QPyTorch: A Low-Precision Arithmetic Simulation Framework

10/09/2019 ∙ by Tianyi Zhang, et al. ∙ cornell university 0

Low-precision training reduces computational cost and produces efficient models. Recent research in developing new low-precision training algorithms often relies on simulation to empirically evaluate the statistical effects of quantization while avoiding the substantial overhead of building specific hardware. To support this empirical research, we introduce QPyTorch, a low-precision arithmetic simulation framework. Built natively in PyTorch, QPyTorch provides a convenient interface that minimizes the efforts needed to reliably convert existing codes to study low-precision training. QPyTorch is general, and supports a variety of combinations of precisions, number formats, and rounding options. Additionally, it leverages an efficient fused-kernel approach to reduce simulator overhead, which enables simulation of large-scale, realistic problems. QPyTorch is publicly available at https://github.com/Tiiiger/QPyTorch.



There are no comments yet.


page 1

page 2

page 3

page 4

This week in AI

Get the week's most popular data science and artificial intelligence research sent straight to your inbox every Saturday.

1 Introduction

Low-precision arithmetic is one of the most successful techniques in compressing and accelerating Deep Neural Networks (DNNs). To obtain high-performance low-precision models, many works study low-precision training algorithms

Hubara et al. (2016); Courbariaux et al. (2015); Wu et al. (2018). Along with the advent of low-precision training techniques, there has been a growing interest in software that simulates low-precision computation in order to understand its statistical effects on training. This simulation circumvents the overhead of building hardware while enabling investigations into the numerical behaviors of different designs.

To facilitate empirical research on low-precision training, we introduce QPyTorch, a low-precision arithmetic simulation framework. In designing QPyTorch, we have the following objectives. First, we aim to support broad and general research into low-precision numeric formats. Popular machine learning frameworks like Tensorflow

Abadi et al. (2016) now support simulating fixed-point computation, in addition to the 16-bit low-precision floating point numbers that are often supported directly on hardware. However, recent algorithms often propose low-precision number formats that are more general than these options Mellempudi et al. (2017); Wang et al. (2018), including block floating point and non-standard-width floating point numbers. To better support this sort of research, we support a diverse range of numeric design choices with our framework, including allowing arbitrary mix-and-match of different precisions, number formats, and rounding options.

Second, we value efficiency on commodity hardware. The current state of low-precision training research often requires validations on large-scale, realistic problems (e.g. ImageNet

Russakovsky et al. (2014)). Efficient simulation enables fast iterations in empirical research. Unfortunately there is inherent trade-off between speed and generality—in some cases, we eschew support for a low-precision operation that would greatly diminish simulator efficiency. In this report, we document the scope of the features QPyTorch supports and evaluate our design choices regarding efficiency.

Third, we develop a convenient front-end interface. Low-precision simulation usually “hijacks” a regular computation graph in deep learning training, and quantization code can easily be buried within a complex machine learning codebase. QPyTorch provides proper abstractions to elucidate the high-level designs in low-precision training, which helps understanding and reproducibility. Additionally, our interface allows users to adjust the settings for individual layer or number categories independently. QPyTorch also implements a common set of low-precision training techniques from the literature

111For instance, many training algorithms keep a higher-precision model copy for gradient accumulation. Courbariaux et al. (2015); Wu et al. (2018); Wang et al. (2018); Yang et al. (2019), which can serve as a set of building blocks for future exploration.

Finally, we focus on the reliability of QPyTorch. Naive implementation of low-precision simulation can be error-prone. For example, high-precision numbers can be accidentally leaked into the training process. In the past, we have found quantization bugs in low-precision codebases that could potentially invalidate some conclusions in the published literature. It is our hope that QPyTorch can help prevent this class of error, both because QPyTorch contains standard test suites to validate the implementation, and because potential errors may be exposed more quickly by a growing open-source community working on a single codebase.

2 Related Works

Low-level low-precision packages. Tensorflow-Lite Jacob et al. (2017) supports dynamically quantizing a trained model into 8 bits at inference time and store computation results in floating point. QNNPACK Maher (2018) provides a mobile-optimized 8-bit fixed point implementation. FBGEMM Khudia (2018) provides low-level matrix-multiplication and convolution support for half precision floating point and 8-bit fixed point.

