1 Introduction

Software and service marketplaces are increasingly used to rapidly assemble powerful online applications. Initially, the focus has been on downloadable software artefacts only [1, 2], but increasingly, developers expect brokered software running as hosted and managed service instances with modest configuration effort [3]. Owing to the popularity of serverless computing [4], marketplaces for cloud functions are particularly suited to accommodate this need [5]. Such functions are considered small, re-usable and composable entities whose ephemerality and statelessness are attractive to developers of extensible applications, event-driven systems and scientific workflows [6]. Although in practice cloud functions have issues such as lack of portability and arbitrary resource limits in the Function-as-a-Service (FaaS) hosting environments of many commercial public clouds, developers recognise the potential for improvement and have come up with workarounds and patterns to many of them [7]. In conjunction with marketplaces, hubs and repositories offering readily configured cloud functions as plug-in solution, the FaaS platforms and tools might eventually evolve into holistic, polyglot and cross-vendor Platform-as-a-Service (PaaS) offerings closely matching the productivity and simplicity expectations of many developers [8].

While not the first marketplace for cloud functions [9], and despite much smaller scale compared to traditional software artefact repositories such as Maven Central and Docker Hub, the Serverless Application Repository by Amazon Web Services (AWS SAR111AWS SAR: https://aws.amazon.com/de/serverless/serverlessrepo/) has certainly become the most well-known and widely used representative. For function developers, SAR allows for public offerings of AWS Lambda functions, under the condition of open source implementations. For developers of function-based (serverless) applications, SAR offers either Lambda-deployable or, for functions marked public, also private FaaS-deployable common dependency functions, as well as orchestrations involving multiple functions and BaaS subscriptions. An example of a such a dependency function with high degree of re-usability is the image-moderation-chatbot function which removes images with explicit content from chats, so that developers of chat applications can focus on core parts of their applications. Another example would be a conjunction of retrieving log files to Lambda and sending the processed output to Slack – a chain of two functions which can be represented as composite application in SAR, as demonstrated by the cw-logs-to-slack function.

According to AWS, the main advantage of using SAR in general is that it makes several steps superfluous including code cloning, compilation, packaging and publishing to AWS Lambda. Having appeared in early 2018, little is known about this marketplace and about the cloud functions and function-based applications delivered through it. This absence of documented knowledge is in contrast to the increasing relevance of integrating cloud functions into software applications [10, 11], and furthermore in contrast to an increasingly active community mining software repositories [12, 13].

In this quantitative study, the aim is thus to gain insights into how functions are implemented, offered and deployed. For this purpose, the evolution of function-level metadata, code-level metadata and code-level implementation statistics of Lambda functions offered through AWS SAR is investigated. For brevity, function-based applications as subsumed under the term function throughout the study. Three guiding research questions determine the study methods and procedures:

  1. How are cloud functions offered and described on commercial marketplaces? More precisely, which information can be extracted from metadata and which findings can be derived from a function-level metadata analysis alone?

  2. How are cloud functions implemented? More precisely, which programming languages, frameworks and structural code patterns can be identified?

  3. Which change patterns and trends on brokered cloud functions can be recognised over time? More precisely, is the assumed popularity growth of serverless computing reflected in growing numbers of functions on marketplaces and growing numbers of deployed cloud function services?

To answer these questions, the study first presents the research methods on metrics collection, function-level and code-level metadata analysis and code-level programming analysis. It then presents the results as corresponding answers . The results are then discussed in a broader context to stimulate follow-up work to reveal more detailed knowledge about the implementations. To maintain a high relevance, many result figures link to their continuously updated online counterparts in a live paper style. In the interest of brevity, no background section on serverless computing or the AWS serverless ecosystem (Lambda, Lambda@Edge, Step Functions, SAR, Serverless Application Model – SAM, CodePipeline, …) is included; peer-reviewed and authoritative background literature is widely available from the regularly curated Serverless Literature Dataset [14].

2 Research Method

The method used is continuous observation in conjunction with extraction, mining and conflation of function repository, code repository and artefact implementation. Hence, this work also contributes to the ongoing global research effort of assessing microservice implementations222MAO-MAO – Microservice Artefact Observatory: https://mao-mao-research.github.io/.

For the preparation of the quantitative analysis, AWS SAR was observed by the author first manually over a period of almost three months, from its launch at the end of February 2018 to mid-May 2018. Subsequently, the observation has been continued with automated tools over a period of one full year, from mid-May 2018 to mid-May 2019. As the observation is ongoing and the study merely presents a one-year snapshot, it covers the complete evolution timeline of AWS SAR across all offered Lambda functions with an increasing number of metrics and indicators.

On a daily automated basis, metrics about deployable functions (which do not require custom capabilities) have been collected, and moreover, function implementation code repositories publicly available for some of the functions have been tracked and evaluated, in particular on GitHub which turned out to host the vast majority of function code. Additionally, from mid-September to mid-December 2018, in-depth dissections of the metadata and code were initially performed, and from mid-January 2019 on have been an integral part of the automated tracking. Only since late April 2019, functions with custom capabilities have been added to the automated observation. Fig. 1 shows how the experiment unfolded over many months, including the undesired omission of historic raw data before the full scope has been achieved.

Figure 1: Timeline of the experiment on observation and mining AWS SAR

The full experiment setup at the end of the timeline is shown in Fig. 2. It shows how all research questions are answered through a rich dataset which is carried forward daily to gain up-to-date and increasingly precise insights. The dataset is produced by the function-level metadata supplied in JSON format by AWS SAR, the referenced licences and README documentation in plain text format, code-level metadata supplied in JSON format by GitHub, and code in various structured formats. Additionally, YAML-formatted deployment instructions are referenced from each function but are only accessible inside the AWS platform. The duration of each daily experiment run is dominated by the rate limitation of the GitHub API, enforcing 61+ second intervals between requests (marked with R). Hence, the duration grows linearly with the number of functions associated to code repositories.

