1 Introduction

Time series clustering has become a very active research area in recent times, with applications in many different fields. However, most methods developed so far do not take into account the possible presence of contamination by outliers or spurious information in the sample. In this work, we propose a clustering algorithm for stationary time series that is based on considering the estimated spectral density functions as functional data. This procedure has robust features that mitigate the effect of noise in the data and help to prevent the identification of spurious clusters.

Liao (2005), Caiado et al. (2015) and Aghabozorgi et al. (2015) provide comprehensive revisions of the area (see also Fu, 2011). Montero and Vilar (2014) present a package in R for time series clustering with a wide range of alternative methods. According to Liao (2005), there are three approaches to clustering of time series: methods that depend on the comparison of the raw data, methods based on the comparison of models fitted to the data and, finally, methods based on features derived from the time series. Our proposal falls within the third approach and the spectral density is the characteristic used to gauge the similarity between time series in the sample.

Several authors have previously considered spectral characteristics as the main tool for time series clustering. Caiado et al. (2006, 2009) considered the use of periodogram and normalized periodogram ordinates for clustering time series. Maharaj and D’Urso (2011) propose a fuzzy clustering algorithm based on the estimated cepstrum, which is the spectrum of the logarithm of the spectral density function. Alvarez-Esteban et al. (2016b) and Euán et al. (2017) consider the use of the total variation distance on normalized estimates of the spectral density as a dissimilarity measure for clustering time series. A brief description of the last two algorithms will be given in Sect. 2.

Other works have focused on developing robust clustering algorithms for time series clustering. Wu and Yu (2006)

use Independent Component Analysis to obtain independent components for multivariate time series and develop a clustering algorithm, known as ICLUS to group time series.

D’Urso et al. (2015)

use a fuzzy approach to propose a robust clustering model for time series based on autoregressive models. A partition around medoids scheme is adopted and the robustness of the method comes from the use of a robust metric between time series.

D’Urso et al. (2016)

present robust fuzzy clustering schemes for heteroskedastic tine series based on GARCH parametric models, using again a partition around medoids approach. Three different robust models are proposed following different robustification approaches, metric, noise and trimming.

Bahadori et al. (2015) propose a clustering framework for functional data, known as Functional Subspace Clustering, which is based on subspace clustering (Vidal, 2011) and can be applied to time series with warped alignments.

Our approach considers the use of functional data clustering as a tool for grouping stationary time series, but the functional object considered is not the time series but its spectral density. The use of Functional Data Analysis is Statistics can be reviewed in the following two monographs: Ramsay and Silverman (2005) and Ferraty and Vieu (2006). Several clustering methods for functional data have been already proposed in the literature as, for instance, James and Sugar (2003), Jacques and Preda (2013) and Bouveyron and Jacques (2011) but these methods are not aimed at dealing with outlying curves. A survey of functional data clustering can be found in Jacques and Preda (2014)

Our proposal for robust time series clustering is based on the use of spectral densities, considered as functional data, and the application of the clustering algorithm recently developed in Rivera-García et al. (2017), which will described in more detail in Sect 3. Trimming techniques for robust clustering have been already applied in García-Escudero and Gordaliza (2005) and Cuesta-Albertos and Fraiman (2007).

The rest of the paper is organized as follows: Section 2 considers time series clustering and describes the idea behind our proposal. Section 3 gives a brief description of the robust clustering algorithm for functional data that supports the time series clustering algorithm. Section 4 presents a simulation study designed to compare the performance of the algorithm with existing alternatives and Sect. 5 gives an application to a real data set. The paper ends with some discussion of the results and some ideas about future work.

2 Time Series Clustering

Consider a collection of stationary time series with . For ease of notation we take all series to have the same length, but this is not a requirement of the procedure. For each time series the corresponding spectral density is estimated by one of the many procedures available. As mentioned in the Introduction, previous clustering methods based on the use of spectral densities relied on similarity measures for discriminating between them.

In this work, the spectra are considered as functional data to which the robust clustering procedure developed in Rivera-García et al. (2017) and described briefly in the next section, is applied. The resulting clusters correspond to time series whose spectral densities have similar shapes, and therefore similar oscillatory behavior. The procedure is able to detect outliers in the collection of spectral densities, which correspond to time series having atypical oscillatory characteristics.

