Parallel Multi-Dimensional LSTM, With Application to Fast Biomedical Volumetric Image Segmentation

06/24/2015 ∙ by Marijn F. Stollenga, et al. ∙ 0

Convolutional Neural Networks (CNNs) can be shifted across 2D images or 3D videos to segment them. They have a fixed input size and typically perceive only small local contexts of the pixels to be classified as foreground or background. In contrast, Multi-Dimensional Recurrent NNs (MD-RNNs) can perceive the entire spatio-temporal context of each pixel in a few sweeps through all pixels, especially when the RNN is a Long Short-Term Memory (LSTM). Despite these theoretical advantages, however, unlike CNNs, previous MD-LSTM variants were hard to parallelize on GPUs. Here we re-arrange the traditional cuboid order of computations in MD-LSTM in pyramidal fashion. The resulting PyraMiD-LSTM is easy to parallelize, especially for 3D data such as stacks of brain slice images. PyraMiD-LSTM achieved best known pixel-wise brain image segmentation results on MRBrainS13 (and competitive results on EM-ISBI12).

READ FULL TEXT VIEW PDF
POST COMMENT

Comments

There are no comments yet.

Authors

page 10

This week in AI

Get the week's most popular data science and artificial intelligence research sent straight to your inbox every Saturday.

1 Introduction

Long Short-Term Memory (LSTM) networks [lstm97and95, Gers:99c]

are recurrent neural networks (RNNs) initially designed for sequence processing. They achieved state-of-the-art results on challenging tasks such as handwriting recognition

[Graves:09tpami], large vocabulary speech recognition [sak2014, sak2014large] and machine translation sutskever2014. Their architecture contains gates to store and read out information from linear units called error carousels that retain information over long time intervals, which is hard for traditional RNNs.

Multi-Dimensional LSTM networks (MD-LSTM [DBLP:conf/icann/GravesFS07]) connect hidden LSTM units in grid-like fashion111For example, in two dimensions this yields 4 directions; up, down, left and right.. Two dimensional MD-LSTM is applicable to image segmentation [DBLP:conf/icann/GravesFS07, graves:2009nips, byeon15] where each pixel is assigned to a class such as background or foreground. Each LSTM unit sees a pixel and receives input from neighboring LSTM units, thus recursively gathering information about all other pixels in the image.

There are many biomedical 3D volumetric data sources, such as computed tomography (CT), magnetic resonance (MR), and electron microscopy (EM). Most previous approaches process each 2D slice separately, using image segmentation algorithms such as snakes [Kass88]

, random forests

[Wang15] and Convolutional Neural Networks [ciresan2012nips]. 3D-LSTM, however, can process the full context of each pixel in such a volume through 8 sweeps over all pixels by 8 different LSTMs, each sweep in the general direction of one of the 8 directed volume diagonals.

Due to the sequential nature of RNNs, however, MD-LSTM parallelization was difficult, especially for volumetric data. The novel Pyramidal Multi-Dimensional LSTM (PyraMiD-LSTM) networks introduced in this paper use a rather different topology and update strategy. They are easier to parallelize, need fewer computations overall, and scale well on GPU architectures.

PyraMiD-LSTM is applied to two challenging tasks involving segmentation of biological volumetric images. Competitive results are achieved on EM-ISBI12 [cardona10]; best known results are achieved on MRBrainS13 [MICCAI15].

2 Method

We will first describe standard one-dimensional LSTM [Gers:99c] and MD-LSTM. Then we introduce topology changes to construct the PyraMiD-LSTM, which is formally described and discussed.

The original LSTM unit consists of an input gate (), forget gate222Although the forget gate output is inverted and actually ‘remembers’ when it is on, and forgets when it is off, the traditional nomenclature is kept. (), output gate (), and memory cell (

) which control what should be remembered or forgotten over potentially long periods of time. All gates and activations are real-valued vectors:

, where is the length of the input. The gates and activations at discrete time (=1,2,…) are computed as follows:

(1)
(2)
(3)
(4)
(5)
(6)

where () is a matrix multiplication, () an element-wise multiplication, and denotes the weights. is the input to the ’cell’ , which is gated by the input gate, and is the output. The non-linear functions and are applied element-wise, where . Equations (1, 2) determine gate activations, Equation (3) cell inputs, Equation (4) the new cell states (here ‘memories’ are stored or forgotten), Equation (5) output gate activations which appear in Equation (6), the final output.

2.1 Pyramidal Connection Topology

Figure 1: The standard MD-LSTM topology (a) evaluates the context of each pixel recursively from neighboring pixel contexts along the axes, that is, pixels on a simplex can be processed in parallel. Turning this order by (b) causes the simplex to become a plane (a column vector in the 2D case here). The resulting gaps are filled by adding extra connections, to process more than 2 elements of the context (c).

In MD-LSTMs, connections are aligned with the grid axes. In 2D, these directions are up, down, left and right. A 2D-LSTM adds the pixel-wise outputs of 4 LSTMs, one scanning the image pixel by pixel from north-west to south-east, one from north-east to south-west, one from south-west to north-east, and one from south-east to north-west.

If the connections are rotated by , all inputs to all units come from either left, right, up, or down (left in case of Figure 1–b). This greatly facilitates parallelization, since all the elements of a whole grid row can be computed independently, which does not work for MD-LSTM simplexes, whose sizes vary. However, this introduces context gaps as in Figure 1–b. By adding an extra input, these gaps are filled as in Figure 1–c.

A similar connection strategy has been previously used to speed up non-euclidian distance computations on surfaces [weber2008parallel]. There are however important differences:

  • [noitemsep]

  • We can exploit efficient GPU-based CUDA convolution operations, but in a way unlike what is done in CNNs, as will be explained below.

  • As a result of these operations, input filters that are bigger than the necessary filters arise naturally, creating overlapping contexts. Such redundancy turns out to be beneficial and is used in our experiments.

  • We apply several layers of complex processing with multi-channeled outputs and several state-variables for each pixel, instead of having a single value per pixel as in distance computations.

  • Our application is focused on volumetric data.

Figure 2: On the left we see the context scanned so far by one of the 8 LSTMs of a 3D-LSTM: a cube. In general, given dimensions, LSTMs are needed. On the right we see the context scanned so far by one of the 6 LSTMs of a 3D-PyraMiD-LSTM: a pyramid. In general, LSTMs are needed.

One of the striking differences between PyraMiD-LSTM and MD-LSTM is the shape of the scanned contexts. Each LSTM of an MD-LSTM scans rectangle-like contexts in 2D or cuboids in 3D. Each LSTM of a PyraMiD-LSTM scans triangles in 2D and pyramids in 3D (see Figure 2). An MD-LSTM needs 8 LSTMs to scan a volume, while a PyraMiD-LSTM needs only 6, since it takes 8 cubes or 6 pyramids to fill a volume. Given dimension , the number of LSTMs grows as for an MD-LSTM (exponentially) and for a PyraMiD-LSTM (linearly).

2.2 PyraMiD-LSTM

Figure 3: PyraMiD-LSTM network architecture. Randomly rotated and flipped inputs are sampled from random locations, then fed to six C-LSTMs over three axes. The outputs from all C-LSTMs are combined into one PyraMiD-LSTM layer and sent to the fully-connected layer.
