Minimal Virtual Machines on IoT Microcontrollers: The Case of Berkeley Packet Filters with rBPF

11/24/2020 ∙ by Koen Zandberg, et al. ∙ 0

Virtual machines (VM) are widely used to host and isolate software modules. However, extremely small memory and low-energy budgets have so far prevented wide use of VMs on typical microcontroller-based IoT devices. In this paper, we explore the potential of two minimal VM approaches on such low-power hardware. We design rBPF, a register-based VM based on extended Berkeley Packet Filters (eBPF). We compare it with a stack-based VM based on WebAssembly (Wasm) adapted for embedded systems. We implement prototypes of each VM, hosted in the IoT operating system RIOT. We perform measurements on commercial off-the-shelf IoT hardware. Unsurprisingly, we observe that both Wasm and rBPF virtual machines yield execution time and memory overhead, compared to not using a VM. We show however that this execution time overhead is tolerable for low-throughput, low-energy IoT devices. We further show that, while using a VM based on Wasm entails doubling the memory budget for a simple networked IoT application using a 6LoWPAN/CoAP stack, using a VM based on rBPF requires only negligible memory overhead (less than 10 small software modules, isolated from OS software, and updatable on-demand, over low-power networks.

READ FULL TEXT VIEW PDF
POST COMMENT

Comments

There are no comments yet.

Authors

page 5

This week in AI

Get the week's most popular data science and artificial intelligence research sent straight to your inbox every Saturday.

I Introduction

The availability of cheap low-power microcontrollers and low-power radios is driving the emergence of the Internet of Things (IoT). Typical microcontrollers based on architecture such as Arm Cortex-M are combined with various sensors/actuators, and with a radio such as Bluetooth Low-Energy, LoRa or IEEE 802.15.4, on a small Arduino-like hardware module. This class of embedded hardware [5] trades off limiting resources (slow processor, kilobytes of RAM and Flash memory…), for small energy consumption (in the milliwatt range) and a small price tag (a few dollars).

In parallel, however, security concerns [16] grow with the emergence of IoT. Cyberphysical chain reactions [21], or extended functionality attacks [19] expand the traditional attack surface of networked systems.

To mitigate such a variety of attacks, specific security mechanisms are needed at all levels of the system. For instance, on-going work defines new network protocols and workflows aiming to mitigate network- and some software-based attack vectors

[23].

Complementary mechanisms focus on isolating critical software processes (e.g. access to specific sections of the address space) from the rest of the application software running on-board the microcontroller. This facilitates establishing a root of trust on the microcontroller, which can bootstrap other security mechanisms.

Concretely, we consider two categories of use-cases:

  1. Isolating high-level business logic, updatable on-demand remotely over the low-power network. This type of logic is rather long-lived, and has loose (non-real-time) timing requirements.

  2. Isolating debug/monitoring code snippets at low-level, inserted and removed on-demand, remotely, over the network. Comparatively, this type of logic is short-lived and exhibits stricter timing requirements.

One approach is to modify the hardware architecture of microcontrollers, adding specific hardware mechanisms to guarantee such isolations. Such hardware functionalities facilitate establishing a root of trust on the microcontroller. Prominent examples of this trend include TrustZone on Arm Cortex-M architectures [18], Sanctum on RISC-V architectures [8], Sancus2.0 on MSP430 architectures [17].

However, changing hardware is both (i) more difficult than upgrading software, and (ii) heavily dependent, by nature, on a specific hardware architecture. Therefore, a legitimate question which arises is: what software-only equivalent can be achieved, to isolate the processes in our use-cases?

Ii Related Work

Different categories of software-based process isolation techniques have been developed specifically for microcontrollers. Small virtual machines are used to host and isolate processes from other processes running on the microcontroller. For example Darjeeling [6] is a subset of the Java VM, modified to use a 16 bit architecture, designed for 8- and 16-bit microcontrollers. Another example is WebAssembly (Wasm [12]), a virtual machine (VM) specification with a stack-based architecture, designed for process isolation in Web browsers, which has recently been ported to microcontrollers [20]. Beyond the low-power IoT domain, tiny VMs are also used in other contexts for a long time. For instance JavaCard [13] uses a small Java VM running on smart cards. Elsewhere, in the Linux ecosystem, eBPF [15, 9] enables a small VM hosting and isolating debug and inspection code, in the Linux kernel, at run-time.

