1 Introduction
Current stateoftheart convolutional neural networks (CNNs) might trace their roots back to LeNet5 digit recognition [20] and CIFAR10 classification [18], but have long since evolved into behemoths orders of magnitude wider and deeper as exemplified by VGG [22], with complex branching first popularized by grouped convolution layers in AlexNet [19], inception layers in GoogLeNet [23], and residual layers in ResNet [12]. However, the competition to improve accuracies has led to diminishing returns both in terms of training and inferencing. Therefore, networks such as SqueezeNet [16] and MobileNet [15] were consciously crafted to strike a fine balance between inference accuracies and compute and storage footprints.
Training and inferencing of CNNs were once markets exclusively owned by CPUs thanks to their ubiquity and ease of programming, but then GPUs exploded into the training market with the advent of NVIDIA’s CUDA, Khronos’ OpenCL, and AMD’s HIP combined with their plethora of singleprecision floatingpoint units. As network sizes increased the significance of a network’s target data type on its compute and storage requirements started gaining increasing attention due to the fundamental energy and space costs to perform arithmetic operations and execute load/store operations between various levels of memory caches [14, 6]. For example, 32bit integer additions cost about 4x more energy to perform compared to 8bit integers, multiplications cost about 16x more energy, and load/stores cost about 4x or more energy depending on changes in cache locality.
The expense of these operations launched a hardware arms race to accelerate reducedprecision arithmetic as a means to scale out for data centers and down for embedded devices beginning with fixedpoint data types and then continuing to floatingpoint data types, for which FPGAs with their reprogrammable logic can be reconfigured with custom circuit designs optimized for target reducedprecision arithmetic while fixed instruction set architectures such as CPUs and GPUs would have to emulate reducedprecision arithmetic not yet hardened.
2 Quantization Scheme
An ideal quantization scheme for CNNs is one whose basic arithmetic operations, i.e., multiplication and addition, are widely available in hardware for at least some common quantization scheme parameters and has relatively little overhead when executing convolution layers. In this section we introduce our dynamic floatingpoint data types and some advanced operations specific to CNNs that we refer back to in later sections.
2.1 Data Type
The suitability of a quantization scheme is often first judged based on its range and precision most commonly centered about zero as a proxy to an error tolerance for a target CNN’s realvalued numerical ranges, which may vary widely even between adjacent layers. To strike such balance between range and precision, our quantization procedure supports any numerical format that can be expressed as according to the following dynamic floatingpoint format:
(1)
More specifically, —defined by quantization parameters and that respectively represent its bitwidth and number of significand bits thereof, and variable bits —is represented by sign and magnitude as
(2)
or by two’s complement as
(3)
where for both representations
(4)
With Equations 1, 2, and 4 now being defined, the relationship between range and precision may be more readily understood from the examples depicted in Figure 1. In fact, our dynamic floatingpoint quantization scheme is the floatingpoint analogue to the dynamic fixedpoint quantization scheme [3], and a generalization and extension of the IEEE 754 Standard for FloatingPoint Arithmetic [1], including default support for subnormal values, i.e., and , in addition to normalized values, but with the default option to extend numeric values in place of infinity and NaN (quiet or signaling).
As highlighted by the normalization in Figure 1, it is often more natural to frame the quantization scheme in terms of a threshold using the simple conversion , or more explicitly
(5)
where equality comes from using the full range by excluding Infs/NaNs. In other words, scale represents the smallest positive subnormal value if subnormals were included, and threshold represents the largest positive value allowed in the quantization scheme.
2.2 Operations
Basic arithmetic operations, that is binary operations between dynamic floatingpoint data types, are just simple cases of more advanced operations found in CNNs. In this section we define two advanced operations that in turn also define binary multiplication and addition.
If given dynamic floatingpoint numbers and such that , , , and for all , then the multiplication and accumulation found in convolution and inner product layers is expressed as follows:
(6)
Now suppose that and are ranges with the smallest upperbounds such that they contain every and , respectively, where , , , , and . Without loss of generality let , and since by construction , then
(7)
We can compute the sum of products above using a bit two’s complement signedinteger accumulator without loss of accuracy so long as and . Therefore the smallest is
(8)
and the largest is
(9)
which generalizes a previous fixedpoint analysis [7], and indicates that we should require and by always clamping IEEE floatingpoint values to and reducedprecision floatingpoint values to .
