Knowledge Distillation of Transformer-based Language Models Revisited

1 Introduction

Recently, the emergence of pre-trained language models, especially the transformer-based model such as BERT (Devlin et al., 2019), and GPT-3 (Brown et al., 2020)

, has revolutionized the research on various natural language processing (NLP), compute vision (CV), and multimodal tasks

(Dosovitskiy et al., 2021, Liu et al., 2021, Lin et al., 2021, Wang et al., 2022) and achieve stunning success. These researches follow the pretrain-then-finetune paradigm: the models are first pre-trained on a large unlabeled corpus and then fine-tuned for specific downstream tasks. Even though these models are effective and prevalent, the heavy model size and high latency limit their application in real-world scenarios, particularly on resource-constrained devices, e.g. mobile phones, IoT devices, and autonomous cars (Zualkernan et al., 2022, Li et al., 2021).

Many model compression techniques have been proposed to obtain a much smaller and eco-friendly model with comparable performance to alleviate the former shortcomings. Among all these methods, knowledge distillation (KD) (Hinton et al., 2015) is simple yet effective and has been frequently used (Wang et al., 2020, Jiao et al., 2020). KD often trains a large and elaborate model as the teacher model to guide the training of a smaller model, named the student model. During the learning procedure, the student model is forced to mimic the behavior of the teacher so that the knowledge from the teacher model will be transferred to the student model.

Despite considerable previous literature having grown up to apply knowledge distillation to transformer-based models for model compression (Wang et al., 2020, Jiao et al., 2020, Sanh et al., 2019, Sun et al., 2020), there are still too many unexplored areas in the mechanism of KD. In this work, we attempt to provide a comprehensive overview of KD for transformer-based models. The main contributions of our work are summarized as follows.

We present a generic distillation framework that contains three main components: initialization, knowledge type, and matching strategy. Any existing method could be identified and incorporated into the framework. To tease apart, we categorize common initialization schemes, knowledge types, and matching strategies and propose a unified formulation of distillation.
We conduct systematic and extensive experiments which consist of about 30,000 experimental results and cost over 23,000 GPU hours to investigate the effects of different parts of the proposed framework. We provide exhaustive analyses about the initialization, temperature and hard label weight, layer match, width-depth trade-off, and teacher model size.
Based on the empirical results, we establish a best-practice guideline on the knowledge distillation of transformer-based models. The model following the guideline achieves better scores with a smaller size compared to previous compact models.

2 Preliminary

2.1 Distillation

Knowledge Distillation (KD) is a wide-used technique in deep learning due to its plug-and-play feasibility. It shares many core concepts with transfer learning,

Ahn et al. (2019) label smoothing Yuan et al. (2020), ensemble learning, Hinton et al. (2015) and contrastive learning Tian et al. (2020). Although KD could achieve the purpose of model compression, inference acceleration, and generalization improvement Gou et al. (2021), we focus on model compression in this paper. The key idea of KD is to drive a large model (the teacher model

T

) to guide the learning of a small model (the student model

S

). Let

Ω

denote the function to extract part of "dark knowledge" from the model

S / T

and the input

x

. Aim to train the student model

S

to mimic the behaviors of the teacher model

S

, KD minimizes the following objective function:

L_{K D} = \sum x \in X L (Ω (T, x), Ω (S, x))

(1)

where $X$ is the dataset and $L$

is the loss function. The choice of loss function

L

and the design of knowledge extractor

Ω

will significantly influence the effectiveness of knowledge distillation and we discuss them later in the Section3.2 respectively.

2.2 Transformer

In this paper, our goal is to explore the distillation framework of language models which fit strict memory and computation constraints. Since Transformer-based language models have achieved much progress in a wide range of NLP tasks Vaswani et al. (2017), Devlin et al. (2019), we select the most popular Transformer as the backbone network and review its architecture first. The vanilla Transformer model follows the encoder-decoder architecture based on a multi-head attention mechanism. Therefore, Transformer consists of two types of building blocks: a self-attention module and a feed-forward network.

Self-attention Module

The self-attention module utilizes the multi-head attention mechanism to generate outputs with a query and a set of key-value pairs. The output of each head is a weighted sum of values according to the attention distribution. The independent attention heads are concatenated and multiplied by a linear layer to match the desired output dimension:

	$M u l t i H e a d (Q, K, V) = ⨁ ({h e a d}^{1}, \dots, {h e a d}^{H}) W^{O}$		(2)
	${h e a d}^{i} = Attention (Q W^{Q_{i}}, K W^{K_{i}}, V W^{V_{i}}) = A^{i} V W^{V_{i}} = s o f t m a x (\frac{Q W^{Q_{i}} (K W^{K_{i}})^{T}}{\sqrt{d_{k}}}) V W^{V_{i}}$		(3)

where $⨁$ denotes concatenation operation. $W^{Q}, W^{K}, W^{V} and W^{O}$ are weight matrices for queries, keys, values, and outputs separately. $A$ is the attention score of $i$ -th head. $d_{k}$ is the dimension of each head and $d_{k} \times H$ is equal to the hidden dimension $h_{h}$ in Transformer.