Another type of approach uses scripted logic interpreters to isolate some processes. For instance, prior work such as [3] uses a small JavaScript run-time container, hosting (updateable) business logic, interpreted on-board a microcontroller, glued atop a real-time OS (RIOT).

Yet another category of solution uses OS-level mechanisms for process isolation. For instance, Tock [14] is an OS written in the Rust programming language, which offers strong isolation between its kernel and application logic processes. However, Tock requires hardware providing an memory protection unit (MPU) (only some Cortex-M and RISC-V hardware is supported so far).

The goal we pursue in this paper is to explore in practice solutions which:

  • require minimal memory footprint;

  • do not depend on extra hardware-specific mechanisms to protect memory;

  • offer tolerable code execution speed slump;

  • require small data transfer over-the-air when isolated code is updated;

For this purpose, we explore approaches based on virtual machines. More specifically, we consider two architectures of VMs: a stack-based VM based on WebAssembly, and a register-based VM based on eBPF, as described below. The main contributions of this paper are:

  • we design rBPF, an adaptation of eBPF providing a software-based solution to isolate processes on low-power microcontrollers;

  • we provide the implementation of two open source prototypes of

    VMs, using rBPF on one hand, and on the other hand using Wasm, based on the WASM3 interpreter;

  • we evaluate the performance of our rBPF prototype compared to Wasm, via experiments running the VMs on real microcontrollers;

  • we show that rBPF offers promising perspectives in terms of smaller memory footprint, we discuss security guarantees and potential next steps.

Iii Background

Iii-a WebAssembly

WebAssembly (Wasm [12]) is a virtual instruction set architecture, standardized by the World Wide Web Consortium (W3C), primarily aimed at portable web applications. The instruction set allows for binaries small in size, to minimize transfer time to the client. The sandbox provided by implementations offers strong guarantees on memory access. Both of these properties aim to ensure security while requiring only limited memory footprint on the platform target.

The WebAssembly VM uses both a stack and a flat heap for memory storage. The stack is required by the architecture, and can be configured to any size. An interface for allocating heap memory is provided by the standard. Specification mandates memory allocations in chunks of (pages).

Toolchain & SDK. The full workflow for development and execution of Wasm applications is depicted in Figure 1. Wasm uses the LLVM compiler: applications in any language supported by LLVM are possible, such as C/C++, D, Rust, and TinyGo among others. A standardized interface is specified for host access in a POSIX-like way is provided by the WASI standard [24].

Interpreter. Once the Wasm binary is created, it can be transferred to the IoT device, on which it is interpreted and executed, as shown in Figure 1. Several interpreters exist, in this paper we use the WASM3 [20] interpreter, which uses a two-stage approach: the loaded application is first transpiled to an optimized executable, which then can be executed in the interpreter.

Fig. 1: Wasm code development and execution workflow with the WASM3 VM.

Iii-B Extended Berkeley Packet Filters

Berkeley Packet Filter (BPF [9]) is a small in-kernel VM available on most Unix-like operating systems. Its original purpose was network packet filtering, for example: only pass to userspace packets matching a set of requirements. Within the Linux kernel the VM is extended (to eBPF) to allow for multiple non-network related purposes. eBPF provides a small and efficient facility for running custom code inside the kernel, hooking into various subsystems.

The state-of-the-art eBPF architecture is 64-bit register based VM with a fixed stack. The stack itself is specified as fixed at . A heap is not contained in the specification. As an alternative, the Linux kernel provides an interface to key-value maps for persistent storage between invocations. The limited stack size and absence of a heap put only minimal requirements on the RAM a platform has to provide for the VM.

Fig. 2: rBPF code development and execution workflow.

The VM itself is inherently suitable for isolating the operating system from the virtualized application: all memory access, including to the stack, happen via load and store instructions. Moreover, branch and jump instructions are also limited, the application has no access to the program counter and a jump is always direct and relative to current program counter. The VM does not provide facilities to directly write the program counter. Both of these potential attack surfaces can be implemented with the necessary checks in place to limit access and execution.

Interfacing with the operating system facilities can be done by providing the necessary bindings on the device.