Figure 2: Experiment setup to conduct quantitative analysis

All raw data as well as the aggregation and analysis scripts are available as open research dataset333Quantitative analysis research data: https://github.com/serviceprototypinglab/aws-sar-dataset,444Quantitative analysis scripts: https://github.com/serviceprototypinglab/aws-sar-analysis. The author and dataset curator encourages other researchers to perform deeper inspections and to continue the metrics collection for more targeted studies on both AWS Lambda-deployable and publicly available (privately deployable) cloud functions.

2.1 Function metadata collection

AWS SAR offers a web interface implemented as dynamically generated Scalable Vector Graphics (SVG) user interface to browse offered functions. Additionally, a web service query interface with JSON format and enforced pagination is available as feed endpoint

555AWS SAR feed: https://shr32taah3.execute-api.us-east-1.amazonaws.com/Prod/applications/browse. Upon retrieving this feed regularly, metadata entries with eight metrics become available. The algorithm for the retrieval of paginated metadata is given in Listing 1.

  undef
  100 # max 100
  IAM,NAMED_IAM,RESOURCE_POLICY,AUTO_EXPAND
LOOP   1.. UNTIL  =
          "https://...FEEDENDPOINT?pageSize=" +
        if  > 1
                   + "&pageNumber=" +
           + "&includeAppsWithCapabilities=" +
          download()
        IF  = 1

        LOOP

Listing 1: Retrieval of AWS SAR feed

The default feed only lists cloud functions which run in unprivileged mode. In contrast, parameterisation allows for specifying resource capabilities and custom identity and access management rules, including also functions requiring these at runtime. The algorithm is therefore designed to fetch all functions while the information about required capabilities is preserved for post-processing. From the metadata, references to further data sources are extracted and processed, crossing multiple system boundaries as outlined in the research method figure.

2.2 Function metadata analysis

To give an answer to , the following analysis steps on individual data fields and metrics are carried out on the retrieved metadata :

  1. Distribution of discrete features among , including vendors and their market shares, labels, deployment counts and averaged deployment ratios

  2. Short description text metrics such as length and language

  3. Referenced long description text and licence text metrics, including a distribution of licencing options

  4. Presence and type of code URLs, also serving as prerequisite for answering

  5. Necessary capabilities and custom IAM rules

  6. Metadata quality issues across all metrics, in particular metadata consistency

2.3 Code repository data collection and analysis

To give an answer to , all identified code URLs are filtered, examined and checked out for code and configuration analysis. The filtering distinguishes between GitHub repositories, other recognisable public repositories, plain websites, invalid entries, and missing entries. GitHub repositories are examined for statistical information on popularity and the dominant programming language. Moreover, deployment artefacts are extracted to get a better picture of how cloud functions are implemented and deployed. From these, further references to local files and archives or even remote files are followed.

A daily snapshot of all publicly accessible valid repositories is maintained updated and processed with code and configuration analysis tools. Among them are standard tools such as SLOCcount [15], but also custom tools to determine specific code metrics and AWS SAM deployment entries.

The subsequent answer to is based on the evolving timeseries of all metadata and data which is stored in an efficient way, storing and transferring only actual changes as they happen.

3 Results

In this section, the state of AWS SAR at the end of the one-year automated observation period is reported on, based on snapshot day May 11, 2019. The timeline which led to this state starting from the launch of the marketplace is also shown for selected metrics, with live update links for evolving metrics.

3.1 How functions are offered

Data model.

AWS SAR contains functions (more rigorously, orchestrated function-based applications) of which metadata, FaaS configuration and deployment are described according to the AWS Serverless Application Model (AWS SAM) specification. The original JSON configuration format captures mostly technical properties including at package level (version numbers, dependencies) and at configuration level (execution handler, assigned runtime memory, timeout, parameter annotations and event trigger connections). The extended YAML deployment format introduced with SAM adds bindings to BaaS as well as nested application support to combine multiple functions. On top of these technical characteristics, the static publishing metadata model for AWS SAM functions in AWS SAR contains the following JSON-formatted properties which are typically given by the function developers upon registration in the repository:

  1. Application name without uniqueness guarantees (e.g. alexa-skills-kit-nodejs-factskill)

  2. Author (publisher, e.g. Alexa Skills Kit)

  3. URL (e.g. GitHub repository, home page)

  4. Human-readable description (e.g. This Alexa sample skill is a template…)

  5. Labels (tags, e.g. skills,fact,alexa)

  6. Licencing information, README and version information – not part of the exported data model, but linked to it

  7. Required capabilities or custom identity rules – if not present, the function will execute in unprivileged mode

The publishing process differentiates between publicly offered functions, which most be open source and can therefore be deployed (with evident issues) in other cloud environments, and private functions which are only visible within one account. After publishing a public function, this model is successively enhanced with dynamic information by the marketplace.

  1. Fully-qualified unique resource identifier (e.g. arn:aws:serverlessrepo:
    us-east-1:*:applications/alexa-...
    )

  2. Number of deployments, serving as measure for popularity along with associated code repository popularity metrics

Function and deployment statistics.