Feed-forward Network

The feed-forward network (FFN) is a two-layer network with two linear projection and an activation function (e.g. ReLU):

F F N (x) = m a x (0, x W^{f_{1}} + b_{1}) W^{f_{2}} + b_{2}

(4)

3 The framework of Distillation

For the transformer-based model, as aforementioned in Section 2.2, it is convenient to regard the teacher-student architectures as homogeneous. Therefore, we choose the BERT as the backbone model without loss of generality in this paper. Given the teacher model, there are two main stages in the progress of distillation: the initialization of the student model and the distillation in the downstream task. We will discuss them in this section.

3.1 Initialization

Since the initialization is crucial (Zhang et al., 2021, Sutskever et al., 2013) in the distillation, a bunch of initialization schemes were proposed to speed up the training progress and improve the final performance Jiao et al. (2020), Wang et al. (2020), Turc et al. (2019), Sun et al. (2020), Sanh et al. (2019). Generally speaking, there are four kinds of initialization schemes:

Random initialization: train the student model from scratch.
Pre-train: pre-train the student model on an unlabeled dataset with a masked LM objective.
General distillation: pre-train the student model with the aid of the teacher model by introducing the distillation loss to the masked LM objective.
Pre-load: load part of the weight of the teacher model directly.

Random initialization is the simplest way but usually suffers from the shortage of data in the downstream tasks. Pre-train has been shown to be effective (Devlin et al., 2019, Liu et al., 2019) recently. General distillation, also known as pre-train distillation, utilizes the power of the teacher model when pre-train the student model Jiao et al. (2020), Wang et al. (2020) .Sanh et al. initialized the student from the selected layers of the teacher. We perform controlled experiments on these schemes to test their effect in Section 4.2.

3.2 Knowledge

In this subsection, we discuss the different categories of knowledge that transfer from the teacher model to the student model. Furthermore, how to calculate the distillation loss for different types of knowledge is also vital and worth investigating in knowledge distillation. Basically, the knowledge could be split into the following three categories: response-based knowledge, feature-based knowledge, and relation-based knowledge.

3.2.1 Response-Based Knowledge

A vanilla knowledge distillation utilizes the output logits of the teacher model as knowledge

(Hinton et al., 2015, Ba and Caruana, 2014). The simple but effective method is widely used in model compression. Let

z_{t}

and

z_{s}

denote the logits of the teacher model and student model respectively, the response-based knowledge loss can be formulated as

L_{r e s} (z_{t}, z_{s}) = D (φ (z_{t}), φ (z_{s}))

(5)

where $D$ indicates the computation of the cost function. $φ$ is the transformation function of logits and the simplest transformation function is $φ (z) = z$ . However, directly matching logits could be ineffective because the output logits of the cumbersome teacher model could be very noisy. A much more powerful and popular transformation is converting logits to soft targets (Hinton et al., 2015)

φ (z_{i}) = \frac{e x p (z_{i} / T)}{\sum_{j} e x p (z_{j} / T)}

(6)

where $T$ is the temperature factor, $z_{i}$ is the logit for the $i$ -th class. The temperature $T$ controls the "hardness" of soft targets and plays a vital role in knowledge distillation which will be discussed later in Section 4.3. Analogous to label smoothing and regularization (Yuan et al., 2020, Ding et al., 2019, Müller et al., 2019), the utilization of soft targets prevents the student model from overfitting and improves its performance significantly. However, merely using the output of the last layer as auxiliary information limits the competency of KD, especially when the teacher model is very deep or the data amount is small. Consequently, some techniques were proposed to exploit the intermediate-level supervision of the teacher model besides the response-based knowledge.

3.2.2 Feature-Based Knowledge

To provide auxiliary information for mimicking the behavior of the teacher model in intermediate layers rather than simply matching the output logits of the last layer, a considerable amount of literature has been worked on feature-based knowledge distillation (Romero et al., 2015, Zagoruyko and Komodakis, 2017, Kim et al., 2018, Passban et al., 2021). The inspiration of feature-based distillation is simple: directly match the intermediate feature between the teacher model and the student model. It could be formulated as

L_{f e a t} (f_{t} (x), f_{s} (x)) = D (ϕ (f_{t} (x)), ϕ (f_{s} (x))) .

(7)

Here $D$ is the similarity function to compute the feature loss. $f_{t}$ and $f_{s}$ indicate the function used to generate a feature map with input $x$ in the teacher model and the student model respectively. As some similarity functions require the elements to share the same dimension, $ϕ$ denotes the mapping function that transforms the features to a proper shape.

In practices of distilling transformer-based models (Jiao et al., 2020, Sun et al., 2020, Wang et al., 2020), the feature map $f (x)$ could be embeddings in the embedding layer, attention matrices $A$ , and hidden states $H$ . With regard to the similarity function $D$ , cross-entropy loss, $l_{n}$

-norm loss, and cosine similarity loss are common choices. Due to the dimension of the teacher model and the student model usually being different,

ϕ

is necessary for feature-based knowledge. The simplest way is to use some dimensionality reduction techniques (e.g. PCA, LDA). However, these methods are not flexible to achieve excellent performance. The most common way to address the problem is to introduce a trainable linear projection layer between the feature map of the teacher model and the student model.