Next, if given dynamic floatingpoint numbers such that and for all , then the addition found in eltwise addition layers is expressed as follows:
(10)
Now suppose that is a range with the smallest upperbound such that it contains every , where , , , and , then
(11)
We can compute the sum above using a bit two’s complement signedinteger accumulator without loss of accuracy so long as and . Therefore the smallest is
(12)
and the largest is
(13)
which further supports our decision to require .
3 Quantization Procedure
An ideal quantization procedure for CNNs is one that with little effort can be made backwards compatible with existing hardware and software. Additionally, it is preferential to be able to reuse existing models to save the time of training from scratch, as featured in Ristretto [10, 11]
and Google’s TensorFlow
[17]. In fact, one would rather not retrain as even that can be time consuming or require the entire labeled data set which may not be available. Another method found in Google’s TensorFlow determines some 8bit fixedpoint quantization parameters online for each batch during inferencing [8], though it does have hooks to save and load these parameters offline. Elsewhere, NVIDIA’s TensorRT determines 8bit fixedpoint quantization parameters offline by inferencing with an unlabeled calibration set and at each layer analyzing the difference between the reference floatingpoint and fixedpoint probability distribution functions
[21]. Our method supports any dynamic floatingpoint scheme and a unified offline/online quantization flow with additional enhancements we found necessary for endtoend post quantization accuracies. In order to limit the scope of this paper, we present our quantization procedure as it pertains to offline quantization.In our method an IEEE 754 floatingpoint value in a tensor is converted to its reducedprecision floatingpoint value
by first clamping the IEEE 754 floatingpoint value to a strictly symmetric threshold range . The threshold valuemay be directly chosen from some statistical analysis of the aforementioned tensor such as a percentile or number of standard deviations, or from similar analyses of historically comparable tensors as shown in Algorithm
1 using a weighted average of over a dozen measures [4], though others have used just the KullbackLeiblerI with reported success [21]. Next, the clamped value is divided by its scale , then the result proceeds through several more steps in order to round to the desired . A reducedprecision floatingpoint value is converted to an IEEE 754 floatingpoint value by simply multiplying through by its scale .We begin our quantization procedure with a few preprocessing steps to prepare the network. Where possible we merge adjacent fork/join memory operations, e.g., multiple concat layers may be combined into a single concat layer. Likewise, any adjacent layers that are linear operations, e.g., batchnorm, scale, bias, convolution, and inner product layers, are combined into either a convolution or inner product layer. If an adjacent convolution or inner product layer does not exist, an identity convolution or inner product layer is created and inserted accordingly. Splicing in identity operations such as the aforementioned layers is a technique we heavily use to give us the ability to explicitly downscale reducedprecision floatingpoint values during endtoend post quantization execution by factors we empirically find during the remainder of our quantization procedure to be on the interval . Where these factors are determined to be unity, i.e., remain identity operations, then those layers are spliced back out. We apply this technique on edges directly connecting fork layers to join layers, and before join layers that directly, or indirectly, could not otherwise be explicitly downscaled, e.g., a maxpool layer following an eltwise layer.
Once the preprocessing steps are complete we iterate through the network quantizing weights with threshold values equal to the maximum absolute value per respective output channel. Meanwhile, threshold values for activations are measured in a bootstrap quantization fashion instead of a divide and conquer approach. Note that the choice of thresholds for biases may either be a function of input thresholds and weight thresholds or output thresholds depending on the target hardware implementation. Furthermore, the determination of threshold values for activations is delayed as long as possible so as to not prematurely drop least significant bits causing irreversible loss of information. For example, the threshold of a convolution layer–as specified by its associated scaling factor in Equation 6
–followed by a ReLU layer is not determined until after the ReLU layer. In particular, this lazy thresholding is necessary to match the scaling factors associated with each input to joining layers such as concat and eltwise layers as indicated in Equation
10.4 Experiments
We conducted three sets of dynamic floatingpoint quantization experiments that each target a variety of modern network features, mainly inception layers, residual layers, and grouped convolution layers in GoogLeNet v1 [23, 9], ResNet50 [12, 13], and MobileNet v1 [15, 24]
, which we will henceforth simply refer to as GoogLeNet, ResNet, and MobileNet, respectively. Each of these models were trained by their authors on the ImageNet data set using singleprecision floatingpoint. We chose GoogLeNet and ResNet as they represent networks typically deployed in data centers, and MobileNet because it is more indicative of networks designed for embedded devices. For each set of experiments we performed our quantization procedure for a calibration set chosen randomly without replacement from the training images and then measured the Top1 inference accuracies for each set of experiments against 1600 validation images. Throughout the three sets of experiments we also varied the calibration set size between between 8, 32, and 128 to measure its relative effect on accuracies. Finally, unless otherwise mentioned, we include subnormals but exclude Infs/NaNs from our quantization scheme.