Comparing eBPF to WebAssembly. As with WebAssembly, eBPF makes use of the LLVM toolchain for compilation (see Figure 2) thus any language supported by LLVM can be used and compiled to bytecode. However, there are differences in terms of architecture, and in terms of memory model. The architecture of WebAssembly reduces the size of instructions significantly. On the other hand, eBPF instructions are always in size, filled with zero bits where a field is not used. The stack-based with heap memory approach from WebAssembly put significant requirements on the available RAM. On the other hand, with eBPF, the few registers combined with the limited stack put only minimal pressure on the available RAM.

Iv rBPF Design

The rBPF VM is a variant of the eBPF VM, designed to be ISA compatible with eBPF. The main difference between rBPF and eBPF lies in the bindings provided for access to the operating system facilities and the events by which execution is triggered. In this paper, we chose RIOT [4] as OS to host our VM prototype, but this choice is arbitrary: our approach could apply to another OS in the same category.

VM integration in the OS. The rBPF virtual machine is integrated in RIOT as shown in Figure 3. Within the operating system the VM is scheduled as a regular thread, restricted by the scheduler to the configured run priority. The VM does not interfere with real-time thread execution on the operating system. However, running real-time constrained applications inside the VM is not suitable.

Fig. 3: VM integration & sandboxed execution of rBPF in host OS.

As shown in Figure 3, multiple OS event sources can trigger the execution of an application. For example a request received on the CoAP server or packets passing through the network stack. Each of these event types can trigger a different rBPF application from the application store, configured by the device administrator. Similar to eBPF the VM supports both an argument passed to the application and a return code from the application back to the calling event. This can be used to communicate vital execution context with the application and pass a return value back to the initiator. Further integration with the operating system is available through function bindings, including access to facilities relevant to IoT applications such as sensor values and network packet creation. With these capabilities the VM application, while isolated from the operating system, it retains enough flexibility to host business logic application or simple measure and debug applications.

The application running inside the VM is expected to be short-lived, updating an intermediate result or formatting a response to a request. To provide persistent data between these short-lived invocations a key-value store is available. An application can read and write values to both a global and a per-script local storage. Counters or aggregate sensor values can be stored for retrieval in a subsequent execution or queried from outside the VM by the operating system.

VM execution sandboxing. The VM is based on an iterative loop design, iterating over the application instructions depicted in Figure 4, which shows the interaction between the instructions, sandbox guards, and the host address space. Both the registers and the application stack reside in the memory of the host. Depending on the instruction to be executed, different protection mechanisms are activated. Two main protection mechanism are in place to isolate the code executed in the VM.

Fig. 4: rBPF execution and memory architecture

First, the host address space is isolated from the sandbox by access policies loaded in the VM. Every memory access, including stack reads and writes, are subjected these access policy rules. Different address space sections can be configured to allow reads, writes or both by the caller of the VM. This offers minimal overhead for memory access while providing the guarantees required for the sandbox.

Second, protections on the code executed ensure the VM does not start executing code outside the supplied application, such as gadgets deployed by an attacker. The mechanism works by guarding the branch and jump instructions, ensuring that the destination is not outside the application address space. As the eBPF ISA implemented does not support indirect jump instructions and no program counter register is available, the only mechanism to modify the virtual program counter is via the already guarded direct branch and jump instructions. While the lack of an indirect jump instruction does somewhat limit the flexibility of the applications, it ensures that all jump destinations are known before executing the application, making a preflight validation of all jump instructions a viable option.

V Experimental setup

We carry out our measurements on popular, commercial off-the-shelf IoT hardware: a Nordic nRF52840 Development Kit, which provides a typical microcontroller (Arm Cortex-M4) with 256 KB RAM, 1 MB Flash, and a 2.4 GHz radio transceiver compatible both with IEEE 802.15.4, and Bluetooth Low-Energy. This hardware is also available for reproduceability on open access testbeds such as IoT-Lab [1].

On this platform, we perform two types of benchmarks. First, we perform embedded computing hosted in the VM, to get an idea of basic VM performance. Then, we perform further benchmarks involving IoT networking capabilities used from within the VM.

V-a Computing Benchmark Setup

First, we benchmark a setup consisting of a Fletcher32 checksum algorithm [10]. The Fletcher32 checksum algorithm requires a mix of mathematical operations memory reads and branches, containing a loop over input data. Benchmark results consist of the impact of the VM on the operating system in the additional memory required to include it. For the VMs themselves, the execution speed and the size of compiled applications loaded into the VM is measured.