As of mid-May 2019, there are 533 public functions in AWS SAR by 232 vendors, with the top vendor being ’AWS’ (105 functions), followed by an individual (29), ’AWS Secrets Manager’ (15) and a long tail of various companies and individuals. The global average supply is 2.3 functions per vendor. These numbers suggest a comparatively small community of independent Lambda developers making use of the repository. The enforced upper bound is 100 public applications per account and region, which is exceeded only by ’AWS’. The limit does not apply to private functions which are however not exposed through the public repository interface and not considered in this study; hence, the number of functions registered in the marketplace overall remains unknown but can be expected to be much higher than the number of public functions.

Of all functions, 95 (17.8%) require special capabilities or custom rules; five functions (0.9%) require even three capabilities in conjunction. There is no automated way to retrieve justifications for any privileged execution, suggesting that problems similar to privileged mobile phone applications [16] may occur.

Correspondingly, there have been 60010 deployments of the offered functions, with the vastly dominating top deployment being alexa-skills-kit-nodejs-factskill which alone is deployed more than all other cloud functions combined. This top spot is followed by various similar Alexa skills such as nodejs-triviaskill and nodejs-howtoskill, but also the obligatory hello-world function and SecretsManagerRDSMySQLRotationSingleUser. Yet again, a long-tail distribution follows with several popular variants of database rotation functions. The top ten deployments are shown in Table 1.

Function Vendor Depl Perc
alexa-skills-kit-nodejs-factskill Alexa Skills Kit 32434 54.0%
alexa-skills-kit-nodejs-triviaskill Alexa Skills Kit 2771 4.6%
hello-world AWS 2058 3.4%
SecretsManagerRDSMySQLRotationSingleUser AWS Secrets Manager 1971 3.3%
alexa-skills-kit-nodejs-howtoskill Alexa Skills Kit 1631 2.7%
SecretsManagerRDSPostgreSQLRotationSingleUser AWS Secrets Manager 1125 1.9%
microservice-http-endpoint AWS 763 1.3%
alexa-skills-kit-color-expert-python AWS 672 1.1%
image-resizer-service Cagatay Gurturk 602 1.0%
SecretsManagerRDSMySQLRotationMultiUser AWS Secrets Manager 558 0.9%
Table 1: Serverless application deployment numbers in AWS SAR (Abbreviations: Depl – Deployments; Perc – Percentage)

Overall, AWS through its multiple vendor designations offers 26% of all functions but due to their popularity their functions account for 84% of all deployments, including the top-eight functions available from the repository which alone combine to 72%. Comparatively, these are the outstanding averaged deployment ratios for vendors across all of their functions:

  1. AWS or the AWS-related Alexa and Amazon brands with 50 or more deployments per function: ’Alexa Skills Kit’ (7473), ’Amazon API Gateway Team’ (325), ’AWS Secrets Manager’ (292), ’Amazon API Gateway’ (198), ’AmazonConnectSalesforceIntegration’ (133), ’AWS’ (73), ’Alexa for Business’ (55)

  2. Third-party companies or individuals with over 200 deployments per function: ’Cagatay Gurturk’ (602), ’Digital Sailors’ (284), ’Datadog’ (288), ’evan chiu’ (267) and ’Jagsp’ (229)

The global average is 113 deployments per function, and 259 deployments per vendor, which with the exception of three AWS-designated vendors and four individuals is not exceeded by any vendor. When discarding the functions requiring capabilities, the averages are significantly higher with 133 deployments per function and 316 deployments per vendor. In other words, providing functions running in unprivileged mode leads to an average 18-22% popularity boost.

Duplicity statistics.

The documentation of SAR does not inform about whether function identifiers without any additional qualifiers (account name or ARN) are supposed to be unique from a user perspective. In practice, duplicates are occasionally visible. In two such cases, AWS-provided functions (kinesis-firehose-cloudwatch-logs-processor and api-gateway-multiple-origin-cors) are also provided by individuals under the same name but with different licences and potentially different runtime behaviour. In another case, a function inbound-ses-spam-filter even appeared twice offered by AWS as vendor, with identical record including the fully-qualified identifier.

Licence statistics.

In AWS SAR, each function metadata references a mandatory licence text and a longer README file. The analysis shows that uniformity is not enforced. Out of 531 licences, the dominating ones (including variants) are: MIT Licence (40.5%), Apache Licence (21.7%) and the proprietary Amazon Licence (4.9%), ahead of the otherwise traditional GNU GPL (1.9%) which, surprisingly, contains one instance of the 30-year old GPLv1 (

Voice-Lexicon-API

function). A total of 15 licences occurs more than once. In contrast, 7.9% of licence texts are unique legal texts, and another 15.4% are unique short texts not corresponding to actual licencing information but rather containing placeholder text. Fig. 3 shows the distribution of licences in a chart.

Figure 3: Distribution of licences across functions

Documentation statistics.

From a software developer perspective, finding the right function quickly is highly important. An efficient function search requires appropriate tags, high-quality brief descriptions and extensive documentation.

Among all functions, 417 (78.2%) are tagged while 116 (21.8%) are not. In total, there are 1914 tags which corresponds to an average of 3.6 tags per function. Considering that there are 750 unique tags in total, each tag is on average re-used less than 2.6 times which indicates that most tags are not currently useful to search for candidate functions. The most-used tags with at least 30 occurrences are predominantly AWS-specific terms such as ’lambda’ (92 times), ’s3’ (59 times), ’nodejs’, ’AWS’, ’api’, ’Lambda’ and ’dynamodb’. On average, a tag is 7.3 characters long, while some are more descriptive and up to 29 characters long (salesforce-api-access-manager).