3.2.3 Relation-Based Knowledge

Different from the previous two types of knowledge, which are the output of different layers, relation-based knowledge focus on the relationship of the representations of samples (Tung and Mori, 2019, Park et al., 2019). The core tenet is that the relations of the learned representations contain more and better knowledge than individual ones. The objective of relation-based knowledge loss is expressed as

L_{r e l} (f_{t} (x), f_{s} (x)) = D (ψ (_{t} (x),_{t} (x)), ψ (_{s} (x),_{s} (x)))

(8)

where $ψ$ denotes the relational potential function that measures a relationship of given inputs $x$ . Here we only consider pair-wise relationship, $_{t} (x),_{t} (x)$ and $_{s} (x),_{s} (x)$ are the feature map generator of the teacher model and the student model.

For example, neuron selectivity transfer

(Huang and Wang, 2017) computes the similarity matrix of hidden states using Maximum Mean Discrepancy (MMD) in two models then compute the MSE loss between two similarity matrices. In this case,

_{t} (x) = H_{i}

_{s} (x) = H_{j}^{T}

indicate the generation of hidden states in the

i

-th and

j

-th layer.

ψ (\cdot)

here is simply matrix multiplication. Therefore, the objective function could be rewritten as

L_{r e l : m m d} (z_{t}, z_{s}) = D_{M S E} (H_{S_{i}} \cdot H_{S_{j}}^{T}, H_{T_{i}} \cdot H_{T_{j}}^{T})

. Other types relationship-based knowledge of transformer-based model include gram matrices (Yim et al., 2017), value relation (Wang et al., 2020), query and key relation (Wang et al., 2021).

D

could be mean square error, cross entropy loss, Frobenius norm, and KL divergence.

3.3 Matching Strategy

Section 3.2 addresses the problem of how to distill knowledge. In this section, we explore the problem of how to match the student model $S$ and the teacher model $T$ . If the depth of $T$ is equal to the depth of $S$ ( $L_{T} = L_{S}$ ), it is easy to solve the problem by matching $T$ and $S$ layer by layer. However, in the most application of distillation, $L_{S}$ is smaller than $L_{T}$ in order to compress the student model. Since the representations learned in different layers and different trained models vary a lot (Kornblith et al., 2019, Li et al., 2015), it is vital to select the proper pair of layers to match between $S$ and $T$ . Generally, the matching strategy includes three types: 1) First- $k$ : select the first $k$ layers to match. 2) Last- $k$ : select the last $k$ layers to match. 3) Dilatation: evenly select the matching layers. Figure 1 demonstrates the three strategies when $L_{T} = 4, L_{S} = 2, k = 2$ .

3.4 Objective Function

The overall objective function could be formulated as

L = L_{r e s} + α L_{h a r d} + \sum k \sum l β_{k l} L_{k l} (f_{t}^{l} (x), f_{s}^{l} (x))

(9)

where $L_{r e s}$ is the response-based knowledge loss (soft label loss). We add the hard label loss $L_{h a r d}$

that is used in common supervised learning with the ground-truth label as a previous study

(Hinton et al., 2015) found it could significantly improve the performance of the student model.

L_{k l}

denotes the

k

-th feature-based or relation-based knowledge loss which is applied in the

l

-th pairs of layers between

T

and

S

α

and

β_{k l}

are all hyper-parameters to balance these loss terms.

4 Empirical Results And Analyses

In this section, we conduct extensive and systematic experiments to investigate the effects of the different parts of knowledge distillation in the transformer-based model. We upload the source code to supplementary material.

4.1 Dataset & Settings

To evaluate different aspects of the distillation of the transformer-based language model, we select the commonly used GLUE benchmark (Wang et al., 2018). Especially, we conduct experiments on Paraphrase Similarity Matching on MPRC (Dolan and Brockett, 2005), QQP, and STS-B (Conneau and Kiela, 2018). For Sentiment Classification, we test on SST-2 (Socher et al., 2013)

; for Natural Language Inference, we test on QNLI

(Rajpurkar et al., 2016)

and RTE

(Wang et al., 2018)

; for linguistic Acceptability, we test on CoLA

(Warstadt et al., 2019).

We use the ${BERT}_{base}$ ( $L = 12, d = 768$ ) as the structure of the teacher model unless otherwise specified. For the optimizer, AdamW (Loshchilov and Hutter, 2017, 2019)

is used. For the evaluation metrics in most tasks, we use accuracy for the convenience of comparison. However, for the STS-B task, we select the Pearson correlation coefficient as the metric. For more details about the dataset and related experimental setting and hyperparameters, please refer to Appendix

A.1.1.

4.2 Initialization

In this subsection, we test aforementioned four initialization schemes (see Section 3.1). In the setting of pre-train and general distillation, we train the model on the corpus that contains the English Wikipedia and the Toronto Book Corpus (Zhu et al., 2015) following the suggestion of original BERT. We select three structures of the student models: ${BERT}_{tiny}$ ( $L = 2, d = 128$ ), ${BERT}_{mini}$ ( $L = 4, d = 256$ ), and ${BERT}_{small}$ ( $L = 4, d = 512$ ). As the pre-load scheme requires the same dimension between $T$ and $S$ , we train a student model with $d = 768$ in this setting.

