1 Introduction

Event recognition systems [Etzion and Niblett (2010)] process sequences of simple events, such as sensor data, and recognize complex events of interest, i.e. events that satisfy some pattern. Logic-based event recognition typically uses a knowledge base of first-order rules to represent complex event patterns and a reasoning engine to detect such patterns in the incoming data. Dialects of the Event Calculus (EC) [Kowalski and Sergot (1986)] have been used as a language for specifying definitions of complex events [Artikis et al. (2015)]. An advantage of this approach is that is offers direct connections to machine learning, via Inductive Logic Programming (ILP) [De Raedt (2008)], alleviating the task of manual authoring of event definitions.

Event recognition applications deal with noisy data streams. Methods that extract insights from such streams need to operate within tight memory and time constraints, building a decision model by a single pass over the training data [Gama and Gaber (2007), Gama (2010)]. Such a framework is under-explored in ILP, where all data is typically in place when learning begins. Alternatively, some ILP systems are capable of theory revision [Esposito et al. (2000)]. Still, such systems need multiple scans of the data to optimize their theories.

We present OLED (Online Learning of Event Definitions), an ILP system that learns EC theories in a single pass over a data stream. OLED uses the Hoeffding bound [Hoeffding (1963)], a statistical tool that allows to build decision models using only a small subset of the data, by relating the size of this subset to a user-defined confidence level on the error margin of not making a (globally) optimal decision [Dhurandhar and Dobra (2012), Domingos and Hulten (2000), Gama et al. (2011)]. OLED learns a clause in a top-down fashion, by gradually adding literals to its body. Instead of evaluating each candidate specialization on the entire input, it accumulates training data from the stream, until the Hoeffding bound allows to select the best specialization. The instances used to make this decision are not stored or reprocessed, but discarded as soon as OLED extracts from them the necessary statistics for clause evaluation.

In the learning problem we address in this work, target clauses are not unrelated, but depend on each other via the axioms of the EC, making it difficult to use common ILP practices that learn clauses in isolation. To handle this issue we use a decoupling scheme of the axioms of the EC during learning, thereby allowing to assess the quality of each clause separately, using a scoring function. Additionally, learning programs in the EC involves non-Observational Predicate Learning (non-OPL) [Muggleton (1995)], a setting where instances of the target predicates are not directly observable in the data. To handle non-OPL we use abduction [Denecker and Kakas (2002)], a framework that may be used for reasoning with incomplete information. We evaluate our approach on an activity recognition application and compare it to a number of batch learning techniques. We obtain results of comparable predicative accuracy with significant speed-ups in training time. We also outperform hand-crafted rules and match the performance of a sound incremental learner that can only operate on noise-free datasets.

The rest of this paper is structured as follows: In Section 2 we discuss related work, while in Section 3 we present some necessary background on the EC, ILP and the Hoeffding bound. In Section 4 we present OLED and in Section 5 we show the results of the empirical analysis. Finally, in Section 6 we discuss some directions for future research and conclude.

2 Related work

The Hoeffding bound has been used for propositional machine learning tasks on data streams, such as learning decision trees

[Domingos and Hulten (2000)] and decision rules [Gama et al. (2011)], and clustering [Domingos and Hulten (2001)]. However, its usage for learning relational models is limited. One reason is that it requires independence of observations, which cannot always be ensured in relational domains, due to dependencies in the data [Jensen (1999), Jensen and Neville (2002), Hulten et al. (2003), Dhurandhar and Dobra (2012)]. An ILP approach that uses the Hoeffding bound for relational learning is HTILDE [Lopes and Zaverucha (2009)], an extension of the TILDE system for learning first-order decision trees [Blockeel and De Raedt (1998)]. These are decision trees where each internal node consists of a conjunction of literals and each leaf is a propositional predicate representing a class. TILDE

 constructs trees by testing conjunctions of literals at each node, using an ILP refinement operator to generate the conjunctions and information gain as the guiding heuristic.

HTILDE extends TILDE by using the Hoeffding bound to perform these internal tests on a subset of the training data. To ensure independence of observations, HTILDE learns from interpretations [Blockeel et al. (1999)], a setting, used also by OLED, where each training instance is assumed a disconnected part of the dataset.