Figure 4: Distribution of tag instances per unique tag (live update available)

The long-tail distribution of selected tags across the frequency spectrum on cloud functions is shown in Fig. 4. Additionally, Table 2classifies the 15 most-used tags according to whether they describe a generic technical subject or technology or a vendor-specific service, referring to dependencies within the AWS ecosystem. Evidently, the most-used tags are not descriptive enough for functional discovery but rather used as filter for technology alignment.

Tag Frequency Generic Term Vendor Term
lambda 90 X
s3 59 X
nodejs 44 X
AWS 42 X
api 32 X
Lambda 31 X
dynamodb 30 X
python 28 X
serverless 27 X
sample 25 X
sns 24 X
logs 19 X
data 18 X
finance 17 X
excel 17 X
Table 2: Most-used tags across functions

The short description text for Lambda functions is limited to 256 characters. Consequently, description texts vary almost linearly from few characters such as ’This is a test’ and around 20 similarly unexpressive descriptions to the permissible maximum such as ’This is a serverless component which sends an email to specified email addresses…’. Interestingly, one of the descriptions is in Japanese while all others are in English, and one is a link to a website. The similarity ratio among all descriptions, applicable to all text strings with 90% overlap or more, is 14.1%. This number suggests that around one out of seven functions is a feature or implementation variant of another one.

With a range comparable to that of licences and short descriptions, the mandatory README files range from few-character placeholders to extensive texts with multi-section markdown structure of around 10-12 kB. A large outlier is

applicationName-227c1372-76ee-4797-a593-83d19dc4f264 provided by ’author’, arguably a test entry, whose README contains an entire web page of around 250 kB. This observation suggests that while AWS confirms manual code quality and licence conformance checks, there are no such checks on metadata or documentation, and the checks on licences do not prevent the emergence of a licence jungle.

3.2 How functions are implemented

Code repository information.

Among all functions, 455 (85.4%) specify a URL with further information. Sometimes, this carries the semantics of a semi-structured home page without direct reference to the implementation, but more often, applying to 392 functions (73.5%), it refers to a GitHub repository which can be analysed automatically. The number of unique repositories is 255, which implies that several functions share one repository, in fact up to 16 of them. The shared repository links are either identical, so that finding the corresponding implementation and configuration becomes heuristic, or different by path and/or branch so that a 1:1 mapping of function to implementation location remains possible. Among the non-GitHub links, the majority point to the vendor sites ’aws.amazon.com’ (13) and ’www.streamdata.io’ (11), while most others have only singular or double occurrence. The dominance of GitHub, beside the popularity of the platform itself, can be explained with the streamlined code publishing process in AWS CodePipeline which updates cloud functions in AWS SAR with every Git commit.

Moreover, some URLs are invalid either syntactically or by referring to non-existing or no longer available content, to password-protected private repositories or to collections of repositories rather than a single repository. Hence, of the 392 GitHub repositories, only 365 (93.1%) could be eventually assessed; among the unique repositories, discarding differences in just the paths, only 238 (93.3%), consequently containing 374 cloud functions in 325 different paths or branches. Even less URLs point properly to the directory containing only the relevant function code, requiring further manual work before an eventual code analysis and leading to unnecessary transmission of repository overhead.

Code repository characteristics.

The aggregate size of the repositories is 2.4 GB. For practical reasons of copying referenced paths and files and the ability to employ external statistics tools, a checked-out copy weighs in at 6.8 GB. Extracting all directories referenced from function metadata, and removing any superfluous versioning information, produces a self-contained implementation folder with a net size of 4.4 GB.

The largest repository by far is lambda-packs which contains 21 pre-compiled Lambda functions, such as Tesseract, Chromium and Pandas, including dependency libraries. Eight of these functions reference the entire pack collection, contributing to a high and redundant capacity requirement which is avoided by the compact duplicate-considerate representation. The repository with most functions is awslabs/serverless-application-model, containing the popular hello-world function along with many others, for a total count of 106 including variants and tests, of which 83 are published on SAR under the AWS and AWS Greengrass vendor designations.

The code repositories show a skewed GitHub popularity distribution with significant factors (around 20 to 80) between the mean and median values. The overall top repository (

hello-world and its variants) has 5146 stars, 326 watchers and 1183 forks.

Programming languages.

Programming languages are assessed on three levels: code repository metadata, code files, and Lambda configurations.

On the code repository metadata level, the most popular languages are indicated to be JavaScript with 108 functions (29.6%) and Python with 206 functions (56.4%), followed by 10 functions each with Go and Java code (2.7% each).

Relative to the assessable code bases spread across 322 unique folders, 159 functions directories (50.0%) contain JavaScript code and 140 (44.0%) contain Python code, irrespective of the code size or complexity, revealing a slightly different picture mostly caused by shared repositories. Moreover, repositories contain a substantial amount of maintenance languages such as Shell code (153 or 48.1%) and Perl (117 or 36.8%). Minor languages with occurrence in less than 10 directories according to both statistics are Java and Go. Despite the theoretic possibility of multiple languages being used per repository, this is hardly the case according to the observation. Hence, polyglot implementations are not common and despite increasing language support by all FaaS providers, developer interest beyond JavaScript and Python is limited. This confirms previous empirical findings [17].

Relative to the FaaS runtimes specified in the Lambda configuration files, often more than one per directory due to composite functions or variants, 305 functions out of 587 (52.0%) use different versions of JavaScript, 214 (36.5%) different versions of Python, and very few indicate either another runtime (5.6%) or none (6.0%).

Concerning the functionality, the complexity ranges from multi-functional function suites such as Serverless Galeria for image processing to very simple and even profane functions such as a ’daily doggo’ picture submission service and a nude filter.