V-B Networked Benchmark Setup

Next, we construct a setup involving a simple IoT networked application as case study. The VM hosts high-level logic, and this loaded application is updateable over the network. The functionality mimics that studied in prior work [3] using small JavaScript run-time containers hosting application code on top of RIOT. The hosted logic has access to both the CoAP stack and the high-level sensor interface (SAUL) provided by RIOT [4]. The VM execution is triggered by a CoAP request and the operating system expects a formatted CoAP response payload or an error code from the application loaded in the VM. The goal is to load an application into the VM that, when triggered by a CoAP request, reads a sensor value and constructs a full CoAP payload as response to the requester.

Vi Experimental Measurements

Using our experimental setup, we carried out an initial set of measurements comparing rBPF and WASM3. With each prototype, we measured the performance of VM logic when it hosts the same Fletcher32 checksum. While this example is specific and artificial, it is a good guinea pig to get an idea of what to expect in general. The Fletcher32 checksum algorithm requires a mix of mathematical operations memory reads and branches, containing a loop over input data.

First and foremost as visible in Table I, we observe that the Flash memory footprint of the interpreter WASM3 is 15 times bigger than the rBPF interpreter. To get a perspective: relatively to the whole firmware image (assuming simple business logic and a CoAP/UDP/6LoWPAN network stack) adding an rBPF VM represents negligible Flash memory overhead (less than 10% increase), whereas adding a Wasm VM more than doubles the size of the firmware image.

ROM size RAM size
WASM3 Interpreter
rBPF Interpreter
Host OS Firmware (without VM)
TABLE I: Memory requirements for WASM3 and rBPF interpreters.

Second, we give an initial measure of the data that needs transfer over the network when modular software update is performed (when VM logic is updated). With the results as in Table II, we observe that Wasm script size seem somewhat smaller than rBPF script size (approximately 30% less in this case). The native C compilation shows the size of the code if the library is compiled into the device firmware itself and is not network updateable.

code size time
Native C
WASM3
rBPF
TABLE II: Size and performance of different targets for the fletcher32 algorithm

Third, we compare the penalty in terms of execution time for VM logic. We measured the performance of Fletcher32 computation on a sample input string of , with each VM. We observe that execution is longer with the rBPF VM, than with the Wasm VM (2 times longer). Both VMs perform significantly slower than native execution, with WASM3 approximately 35 times slower and rBPF around 70 times slower. While this relative overhead is significant, the absolute overhead is not significant for hosted logic that is not computation-intensive. Furthemore, in terms of instructions, rBPF still enables 1.3M instructions per seconds – enough for a low-power IoT device, which is generally not required to process ultra-high data throughput.

Based on these preliminary measurements, we can conclude that rBPF seems to offer acceptable performance in general, and in particular a very substantial advantage in terms of Flash memory footprint compared to Wasm. Hence, a VM approach based on rBPF seemed promising, and we have thus fleshed out our prototype further, to perform additional experiments with IoT use-cases involving a CoAP network stack, which next we report on.

Vi-a rBPF with Logic involving IoT Networking

We here reproduce a use-case described in prior work [3], whereby high-level logic involving CoAP networking is executed by the VM. More precisely, we evaluated the performance the hosted code shown in 1. The application requests a measurement value from the first sensor and stores the value in a CoAP response. The functions called from the application are provided as bindings by the host operating system and exposed to the VM. We implemented the CoAP bindings and as well as the bindings to the high-level sensor interface (SAUL) as depicted in Figure 3.

int coap_resp(bpf_coap_ctx_t *gcoap)
{
    /* Find first sensor */
    bpf_saul_reg_t *sens = bpf_saul_reg_find_nth(1);
    phydat_t m; /* measurement value */
    if (!sens ||
            (bpf_saul_reg_read(sens, &m) < 0)) {
        return ERROR_COAP_INTERNAL_SERVER;
    }
    /* Format the CoAP Packet */
    bpf_gcoap_resp_init(gcoap, COAP_CODE_CONTENT);
    bpf_coap_add_format(gcoap, 0);
    ssize_t pdu_len = bpf_coap_opt_finish(gcoap,
            COAP_OPT_FINISH_PAYLOAD);
    /* Add the sensor as payload */
    uint8_t *payload = bpf_coap_get_pdu(gcoap);
    pdu_len += bpf_fmt_s16_dfp(payload, m.val[0],
                               m.scale);
    return pdu_len;
}
Listing 1: Example networked sensor read application

When compiled, the size of the bytecode is . The overhead of the full script execution, including the execution of the function calls, is . The additional overhead caused by the VM is negligible, when compared to network latencies of several milliseconds.