Two methods recently proposed in the literature, that are based on the use estimated spectral densities as the characteristic feature of each time series, are presented in Alvarez-Esteban et al. (2016b) and Euán et al. (2017)

. We describe these two procedures in more detail since they will be used for comparison purposes in the next sections, and we refer to them as “TVDClust” and “HSMClust”, respectively. In both cases the total variation distance (TVD) is used to measure similarity between spectral densities. TVD is a frequently-used distance between probability measures that, in the case of probabilities having a density, measures the complement of the common area below the density curves. Thus, the more alike the densities are, the larger this common area and the smallest the TV distance.

To use this distance to compare spectral densities, a prerequisite is that they have to be normalized so that the total area below the curve is equal to 1, which is equivalent to normalizing the original time series so that it has unit variance. Thus, it is the oscillatory behavior of the series, and not the magnitude of the oscillations that is taken into account in these clustering algorithms.

For the first method, “TDVClust”, a dissimilarity matrix is built up by measuring the TVD distance between all pairs of normalized estimated spectral densities. This matrix is then fed to a hierarchical agglomerative algorithm with the complete or average linkage functions. The result is a dendrogram which can be cut to obtain the desired number of groups. To decide on the number of clusters an external criteria such as the Silhouette or Dunn’s index is used. More details on this algorithm can be found in Alvarez-Esteban et al. (2016b).

The second method, “HSMClust”, is a modification of the previous one in which every time two clusters are joined together, all the information in them is used to obtain a representative spectrum for the new cluster. There are two ways to do this, either all the spectral densities are averaged to obtain a representative spectral density for the new group, which is the average option in the algorithm, or else all the time series in the two groups are concatenated and a new spectral density is estimated, which corresponds to the single option. Under the assumption that the series in the same cluster have common oscillatory characteristics, either of this procedures will give a more accurate estimation of the common spectral density for the whole group. This algorithm, which comprises the two options described, is known as the Hierarchical Spectral Merger (HSM) algorithm, and its implementation in R is available at http://ucispacetime.wix.com/spacetime#!project-a/cxl2.

Every time two clusters are joined together, the dissimilarity matrix reduces its size. In the previous algorithm, “TVDClust”, the dissimilarity matrix remains the same throughout the procedure and the distances between clusters are calculated using linear combinations of the distances of the individual points in each cluster. The linear combination used is determined by the linkage function employed. Euán et al. (2017) present two methods for determining the number of clusters. One of them is based on the value of the distance between the closest clusters at each step, and the other one is based on bootstrap procedures. More details can be found in the reference.

3 Robust Clustering for Functional Data

In this section we give a brief description of the algorithm proposed in Rivera-García et al. (2017), where more details can be found.

Let

be a random variable taking values in the Hilbert space

of functions with inner product given by . If and , then it is usual to represent through its Karhunen-Loève expansion . In that expansion, the

are an orthonormal system of functions obtained as eigenfunctions of the covariance operator

, i.e.

, and the eigenvalues

are taken in decreasing order and assumed to satisfy . The principal component scores are uncorrelated univariate random variables with zero mean and variance equal to . Delaigle and Hall (2010) show that can be approximated by , for any and small , where

corresponds to the probability density function of

and . This approximation entails a kind of “small-ball pseudo-density” approach for Functional Data Analysis by taking into account that probability density functions in the finite dimensional case can be seen as the limit of when . In the particular case of being a Gaussian process, the

are independent normally distributed random variables with mean equal to 0 and variance equal to

.

With these previous ideas in mind, Jacques and Preda (2013) propose a “model-based” approach for clustering of functional data, where a finite number of independent normally distributed principal component scores are assumed and different variances are also allowed for each cluster. To simplify this largely parameterized problem, Bouveyron and Jacques (2011) consider an alternative approach, where a certain fraction of the smallest variances are constrained to be equal for each cluster.

