# On the Hardness of Energy Minimisation for Crystal Structure Prediction

Crystal Structure Prediction (csp) is one of the central and most challenging problems in materials science and computational chemistry. In csp, the goal is to find a configuration of ions in 3D space that yields the lowest potential energy. Finding an efficient procedure to solve this complex optimisation question is a well known open problem in computational chemistry. Due to the exponentially large search space, the problem has been referred in several materials-science papers as ”NP-Hard and very challenging” without any formal proof though. This paper fills a gap in the literature providing the first set of formally proven NP-Hardness results for a variant of csp with various realistic constraints. In particular, we focus on the problem of removal: the goal is to find a substructure with minimal potential energy, by removing a subset of the ions from a given initial structure. Our main contributions are NP-Hardness results for the csp removal problem, new embeddings of combinatorial graph problems into geometrical settings, and a more systematic exploration of the energy function to reveal the complexity of csp. In a wider context, our results contribute to the analysis of computational problems for weighted graphs embedded into the three-dimensional Euclidean space.

## Authors

• 4 publications
• 18 publications
• 3 publications
• 13 publications
• ### Kemeny ranking is NP-hard for 2-dimensional Euclidean preferences

The assumption that voters' preferences share some common structure is a...
06/24/2021 ∙ by Bruno Escoffier, et al. ∙ 0

• ### A Simpler NP-Hardness Proof for Familial Graph Compression

This document presents a simpler proof showcasing the NP-hardness of Fam...
09/07/2020 ∙ by Ammar Ahmed, et al. ∙ 0

• ### Minimum Constraint Removal Problem for Line Segments is NP-hard

In the minimum constraint removal (MCR), there is no feasible path to mo...
07/07/2021 ∙ by Bahram Sadeghi Bigham, et al. ∙ 0

• ### Improved hardness for H-colourings of G-colourable graphs

We present new results on approximate colourings of graphs and, more gen...
07/01/2019 ∙ by Marcin Wrochna, et al. ∙ 0

• ### r-Gathering Problems on Spiders:Hardness, FPT Algorithms, and PTASes

We consider the min-max r-gathering problem described as follows: We are...
12/05/2020 ∙ by Soh Kumabe, et al. ∙ 0

• ### The algorithmic hardness threshold for continuous random energy models

We prove an algorithmic hardness result for finding low-energy states in...
10/11/2018 ∙ by Louigi Addario-Berry, et al. ∙ 0

• ### A Tutorial on Online Supervised Learning with Applications to Node Classification in Social Networks

We revisit the elegant observation of T. Cover '65 which, perhaps, is no...
08/31/2016 ∙ by Alexander Rakhlin, et al. ∙ 0