Like TILDE, HTILDE learns clauses with a propositional predicate in the head (representing a class). However, the head of a complex event definition is typically a first-order predicate, containing variables that appear in the body of the clause and express relations between entities. Therefore, HTILDE is not general enough for the problem we address in this work. Additionally, HTILDE requires a fully annotated dataset, while in the setting we assume here, annotation for target predicates is missing.

Learning programs in the EC is a challenging task that most ILP learners cannot fully undertake [Ray (2009), Katzouris et al. (2015)], mainly due to the non-monotonicity of negation as failure (NaF) that the EC uses. XHAIL [Ray (2009)] and TAL/ASPAL/RASPAL [Athakravi et al. (2013)] are systems that can handle the task, by combining ILP with the non-monotonic semantics of abductive logic programming. These approaches ensure soundness of the outcome, which in the presence of NaF requires learning whole theories by jointly optimizing their clauses. This implies an intractable search space, even with relatively small amounts of data. As a result, the aforementioned approaches do not scale to event recognition applications with temporal data streams. In contrast, OLED learns clauses separately using only fragments of the data in an online setting, trading soundness for efficiency.

ILED [Katzouris et al. (2015)] is a recently proposed scalable extension of the XHAIL system that is able to learn EC theories. It is an incremental learner that revises past hypotheses to fit new observations, and a full-memory system, meaning that revisions should account for a growing historical memory of accumulated data. Using a compressive memory structure to encode the positive examples that each clause entails in the historical memory, ILED requires at most one pass over the past data to revise a hypothesis. One difference from OLED is that the latter learns in an online fashion, thus it does not re-process past examples. Also, ILED is designed to learn sound theories and a key assumption for its scalable strategy is that the training data is noise-free. Other incremental ILP systems, such as INTHELEX [Esposito et al. (2000)] and FORTE [Richards and Mooney (1995)], cannot be applied to the task we address in this work, since they cannot handle negation (FORTE) and non-observable target predicates (INTHELEX, FORTE).

3 Background and Running Example

We assume a logic programming setting, where predicates, terms, atoms, literals, clauses and programs (theories) are defined as in [Gebser et al. (2012)] and not denotes NaF. Following Prolog’s convention, predicates and ground terms in logical formulae start with a lower case letter, while variable terms start with a capital letter.

Predicate Predicate Meaning Axioms happensAt Event occurs at time initiatedAt At time a period of time for which fluent holds is initiated terminatedAt At time a period of time for which fluent holds is terminated holdsAt Fluent holds at time
Table 1: The basic predicates and domain-independent axioms of the EC dialect.

The Event Calculus (EC) [Kowalski and Sergot (1986)] is a temporal logic for reasoning about events and their effects. Its ontology comprises time points, represented by integers; fluents, i.e. properties which have certain values in time; and events, i.e. occurrences in time that may affect fluents and alter their value. The axioms of the EC incorporate the common sense law of inertia, according to which fluents persist over time, unless they are affected by an event. We use a simplified version of the EC that has been shown to suffice for event recognition [Artikis et al. (2015)]. The basic predicates and its domain-independent axioms are presented in Table 1. Axiom (1) states that a fluent holds at time if it has been initiated at the previous time point, while Axiom (2) states that continues to hold unless it is terminated.

Definitions of initiatedAt/2 and terminatedAt/2 predicates are provided by a set of domain-specific axioms. To illustrate our learning approach we use the task of activity recognition, as defined in the CAVIAR project111http://homepages.inf.ed.ac.uk/rbf/CAVIARDATA1/. The CAVIAR dataset consists of videos of a public space, where actors perform some activities. These videos have been manually annotated by the CAVIAR team to provide the ground truth for two types of activity. The first type, corresponding to simple events, consists of knowledge about a person’s activities at a certain video frame/time point (e.g. walking, standing still and so on). The second type, corresponding to complex events, consists of activities that involve more than one person, for instance two people moving together, meeting each other, fighting and so on. The aim is to recognize complex events by means of combinations of simple events and some additional domain knowledge, such as a person’s position and direction.

