with reconstructed position of the peak $| t_{r e c .} - t_{t r u e} | < 5$

ns. Networks with 3-4 layers show similar result, only addition of the 5th layer increases of the purity. Networks with 5 layers have a large number of degrees of freedom which leads to overfitting with our limited size of the training dataset.

3 Summary

Figure 2: From left to right 1) distribution of reconstructed events as function of energy; 2) angular resolution of different methods; 3) efficiency; 4) purity.

We have improved Tunka-Rex signal reconstruction by implementing matched filter and autoencoder. New methods show promising results in the lowering of the threshold. We will improve current results by extending the library of templates for matched filter and optimization of autoencoder architectures.

Acknowledgements

This work is supported by the Helmholtz grant HRSF-0027, the Russian Federation Ministry of Education and Science (Tunka shared core facilities, unique identifier RFMEFI59317X0005, 3.9678.2017/8.9, 3.904.2017/4.6, 3.6787.2017/7.8, 3.6790.2017/7.8), the Russian Foundation for Basic Research (Grants No. 16-02-00738, No. 17-02-00905, No. 18-32-00460). In preparation of this work we used calculations performed on the HPC-cluster Academician V.M. Matrosov and on the computational resource ForHLR II funded by the Ministry of Science, Research and the Arts Baden-Württemberg and Deutsche Forschungsgemeinschaft. The work presented in Section 2 of this paper was funded by the Russian Science Foundation (the grant No. 18-41-06003).

References

(1) P. A. Bezyazeekov et al., Nucl. Instrum. Meth. A 802, 89 (2015)
(2) V. V. Prosin et al., Nucl. Instrum. Meth. A 756, 94 (2014).
(3) N. M. Budnev et al., Bull. Russ. Acad. Sci. Phys. 79, 395 (2015) [Izv. Ross. Akad. Nauk Ser. Fiz. 79, no.3, 430 (2015)].
(4) T. Huege et al., AIP Conf. Proc. 1535, 128 (2013), arXiv:1301.2132 [astro-ph.HE].
(5) P. Abreu et al., Nucl. Instrum. Meth. A635, 92 (2011), arXiv:1101.4473 [astro-ph.IM].