Rivera-García et al. (2017), starting from Bouveyron and Jacques (2011), propose a robust functional clustering procedure where a proportion of curves are allowed to be trimmed and constraints on the variances are considered. To be more precise, if is a set of curves in , we consider the maximization of a trimmed mixture-loglikelihood defined as

(1)

where is the -th principal component score of curve in group , , and, is an indicator function with if the curve is trimmed and 1 if it is not. A proportion of curves is trimmed, so that . The main cluster variances are modeled through ,…, , for the -th cluster, while serves to model the “residual” variance. Notice that we take an equal number of principal components scores in every cluster but the number of main variance components may vary across clusters. Finally, to prevent the detection of spurious clusters, two constants and were fixed such that the maximization of (1) is done under the constraints:

(2)

and

(3)

A feasible algorithm for performing the constrained maximization was detailed in Rivera-García et al. (2017). This algorithm is a modification of the traditional EM algorithm used in model-based clustering where a “trimming” step (T-step) is also added. In the trimming step, those curves with smallest contributions to the trimmed likelihood are temporarily not taken into account in each iteration of the algorithm. That trimming step is similar to that applied in the “concentration” steps applied when performing the fast-MCD algorithm (Rousseeuw and Van Driessen, 1999). To enforce the required constraints on the variances, optimally truncated variances as done in Fritz et al. (2013) are adopted if needed.

With respect to the estimation of the dimensions in each cluster, a BIC approach was proposed in Rivera-García et al. (2017) as a sensible way to estimate those dimensions.

4 Simulation Study

In order to evaluate the performance of the methodology proposed here, a simulation study was carried out. We now describe the different scenarios and contamination types. As in Euán et al. (2017), the simulations are based on combinations of autoregressive processes of order 2. AR(2) processes are defined as

(4)

where

is a white noise process. The characteristic polynomial associated with this model is

and its roots, denoted by and are related to the oscillatory properties of the corresponding time series. If the roots are complex-valued, then they must be conjugate, i.e., and their polar representation is

(5)

where is the sampling frequency in Hertz; is the magnitude of the root ( for causality) and the frequency index, . The spectrum of the AR(2) process with roots defined as above will have modal frequency in . The modal frequency will be sharper when and narrower when . Then, given () we have

(6)

where .

Two groups of 50 time series each were simulated, with parameters , , , and length . From the simulated time series, the spectral densities were estimated using a smoothed lag-window estimator with a Parzen window and bandwidth 100/T. The estimated spectral densities for both clusters are shown in Figure 1(a). The functional form of the estimated spectral densities was recovered using a B-Spline basis of degree 3 with equispaced nodes and smoothing parameter (see e.g. Ramsay and Silverman, 2005, Ch. 3) We want to test the performance of the different algorithms in recovering these two groups, even in the presence of contaminating data. In the absence of contamination we have 100 observations divided into two groups.

Before describing the contamination schemes considered, we introduce the mixtures of AR(2) processes that will be used in some cases. Let be two AR(2) processes with parameters and , . Their mixture is given by

(7)

where the are the weights and is a white noise process. This mixture of AR(2) processes creates a signal that combines the oscillatory behavior of the original processes .

Starting from the two groups of 50 AR(2) time series described in the beginning of this section, which are considered as the clean data, we added another 11 time series (around 10% contamination level). We consider the following schemes for generating these additional time series:

  • Using the previously described simulation procedure, simulate 11 AR(2) processes with parameters

    chosen randomly with uniform distribution in the interval

    , denoted as , ; and . This means that the contaminating curves have less energy than the series in the clusters. See Fig. 1(b).

  • A mixture of two AR(2) processes having parameters and ; , y . See Fig. 1(c).

  • A mixture of two processes with random parameters y ; , and , See Fig. 1(d).

Figures 1(b), (c) and (d) show the spectral density for the simulated time series with the three contamination schemes described.

Figure 1: Spectral density of the simulated time series: (a) No contamination, (b) Contamination type (i), (c) Contamination type (ii) and (d) Contamination type (iii)

In order to test the performance of the robust functional clustering (RFC) methodology proposed here, the simulated proceses and their estimated spectral densities were used to compare with the results obtained when using the “Funclust” algorithm (Jacques and Preda, 2013) and hierarchical methods using the total variation distance: “HSMClust” (Euán et al., 2017) and “TVDClust” (Alvarez-Esteban et al., 2016a, b).

