On the Secrecy Rate of Spatial Modulation Based Indoor Visible Light Communications

06/22/2019 ∙ by Jin-Yuan Wang, et al. ∙ King Abdullah University of Science and Technology 0

In this paper, we investigate the physical-layer security for a spatial modulation (SM) based indoor visible light communication (VLC) system, which includes multiple transmitters, a legitimate receiver, and a passive eavesdropper (Eve). At the transmitters, the SM scheme is employed, i.e., only one transmitter is active at each time instant. To choose the active transmitter, a uniform selection (US) scheme is utilized. Two scenarios are considered: one is with non-negativity and average optical intensity constraints, the other is with non-negativity, average optical intensity and peak optical intensity constraints. Then, lower and upper bounds on the secrecy rate are derived for these two scenarios. Besides, the asymptotic behaviors for the derived secrecy rate bounds at high signal-to-noise ratio (SNR) are analyzed. To further improve the secrecy performance, a channel adaptive selection (CAS) scheme and a greedy selection (GS) scheme are proposed to select the active transmitter. Numerical results show that the lower and upper bounds of the secrecy rate are tight. At high SNR, small asymptotic performance gaps exist between the derived lower and upper bounds. Moreover, the proposed GS scheme has the best performance, followed by the CAS scheme and the US scheme.

READ FULL TEXT VIEW PDF
POST COMMENT

Comments

There are no comments yet.

Authors

page 1

page 2

page 3

page 4

This week in AI

Get the week's most popular data science and artificial intelligence research sent straight to your inbox every Saturday.

I Introduction

For the fifth generation (5G) wireless communications, multi-input multi-output (MIMO) will be employed as one of the promising technologies [1]. However, by using multiple radio frequency (RF) chains, the hardware cost of MIMO systems is very high. To break such a limitation, spatial modulation (SM), which employs only one RF chain, has been proposed as a low complexity solution [2, 3].

The concept of SM in conventional RF wireless communications was first proposed by Chau and Yu [4]. For SM systems with a multi-antenna transmitter, only one antenna is activated at each time slot, while other antennas remain silent. A portion of the source data bits contains the index of the active antenna. Therefore, the dimension of information is increased, which can help to enhance the system performance. The transceiver designs of SM were introduced in [5] and [6]

. At the receiver of SM systems, the active antenna index and the received signal should be estimated simultaneously. To perform detection, the maximum likelihood detection

[7], matched filter based detection [8], sphere decoding algorithm based detection [9], and hybrid detection [10] were proposed. Based on the transceiver design, the performance indicators, such as channel capacity [11], bit error rate [12]

, and average bit error probability

[13], were investigated. For a comprehensive introduction about SM, the readers can refer to [14].

The large amount of research on SM has verified the advantages of SM over MIMO. Recently, the investigation of SM has been extended to the field of visible light communications (VLC) [2]. VLC is a novel data communication variant which uses visible light between 400-800 THz. The concept of optical SM was proposed in [15], while the SM applied to indoor VLC was discussed in [16]. In indoor environment, the SM was compared with the repetition coding and the spatial multiplexing in [17]. Moreover, the constellation optimization design and the mutual information analysis for SM based VLC were investigated in [18] and [19], respectively. By using the channel state information (CSI), the channel adaptive SM schemes were analyzed in [20] and [21]. To break the limitation that the number of required transmitters must be a power of two, a channel adaptive bit mapping scheme was proposed in [22] for SM based VLC. In [23], a collaborative constellation based generalized SM encoding was presented. In [24], the impact of synchronization error on optical SM was analyzed. In [25], an iterative combinatorial symbol design algorithm was proposed for generalized SM in VLC. Note that the above literatures do not consider the secure transmissions in the viewpoint of information-theoretic security.