Low-precision simulation frameworks. TensorQuant Loroch et al. (2017) is one of the first software frameworks that supports fixed point computation simulation. Tensorflow Abadi et al. (2016) supports simulating fixed point computation of arbitrary bits with nearest rounding. In comparison, our framework supports a wider range of number formats and rounding options. QPyTorch also allows the users to configure individual layers and number categories independently.

3 Design

At its core, QPyTorch operates by (1) representing low-precision numbers as their corresponding floating-point number, and (2) simulating low-precision computation by running single-precision floating-point computation and then removing the extra precision through quantization. For individual base operations (e.g. scalar , ), this approach is equivalent to low-precision computation. However, for composite operations (e.g. matrix multiplication), this corresponds to using a high-precision accumulator rather than accumulating in the same low-precision format: this choice is standard in the literature Wu et al. (2018); Yang et al. (2019). For QPyTorch, we are motivated by efficiency: quantizing after each base operation would significantly slow down the simulator (see discussion in Loroch et al. (2017)).

3.1 Features of QPyTorch

Number Formats.

(a) Illustration of QPyTorch’s two-kernel approach.
(b) Example supported formats
Figure 1:

QPyTorch can simulate a diverse set of low-precision number formats (Fig 0(b)), including floating point, fixed point, and block floating point numbers. For floating point numbers, QPyTorch can simulate any floating point format that uses fewer bits than single precision (i.e. those that use fewer than 8 bits for exponent and fewer than 23 bits for mantissa). Among these are the Brain Floating Point (bfloat16) and the effective 8-bit and 16-bit format proposed in Wang et al. (2018). In the interest of efficiency, we do not simulate denormals, NaN, and Inf, as these numbers are expected to occur rarely in training and are often not all supported in low-precision hardware 2.

QPyTorch also supports fixed point, which is a popular format that has been used in many algorithms Gupta et al. (2015); Wu et al. (2018). QPyTorch can simulate fixed point numbers with arbitrary precision although the precision is again limited by the underlying single precision computation (restricting us to fixed-point numbers with at most 24 bits of precision). Block floating point numbers reduce the bit usage of floating point numbers by sharing the exponent bits across a block Yang et al. (2019). QPyTorch can simulate any block floating point format that allocates fewer than 8 bits for exponent and fewer than 23 bits for mantissa. The assignment of numbers to blocks appears to be an important design decision in low-precision training algorithms that use block floating point Zhou et al. (2016); Yang et al. (2019)

. QPyTorch supports assigning the block over an arbitrary dimension of a tensor or treating the tensor as an single block. Finally, QPyTorch provides a unified API to combine these primitive quantizations with additional PyTorch code to define more specialized formats

Wu et al. (2018); Zhou et al. (2016).

Rounding mode.

Stochastic rounding has been shown to be beneficial for neural network training Gupta et al. (2015). QPyTorch implements both stochastic and nearest-neighbor rounding. For handling the middle-points with nearest-neighbor rounding, QPyTorch supports round-away-from-zero, round-toward-zero, and round-to-nearest-even.

Front-end interface.

(a) Categories of numbers in low-precision training
(b) Example QPytorch implementation
Figure 2:

Neural network training involves distinctive groups of numbers De Sa et al. (2017). Figure 1(a) illustrates the different roles of weight, accumulator, gradient, activation, and error in a single layer. Different categories and different layers in a neural network may require distinct precision and quantization Gupta et al. (2015). QPyTorch provides a convenient interface to handle different number categories independently, allowing the search for more effective combinations of different precision, formats, and rounding mode. Specifically, QPyTorch injects the quantization of activation and error as a separate PyTorch module into each layer and abstracts the quantization of weight, gradient, and accumulators into a low-precision optimizer. In addition, we provide a useful tool to automatically inject the quantization modules so that low-precision networks do not require a separate model definition. Using these convenient designs, it only takes around 10 lines of code to convert an existing full-precision training codebase into a low-precision one (Figure 1(b)).