It is important to recall that we assume the dimensions in the RFC procedure to be unknown parameters and that the BIC criterion is used to estimate them when applying this algorithm. The results in Rivera-García et al. (2017) already show the importance of trimming. Trimming levels and are used. As regards the constraints, we are assuming to simplify the simulation study. Values of , and (i.e., almost unconstrained in this last case) were used. We always return the best solution in terms of the highest BIC value for each combination of all those fixed values of trimming level and constraints. We use 100 random initializations with 20 iterations.

For the “Funclust” method we have used the library Funclustering (Soueidatt, 2014) in R where the EM algorithm has been initialized with the best solutions out of 20 “short” EM algorithms with only 20 iterations and threshold values of in the Cattell test. In case of the agglomerative methods we use the library HSMClust in R for “HSMClust” and “TVDClust” by means of the algorithm described in Alvarez-Esteban et al. (2016a, b).

Figure 2 shows the results for the simulation study. This figure is composed of a matrix of graphs, where the rows correspond to the different contamination schemes (uncontaminated in the first row) while the columns correspond to the methodologies tested. The first column corresponds to “Funclust”, the second to “HSMClust”, the third shows the results for the robust functional clustering (RFC) procedure with trimming levels (untrimmed) and and three constraint levels , and (i.e., almost unconstrained in this last case). Finally the fourth column shows the results corresponding to “TVDClust”. The -axis corresponds to the threshold applied in the Cattell test for “Funclust”, the procedure in “HSMClust”, the constraint level for RFC and the linkage function for the agglomerative method “TVDClust”, while the -axis corresponds to the correct classification rate (CCR).

Figure 2: Correct classification rate (CCR) for the four methods considered, represented in different columns. Rows correspond to the different contamination schemes described previously in this section, starting with no contamination in the first row and following with contamination schemes (i), (ii) and (iii) described in the text. Constraint levels , and , trimming levels and were used for the RFC method. Threshold values and are used for the “Cattell” procedure in “Funclust”. Single and average version were used for “HSMClust” while average and complete linkage functions were used for “TVDClust”.

Results show that the hierarchical methods, “HSMClust” and “TVDClust” are better in the absence of contamination, giving very consistent results. However, their performance degrades sharply in the presence of noise. This is not susprising since these procedures were not designed to handle contamination in the sample. The joint use of trimming and constraints in RFC improve the results (CCR) substantially. Results are very good for moderate and small values of the constraint constants, while for high values the results are poor. Very high values for these constants are equivalent to having unconstrained parameters. The use of trimming also turns out to be very useful in all the contaminated cases while the results are not affected by trimming in the uncontaminated case.

In the presence of contamination, the results for “Funclust”, “HSMClust” and “TVDClust” fall below those of RFC when applying the trimming and small/moderate values and for the variance parameters.

5 Analysis of Real Data

In this section we consider wave-height data measured by a buoy located in Waimea Bay, Hawaii, at a water depth of approximately 200 m. This buoy is identified as number 106 (51201 for the National Data Buoy Centre). The data was collected in June 2004 and has previously been analyzed by Alvarez-Esteban et al. (2016a) where more details can be found. The data corresponds to 72.5 hours divided into 30-minute intervals.

In their work, for each of these 145 30-minute intervals, the spectral density of the corresponding time series was estimated using a lag window estimator with a Parzen window. These densities were normalized, so the total area below the curve is equal to one, and the total variation distance between all spectral densities was used to build a dissimilarity matrix, that was fed into a hierarchical agglomerative clustering algorithm. For more details on this procedure see Alvarez-Esteban et al. (2016b). The 145 normalized densities are shown in figure 3(a).

Figure 3: Spectral densities for the sea wave data after normalization so that the integral of the densities are all equal to one. (a) Original data. (b) Original data plus 22 additional densities in black color, considered as noise.

The RFC method was applied to this data set considering the spectral densities as functional data in order to obtain an alternative clustering. The functional form of the data was recovered using a B-splines of order with equispaced nodes. We use initializations with iterations each. The constraint level considered was , and the trimming level . In Alvarez-Esteban et al. (2016a) two different clusterings were obtained, depending on the linkage function used: 4 clusters for the complete linkage and 3 for average. We will only consider the clustering into 4 groups for comparison purposes in what follows.

To compare with the results obtained using the RFC method, the Adjusted Rand Index (Hubert and Arabie, 1985) was used. This Adjusted Rand Index (ARI) is an improvement with respect to the original Rand Index (Rand, 1971) and it measures the similarity between two partitions of the same set having value equal to 1 when there is exact coincidence and close to 0 in the case of considering a completely “random” partition of data into clusters.