Table 1 shows the results of different initialization schemes. The figures indicate that random initialization is the worst choice among all four methods. Besides, the pre-load technique shows little advantage in practice. The score of pre-load in the QQP and SST-2 task is relatively high because the width (768) here is much bigger than in others (128), which makes an unfair comparison. Generally speaking, the general distillation and pre-train are better initialization methods because the unsupervised representation of the student model is significant. As a rough guideline, for a comparatively small model size of $S$ , just pre-train the student model is the best way to initialize it. If the model size of $S$ increases, it is better to consider general distillation because the student model is able to take more advantage of complementary information provided by the teacher model(Turc et al., 2019).

{B E R T}_{t i n y}

{B E R T}_{m i n i}

{B E R T}_{s m a l l}

Initialization

Random

Pre-load

General

Distillation

Pre-train

Random

Pre-load

General

Distillation

Pre-train

Random

Pre-load

General

Distillation

Pre-train

QNLI

0.6158

0.6711

0.6286

0.7943

0.6074

0.6711

0.8411

0.8428

0.6149

0.7439

0.8561

0.8673

MRPC

0.6838

0.723

0.7034

0.7647

0.7010

0.7132

0.7843

0.7917

0.7181

0.7206

0.8015

0.7941

RTE

0.5307

0.5487

0.6209

0.5487

0.5451

0.5776

0.6751

0.5596

0.5343

0.5704

0.657

STSB

0.0229

0.4681

0.0907

0.6289

0.0639

0.2448

0.7503

0.8523

0.158

0.217

0.8256

0.8654

QQP

0.7853

0.8826

0.8484

0.8653

0.8342

0.8649

0.8884

0.8914

0.8378

0.8813

0.8995

0.901

MNLI

0.5704

0.6030

0.7270

0.6329

0.6216

0.6329

0.7016

0.7046

0.6208

0.6120

0.7479

0.7386

0.7574

0.7607

0.7664

0.7695

0.6287

0.6393

0.7613

0.7695

0.7908

0.7965

0.7891

0.7893

SST2

0.7959

0.8337

0.8314

0.8222

0.7959

0.8704

0.8842

0.8716

0.7959

0.8337

0.8314

0.8222

CoLA

0.6913

0.6922

0.6913

0.7450

0.6913

0.6989

0.7833

0.767

Table 1: Experimental Results of Different Initialization Schemes

4.3 Temperature and Hard Label

The temperature in the distillation plays an important role in controlling the communication between $T$ and $S$ . Higher temperature softens the distribution generated by the teacher model and works in a way that is similar to the label smoothing (Yuan et al., 2020). Hinton et al. found that a weighted average of soft logits loss and hard label loss helps the knowledge transfer from the cumbersome teacher model to the student model. Therefore, the weight of the hard label is also crucial.

To test the effect of two main hyper-parameters and tune them for experiments afterwards, we search from a grid of parameter values (temperature : {1, 2, 4, 8}, hard label weight : {0.1, 0.2, 0.5, 1.0, 2.0, 5.0}). Here, we use ${BERT}_{mini}$ as the student model. Table 4 in Appendix A.3.1illustrates some interesting facts about these two hyperparameters. First, when the data amount of the downstream task is small, the model distilled with a higher temperature (above 2) achieves better performance. On bigger datasets, lower temperatures result in higher scores. Secondly, although recent studies claim that the hard label is not necessary as the soft logits are sufficiently informative (Shen et al., 2019, Shen and Savvides, 2020), we found a slight hard label weight (e.g. 0.1 or 0.2) is always helpful. In the following experiments, we will use the best hyperparameter setting in Table 4 as the default setting.

4.4 Layer Match

As mentioned in Section 3.2, apart from the response-based knowledge (e.g. soft target) in original knowledge distillation, feature-based knowledge, and relation-based knowledge could provide more nuanced information to help the distillation of knowledge. In this subsection, we select several types of knowledge that are widely used. The core idea of KD is to let the student model learn the behavior of the teacher model. The soft target enables the imitation of the result and other knowledge strives to mimic the intermediate layers. Therefore, we name this part of the experiments as layer match experiments.

We select ten kinds of knowledge that widely used in previous studies (Wang et al., 2020, 2021, Sanh et al., 2019, Jiao et al., 2020, Sun et al., 2019, Huang and Wang, 2017, Yim et al., 2017), including five types of feature-based knowledge: attention mse, attention ce, hidden mse, cos, pkd; and five types of relation-based knowledge: mmd, gram, query relation, key relation, and value relation. See the Appendix A.2 for their definitions and formulas. Three student models are used in this group of experiments: ${BERT}_{tiny}$ , ${BERT}_{mini}$ , and ${BERT}_{small}$ . Not only the knowledge types, but we also conduct extensive experiments to test the effect of the three matching strategies mentioned in Section 3.3.