3.2 Two-Kernel Approach

One can imagine several potential designs for QPyTorch. The most straightforward is to utilize existing PyTorch operations directly. The caveat is that each PyTorch operation would launch a separate CUDA kernel and many separate launches are inefficient. Moreover, due to the lack of support for bitwise operations in PyTorch, this approach cannot simulate low-precision floating point numbers. From now on, we refer to this strategy as the many-kernel approach. On the other hand, we could implement a customized kernel for each common operation, such as matrix multiplication, convolution, nonlinearities, etc. This one-kernel design is a popular choice when efficiency is of major concern, e.g., in software packages designed to leverage low-precision hardware Maher (2018); Khudia (2018). Although fast, this approach is cumbersome for general research purposes: as any new operations arising in frontier research would require a separate kernel, this adds significant maintenance overhead. QPyTorch adopts an intermediate approach. We fuse instructions specific to quantization into a single kernel and then append it to a regular full-precision operation run in a separate kernel. Figure 0(a) illustrates this two-kernel approach.

4 Validation

To validate the correctness of our framework, we train various low-precision models. We use the CIFAR10 Krizhevsky and Hinton (2009)

dataset to benchmark the system performance. We first study applying stochastic gradient descent to train VGG16 models with two precision settings, half-precision floating point and 8-bit block floating point where each tensor is treated as a block. We apply standard data augmentation and borrow other training hyperparameters from

Yang et al. (2019). Then, we implement two state-of-the-art low-precision training algorithms Yang et al. (2019); Wu et al. (2018) in QPyTorch and compare to the reported performance. For SWALP Yang et al. (2019), we train a VGG16 model using the reported 8-bit small-block block floating point format. For WAGE Wu et al. (2018), we implement the customized VGG model and the specialized number format, which can be viewed as a variant of fixed point. Table 1 shows that QPyTorch performs as expected.

We also evaluate QPyTorch’s two-kernel approach. We cannot fairly compare to a one-kernel approach by modifying existing optimized full-precision kernels because source code for these kernels is not publicly available: therefore, we restrict our evaluation to a comparison between the two-kernel and the many-kernel approaches. We implemented the many-kernel approach directly through PyTorch operations, and compare it with our CUDA implementation of the two-kernel approach used in QPyTorch. Since PyTorch does not support bitwise shift operations, a many-kernel implementation of floating point quantization is not possible, so we restrict our comparison to the fixed point and block floating point formats. We denote our PyTorch implementation of fixed point quantization many-fixed and block floating point quantization many-block. Similarly, denote the fused kernels of QPyTorch two-kernel-fixed, two-kernel-block. We refer to the floating point quantization in QPyTorch as two-kernel-float. In Figure 3, we plot the wall clock time spent quantizing tensors of different sizes. Figure 3 demonstrates the efficiency of our two-kernel approach. Notably, two-kernel-fixed with nearest rounding on GPU is about 5x faster than many-kernel-fixed. In addition, for Block Floating Point which is most expensive to simulate, two-kernel-block is about 2.6x faster than many-kernel-block

. We observe similar results for stochastic rounding and quantizing on CPUs. Additionally, we compare the run time of training WAGE for one epoch. Figure

4 shows that QPyTorch effectively halves the end-to-end simulation overhead (3.9s vs. 7.56s).

Algorithm PyTorch QPyTorch FP16 SGD 6.88 6.89 Block8 SGD 8.24 8.4 WAGE 6.96 6.95 SWALP 6.7 6.67 Table 1: Error rate of four models trained with PyTorch and QPyTorch on CIFAR10. Figure 3: Wall Clock Time of Quantization Kernels. Figure 4: Wall Clock Time of training WAGE for one Epoch.

5 Conclusion and Future Work

In this report we introduce QPyTorch, a low-precision arithmetic simulation framework. QPyTorch targets low-precision training research, facilitating studies on various number formats, rounding choices. QPyTorch adopts a two-kernel approach for efficient simulation and offers a convenient interface that is tailored for recent algorithms. We validate QPyTorch by training low-precision neural networks in four diverse settings and demonstrate its efficency empirically.