First of all, we will see that the effect of trimming and constraints is not harmful even in the case where no contaminating time series were added. For instance, we can see that the ARI of RFC with and is equal to 0.513 with respect to the “reference” partition which is obtained when applying Alvarez-Esteban et al. (2016a)

with 4 groups. To compute this ARI index we assign all the time series (trimmed and non-trimmed) to clusters by using “posterior” probabilities from the fitted mixture model that was described in Sect 3. The two rows in Fig.

4 show the clusters found when using the total variation distance and RFC, respectively. Even though in this case the groups have differences in membership and size, it is possible to see from the figures that the shape of the functions in the corresponding clusters are very similar and the mean value functions look alike. The variations are probably due to the different clustering techniques employed, but the similarity in the groups obtained point to consistent results for both clustering methods. Observe that the trimmed curves for the RFC method are different from the rest of the functions in their cluster. For “HMSClust” , both versions, single and average, gave a value of 0.723 for the ARI, higher than that obtained with RFC, while for “Funclust” , values were lower, with a maximum of 0.315 with a threshold value of 0.01 or 0.1 in the “Cattell” test.

Figure 4: (top) Clusters found using the total variation distance using the complete linkage function. (bottom) Clusters found using the RFC method for with constrains and trimming . Each panel corresponds to spectral densities in each cluster, grey lines represent the means and black lines represent the trimmed observations.

In order to test the performance of the different clustering methods with real data and in the presence of contamination, 22 time series were added to the sample. These series are measurements recorded at the same location and during the same month of June, but during different days. The corresponding estimated spectral densities are shown in black in Fig. 3(b). Some of these densities are bimodal while others are unimodal but have lower modal frequency than those in the original sample.

The four clustering procedures that are being considered were applied to this contaminated sample and the obtained results were compared using again as “reference” the clustering obtained in Alvarez-Esteban et al. (2016a) with 4 groups applied to the clean (i.e., before adding the contaminating curves). The ARI was computed by taking only into account the classification of the non-contaminating densities to evaluate the performance of the different methodologies. In the case of the RFC methodology, the assignments based on “posterior” probabilities were considered for the wrongly trimmed observations. Table 1 shows the results for the RFC method with constraints and different trimming levels. The associated ARI when using Funclust are always below 0.21 for all three Cattell thresholds tested (0.001, 0.05 and 0.1) as this method is not designed to cope with outlying curves. The other methods tested, “linkage TVD” and “Linkage HSWClust”, have even worst results in this contaminated case reaching ARI values equal to 0 in both case. Therefore, the best results overall were obtained using RFC with a trimming level while the other methods show poor results in the presence of contaminating data.

0.167 0.723 0.596
Table 1: Adjusted Rand Index for partitions with four clusters in Alvarez-Esteban et al. (2016a) in the presence of contamination. The values correspond to the RFC method with constraint levels and three different trimming levels.

To reinforce previous claims, Figure 5 shows in the first row, the partition obtained in Alvarez-Esteban et al. (2016a) with four clusters before adding the contaminating time series. In the second row, the results when using RFC with four clusters, and trimming level to the “contaminated” data set. In the third row the results obtained with “TDVClust”, then “HMSClust” and “Funclust”, also in case that the contaminating time series were added. Once again, we can see that the clusters obtained with RFC differ slightly from those obtained in Alvarez-Esteban et al. (2016a) but, in spite of the presence of contamination, the shape of the spectral densities in the corresponding clusters are very similar and the four average densities are very close. The trimmed functions when using level are shown in black in the second row. The last three rows show the poor results obtained with the other three clustering methods. For instance, in the third row, which corresponds to “TVDClust” , all the original sample is clustered together in a single group in the leftmost panel, while the other three groups only contain contaminating functions that were added as noise.

Figure 5: Clusters found with the different procedures when . Each panel corresponds to a cluster of spectral densities found. Gray lines represent the means and black lines represent the trimmed observations. First row: Original clusters for the total variation distance using the complete linkage function before adding contaminating time series. Second row: Clusters for the RFC method for with constrains and trimming . Third row: Clusters for the “TVDClust” method with complete linkage. Fourth row: Clusters for “HSMClust” method. Fifth row: Clusters for “Funclust”

Given that , there were 19 trimmed curves when applying the RFC procedure. Most of these trimmed densities come from the contaminating series that were added to the original sample. Finally, it is also important to point out that trimming and clustering are performed simultaneously in the RFC approach.