Figure 5: Programming languages and code sizes (live update available)

Fig. 5 summarises the programming languages according to the code files analysis. Repositories with more than 3000 lines of code are excluded for reasons of visualisation, leaving 306 out of 322 unique code folders (95.0%) while excluding among others the largest repository with over 8 million lines of predominantly Python code, most of which is not representative of the actual cloud function. The diagram shows a large similarity of the middle section in which more than half of the code consists of maintenance shell scripts while the distinct bars show JavaScript (darker grey) and Python (brighter grey).

Programming models.

This study provides only a high-level sample peek into the code structures and programming models of the cloud functions themselves. The reason for this limitation is the large diversity in terms of structures, models and patterns, and the need to develop custom metering tools for each programming language, in conjunction with the nondeterministic mapping of code repository contents to functions. Nevertheless, the sampling already confirms some previously empirically confirmed patterns such as dispatcher functions [17]. Table 3 shows a sample of ten different functions from the vendor ’AWS’. Its repository folder identifiers are taken from the reference dataset.

Id# Language Dependencies Files Code
3-102 python requests 1 ”dispatcher”, 21 functions
3-103 nodejs algorithmia 1 ”simple”, 2 nested callbacks
3-107 python requests 1 ”simple-iterator”
3-108 mixed (algorithmia) 2 ”simple”, global variables
3-113 nodejs algorithmia 1 ”simple”, 1 callback
3-114 python 1 ”simple-iterator”, 5 methods
3-116 python requests 1 ”dispatcher”, 21 functions
3-118 python requests 1 ”simple”, 2 functions
3-121 python requests 1 ”dispatcher”, 10 functions
3-127 nodejs 1 ”simple”, 3 functions
Table 3: Structural Lambda code characteristics

Only one out of ten cloud function implementations uses object-oriented programming. Noteworthy is the popularity of the requests module which suggests that it could be included in Lambda’s Python runtime by default. Repository folder 3-108 (function cloudwatch-alarm-to-slack-python) contains both a Python and a JavaScript implementation of the same function, presumably due to a programming mistake by copying cloudwatch-alarm-to-slack without removing the original code file. All other folders contain a single source file. The code analysis shows further sources for duplicity, such as almost-identical functions with slightly different syntax to target distinct versions of a programming language, for instance, Python 2.7 and Python 3.6.

Function application orchestration.

The exploration of SAM files allow for a better understanding of function implementation retrieval and the composite nature of Lambda-based applications. In total, there are 509 SAM files or on average 1.6 per code folder. Finding them is a heuristic process due to different names, although many are called template.yaml, and due to the co-existence with other YAML files in many software projects.

285 code repositories (88.5%) contain SAM files which configure the Lambda execution and reveal bindings to BaaS through resource definitions. Among all SAM files, 587 resources of type ’AWS::Serverless::Function’ are defined, averaging more than one per file and covering 272 (95.4%) of all code folders. Beyond this dominant resource entry, several BaaS entries stand out albeit all at lesser scale. The top resources are ’AWS::S3::Bucket’ (103, 20.2%), ’AWS::IAM::Role’ (61, 12.0%), ’AWS::Serverless::Api’ (45, 8.8%) and ’AWS::DynamoDB::Table’ (44, 8.6%). This suggests that the typical Lambda-based application stores blob data on Amazon S3, relational data in DynamoDB, and is invoked externally through the API Gateway.

A clustering analysis discarding the multiplicity of resource types reveals common structures of serverless applications as precursor to a deeper cloud function pattern analysis which has recently become a research topic

[18]. There are 93 distinct resource composition types across all SAM files of which nine can be considered significant due to occurring more than five times each. Table 4 shows these patterns, among which the single function is occurring in every second serverless application. This does not necessarily mean that no BaaS is involved in such applications, but it does depart with the view that in practice, serverless applications are mostly expressed as explicit composition of a FaaS resource with one or more BaaS resources. Among the most-popular functions, Alexa Facts Skill has its data hard-coded in the implementation and Alexa Trivia and HowTo Skills load data from local files. Despite Lambda resource limits, such almost monolithic designs appear to be popular with developers.

Type Occurrences Percentage
Function 269 53.0%
Function + S3 (storage) 40 7.9%
Function + API-Gateway 25 4.9%
Function + SNS (notifications) 19 3.7%
Function + SimpleTable (database) 13 2.6%
Function + DynamoDB (database) 11 2.2%
Function + Permission 8 1.6%
Function + Kinesis (streaming) 6 1.2%
Function + IAM (authorisation) 6 1.2%
Table 4: Serverless application composition types in AWS SAR

On the other end of the spectrum, individual compositions with only one occurrence but multiple resources exist. The most complex composition, named api-gateway-dev-portal, involves 17 resource types including the AWS cloud services CloudFront, Cognito, DymamoDB, Route53, S3, SNS, API Gateway and IAM, as well as custom resource policies and other capabilities.

Among all SAM files, 69 reference no code, 63 reference only remote (S3-hosted) code, 4 reference local code encapsulated in ZIP files, and 373 reference repository-local code paths. The definitions without code are in most cases either composite applications or pre-configured blank templates in which developers still insert code but are otherwise already readily connected to BaaS. By excluding code repositories which reference no or only remote data, the cumulative code size shrinks from 4.4 GB to a mere 585 MB, making a further code analysis easier.

Entities, relations and numbers.

The entire drill-down process from the AWS SAR metadata to code repositories, function-specific directories, SAM files and external implementation references is shown in Fig. 6. Eventually, the rather complex constructs lead to key metrics on the use of FaaS and BaaS such as occurrence statistics and patterns.