In indoor VLC, the information security is a critical issue for users. Owing to the line-of-sight propagation, VLC is more secure than conventional RF wireless communications. However, any receiver in VLC can receive information as long as it is located in the illuminated zone of the light-emitting diode (LED). Therefore, such a feature still provides a possibility for unintended users to eavesdrop information. To ensure secure transmission, physical layer security techniques for indoor VLC have been proposed recently. As it is known, the secrecy performance in VLC depends on the input distribution. By employing the uniform [26], truncated generalized normal [27], and discrete [28]

input distributions, the secrecy performance for indoor VLC was discussed. Analytical results suggest that the discrete input distribution significantly outperforms the truncated Gaussian and uniform distributions. However, the discrete input distribution is still sub-optimal. To further improve secrecy performance, a better input distribution was obtained in

[29]. Focusing on a hybrid VLC/RF communication system with energy harvesting, the secrecy outage probability (SOP) was analyzed in [30]. For VLC with spatially random terminals, the average secrecy capacity and the SOP were discussed in [31]. To the best of our knowledge, the secrecy performance for the SM based VLC has not been well studied in open literature.

Motivated by the above work, this paper analyzes the secrecy performance for an SM based VLC network, which is consisted of multiple transmitters, a legitimate receiver, and an eavesdropper. The main contributions are listed as follows.

  • The secrecy rate for SM based VLC with non-negativity and average optical intensity constraints is analyzed. By using the uniform selection (US) scheme and the existing results [29], a lower bound on secrecy rate is derived. According to the dual expression of secrecy rate, an upper bound of the secrecy rate is obtained. Both the lower and upper bounds are in closed-forms. Numerical results verify the tightness of these two newly derived bounds.

  • The secrecy rate for SM based VLC with non-negativity, average optical intensity, and peak optical intensity constraints is analyzed. By adding the peak optical intensity constraint, the closed-form expressions of the secrecy rate bounds are further derived. The tightness of the lower and upper bounds are confirmed by numerical results.

  • The asymptotic behaviors of the secrecy rate at high signal-to-noise ratio (SNR) are analyzed. At high SNR, the performance gap between the lower and upper bounds is small. Moreover, when the number of transmitter is one, the SM vanishes, the secrecy rate results coincide with the results in [29].

  • To improve the secrecy performance, a channel adaptive selection (CAS) scheme and a greedy selection (GS) scheme are proposed to select the active transmitter. Numerical results show that the proposed GS scheme performs better than the CAS and US schemes.

The rest of this paper is presented as follows. Section II shows the system model. In Sections III and IV, the secrecy rate bounds and the asymptotic behaviors for the SM based VLC are analyzed over two scenarios. Section V provides two transmitter selection schemes to improve secrecy performance. Some typical numerical examples are given in Section VI. Finally, Section VII concludes the paper and provides some future research directions.

Ii System Model

As illustrated in Fig. 1, an indoor VLC system with transmitters (i.e., Alice), a legitimate receiver (i.e., Bob), and an eavesdropper (i.e., Eve) is considered. For Alice, each transmitter employs an LED as the lighting source, which is installed on the ceiling. At Alice, the SM is employed, i.e., only one LED is active at each time instant and the others are silent. The diagram of the SM in VLC is shown in Fig. 2. At the receiver side, both Bob and Eve are located on the ground, and each of them employs a photodiode (PD) to perform the optical-to-electrical conversion. When an active LED transmits information to Bob, Eve can also receive the signal.

Fig. 1: An indoor VLC network with Alice, Bob and Eve.
Fig. 2: The diagram of the SM in VLC.

At the current time instant, we suppose that the -th LED is activated. Therefore, the received signals at Bob and Eve are given by

(1)

where and are additive white Gaussian noises at Bob and Eve, and

are the noise variances.

is the direct current channel gain between the -th LED and the -th receiver ( for Bob and for Eve), which is given by (6) in [32].

By using SM, only one LED is activated at each time instant. To choose the active LED, the uniform selection (US) scheme is utilized, i.e., selecting each LED is equi-probable. Therefore, the probability can be expressed as

(2)

In (1), the input signal is the transmitted optical intensity signal, which satisfies the non-negativity constraint, i.e.,

(3)

Considering its physical characteristics, the LED is limited by its peak optical intensity . Consequently, the peak optical intensity constraint can be presented as

(4)

To satisfy the illumination requirement in indoor scenario, the dimmable average optical intensity constraint should be considered. In VLC, the average optical intensity constraint depends on the dimming target, which is given by [33]

(5)

where is the expectation operator, denotes the dimming target, and represents the nominal optical intensity of each LED.