Knowledge Type

For the knowledge types, we consider the situation of using only one layer match (single-match) firstly. Table in Appendix A.3.2 shows the result of distilling different knowledge. Compared with solely using soft targets, almost adding any feature-based knowledge or relation-based knowledge improves the performance. When the size of $T$ is smaller or the amount of data in the task is smaller, the model aided by relation-based knowledge tends to achieve a better score than feature-based ones. One reason is the inequality of the dimension of $T$ and $S$ necessitate a learnable projection matrix. However, for some tasks with data shortage, the labeled data is insufficient to train these matrices. Another reason is to preserve the relationship in the representation space of $S$ is easier than mimicking the representation space of $T$ directly. Besides, among the feature-based knowledge, the knowledge about the attention score is more tractable than hidden states as the attention itself could be regarded as a self-relation knowledge. In previous experiments, we set the hyperparameters of loss weight $β_{k l}$ to be 1. Nevertheless, the magnitudes of different types of knowledge vary a lot. Therefore, we designed an experiment to see if the loss of weight affects the final results. We tuned the weight so that the loss term value of a single-match reaches about 1/10 of the soft label loss. Table 8 in Appendix A.3.5 illustrates that even the roughly selected loss weight improves the performance of over 80% of the student models in different tasks.

To study the effect of the combination of different knowledge types, the second group of experiments tests the models that are distilled with two types of knowledge. We divide all the knowledge types into three categories by the region they take effect: attention (attention mse, attention ce), hidden state (hidden mse, mmd, gram, cos, pkd), query/key/value (query relation, key relation, value relation). Then we test the binary combinations of these 3 tuples. All the 31 double-match settings are applied in three kinds of student models and trained on 8 downstream tasks. The result in Appendix A.3.3 shows that not all double-match settings are better than single-match due to the conflict between different knowledge. However, some double-match could improve the performance significantly, especially the combination of attention ce and relation-based knowledge. It reveals a compound effect as they both respond to the self-attention module.

Matching Strategy

In the absence of theoretical underpinnings, the choice of matching strategy is really tricky. We conduct extensive controlled experiments to explore this area. Based on three matching strategies mentioned in Section 3.3, we design five settings: (1) match the first $L_{S}$ layers (First), (2) match the first one layer (First-1), (3) match the last $L_{S}$ layers (Last), (4) match the last one layer (Last-1), and (5) match the layers evenly (Dilatation).

In the single-match setting, the average variance of different matching strategies in different tasks and models is about only 0.00045. However, it does not reveal that the matching strategy is not important. In fact, among all experimental conditions in the single-match setting (3 model size

\times

9 downstream tasks), the best configuration in 25 out of 27 is Last-1 or First-1. Similarly, the ratio in the double-match setting is 22 out of 27 (see Appendix A.3.3). It is not a coincidence. Some previous studies point out that, from lower layers to higher layers, the function of each layer varies from encoding surface information to encoding semantics (Jawahar et al., 2019, Peters et al., 2018, Simoulin and Crabbé, 2021). Nonetheless, the success of the transformer-based model using cross-layer weight-share, such as ALBERT (Lan et al., 2020), indicates that the mechanism of transformer layers is still vague. Therefore, the functionality of the intermediate layer in

T

and

S

could be diverse and the other three matching strategies do not work well. However, the behavior, purpose, and function of the first or the last layer are comparably similar. Accordingly, the discrepancy of these layers between the teacher model and the student model is slighter. Therefore, a superior way to select a matching strategy is to use Last-1 or First-1 as the initial trial in the application.

4.5 Deeper or Wider

In the application of small pre-train language models, the limited computing power of mobile devices necessitates the compression of the student model. Given a typical BERT model, the space complexity is $O (L (h d n + h n^{2})$ and the time complexity is $O (L h d n^{2})$ . $L$ is the number of transformer layers and $d$ is the embedding dimension. $n$ denotes the length of the input sequence and $h$ is the number of heads in the multi-head attention layer. As the sequence length is usually determined by the input of the downstream task, the depth $L$ and the width $d$ are the main hyper-parameters to reduce the model size and speed up inference time. Along this line, one crucial problem is the trade-off between the depth and the width. The width not only influences the number of parameters in transformer layers but also affects the embedding layer. The space complexity of the embedding layer is $O (| V | d)$ where $| V |$ is the fixed vocabulary size (set to be 30,522 in BERT). Therefore, the smaller a model is, the larger the proportion of the embedding layers to the total model. For instance, the embedding layer in ${BERT}_{m i n i}$ makes up 71% of all parameters and embedding layer parameters account for a over 90% proportion in ${BERT}_{t i n y}$ ( $L = 2, d = 128$ ).

Levine et al. proved that for models with $L > L_{t h} (d) \sim log (d)$ , the ability to model input dependencies increases similarity with depth and width. For small models, the network with the depth of $log (d)$ is too shallower for good performance. Therefore the theoretical findings are not helpful in this situation. We design a bunch of experiments to probe into the matter. We construct several student models with 1) fixed model size of about 6 million parameters, 2) fixed flops (floating-point of operations) of 2G, and uncover how student models perform vary with width and depth. These models were firstly general distilled with the aid of the same teacher model and then distilled in downstream tasks of GLUE. In the setting of fixed model size, the experimental results in Table 2 illustrates that depth-efficiency takes place in transformer-based models. Under the same hyperparameters except for the width and depth, the deeper models in different tasks usually outperform the other models. In the tasks with small datasets (MRPC, CoLA, STS-B, and RTE), relatively shallower (than the deepest) models achieve the best score. Besides, the results are similar to the conclusion of Kaplan et al.. However, the conclusion is contrary in the setting of fixed flops. The results in the bottom half of Table 2 reveals depth inefficiency. Another perspective is the time-space trade-off. In the first experiment, fixing the model size, the models take more time (bigger flops and higher latency) to perform better; in the second experiment, with similar time consumption, bigger models achieve better scores.