Table 2(a) presents an example of CAVIAR data, consisting of a narrative of simple events in terms of happensAt/2, expressing the short-term activities of people, and context properties in terms of holdsAt/2, denoting the coordinates and direction of the people. Table 2(a) also shows the annotation of complex events (long-term activities) for each time-point in the narrative. The annotation about complex events is obtained via the closed world assumption (we state both positive and negated annotation atoms in Table 2 to avoid confusion). An example of two domain-specific axioms in the EC is presented in Table 2(b).

(a) (b) Narrative for time 1: Narrative for time 2: Two Domain-specific axioms: Annotation for time 1: Annotation for time 2: not holdsAt holdsAt
Table 2: (a) Example data from activity recognition. For instance, at time point 1 person is walking, her coordinates are and her direction is . The annotation for the same time point states that persons and are not moving together, in contrast to the annotation for time point 2. (b) An example of two domain-specific axioms in the EC. The first clause dictates that moving of two persons and is initiated at time if both and are walking at time , their euclidean distance is less than and their difference in direction is less than . The second clause dictates that moving of and is terminated at time if one of them is standing still at time (exhibits an inactive behavior) and their euclidean distance at is greater that 30.

Our goal is to learn a set of domain-specific axioms specifying complex events. Inductive Logic Programming (ILP) [De Raedt (2008)] provides techniques for learning logical theories from examples. In the Learning from Interpretations (LfI) [Blockeel et al. (1999)] setting that we use in this work, each training example is an interpretation, i.e. a set of true ground atoms, as in Table 2(a). Given a set of training interpretations and some background theory , which in our case consists of the domain-independent axioms of the EC, the goal in LfI is to find a theory , such that for each interpretation , covers , i.e. is a model of . Although different semantics are possible, in this work a “model” is an answer set [Gebser et al. (2012)].

To allow for an online learning setting, we use the Hoeffding bound [Hoeffding (1963)]

, a statistical tool that may be used as a probabilistic estimator of the generalization error of a model (true expected error on the entire input), given its empirical error (observed error on a training subset)

[Dhurandhar and Dobra (2012)]

. Given a random variable

with range in and an observed mean of its values after

independent observations, the Hoeffding Bound states that, with probability

, the true mean of the variable lies in an interval , where . In other words, the true average can be approximated by the observed one with probability , given an error margin that decreases with the number of observations .

4 Online Learning of Event Definitions

ILP learners typically employ a separate-and-conquer strategy: clauses that cover subsets of the examples are constructed one by one recursively, until all examples are covered. Each clause is constructed in a top-down fashion, starting from an overly general clause and gradually specializing it by adding literals to its body. The process is guided by a heuristic function that assesses the quality of each specialization on the entire training set. At each step, the literal (or set of literals) with the optimal -score is selected and the process continues until certain criteria are met. To adapt this strategy to an online setting, we use the Hoeffding bound to evaluate candidate specializations on a subset of the training interpretations, instead of evaluating them on the entire input. To do so, we use an argument adapted from [Domingos and Hulten (2000)]. Let be a clause and a clause evaluation function with range in . The evaluation function that we use in this work will be discussed shortly. Assume also that after training instances, is ’s specialization with the highest observed mean -score and is the second best one, i.e. . Then by the Hoeffding bound we have that for the true mean of the scores’ difference it holds , where . Hence, if then , implying that is indeed the best specialization to select at this point, with probability . In order to decide which specialization to select, it thus suffices to accumulate observations from the input stream until . Since decreases with the number of observations, given a desired , the number of observations needed to reach a decision may be traded for a tolerable generalization error of not selecting the optimal specialization at a certain choice point. The observations need not be stored or reprocessed. We process each observation once to extract the necessary statistics for the computation of the -score of each candidate specialization. This gives rise to a single-pass clause construction strategy.

In LfI each interpretation is independent form others [Blockeel et al. (1999)]. This guarantees the independence of observations that is necessary for using the Hoeffding bound. In our setting, an interpretation consists of ground atoms known true at two consecutive time points and , as in Table 2(a). In our EC dialect, the initiation/termination of complex events depends only on the simple events and contextual information of the previous time-point, therefore each interpretation is an independent training instance.