6 Conclusions

A feasible methodology of robust clustering for stationary time series has been proposed and illustrated. The key idea behind the algorithm presented is the use of estimated spectral densities of the time series, that are then considered as functional data. A robust model-based algorithm based on approximation of the “density” for functional data, together with the simultaneous use of trimming and constraints is then used to cluster the original time series.

The use of trimming tools protects the estimation of the parameters against effect of outlying curves, while the constraints avoid the presence of spurious clusters in the solution and improve the performance of the algorithms. The simulation study shows that the joint use of constraints and trimming tools improve results of the clustering algorithm in the presence of outliers, in comparison to some other procedures for time series and functional data clustering, not designed to work with contamination. The real data example shows that the proposed RFC method for time series clustering has a good performance, with or without the presence of outlying curves. The trimmed curves often correspond to curves with different characteristics to the rest. Moreover, in the presence of contamination, the RFC method is able to detected almost all the outliers in the data. In fact, we conclude that the proposed robust methodology can be a useful tool to detected contamination and groups in a time serie data set simultaneously.

However, this methodology has some limitations. The choice of trimming level and the choice of the scatter constraints constants and

, can be subjective and sometimes depend on the final purpose of the cluster analysis. For this reason, we always recommend the use of different values of trimming and constraint, monitoring the effect in the clustering partition of these choices. The development of more automated selection procedures for these values may be considered as an open problem for future research.

7 Acknowledgements

Data for station 160 were furnished by the Coastal Data Information Program (CDIP), Integrative Oceanographic Division, operated by the Scripps Institution of Oceanography, under the sponsorship of the U.S. Army Corps of Engineers and the California Department of Boating and Waterways (http://cdip.ucsd.edu/). Research by DRG and JO was partially supported by Conacyt, Mexico Project 169175 Análisis Estadístico de Olas Marinas, Fase II, Research by LA G-E and A M-I was partially supported by the Spanish Ministerio de Economía y Competitividad y fondos FEDER, grant MTM2014-56235-C2-1-P, and by Consejería de Educación de la Junta de Castilla y León, grant VA212U13

References

  • Aghabozorgi et al. (2015) Aghabozorgi, S., A. S. Shirkhorshidi, and T. Y. Wah (2015). Time-series clustering – a decade review. Information Systems 53, 16 – 38.
  • Alvarez-Esteban et al. (2016a) Alvarez-Esteban, P. C., C. Euán, and J. Ortega (2016a). Statistical analysis of stationary intervals for random waves. In Proceedings of the International Offshore and Polar Engineering Conference, Volume 3, pp. 305–311.
  • Alvarez-Esteban et al. (2016b) Alvarez-Esteban, P. C., C. Euán, and J. Ortega (2016b). Time series clustering using the total variation distance with applications in oceanography. Environmetrics 27(6), 355–369.
  • Bahadori et al. (2015) Bahadori, M. T., D. C. Kale, Y. Fan, and Y. Liu (2015). Functional subspace clustering with application to time series. In