4.1 Subnormals and Infs/NaNs
The first set of experiments measure the effect of excluding subnormals or including Infs/NaNs since both reduce the numeric values representable by our quantization scheme, see Figures 2, 3, and 4. Here we use the same quantization scheme for weights as we do for activations. For the same bitwidth, Figure 3 shows no discernible difference in accuracies compared to Figure 2, while Figure 4 exhibits a significant drop in accuracies with fewer than 3 exponent bits. In fact, in each experiment there is no significant improvement in accuracies with more than 3 exponent bits. Finally, compared to results for a single exponent bit in Figure 2, which are by definition dynamic fixedpoint schemes, there is between a 1–30% improvement in accuracies when using dynamic floatingpoint schemes of the same bitwidth and 3 exponent bits. This improvement is more pronounced in MobileNet, less so in ResNet, negligible in GoogLeNet, and generally more significant for smaller bitwidths.
4.2 Activations and Weights
The second set of experiments measure the effect of trading exponent bits for significand bits on the activations and weights for , see Figure 5. When testing the response for activations we set for the weights, and when testing the response for weights we set for the activations. From Figure 5 we see that activations and weights both need at least a few significand bits, but beyond that there is no significant difference in accuracies between activations and weights or more significand bits.
4.3 Exponent and Significand Bits
The third and final set of experiments measure the effect of reducing the bitwidth of the weights at the cost of either exponent bits or significand bits all while setting and for activations, see Figure 6. When testing the response on weights for exponent bits we start with and and decrement by one until all while keeping . Similarly, when testing the response on weights for significands bits we start with and and decrement both and by one until . In Figure 6 it appears that weights for GoogLeNet and ResNet can scale down from 8 bits to only 5 bits without significant loss in accuracies, but for MobileNet weights can only scale down to 7 bits before loss in accuracies become prohibitive. Furthermore, weights appear less sensitive to the exact allocation of exponent bits versus significand bits, but instead respond to the bitwidth itself.
5 Discussion
Our dynamic floatingpoint quantization scheme and procedure yields endtoend post quantization inference accuracies similar if not indistinguishable to reference singleprecision floatingpoint models by calibrating against a single inference batch, all while shrinking hardware and energy costs by 4x or more by replacing 32bit operations with reducedprecision operations of 8bits or fewer. In particular, we achieve 100% normalized top1 accuracies for GoogLeNet for fp8 through fp6, whereas Intel recently reported slightly exceeding 60% for fp8 [2]. Furthermore, we found that for fp8 the best accuracies were obtained using or . Our method allows Xilinx FPGA users to create custom circuit designs for various quantization parameters and reconfigure their FPGAs to match each target network’s optimal parameters. In fact, our results show that one can achieve accurate inference results with as few as 3 exponent bits and that 4 exponent bits is generally no better than 3 exponent bits, which would seem to contradict a prevailing belief popularized by NVIDIA that "fp16 is great, what’s actually even better than fp16 is truncated fp32" [5]. Nevertheless, cost savings are even available for a variety of existing hardware by increasing the effective bandwidth, reducing the effective on and offchip storage, even reducing the effective toggle rate by using , a.k.a. int8, or , a.k.a. truncated halfprecision floatingpoint that can be casted onthefly to and from full halfprecision floatingpoint to perform arithmetic operations, albeit both at the potential cost of inference accuracies. We also demonstrated that for some networks fp7 and fp6 are viable alternatives to fp8 with and achieved inference accuracies superior to their dynamic fixedpoint scheme analogues, which can only be explained by the greater range and increased precision about zero provided by our dynamic floatingpoint scheme. Thus for the densest compute platform developers may reconfigure a Xilinx FPGA for a particular configuration that meets their inference accuracy requirements. Since we’re not (re)training here, our dynamic floatingpoint quantization scheme and procedure can be thought of as an offline network compression with as few as eight calibration images, which could even potentially be substituted with artificial images obtained by playing the network in reverse. Finally, we’re confident that we could scale down even further if allowed to re(train) with quantizationintheloop (QIL) like [11] given that our accuracies are just as good or better using only a small calibration set.