4.1 Evaluating Clauses

We relax the LfI requirement that a hypothesis covers every training interpretation to account for noise, and thus seek for a theory with a good fit in the training data. To this end, we define true positive, false positive and false negative atoms as follows:

Definition 1 (TP, FP, FN atoms)

Let consist of the domain-independent EC axioms, be a clause and an interpretation. We denote by and the narrative and the annotation part of respectively (see also Table 2(a)). We denote by an answer set of . Given an annotation atom we say that:

  • is a true positive (TP) atom w.r.t. clause iff .

  • is a false positive (FP) atom w.r.t. clause iff but .

  • is a false negative (FN) atom w.r.t. clause , iff but .

We seek a theory that maximizes the TP atoms, while minimizing the FP and FN atoms, collectively for all its clauses. To do so, we maintain a count per clause for each such atom. For an initiatedAt clause, its TP (resp. FP) count is increased each time it correctly (resp. incorrectly) initiates a complex event (according to the annotation). For a terminatedAt clause, its TP count is increased each time it correctly allows a complex event to persist, by not terminating it. Its FN count is increased when it incorrectly terminates a complex event.

When learning structure in Horn (negation-free) logic with ILP, a theory is augmented with new clauses to increase its total TP count, while existing clauses in are specialized to decrease the FP count. This strategy is not directly applicable to the problem at hand. When learning programs in the EC, the addition of new clauses may be necessary to eliminate FPs, while clause specialization may be necessary to increase TPs, as we explain below. Given a theory and interpretation , assume that does not cover . Then one of the following holds:

  1. The FN case. There is at least one FN atom . This may be due to one of the following:

    1. No initiatedAt clause in “fires”, failing to initiate the complex event that corresponds to , when it should. In this case, generating a new initiatedAt clause, eliminates the FN atom, turning it into a TP.

    2. One or more terminatedAt clauses in are over-general, terminating the complex event that corresponds to when they should not. Specializing the over-general clauses, eliminates the FN atom, turning it into a TP.

  2. The FP case. There is at least one FP atom . This may be due to one of the following:

    1. No terminatedAt clause in “fires”, failing to terminate the complex event that corresponds to when it should, so erroneously persists by inertia. Generating a new terminatedAt clause eliminates the FP.

    2. One or more initiatedAt clauses are over-general, re-initiating a corresponding complex event when they should not. Specializing the over-general clauses eliminates the FP.

Given the different possible behaviours of initiation and termination clauses in the process of optimizing a theory , we next define the clause evaluation function.

Definition 2 (Clause evaluation function)

Let us denote by and respectively, the accumulated TP, FP and FN counts of clause over the input stream. The clause evaluation function for a clause is a function with range in defined as follows:

Both initiatedAt and terminatedAt clauses affect the total TP count of a theory , therefore TP counts per clause are taken into account for the evaluation of both types of clauses. Additionally, specializing existing clauses further improves the quality of by eliminating FPs in the initiatedAt case (case 2(b) above) and FNs in favor of TPs in the terminatedAt case (case 1(b)). Therefore FPs (resp. FNs) should also be taken into account when evaluating initiatedAt (resp. terminatedAt) clauses. On the other hand, the total FP (resp. FN) count of a theory is not affected by its existing terminatedAt (resp. initiatedAt) clauses, but instead requires new clauses to be generated (cases 2(a) and 1(a) respectively). Therefore FPs and FNs are irrelevant for the evaluation of existing terminatedAt and initiatedAt clauses respectively. Combining these observations we derive the scoring function of Definition 2

, that uses precision and recall for

initiatedAt and terminatedAt clauses respectively.