The size of the full firmware image is , including the rBPF interpreter. While the Flash memory required for the core rBPF interpreter is identical to the previous example (see Table I), there is however an increase in Flash size due to the additional bindings to the CoAP and sensor interfaces. The RAM requirements are increased by for an additional memory access region, used to allow access to the CoAP packet.

Here, as an additional point of comparison, we can refer to similar logic hosted in a small embedded JavaScript run-time container with RIOT bindings, studied and measured in [3] on similar hardware (a Arm Cortex-M microcontroller). These measurements show that similar logic requires for the JavaScript engine, on top of the used by RIOT, and the hosted code (script) size which was around . Note furthermore that these JavaScript containers did not specific memory isolation guarantees, as does rBPF. We can thus conclude that rBPF offers much better prospects than embedded JavaScript run-time containers too, in terms of memory requirements, hosted logic size (and network traffic overhead required to transmit VM updates).

Vii Discussion & Next Steps

Inherent Limitations with a VM

By construction, a VM causes execution overhead, and thus increased power consumption, for logic executed within the VM. Measuring the full impact of the VM on power consumption is a complex task. However, this impact is mitigated by two factors. On one hand, depending on the characteristics of the logic executed in the VM, this overhead may be negligible. Here, we gear the VM towards hosting simple scripts, implementing short decision steps rather than lengthy bulk data processing. In such cases, the additional power consumed is not substantial. On the other hand, smaller script size decreases drastically the energy needed otherwise to transfer software updates – especially compared to an alternative such as firmware updates, as shown in [3].

Decreasing Wasm RAM usage

WebAssembly has large RAM requirements: memory pages increment is big for microcontrollers. The WASM3 interpreter also adds an intermediate compile step, which increases speed, and collaterally RAM usage, by another . We thus cannot conclude just yet on how useful Wasm really is for low-power IoT. An adaptation skipping this step and/or using smaller memory pages increments could reduce RAM requirements. Next steps here could also include trying out other Wasm interpreters, such as for instance Wasm-micro-runtime [7] and WARDuino [11].

Improving rBPF execution time overhead

If execution time overhead is an issue, an option is to design from scratch a solution going beyond software-only, using hardware MPU or even an MMU as base. Another option is adding an intermediate transpilation technique to rBPF (similar to what is used by WASM3) translating the raw eBPF instructions to a format more suitable for direct consumption on the system. A more advanced step would be to translate these, ahead-of-time, into native instructions on the embedded device.

Decreasing rBPF script size overhead

The rBPF VM implementation is designed as a secure sandbox for running untrusted code on small embedded devices while adhering to the already defined eBPF ISA. It can be seen from the application script sizes that the current implementation are relative big compared to applications compiled to WebAssembly. As the eBPF instructions are fixed in size and can contain a lot of unused bit fields depending on the exact instruction, compressing them with well known algorithms can solve this downside. Initial measurements show that Heatshrink [2], an LZSS-based [22] compression library suitable for small embedded systems, can reduce the application size by depending on the application surpassing similar WebAssembly applications.

Extending rBPF sandboxing guarantees

The current use case of rBPF targets execution of small-sized business logic and debug applications. However the current VM design does not limit the actual execution time of the application: a virtualised application can keep the system busy without limitations, possibly draining the battery of the IoT device. A potential next step could be to cap the CPU time which a single invocation of the virtual machine can occupy.

Viii Conclusion

In this paper we have designed, implemented and studied experimentally two minimal virtual machines targeting low-power, microcontroller-based IoT devices. We designed rBPF, a register-based VM hosted in RIOT, and an interpreter, based on Linux’s extended Berkeley Packet Filters. We compared its performance, experimentally on commercial IoT hardware, to an approach hosting and isolating logic in an embedded WebAssembly virtual machine. We show that, compared to WebAssembly and to prior work on small run-time containers for interpreted logic, rBPF is a promising approach to host and isolate small software modules, yielding acceptable overhead in execution time, and very small memory overhead (approx. 10%) for a typical IoT application.