#para $≃$ 6.2M
Dimension	#Layer	#para (M)	flops (G)	Latency (ms)	CoLA	MRPC	STS-B	RTE	QQP	MNLI-m	SST-2	QNLI
128	12	6.36	2.83	148	0.6961	0.6838	0.7975	0.5884	0.8787	0.773	0.8658	0.8501
144	8	6.49	2.35	130	0.7622	0.6838	0.8077	0.6137	0.8843	0.7589	0.8681	0.8371
160	4	6.22	1.43	74.1	0.722	0.7451	0.8206	0.6029	0.8773	0.7403	0.8773	0.8259
168	3	6.26	1.18	52.7	0.7335	0.7328	0.8215	0.6029	0.8729	0.7429	0.8532	0.8202
176	2	6.24	0.86	41.3	0.7133	0.7157	0.4792	0.5776	0.8336	0.6769	0.8268	0.6288
flops = 2G
Dimension	#Layer	#para (M)	flops (G)	Latency (ms)	CoLA	MRPC	STS-B	RTE	QQP	MNLI-m	SST-2	QNLI
132	8	5.8	2	125	0.7354	0.7181	0.7869	0.5957	0.8798	0.7498	0.8521	0.8376
142	7	6.13	2	108	0.7325	0.7304	0.7652	0.5848	0.8809	0.7530	0.8567	0.8371
154	6	6.52	2	120	0.7344	0.7745	0.8206	0.5343	0.8810	0.7527	0.8647	0.8234
170	5	7.05	2	106	0.7402	0.7868	0.8215	0.5776	0.8826	0.7656	0.8612	0.8314

Table 2: Experimental results of student models with fixed model size and flops

4.6 Larger Teacher Teach Better?

Teacher Model		Student Model
		bert-small		bert-mini		bert-tiny
bert-base	bert-large	bert-base	bert-large	bert-base	bert-large	bert-base	bert-large
0.8775	0.8799	0.8015	0.8186	0.8186	0.8039	0.7525	0.7770
0.9231	0.9289	0.8933	0.8876	0.8670	0.8796	0.8280	0.8280
0.909	0.9107	0.8863	0.8908	0.8896	0.8834	0.8721	0.8649
0.9154	0.9223	0.8710	0.8671	0.8440	0.8433	0.7948	0.8007
0.7256	0.7328	0.6606	0.6679	0.6643	0.6390	0.6282	0.6209
0.812	0.8485	0.7728	0.7593	0.7411	0.7210	0.6989	0.6913
0.8804	0.9034	0.8729	0.8774	0.8664	0.8614	0.8171	0.8159
0.8484	0.8591	0.8040	0.8061	0.7891	0.7939	0.7302	0.7273
0.8456	0.8665	0.7999	0.8100	0.7748	0.7748	0.7267	0.7340

Table 3: Experimental results with different teacher models and student models

In previous experiments, we fix the teacher model to study the behavior of the student models. Another crucial part to be explored is the teacher model. In this experiment, we mainly answer the research question: does the larger teacher model teach better? Two teacher models are tested here: ${BERT}_{b a s e}$ and ${BERT}_{l a r g e}$ ( $L = 12, d = 1024$ ). The left side of the Table 3 is the performance of these two teacher models, in all tasks the larger teacher gets better scores (better scores are bolded). However, when teaching students models, the conclusion of "the larger the better" does not hold true. Table 3 indicates that the larger $T$ teaches better students when the model size of $T$ is relatively larger ( ${BERT}_{s m a l l}$ ). Conversely, when the capacity of $S$ is lower, the smaller teacher teaches better because of the capacity gap (Mirzadeh et al., 2020).

4.7 Best Practices of Distilling Extremely Small Models for On-device Application

Constraints

Recently, high-end mobile phones have strong computing power. For instance, the A15 Bionic chip in iPhone 13 performs up to 1500 GFLOPS (Giga Floating Point Of Per Second) and the GPU FP32 floating point in Qualcomm 8 Gen 1 is 1800 GFLOPS. However, most devices in the world including low-to-mid-end mobile phones and IoT devices are not so fast. Therefore, considering the required runtime latency in the common device, we follow the constraints in previous studies (Ge and Wei, 2022) and use the 2G flops (floating-point of operations) as the restrictions. Besides, we limit the model size up to 14 million parameters including the embedding layer following previous work (Wu et al., 2020). Therefore, the ${BERT}_{m i n i}$ model that contains 11 million parameters is a proper structure for the on-device application.