1:
2:for each  do
3:      Update and counts from , for each and each , where denotes the number of examples on which has been evaluated so far.
4:     if  then
5:
6:     else
7:          for each clause  do
8:
9:
10:return
11:function :
12:    Generate a bottom clause from and
13:
14:
15:
16:    return
17:function :
18:    Compute and let denote the mean value of a clause’s -score
19:    Let be the best specialization of , the second best and
20:    Let equal the mean value of observed so far
21:    if and [ or ]:
22:
23:        return
24:    else return
25:function :
26:    Remove from each clause for which , where is the current Hoeffding bound
27:    return
Algorithm 1 OnlineLearning
Input: : A stream of training interpretations; : Background knowledge; : Clause evaluation function; Confidence for the Hoeffding test; Specialization depth; Clause -score quality threshold.

4.2 The Oled system

In this section we discuss the main functionality of OLED, presented in Algorithm 1, in detail. Learning begins with an empty hypothesis . On the arrival of new interpretations, OLED either expands , by generating a new clause, or tries to expand (specialize) an existing clause. Clauses of low quality are pruned, after they have been evaluated on a sufficient number of examples. Each incoming interpretation is processed once, to extract the necessary statistics for clause evaluation in the form of TP, FP and FN counts, and is subsequently discarded.

Process Cause of Failure Action Justification FP Clause expansion Case 2(b) FN Theory expansion Case 1(a) FP Theory expansion Case 2(a) FN Clause expansion Case 1(b)
Table 3: Action dispatching scheme for OLED’s initiatedAt () and terminatedAt () parallel processes. The justification refers to the different cases analysed in Section 4.1

To distinguish between the different cases presented in Section 4.1, initiation and termination clauses are learnt separately in parallel, by two processes and respectively (each one of these processes runs separately Algorithm 1). The input stream is forwarded to each of these processes simultaneously. Thanks to this decoupling, when either process fails to account for a training interpretation, it is able to infer the causes of failure in terms of FP and FN atoms. In particular detects FP/FN-failures based on cases 2(b)/1(a) respectively and detects FP/FN-failures based on cases 2(a)/1(b). According to the cause of failure, the process dispatches control either to the theory expansion, or the clause expansion subroutines. The choice among these actions is made by the boolean function ExpandTheory in line 4 of Algorithm 1. Action selection is based on the analysis of Section 4.1 and summarised in Table 3. Below we present an example for illustration purposes.

Example   Initially, processes and start with two empty hypotheses, and . Assume that the annotation in one of the incoming interpretations dictates that the moving complex event holds at time , while it does not hold at time . Since no clause in yet exists to initiate moving at time , detects the moving instance at time as an FN and proceeds to theory expansion (second case in Table 3), generating an initiation clause for moving. is not concerned with initiation conditions, so it will take no actions in this case. Then, a new interpretation arrives, where the annotation dictates that moving holds at time , but does not hold at time . In this case, since no clause yet exists in to terminate moving at time , will detect an FP instance at time . It will then proceed to theory expansion (third case in Table 3), generating a new termination condition for moving. At the same time, assume that the initiation clause in is over-general and erroneously re-initiates moving at time , generating an instance for the process at time . In response to that, will proceed to clause expansion (first case in Table 3), penalizing the over-general initiation clause by increasing its FP count, thus contributing towards its potential replacement by one of its specializations.

In the remainder of this section, we go into the details of theory and clause expansion, as well as some other aspects of OLED’s functionality.

Theory Expansion. The theory expansion process is handled by the StartNewClause function in Algorithm 1. A new clause is generated in a data-driven fashion, by constructing a bottom clause from a training interpretation [Muggleton (1995)]. Theory expansion consists of the addition of the clause to theory . From that point on, is gradually specialized by the addition of literals from to its body. We denote by the bottom clause associated to clause .

In a typical ILP setting, a bottom clause is constructed by selecting a target predicate instance as a “seed”, placing it in the head of a newly generated clause with an empty body. A set of atoms that follow deductively from and the background knowledge are placed in the body of . Constants in are replaced with variables, where appropriate, as indicated by a particular language bias, typically mode declarations [Muggleton (1995)]. To find a clause with a good fit in the data, a refinement operator is used to generate candidate clauses that -subsume .