References
 [1] IEEE standard for floatingpoint arithmetic. IEEE Std 7542008, pages 1–70, 2008.
 [2] G. R. Chui, A. C. Ling, D. Capalija, A. Bitar, and M. S. Abdelfattah. Flexibility: FPGAs and CAD in deep learning acceleration. ISPD, 2018.
 [3] M. Courbariaux, Y. Bengio, and J.P. David. Training deep neural networks with low precision multiplications. arXiv:1412.7024, 2014.
 [4] P. D’Alberto and A. Dasdan. NonParametric InformationTheoretic Measures of OneDimensional Distribution Functions from Continuous Time Series, pages 685–696. 2009.

[5]
B. Dally.
Scaling of machine learning.
Scaled ML, https://www.youtube.com/watch?v=h3QKvUPg_AI, 2018.  [6] W. Dally. Highperformance hardware for machine learning. NIPS Tutorial, 2015.
 [7] Y. Fu, E. Wu, and A. Sirasao. 8bit dotproduct acceleration. White Paper: UltraScale and UltraScale+ FPGAs, 2017.
 [8] Google. TensorFlow. https://github.com/tensorflow/tensorflow/tree/r1.5/tensorflow/tools/graph_transforms, 2017.
 [9] S. Guadarrama. BVLC GoogLeNet. https://github.com/BVLC/caffe/tree/master/models/bvlc_googlenet, 2014.
 [10] P. Gysel, M. Motamedi, and S. Ghiasi. Hardwareoriented approximation of convolutional neural networks. arXiv preprint arXiv:1604.03168, 2016.
 [11] P. Gysel, J. Pimentel, M. Motamedi, and S. Ghiasi. Ristretto: A framework for empirical study of resourceefficient inference in convolutional neural networks. IEEE Transactions on Neural Networks and Learning Systems, pages 1–6, 2018.
 [12] K. He, X. Zhang, S. Ren, and J. Sun. Deep risidual learning for image recognition. arXiv:1512.03385, 2015.
 [13] K. He, X. Zhang, S. Ren, and J. Sun. Deep residual networks. https://github.com/KaimingHe/deepresidualnetworks, 2016.
 [14] M. Horowitz. 1.1 computing’s energy problem (and what we can do about it). In 2014 IEEE International SolidState Circuits Conference Digest of Technical Papers (ISSCC), pages 10–14, 2014.
 [15] A. G. Howard, M. Zhu, B. Chen, D. Kalenichenko, W. Wang, T. Weyand, M. Andreetto, and H. Adam. MobileNets: Efficient convolutional neural networks for mobile vision applications. CoRR, abs/1704.04861, pages 1,2,7,8,12,13, 2017.
 [16] F. N. Iandola, M. W. Moskewicz, K. Ashraf, S. Han, W. J. Dally, and K. Keutzer. SqueezeNet: AlexNetlevel accuracy with 50x fewer parameters and 1MB model size. arXiv:1602.07360, 2016.
 [17] B. Jacob, S. Kligys, B. Chen, M. Zhu, M. Tang, A. Howard, H. Adam, , and D. Kalenichenko. Quantization and training of neural networks for efficient integer arithmeticonly inference. arXiv:1712.05877v1, 2017.
 [18] A. Krizhevsky. cudaconvnet. https://code.google.com/archive/p/cudaconvnet/, 2012.
 [19] A. Krizhevsky, I. Sutskever, and G. E. Hinton. Imagenet classification with deep convolutional neural networks. In Advances in Neural Information Processing Systems, pages 1097–1105, 2012.
 [20] Y. Lecun, L. Bottou, Y. Bengio, and P. Haffner. Gradientbased learning applied to document recognition. Proceedings of the IEEE, pages 2278–2324, 1998.
 [21] S. Migacz. 8bit inference with TensorRT. GPU Technology Conference, 2017.
 [22] K. Simonyan and A. Zisserman. Very deep convolutional networks for largescale image recognition. arXiv:1409.1556, 2014.
 [23] C. Szegedy, W. Liu, Y. Jia, P. Sermanet, S. Reed, D. Anguelov, D. Erhan, V. Vanhoucke, and A. Rabinovich. Going deeper with convolutions. arXiv:1409.4842, 2014.

[24]
S. Yang.
MobileNetCaffe.
https://github.com/shicai/MobileNetCaffe, 2017.