Based on the empirical results above, we provide several rules of thumb. The first step is to tune the three hyperparameters: learning rate, temperature, and hard label weight (See Section 4.3 for the guideline for tuning temperature and hard label weight). The second step is to choose the initialization method. We recommend the pre-train method for ${BERT}_{m i n i}$ and the general-distillation method for larger student models. Then, for the matching strategy, we suggest the First-1 or Last-1 as mentioned in Section 4.4. With regard to the knowledge types, relation-based knowledge is preferred and for smaller models (e.g. ${BERT}_{t i n y}$ ) combining attention-related knowledge could further improve the performance. Besides, several tricks are also exceedingly useful including data augmentation and label smoothing (Jiao et al., 2020, Yuan et al., 2020). Finally, the student model after distillation achieves the comparative score while reducing about 20% model size of the previous SOTA (see Table 7 in Appendix A.3.4).

5 Conclusion

In this paper, we propose a generic framework to distill the transformer-based models, which includes the initialization schemes, knowledge types, and matching strategies. We conduct extensive experiments to investigate the effect of different components in knowledge distillation. Moreover, we provide a best-practice guideline to distill the ${BERT}_{mini}$ for on-device applications.

References

S. Ahn, S. X. Hu, A. C. Damianou, N. D. Lawrence, and Z. Dai (2019) Variational information distillation for knowledge transfer.
2019 IEEE/CVF Conference on Computer Vision and Pattern Recognition (CVPR)
, pp. 9155–9163. Cited by: §2.1.
J. Ba and R. Caruana (2014) Do deep nets really need to be deep?. In NIPS, Cited by: §3.2.1.
T. B. Brown, B. Mann, N. Ryder, M. Subbiah, J. Kaplan, P. Dhariwal, A. Neelakantan, P. Shyam, G. Sastry, A. Askell, S. Agarwal, A. Herbert-Voss, G. Krueger, T. J. Henighan, R. Child, A. Ramesh, D. M. Ziegler, J. Wu, C. Winter, C. Hesse, M. Chen, E. Sigler, M. Litwin, S. Gray, B. Chess, J. Clark, C. Berner, S. McCandlish, A. Radford, I. Sutskever, and D. Amodei (2020) Language models are few-shot learners. ArXiv abs/2005.14165. Cited by: §1.
A. Conneau and D. Kiela (2018) SentEval: an evaluation toolkit for universal sentence representations. ArXiv abs/1803.05449. Cited by: §4.1.
J. Devlin, M. Chang, K. Lee, and K. Toutanova (2019) BERT: pre-training of deep bidirectional transformers for language understanding. ArXiv abs/1810.04805. Cited by: §1, §2.2, §3.1.
Q. Ding, S. Wu, H. Sun, J. Guo, and S. Xia (2019) Adaptive regularization of labels. ArXiv abs/1908.05474. Cited by: §3.2.1.
W. B. Dolan and C. Brockett (2005) Automatically constructing a corpus of sentential paraphrases. In IJCNLP, Cited by: §4.1.
A. Dosovitskiy, L. Beyer, A. Kolesnikov, D. Weissenborn, X. Zhai, T. Unterthiner, M. Dehghani, M. Minderer, G. Heigold, S. Gelly, J. Uszkoreit, and N. Houlsby (2021) An image is worth 16x16 words: transformers for image recognition at scale. ArXiv abs/2010.11929. Cited by: §1.
T. Ge and F. Wei (2022) EdgeFormer: a parameter-efficient transformer for on-device seq2seq generation. ArXiv abs/2202.07959. Cited by: §4.7.
J. Gou, B. Yu, S. J. Maybank, and D. Tao (2021) Knowledge distillation: a survey. ArXiv abs/2006.05525. Cited by: §2.1.
G. E. Hinton, O. Vinyals, and J. Dean (2015)
Distilling the knowledge in a neural network
. ArXiv abs/1503.02531. Cited by: §1, §2.1, §3.2.1, §3.4, §4.3.
Z. Huang and N. Wang (2017) Like what you like: knowledge distill via neuron selectivity transfer. ArXiv abs/1707.01219. Cited by: §3.2.3, §4.4.
G. Jawahar, B. Sagot, and D. Seddah (2019) What does bert learn about the structure of language?. In ACL 2019-57th Annual Meeting of the Association for Computational Linguistics, Cited by: §4.4.
X. Jiao, Y. Yin, L. Shang, X. Jiang, X. Chen, L. Li, F. Wang, and Q. Liu (2020) TinyBERT: distilling bert for natural language understanding. ArXiv abs/1909.10351. Cited by: §1, §1, §3.1, §3.2.2, §4.4, §4.7.
J. Kaplan, S. McCandlish, T. J. Henighan, T. B. Brown, B. Chess, R. Child, S. Gray, A. Radford, J. Wu, and D. Amodei (2020) Scaling laws for neural language models. ArXiv abs/2001.08361. Cited by: §4.5.