The aforementioned approach cannot be applied directly to the problem we address here, which falls in the non-Observational Predicate Learning (OPL) class of problems [Muggleton (1995)]. In non-OPL, instances of target predicates, that are normally used as seeds for the construction of , are not directly observable in the training data. In our case, target predicates are initiatedAt/2 and terminatedAt/2, while the annotation in the training interpretations consists of complex event instances in terms of the holdsAt/2  predicate (see Table 2). A workaround is to use abduction to obtain the missing target predicate instances and then construct bottom clauses from them. This approach is followed by the XHAIL system [Ray (2009)] and we also adopt it here. Like XHAIL, OLED also uses mode declarations for specifying the language bias.

OLED may output the hypothesis constructed so far at any time during the learning process. We allow a “warm-up” period, in the form of a minimum number of training instances on which a clause must be evaluated before it can be included in an output hypothesis.

Clause Expansion. We use the Hoeffding bound to select among competing specializations of a clause . These specializations are generated by adding one or more literals from to the body of . An input parameter for specialization depth serves as an upper bound to the number of literals that may be added at each time. We use to denote the set of specializations for clause . Formally, . E.g. consists of all “one-step” specializations of (i.e. those that result by the addition of a single literal from ), while consists of plus all “two-step” specializations, and so on.

A clause is expanded, i.e. replaced by its best-scoring specialization from , when a sufficient number of interpretations have been seen, such that , where is the observed difference between the mean -scores of ’s best and second best specializations. To ensure that no clause is replaced by a specialization of lower quality, itself is also considered as a potential candidate along with its specializations from . This ensures that expanding a clause to its best-scoring specialization is better, with probability , than not expanding it at all.

Online learners are typically subject to order effects, i.e. they are sensitive to the order in which the examples are presented. Using the Hoeffding bound allows OLED to mitigate such effects, since clause expansion is postponed until sufficient evidence for the quality of the candidate specializations is provided by the data.

Tie-breaking. When the scores of two or more specializations are very similar, a large number of training instances may be required to decide between them. This could be wasteful, since any one of the specializations may be chosen. In such cases, as in [Domingos and Hulten (2000)], we break ties as follows: Instead of waiting until , as required by the Hoeffding bound-based heuristic, we expand to its best-scoring specialization if , where is a tie-breaking threshold (recall that decreases with the number of training examples, thus it may fall below ). We follow [Yang and Fong (2011)] and use an adaptive tie-breaking threshold, set to the mean value of that has been observed so far in the training process (see line 20, Algorithm 1). In the case of a tie between itself and its best-scoring specialization, we follow a conservative approach and do not expand .

Clause pruning. OLED supports removal of clauses whose score is smaller than a quality threshold . To decide when a clause may be removed we also use the Hoeffding bound. If , then with probability , the true mean of ’s -score is lower than the quality threshold and therefore should be removed.

Method Precision Recall -score Theory size Time (sec) (a) Moving 0.909 0.634 0.751 28 0.844 0.941 0.890 28 1692 XHAIL 0.779 0.914 0.841 14 7836 0.709 0.948 0.812 34 12 Meeting 0.687 0.855 0.762 23 0.919 0.813 0.863 23 1133 XHAIL 0.804 0.927 0.861 15 7248 0.943 0.750 0.836 29 23 (b) Moving 0.721 0.639 0.677 28 0.653 0.834 0.732 42 124 0.644 0.855 0.735 23 Meeting 0.678 0.953 0.792 30 107 (c) Moving 0.947 0.981 0.963 55 34 0.963 0.934 0.948 31 35 Meeting 0.930 0.976 0.952 65 30 0.975 0.933 0.953 53 42
Table 4: Experimental results from the CAVIAR dataset

5 Experimental Evaluation

We evaluate OLED’s performance on CAVIAR (see Section 3), a benchmark dataset for activity recognition. CAVIAR contains a total of 282067 training interpretations with a mean size of 25 atoms each. The size of the search space (clause subsumption lattice) is determined by the size of bottom clauses, which in these experiments consisted on average of 15 literals each. All experiments were conducted on a Linux machine with a 3.6GHz processor (4 cores and 8 threads) and 16GiB of RAM. The code and data are available online222https://github.com/nkatzz/OLED.