Figure 6: Code drill-down process from SAR to FaaS and BaaS metrics

3.3 Which change patterns exist

Evolution of functions and deployments.

At launch time on February 28, 2018, AWS SAR contained already 180 functions, based on approximated manual observation. This number grew to approximated 260 on mid-May 2018. The further development captured through automated observation is shown in Fig. 7, first still approximated until mid-July, 2018, and afterwards, due to more precise measurements, as actual numbers, with privileged functions omitted from the measurements until late April 2019. After one year of automated observation, 438 non-privileged and 533 overall public functions (with ”caps” meaning required deployment capabilities) have become available. Overall, a stable average growth of around 14-16 functions per month is visible, corresponding to a declining month-over-month growth more than 6% to less than 1%, averaging at slightly below 4%.

Figure 7: Number of cloud functions at AWS SAR over time (live update available)

In comparison, other polyglot microservice artefacts show a similar growth rate, with slightly above 4% for Helm charts over the same observation period. Long-established repositories for programming language-specific artefacts however show slower monthly growth rates, such as PyPI for Python libraries (2.4%), Maven for Java libraries (1.1%) and Ruby Gems (0.5%).

An important complementary metric to the growth is the volatility, because the growth curve alone does not express neutralising additions and removals of cloud functions. The volatility with daily additions and removals is shown in Fig. 8. Over a period of 304 days, around 221 functions were added and 71 removed, a damping in the potential growth rate of around 24%. Each day, an average of 0.7 additions and 0.2 removals occur, with few changes over time to these numbers and only few spikes mostly related to mistaken duplicate entries. The reasons for function removals are not clear and might include renaming as well as intermittent depublication.

Figure 8: Volatility of cloud functions at AWS SAR over time (live update available)

While the growth and decline in the number of functions represents the supply side, function deployments signal the corresponding demand side and are therefore analysed in the same context.

Figure 9: Ratio of AWS-provided and third-party-provided functions and their deployments over time (live update available)

Notably, despite a similar growth in AWS SAR vendor diversity, and in consequence a decreasing share of AWS-provided functions among all vendors, the share of AWS-provided function deployments has been initially increasing with almost opposite tenacity before remaining stable, as evidenced in Fig. 9. Much of this growth can be attributed to the popularity of Alexa functions. Again, the figure includes privileged functions from end-April 2019, visualised by a small sudden reduction of the shown ratios.

A peek into trends in serverless computing is permitted by extracting trending functions, defined as fastest-growing functions over the last month of the observation period. Evidently, the growth rate is infinite for newly appeared functions, and still very high for functions just published before the trend window or with just few initial deployments. Therefore, the analysis focuses on functions with already at least 100 deployments at the beginning of the trend window. Moreover, the growth rate is typically stabilising (although not necessarily low) for widely deployed functions, leading to an upper bound of 1000 deployments. Both bounds are arbitrarily chosen but allow for visualising the trends. Fig. 10 shows a cluster analysis of deployment numbers to growth rates.

Figure 10: Single-month growth rates (in %) of a relevant subset of functions (live update available)

According to the analysis, five Lambda functions are very popular with growth rates of 10% or more per month, higher than the overall average of 7.0%. But even among the selected 35 functions, some (e.g. signalfx-lambda-example-nodejs) show zero or near-zero growth. Among the overall top-five functions in terms of at least 1500 deployments, the growth rates are between 3.8% and, for the ubiquitous hello-world function, 13.4%.

The growth rate can be similarly determined for the supply side in terms of the number of functions offered by vendors. Fig. 11 shows an excerpt of growth metrics for all vendors with at least five functions in their portfolio at the beginning of the trend window. While most vendors show no growth over one month, two individuals as well as AWS stand out for significant additions, demonstrating isolated supply-side popularity with selected serverless application developers.

Figure 11: Single-month growth rates (in %) of a relevant subset of vendors (live update available)

Evolution of metadata quality.

Fig. 12 shows the timeline of functions with duplicate names.

Figure 12: Percentage of functions affected by duplicate names over time

Evidently, while duplicates are not prohibited by the SAR data model, they appear to result from copy and paste of function metadata by developers and are undesirable. Accordingly, upon occurrence they are quickly corrected in most cases. In March 2019, several functions were added twice by the vendor HERE Technologies, causing a larger spike which statistically affected every 20th function in the repository. Moreover, a baseline of at least two continuous duplicates remains, although it is negligible in practice as it affects only 1% of all offered functions.

Evolution of code repositories.

The evolution of code repositories associated to cloud functions starting in January 2019 is shown in Fig. 13. Interestingly, the growth period at the beginning of the year could be contributed almost exclusively to new repositories rather than additional functions from existing repositories.

Figure 13: Code repositories linked to cloud functions (live update available)

When comparing the number of repository forks with the deployments of cloud functions, one remarkable development is that forks exceed deployments. This means that repositories of many cloud functions are often cloned, perhaps in a hoarding manner. Only for the most popular Alexa functions, the number of forks can be explained by the popularity indicated by deployments, such as developers initially deploying the original code and then performing modifications or adding debugging statements in troubleshooting scenarios. Private deployments may also be a reason. A particular counterexample is s3-presigned-url which is forked a lot (1169 times) but hardly deployed (34). In this case, the discrepancy is due to the repository sharing. Hence, the n:1 mapping of cloud functions to repositories presents difficulties in deriving generalised statements on popularity.

4 Discussion

The study opens broader discussion potential on a number of topics. Three of them – re-use, vendors, and description quality – shall be discussed briefly here.

Function re-use.