Iii Secrecy Rate for SM Based VLC with Constraints (3) and (5)

Under constraints (3) and (5), the secrecy rate bounds for SM based VLC will be analyzed in this section, The asymptotic behaviors of the secrecy rate at high SNR will be presented.

According to information theory [34], when the main channel is inferior to the eavesdropper’s channel (i.e., ), the secrecy rate is zero; otherwise, a positive secrecy rate for SM based VLC with constraints (3) and (5) is derived by solving the following problem

(6)

where

is the probability density function (PDF) of

, denotes the mutual information. Note that it is extremely challenging to solve optimization problem (6). Alternatively, tight secrecy rate bounds will be analyzed in the following.

Iii-a Lower Bound of Secrecy Rate

By analyzing optimization problem (6), a lower bound on secrecy rate for SM based VLC with constraints (3) and (5) is obtained in the following theorem.

Theorem 1

For the SM based VLC with constraints (3) and (5), the secrecy rate is lower-bounded by

(7)

See Appendix A.

Corollary 1

When the number of LEDs is one (i.e., ), the SM scheme vanishes, and the secrecy rate bound in (7) coincides with (8) in [29].

Iii-B Upper Bound of Secrecy Rate

In this subsection, the dual expression of the secrecy rate [35, 36, 37] is adopted to further analyze the upper bound on the secrecy rate.

To facilitate the derivation, eq. (1) can be re-formulated as

(8)

where , , , and .

Lemma 1

The conditional mutual information is upper-bounded by

(9)

where denotes a relative entropy, and it is defined as

(10)

where is an arbitrary conditional PDF of given .

See Appendix B.

From Lemma 1, it can be observed that selecting an arbitrary in (9) will result in an upper bound of . Therefore, we have

(11)

According to (8) and (A.1), can be re-expressed as

(12)

Note that a unique input PDF can be found to maximize under constraints (3) and (5). Therefore, in (12) can be further written as [26]

(13)

where and denote the optimal input and its PDF.

Consequently, we can get an upper bound of the secrecy rate as [26]

(14)

By analyzing (14), Theorem 2 is obtained as follows.

Theorem 2

For the SM based VLC with constraints (3) and (5), the secrecy rate is upper-bounded by

(15)

See Appendix C.

Corollary 2

When the number of LEDs is one, eq. (15) is the same as (16) in [29].

Iii-C Asymptotic Behavior Analysis

In a typical indoor VLC scenario, the received SNR is large (generally greater than 30 dB). Therefore, we are more interested in the secrecy rate in the high SNR regime. In this subsection, under constraints (3) and (5), we analyze the asymptotic behaviors of the upper and lower bounds of the secrecy rate when tends to infinity.

By analyzing Theorem 1, when , we have

(16)

By analyzing Theorem 2, when , we have

(17)
Corollary 3

For the SM based VLC under constraints (3) and (5), the asymptotic behavior of the secrecy rate bounds in the high SNR regime is expressed as

(18)
Remark 1

In Corollary 3, the asymptotic lower and upper bounds on secrecy rate do not coincide, and their difference is nat/transmission. In other words, the asymptotic performance gap is small.

Iv Secrecy Rate for SM Based VLC with Constraints (3), (4) and (5)

By adding a peak optical intensity constraint (4), the secrecy rate bounds and the asymptotic behaviors at high SNR for the SM based VLC will be further analyzed.

Similarly, when , the secrecy rate is zero. When , the secrecy rate for SM based VLC with constraints (3), (4) and (5) derived by solving

(19)

Note that it is also challenging to obtain a closed-form solution for problem (19). Similarly, tight secrecy rate bounds will be analyzed in the following subsections.

Iv-a Lower Bound of Secrecy Rate

At first, we define the average to peak optical intensity ratio as . By analyzing problem (19), a lower bound on secrecy rate for SM based VLC with constraints (3), (4) and (5) is obtained in the following theorem.

Theorem 3

For the SM based VLC with constraints (3), (4) and (5), the secrecy rate is lower-bounded by

(20)

where can be obtained by solving the following equation

(21)

See Appendix D.

Corollary 4

When the number of LEDs is one, eq. (20) is the same as (20) in [29].