5.1 Comparison with Manually Constructed Rules and Batch Learning

The purpose of this experiment was to assess whether OLED is able to efficiently learn theories of comparable quality to hand-crafted rules and state-of-the-art batch learning approaches. We compare OLED to the following: (i) , a hand-crafted set of clauses for the CAVIAR dataset, described in [Artikis et al. (2010)]; (ii) [Skarlatidis et al. (2015)], a probabilistic version of with weights learnt by the Max-Margin weight learning method for Markov Logic Networks (MLNs) of [Huynh and Mooney (2009)]; (iii) XHAIL [Ray (2009)], a hybrid abductive-inductive learner capable of learning programs in the EC. was selected because it was shown to achieve good results on CAVIAR [Skarlatidis et al. (2015)]. XHAIL was selected as one of the few ILP systems that is able to learn theories in the EC. OLED and XHAIL were implemented using the Clingo333http://potassco.sourceforge.net/ answer set solver as the core reasoning component, while the approach used in this experiment was implemented in the LoMRF framework444https://github.com/anskarl/LoMRF for MLNs.

To evaluate , [Skarlatidis et al. (2015)] used a fragment of the CAVIAR dataset, which is also the one we use in this experiment. The target complex events in this dataset are related to two persons meeting each other or moving together and the training data consists of the parts of CAVIAR that involve these complex events. The fragment dataset contains a total of 25738 training interpretations. There are 6272 interpretations in which moving occurs and 3722 in which meeting occurs. OLED’s results were achieved using significance , a clause pruning threshold of for meeting and for moving and specialization depth parameter for meeting and for moving. The results reported with this parameter configuration are the best among several other parameter settings that we tried for and . The training time for each run of OLED was the maximum training time of the two parallel processes and .

Results were obtained using 10-fold cross validation and are presented in Table 4(a) in the form of precision, recall and -score. These statistics were micro-averaged over the instances of recognized complex events from each fold of the 10-fold cross validation process. Table 4(a) also presents average training time per fold for all approaches except (where no training is involved), average theory sizes (total number of literals) for OLED and XHAIL, as well as the fixed theory size of and .

achieves the best -score for both complex events, followed closely by XHAIL. OLED achieves a comparable predictive accuracy (particularly for meeting), while it outscores the hand-crafted rules. Moreover, OLED achieves speed-ups of several orders of magnitude as compared to and XHAIL, due to its single-pass strategy. The superior accuracy of and XHAIL is due to them being batch learners, optimizing their respective outcomes over the entire training set. This also explains the increased training times for both. Regarding theory size, XHAIL learns significantly more compressed hypotheses than OLED. The reason is that XHAIL learns whole theories, while OLED learns each clause separately to gain in efficiency.

5.2 Activity Recognition on the Entire CAVIAR Dataset

We also present experimental results from running OLED on the entire CAVIAR dataset. The target complex events are meeting and moving as previously. The number of positive interpretations for both complex events is also the same as before, since the data fragment used in the previous experiment contains the parts of CAVIAR where these complex events occur. In contrast, the number of negative training instances is much larger in this experiment.

Due to the high training times of XHAIL and , we do not present results with these approaches, and compare OLED only to the set of manually developed clauses . The experimental setting was as follows: We used 10-fold cross validation over the fragment used in the previous experiment, but in each fold, the training and test sets were augmented by a number of negative training sequences. In particular, in each fold, 90% of the negative training sequences from the remaining part of CAVIAR (i.e. the part not contained in the data fragment of the previous experiment) was added to the training set of the fold, while the remaining 10% was added to the test set. The parameter configuration for OLED was the same as in the previous experiment, with the exception of the specialization depth for meeting, which was set to . The limited size of the training sets in the experiment of Section 5.1 prevented OLED from sufficiently expanding its clauses when , resulting in over-general theories. Setting , thus trying 2-step specializations as well, made it possible to obtain the results reported in Table 4(a). In contrast, this was not necessary in this experiment, where due to the significantly larger training set size, OLED was able to find good clauses by trying 1-step specializations only.