Despite the current high industry interest around cloud functions and especially around AWS Lambda as one of the most-used services, the re-use potential of cloud functions needs to be explored in more detail. The almost monotonic but slow growth of Lambda functions in AWS SAR suggests that most software applications are not quickly rewritten to make use of functions, or that the resulting functions are not shared on open repositories, hubs and marketplaces.

Function vendors.

The fact that AWS operates both the SAR marketplace and many of the functions resembles the schema known from the Amazon marketplace, operated by its parent company, in which market share in products is increasingly sought by offerings by Amazon under different names. In AWS SAR, such offerings are openly named after AWS or well-known Amazon products such as Alexa; still, the longer-term implication of having the double role advantage, and its effect on the large share of deployments, will require more economic-analytical work.

Function description quality.

Even though the number of functions in SAR is still manageable, several data inconsistencies are evident. Functions with custom capabilities appear in the feed reserved for functions not requiring those (2 out of 10 of ’CAPABILITY_AUTO_EXPAND’), vendors designations are not always clear (Amazon WorkMail vs. AWS WorkMail), function names are not unique across vendors, documentation quality varies significantly, code repository links are outdated or do not refer to code repositories at all, and licence information consists of a mix of actual licence text and placeholder text. In order to increase the automation potential for enacting and using cloud functions dynamically, small inconsistencies are avoidable obstacles and should be avoided as part of the function provisioning quality checks.

5 Conclusions and Future Work

Answers to research questions.

This study evidently represents a snapshot of ongoing evolution. Summarising the details results presentation, the answers to the research questions are as follows.

  1. (How are cloud functions offered?) According to the principle of discoverability of (micro)services, cloud functions should be uniformly described. In practice, the pieces of this description are scattered across different systems, making discoverability harder than necessary and partially dependent on heuristics. Nevertheless, many cloud functions are subscribed with several metrics which contribute to the decision making process when building a function-based serverless application.

  2. (How are cloud functions implemented?) Despite attempt to support polyglot software development, cloud functions programming presents effectively a binary choice between two programming languages, JavaScript and Python. The function binding is another binary choice. Functions are either unbound, or bound to a structural composition of BaaS. Finally, although most function implementations have a clear representation in version control systems, the details of this representation varies between direct file access, archived (built) file archives, and remote files.

  3. (Which change patterns can be recognised?) After several years of commercial success and developer attraction around FaaS and other serverless computing offerings, a significant share of automation tasks and application functionality is covered by cloud functions. On repositories, the available cloud functions saturate the current demand, as the growth has slowed down (to around 1% per month) but deployments are still growing at linear rate (around 7% per month).

Contributions.

This work complements earlier mixed-method empirical studies on industrial practice in cloud function development [17]. It adds a ground truth perspective with varying degrees of representativeness with most metrics related to a few hundred serverless applications or cloud functions. Through available automated assessment scripts, assuming a further growth of the serverless computing and applications ecosystem, the representativeness can be reevaluated at a later point in time with litte effort. The main practical outcome of this work is a reusable evolving dataset containing metadata and code metrics from AWS SAR. Further data has been produced as side product of the work, including code dumps and additional repository mining scripts, and will be properly packaged and made available in the future.

Future work.

This work enables future quantitative research and innovation in the following directions.

  • Understanding microservices in practice. Cloud functions are one of the few microservice technologies which inherently offer a service interface, rather than being a mix of services and application support components, securing their position among ongoing microservice research [19, 20]. The metrics from AWS SAR give insights into practical design and implementation decisions by developers and could further be exploited to understand trends in microservice development including programming models and code structures.

  • Software design patterns. The resource compositions can be investigated deeper to identify not just statistical clusters, but actual patterns of how FaaS and BaaS resources are interacting and how data flows between them. Such an analysis will have to consider environment variables and other explicitly expressed links between the resources with intrinsic knowledge of the cloud provider’s resource model.

  • Runtime assessment of cloud functions. Moving beyond the code and configuration analysis, a generic runtime framework for testing and performance evaluation based on AWS Lambda or with FaaS/BaaS emulation (e.g. SAM-Local and Localstack) could be constructed. This would allow deeper insight into the execution behaviour over time, including performance deviations with varying configurations such as FaaS memory allocation or storage backend latency.

  • Open serverless marketplaces. The conjunction of open source FaaS marketplace frameworks [5] and the open source implementations underlying most of the functions offered on AWS SAR, compressed as single dataset by this work, allows for a rapid prototyping of serverless marketplaces with dozens to hundreds of working functions. The openness is impeded by the reliance on the SAM-CloudFormation mapping; through improved orchestration portability [21] and broader availability of open source BaaS alternatives, the impediment could be overcome.

Acknowledgements

The author thanks the student group aweSoME (Clara-Maria Barth, Timucin Besken, Alphonse Mariyagnanaseelan, Anna Katharina Fitze, Jürg Bargetze) at University of Zurich for extending the early analysis scripts with a code contribution of GitHub metadata retrieval and several idea contributions around code analysis.