Iv-B Upper Bound of Secrecy Rate

In this subsection, the dual expression of the secrecy rate [35, 36, 37] is also utilized to analyze the upper bound of the secrecy rate. For this scenario, eq. (14) can also be derived. By analyzing (14), Theorem 4 is obtained.

Theorem 4

For the SM based VLC with constraints (3), (4) and (5), the secrecy rate is upper-bounded by

(22)

See Appendix E.

Corollary 5

When the number of LEDs is one, eq. (22) reduces to (26) in [29].

Iv-C Asymptotic Behavior Analysis

In subsections IV-A and IV-B, the lower and upper bounds on secrecy rate for the SM based VLC with constraints (3), (4) and (5) are derived. In this subsection, the asymptotic behavior of the secrecy rate when tends to infinity will be analyzed.

By analyzing Theorem 3, when , we have . Therefore, eq. (20) can be further written as

(23)

Then, we can get

(24)

By analyzing Theorem 4, when , we have

(25)
Corollary 6

For the SM based VLC with constraints (3), (4) and (5), the asymptotic behavior of the secrecy rate when is given by

(26)
Remark 2

In Corollary 6, when , the asymptotic performance gap equals nat/transmission. Although a performance gap exists between the asymptotic lower and upper bounds, the difference is small.

When and , we have . Moreover, for any in (21), is a constant. Let , eq. (20) can be further written as

(27)

where can be derived by

(28)

When , eq. (27) can be written as

(29)

According to (25) and (29), the following corollary is obtained.

Corollary 7

For the SM based VLC with constraints (3), (4) and (5), the asymptotic behavior of the secrecy rate when and is given by

(30)
Remark 3

In Corollary 7, when and , the asymptotic performance gap at high SNR is nat/transmission. Numerical results in Section VI will show that such a performance gap is small.

V Secrecy Performance Improvement Schemes

In Section II, the US scheme is utilized to select an active transmitter, i.e., the probability of selecting each LED is assumed to be the same. However, such a selection scheme does not perform well in some cases. To improve the secrecy rate, two novel transmitter selection schemes are provided in this section.

V-a Channel Adaptive Selection Scheme

As it is known, the probability of selecting each LED depends on the CSI of both Bob and Eve. The larger the difference between and is, the larger the secrecy rate becomes. To enhance the secrecy rate, the LED with large should be selected with large probability. Therefore, the probability of selecting the -th LED in (2) is modified as

(31)

In practice, the process of selecting each LED in the CAS scheme is presented in Algorithm 1. Based on the CAS scheme, Theorems 1 and 2 can be updated as Theorem 5.

1:Given the noise variances , , and the number of LEDs .
2:Obtain the positions of Alice, Bob and Eve.
3:Compute the probability of selecting each LED by using (31).
4:Compute the cumulative probabilities .
5:Generate a random number in the range of .
6:if  then
7:     The first LED is selected;
8:elseif then
9:     The -th LED is selected.
10:endif
11:Repeat Steps 2-10 to select another LED for the next time instant.
Algorithm 1 The CAS scheme
Theorem 5

For the SM based VLC with constraints (3) and (5), by using the CAS scheme in (31), the lower and upper bounds of the secrecy rate are given by

(32)

and

(33)

By considering the CAS scheme in (31), Theorems 3 and 4 can be modified as Theorem 6.

Theorem 6

For the SM based VLC with constraints (3), (4) and (5), by using the CAS scheme in (31), the lower and upper bounds of the secrecy rate are given by

(34)

and

(35)

V-B Greedy Selection Scheme

In this subsection, the GS scheme is introduced. In this scheme, the LED with the maximum value of is selected at each time instant. Therefore, the probability of selecting the -th LED is re-expressed as

(36)

For this scheme, the process of selecting each LED in the GS scheme is provided in Algorithm 2. By using the GS scheme, Theorems 1 and 2 can be updated as Theorem 7.

1:Given the noise variances , , and the number of LEDs .
2:Obtain the positions of Alice, Bob and Eve.
3:Compute for .
4:if  then
5:     The -th LED is selected.
6:endif
7:Repeat Steps 2-6 to select another LED for the next time instant.
Algorithm 2 The GS scheme
Theorem 7

For the SM based VLC with constraints (3) and (5), by using the GS scheme in (36), the lower and upper bounds of the secrecy rate are given by

(37)

and