Table 4(b) shows the results. Both approaches’ performance is decreased, as compared to the previous experiment, due to the increased number of false positives, caused by the large number of additional negative instances. OLED still outscores the hand-crafted knowledge base.

5.3 Comparison with an Incremental Learner

We compared OLED to ILED [Katzouris et al. (2015)], an incremental learner that is able to learn theories in the EC. Recall that ILED cannot learn from noisy data (see also Section 2), therefore, it cannot be used in CAVIAR, which exhibits various types of noise – see [Artikis et al. (2010)] for details. In order to compare the two systems, we thus generated a noise-free version of CAVIAR with artificial annotation for the moving and meeting complex events. To produce the annotation, we used the hand-crafted knowledge base for inference over the CAVIAR narrative. We used 10-fold cross validation to assess the performance of the the compared systems. For each fold, the training (resp. test) set consisted of the 90% (resp. 10%) of positive and negative interpretations for each complex event. OLED’s parameter setting was as reported in Section 5.2.

The results are presented in Table 4(c). Predictive accuracy for both systems is comparable, with ILED’s being slightly better. This was expected, since ILED re-scans the historical memory of past data to revise its theories. Training times are also comparable, with OLED’s being slightly higher, as compared to ILED’s. ILED is able to avoid certain computations by inferring that they are redundant, based on the assumption that the data is noise-free. Regarding theory size, OLED learns significantly shorter hypotheses that ILED. OLED prunes a number of its learnt clauses, in an effort to avoid fitting potential noise in the data and also follows a conservative clause expansion strategy. In contrast, ILED tries to account for every positive example (and exclude every negative one), since it is designed for learning sound hypotheses.

5.4 Scalability

Figure 1: OLED’s mean processing time and mean ground program size per training interpretation, for varying interpretation sizes.

In this experiment we assess OLED’s scalability. When learning from the entire CAVIAR dataset (Section 5.2) the average processing time per training interpretation was 6.7 milliseconds (ms), while the frame rate in CAVIAR, i.e. the rate in which video frames containing new data arrive is 40 ms. As a “stress-test”, we evaluated OLED’s performance in more demanding learning tasks. We generated 4 different datasets, each of which consisted of a number of copies of CAVIAR. The new datasets differ from the original one in the constants referring to the tracked entities in simple and complex events. We generated datasets consisting of 2, 5, 8 and 10 copies, each of which contained 20, 50, 80 and 100 different entities respectively. Like in the previous experiments, each interpretation includes narrative and annotation atoms from two time points. In this experiment however, the number of atoms in each interpretation grows proportionally to the number of copies of the dataset.

We performed learning with OLED on the original and the enlarged datasets and measured the average processing time per training interpretation. Figure 1 presents the results. For instance, interpretations in the 10 copies of CAVIAR are handled in approximately 2.5 sec in a standard desktop computer. The growth in average processing time is due to the increased number of annotation atoms in the datasets, as well as the additional domain constants, that result in an exponential increase in the size of the ground program produced during the clause evaluation process (see the dashed line in Figure 1). OLED’s performance may be improved by some optimizations, such as taking advantage of domain knowledge about relational dependencies in the data. For instance, in CAVIAR complex events involve two different entities, therefore learning may be split across different processing cores that learn from independent parts of the data. Such optimizations are part of our current work.

6 Conclusions and Further Work

We presented OLED, an ILP system for online learning of complex event definitions in the Event Calculus. OLED is an any-time system that learns by a single-pass over a stream, using the Hoeffding bound to evaluate candidate clauses on a subset of the input. Results of the empirical evaluation indicate that OLED achieves speed-ups of several orders of magnitude, as compared to batch learners, with a comparable predictive accuracy. It also outscores hand-crafted rules and matches the performance of a sound incremental learner that can only operate on noise-free datasets. We intend to improve OLED in several aspects, including scalability and development of adaptive techniques for automated configuration of its parameters. We also plan to experiment with dialects of the EC that allow long-term temporal relations between entities and combine OLED with weight learning techniques towards online statistical relational learning.

Acknowledgements

This work was partly funded by the EU Project REVEAL (FP7 610928).