References

  • [1] Rui Shu, Xiaohui Gu, and William Enck. A Study of Security Vulnerabilities on Docker Hub. In Proceedings of the Seventh ACM on Conference on Data and Application Security and Privacy, CODASPY 2017, Scottsdale, AZ, USA, March 22-24, 2017, pages 269–280, 2017.
  • [2] César Soto-Valero, Amine Benelallam, Nicolas Harrand, Olivier Barais, and Benoit Baudry. The Emergence of Software Diversity in Maven Central. CoRR, abs/1903.05394, 2019.
  • [3] Nick Bassiliades, Moisis Symeonidis, Panagiotis Gouvas, Efstratios Kontopoulos, Georgios Meditskos, and Ioannis P. Vlahavas. PaaSport semantic model: An ontology for a platform-as-a-service semantically interoperable marketplace. Data Knowl. Eng., 113:81–115, 2018.
  • [4] Hyungro Lee, Kumar Satyam, and Geoffrey Fox. Evaluation of Production Serverless Computing Environments. In IEEE 11th International Conference on Cloud Computing (CLOUD), San Francisco, CA, USA, July 2018.
  • [5] Yessica Bogado, Walter Ramón Benítez Dávalos, Josef Spillner, and Fabio López-Pires. Towards sustainable ecosystems for cloud functions. In Proc. European Symposium on Serverless Computing and Applications (ESSCA), Zurich, Switzerland, December 2018. CEUR-WS vol. 2330.
  • [6] José Luis Vázquez-Poletti and Ignacio Martín Llorente. Serverless Computing: From Planet Mars to the Cloud. Computing in Science and Engineering, 20(6):73–79, 2018.
  • [7] Eric Jonas, Johann Schleier-Smith, Vikram Sreekanti, Chia-che Tsai, Anurag Khandelwal, Qifan Pu, Vaishaal Shankar, Joao Carreira, Karl Krauth, Neeraja Jayant Yadwadkar, Joseph E. Gonzalez, Raluca Ada Popa, Ion Stoica, and David A. Patterson. Cloud Programming Simplified: A Berkeley View on Serverless Computing. CoRR, abs/1902.03383, 2019.
  • [8] Robail Yasrab. PaaS Cloud: The Business Perspective. CoRR, abs/1803.07680, 2018.
  • [9] Josef Spillner. Cloud Function Marketplaces as Enablers of Serverless Computing Communities. Service Prototyping Lab blog post, March 2018.
  • [10] Johann Schleier-Smith. Serverless Foundations for Elastic Database Systems. In CIDR 2019, 9th Biennial Conference on Innovative Data Systems Research (Gong Show), 2019.
  • [11] Kyriakos Kritikos and Pawel Skrzypek. A Review of Serverless Frameworks. In 2018 IEEE/ACM International Conference on Utility and Cloud Computing Companion (UCC Companion), 2018.
  • [12] Gerald Schermann, Sali Zumberi, and Jürgen Cito. Structured information on state and evolution of dockerfiles on github. In Proceedings of the 15th International Conference on Mining Software Repositories, MSR 2018, Gothenburg, Sweden, May 28-29, 2018, pages 26–29, 2018.
  • [13] Yuzhan Ma, Sarah Fakhoury, Michael Christensen, Venera Arnaoudova, Waleed Zogaan, and Mehdi Mirakhorli. Automatic classification of software artifacts in open-source applications. In Proceedings of the 15th International Conference on Mining Software Repositories, MSR 2018, Gothenburg, Sweden, May 28-29, 2018, pages 414–425, 2018.
  • [14] Josef Spillner and Mohammed Al-Ameen. Serverless Literature Dataset. Zenodo dataset (3rd revision) at https://doi.org/10.5281/zenodo.1175423, April 2019.
  • [15] Antonio Terceiro and Christina Chavez. Structural Complexity Evolution in Free Software Projects: A Case Study. In in QACOS-OSSPL 2009: Proceedings of the Joint Workshop on Quality and Architectural Concerns in Open Source Software (QACOS) and Open Source Software and Product Lines (OSSPL), 2009.
  • [16] Mark H. Meng, Guangdong Bai, Joseph K. Liu, Xiapu Luo, and Yu Wang. Analyzing Use of High Privileges on Android: An Empirical Case Study of Screenshot and Screen Recording Applications. In Information Security and Cryptology - 14th International Conference, Inscrypt 2018, Fuzhou, China, December 14-17, 2018, Revised Selected Papers, pages 349–369, 2018.
  • [17] Philipp Leitner, Erik Wittern, Josef Spillner, and Waldemar Hummer. A mixed-method empirical study of Function-as-a-Service software development in industrial practice. Journal of Systems and Software, 146:340–359, March 2019.
  • [18] Sanghyun Hong, Abhinav Srivastava, William Shambrook, and Tudor Dumitras. Go Serverless: Securing Cloud via Serverless Design Patterns. In 10th USENIX Workshop on Hot Topics in Cloud Computing (HotCloud 18), 2018.
  • [19] Manuel Mazzara, Antonio Bucchiarone, Nicola Dragoni, and Victor Rivera. Size matters: Microservices research and applications. CoRR, abs/1904.03027, 2019.
  • [20] Yu Gan, Yanqi Zhang, Dailun Cheng, Ankitha Shetty, Priyal Rathi, Nayan Katarki, Ariana Bruno, Justin Hu, Brian Ritchken, Brendon Jackson, Kelvin Hu, Meghna Pancholi, Yuan He, Brett Clancy, Chris Colen, Fukang Wen, Catherine Leung, Siyuan Wang, Leon Zaruvinsky, Mateo Espinosa, Rick Lin, Zhongling Liu, Jake Padilla, and Christina Delimitrou. An open-source benchmark suite for microservices and their hardware-software implications for cloud & edge systems. In Proceedings of the Twenty-Fourth International Conference on Architectural Support for Programming Languages and Operating Systems, ASPLOS 2019, Providence, RI, USA, April 13-17, 2019, pages 3–18, 2019.
  • [21] Elena Markoska, Ivan Chorbev, Sasko Ristov, and Marjan Gusev. Cloud portability standardization overview. In 38th International Convention on Information and Communication Technology, Electronics and Microelectronics, MIPRO 2015, Opatija, Croatia, May 25-29, 2015, pages 286–291, 2015.