    Proceedings of the 32nd International Conference on Machine Learning

    , pp. 228–237.
  • Bouveyron and Jacques (2011) Bouveyron, C. and J. Jacques (2011). Model-based clustering of time series in group-specific functional subspaces. Adv. Data Anal. Classif. 5(4), 281–300.
  • Caiado et al. (2006) Caiado, J., N. Crato, and D. Peña (2006). A periodogram-based metric for time series classification. Computational Statistics & Data Analysis 50(10), 2668 – 2684.
  • Caiado et al. (2009) Caiado, J., N. Crato, and D. Peña (2009). Comparison of times series with unequal length in the frequency domain. Communications in Statistics - Simulation and Computation 38(3), 527–540.
  • Caiado et al. (2015) Caiado, J., E. A. Maharaj, and P. D’Urso (2015). Time Series Clustering, Chapter 12, pp. 241–263. Chapman & Hall/CRC Handbooks of Modern Statistical Methods. Taylor & Francis.
  • Cuesta-Albertos and Fraiman (2007) Cuesta-Albertos, J. A. and R. Fraiman (2007). Impartial trimmed -means for functional data. Comput. Statist. Data Anal. 51(10), 4864–4877.
  • Delaigle and Hall (2010) Delaigle, A. and P. Hall (2010). Defining probability density for a distribution of random functions. Ann. Statist. 38(2), 1171–1193.
  • D’Urso et al. (2015) D’Urso, P., L. D. Giovanni, and R. Massari (2015). Time series clustering by a robust autoregressive metric with application to air pollution. Chemometrics and Intelligent Laboratory Systems 141, 107 – 124.
  • D’Urso et al. (2016) D’Urso, P., L. D. Giovanni, and R. Massari (2016). Garch-based robust clustering of time series. Fuzzy Sets and Systems 305, 1 – 28. Theme: Classification, Recognition and Clustering.
  • Euán et al. (2017) Euán, C., H. Ombao, and J. Ortega (2017). The Hierarchical Spectral Merger algorithm: A New Time Series Clustering Procedure. J. of Classification (accepted).
  • Ferraty and Vieu (2006) Ferraty, F. and P. Vieu (2006). Nonparametric functional data analysis. Springer Series in Statistics. Springer, New York.
  • Fritz et al. (2013) Fritz, H., L. A. García-Escudero, and A. Mayo-Iscar (2013). A fast algorithm for robust constrained clustering. Comput. Statist. Data Anal. 61, 124–136.
  • Fu (2011) Fu, T. (2011). A review on time series data mining.

    Engineering Applications of Artificial Intelligence

     24, 164–181.
  • García-Escudero and Gordaliza (2005) García-Escudero, L. A. and A. Gordaliza (2005). A proposal for robust curve clustering. J. Classification 22(2), 185–201.
  • Hubert and Arabie (1985) Hubert, L. and P. Arabie (1985). Comparing partitions. Journal of Classification 2(1), 193–218.
  • Jacques and Preda (2013) Jacques, J. and C. Preda (2013). Funclust: A curves clustering method using functional random variables density approximation. Neurocomputing 112, 164–171.
  • Jacques and Preda (2014) Jacques, J. and C. Preda (2014). Functional data clustering: a survey. Adv. Data Anal. Classif. 8(3), 231–255.
  • James and Sugar (2003) James, G. M. and C. A. Sugar (2003). Clustering for sparsely sampled functional data. J. Amer. Statist. Assoc. 98(462), 397–408.
  • Liao (2005) Liao, T. W. (2005). Clustering of time series data – a survey. Pattern Recognition 38, 1857–1874.
  • Maharaj and D’Urso (2011) Maharaj, E. A. and P. D’Urso (2011). Fuzzy clustering of time series in the frequency domain. Information Sciences 181(7), 1187–1211.
  • Montero and Vilar (2014) Montero, P. and J. Vilar (2014). TSclust: An R package for time series clustering. Journal of Statistical Software 62(1), 43.
  • Ramsay and Silverman (2005) Ramsay, J. O. and B. W. Silverman (2005). Functional data analysis (Second ed.). Springer Series in Statistics. Springer, New York.
  • Rand (1971) Rand, W. M. (1971). Objective criteria for the evaluation of clustering methods. Journal of the American Statistical Association 66, 846–850.
  • Rivera-García et al. (2017) Rivera-García, D., L. A. García-Escudero, A. Mayo-Iscar, and J. Ortega (2017). Robust clustering for functional data based on trimming and constraints. arXiv:1701.03267.
  • Rousseeuw and Van Driessen (1999) Rousseeuw, P. and K. Van Driessen (1999). A fast algorithm for the minimum covariance determinant estimator. Technometrics 41, 212–223.
  • Soueidatt (2014) Soueidatt, M. (2014). Funclustering: A package for functional data clustering. R package version 1.0.1.
  • Vidal (2011) Vidal, R. (2011). Subspace clustering. IEEE Signal Processing Magazine 28(2), 52–68.
  • Wu and Yu (2006) Wu, E. H. C. and P. L. H. Yu (2006). Iclus: A robust and scalable clustering model for time series via independent component analysis. International Journal of Systems Science 37(13), 987–1001.