  • M. Abadi, P. Barham, J. Chen, Z. Chen, A. Davis, J. Dean, M. Devin, S. Ghemawat, G. Irving, M. Isard, M. Kudlur, J. Levenberg, R. Monga, S. Moore, D. G. Murray, B. Steiner, P. A. Tucker, V. Vasudevan, P. Warden, M. Wicke, Y. Yu, and X. Zhang (2016) TensorFlow: a system for large-scale machine learning. In OSDI, Cited by: §1, §2.
  • [2] BFLOAT16 – hardware numerics definition. External Links: Link Cited by: §3.1.
  • M. Courbariaux, Y. Bengio, and J. David (2015) Binaryconnect: training deep neural networks with binary weights during propagations. In Advances in neural information processing systems, pp. 3123–3131. Cited by: §1, §1.
  • C. De Sa, M. Feldman, C. Ré, and K. Olukotun (2017) Understanding and optimizing asynchronous low-precision stochastic gradient descent. SIGARCH Comput. Archit. News, pp. 561–574. External Links: ISSN 0163-5964 Cited by: §3.1.
  • S. Gupta, A. Agrawal, K. Gopalakrishnan, and P. Narayanan (2015) Deep learning with limited numerical precision. In International Conference on Machine Learning, pp. 1737–1746. Cited by: §3.1, §3.1, §3.1.
  • I. Hubara, M. Courbariaux, D. Soudry, R. El-Yaniv, and Y. Bengio (2016) Binarized neural networks. In Advances in Neural Information Processing Systems 29, D. D. Lee, M. Sugiyama, U. V. Luxburg, I. Guyon, and R. Garnett (Eds.), pp. 4107–4115. Cited by: §1.
  • B. Jacob, S. Kligys, B. Chen, M. Zhu, M. Tang, A. G. Howard, H. Adam, and D. Kalenichenko (2017) Quantization and training of neural networks for efficient integer-arithmetic-only inference. CoRR abs/1712.05877. Cited by: §2.
  • D. Khudia (2018) FBGEMM. External Links: Link Cited by: §2, §3.2.
  • A. Krizhevsky and G. Hinton (2009) Learning multiple layers of features from tiny images. Cited by: §4.
  • D. M. Loroch, N. Wehn, F. Pfreundt, and J. Keuper (2017) TensorQuant - a simulation toolbox for deep neural network quantization. In MLHPC@SC, Cited by: §2, §3.
  • B. Maher (2018) QNNPACK. External Links: Link Cited by: §2, §3.2.
  • N. Mellempudi, A. Kundu, D. Das, D. Mudigere, and B. Kaul (2017) Mixed low-precision deep learning inference using dynamic fixed point. arXiv preprint arXiv:1701.08978. Cited by: §1.
  • O. Russakovsky, J. Deng, H. Su, J. Krause, S. Satheesh, S. Ma, Z. Huang, A. Karpathy, A. Khosla, M. S. Bernstein, A. C. Berg, and F. Li (2014) ImageNet large scale visual recognition challenge. arXiv abs/1409.0575. Cited by: §1.
  • N. Wang, J. Choi, D. Brand, C. Chen, and K. Gopalakrishnan (2018) Training deep neural networks with 8-bit floating point numbers. In Advances in Neural Information Processing Systems 31, S. Bengio, H. Wallach, H. Larochelle, K. Grauman, N. Cesa-Bianchi, and R. Garnett (Eds.), pp. 7685–7694. Cited by: §1, §1, §3.1.
  • S. Wu, G. Li, F. Chen, and L. Shi (2018) Training and inference with integers in deep neural networks. In ICLR, Cited by: §1, §1, §3.1, §3, §4.
  • G. Yang, T. Zhang, P. Kirichenko, J. Bai, A. G. Wilson, and C. D. Sa (2019) SWALP : stochastic weight averaging in low-precision training. In ICML, Cited by: §1, §3.1, §3, §4.
  • S. Zhou, Y. Wu, Z. Ni, X. Zhou, H. Wen, and Y. Zou (2016)

    DoReFa-Net: training low bitwidth convolutional neural networks with low bitwidth gradients

    arXiv preprint arXiv:1606.06160. Cited by: §3.1.