J. Kim, S. Park, and N. Kwak (2018) Paraphrasing complex network: network compression via factor transfer. ArXiv abs/1802.04977. Cited by: §3.2.2.
S. Kornblith, M. Norouzi, H. Lee, and G. E. Hinton (2019) Similarity of neural network representations revisited. ArXiv abs/1905.00414. Cited by: §3.3.
Z. Lan, M. Chen, S. Goodman, K. Gimpel, P. Sharma, and R. Soricut (2020) ALBERT: a lite bert for self-supervised learning of language representations. ArXiv abs/1909.11942. Cited by: §4.4.
Y. Levine, N. Wies, O. Sharir, H. Bata, and A. Shashua (2020) The depth-to-width interplay in self-attention.. arXiv: Learning. Cited by: §4.5.
Y. Li, J. Yosinski, J. Clune, H. Lipson, and J. E. Hopcroft (2015) Convergent learning: do different neural networks learn the same representations?. In FE@NIPS, Cited by: §3.3.
Z. Li, G. Yuan, W. Niu, P. Zhao, Y. Li, Y. Cai, X. Shen, Z. Zhan, Z. Kong, Q. Jin, Z. Chen, S. Liu, K. Yang, B. Ren, Y. Wang, and X. Lin (2021) NPAS: a compiler-aware framework of unified network pruning and architecture search for beyond real-time mobile acceleration. 2021 IEEE/CVF Conference on Computer Vision and Pattern Recognition (CVPR), pp. 14250–14261. Cited by: §1.
J. Lin, R. Men, A. Yang, C. Zhou, M. Ding, Y. Zhang, P. Wang, A. Wang, L. Jiang, X. Jia, J. Zhang, J. Zhang, X. Zou, Z. Li, X. Q. Deng, J. Liu, J. Xue, H. Zhou, J. Ma, J. Yu, Y. Li, W. Lin, J. Zhou, J. ie Tang, and H. Yang (2021) M6: a chinese multimodal pretrainer. ArXiv abs/2103.00823. Cited by: §1.
Y. Liu, M. Ott, N. Goyal, J. Du, M. Joshi, D. Chen, O. Levy, M. Lewis, L. Zettlemoyer, and V. Stoyanov (2019) RoBERTa: a robustly optimized bert pretraining approach. ArXiv abs/1907.11692. Cited by: §3.1.
Z. Liu, Y. Lin, Y. Cao, H. Hu, Y. Wei, Z. Zhang, S. Lin, and B. Guo (2021) Swin transformer: hierarchical vision transformer using shifted windows. 2021 IEEE/CVF International Conference on Computer Vision (ICCV), pp. 9992–10002. Cited by: §1.
I. Loshchilov and F. Hutter (2017) Fixing weight decay regularization in adam. ArXiv abs/1711.05101. Cited by: §4.1.
I. Loshchilov and F. Hutter (2019) Decoupled weight decay regularization. In ICLR, Cited by: §4.1.
S. I. Mirzadeh, M. Farajtabar, A. Li, N. Levine, A. Matsukawa, and H. Ghasemzadeh (2020) Improved knowledge distillation via teacher assistant. In AAAI, Cited by: §4.6.
R. Müller, S. Kornblith, and G. E. Hinton (2019) When does label smoothing help?. In NeurIPS, Cited by: §3.2.1.
W. Park, D. Kim, Y. Lu, and M. Cho (2019) Relational knowledge distillation. 2019 IEEE/CVF Conference on Computer Vision and Pattern Recognition (CVPR), pp. 3962–3971. Cited by: §3.2.3.
P. Passban, Y. Wu, M. Rezagholizadeh, and Q. Liu (2021) ALP-kd: attention-based layer projection for knowledge distillation. In AAAI, Cited by: §3.2.2.
M. E. Peters, M. Neumann, L. Zettlemoyer, and W. Yih (2018) Dissecting contextual word embeddings: architecture and representation. arXiv preprint arXiv:1808.08949. Cited by: §4.4.
P. Rajpurkar, J. Zhang, K. Lopyrev, and P. Liang (2016) SQuAD: 100,000+ questions for machine comprehension of text. In EMNLP, Cited by: §4.1.
A. Romero, N. Ballas, S. E. Kahou, A. Chassang, C. Gatta, and Y. Bengio (2015) FitNets: hints for thin deep nets. CoRR abs/1412.6550. Cited by: §3.2.2.
V. Sanh, L. Debut, J. Chaumond, and T. Wolf (2019) DistilBERT, a distilled version of bert: smaller, faster, cheaper and lighter. ArXiv abs/1910.01108. Cited by: §1, §3.1, §4.4.
Z. Shen, Z. He, and X. Xue (2019) MEAL: multi-model ensemble via adversarial learning. ArXiv abs/1812.02425. Cited by: §4.3.
Z. Shen and M. Savvides (2020)
MEAL v2: boosting vanilla resnet-50 to 80%+ top-1 accuracy on imagenet without tricks
. ArXiv abs/2009.08453. Cited by: §4.3.
A. Simoulin and B. Crabbé (2021) How many layers and why? an analysis of the model depth in transformers. In Proceedings of the 59th Annual Meeting of the Association for Computational Linguistics and the 11th International Joint Conference on Natural Language Processing: Student Research Workshop, pp. 221–228. Cited by: §4.4.
R. Socher, A. Perelygin, J. Wu, J. Chuang, C. D. Manning, A. Ng, and C. Potts (2013) Recursive deep models for semantic compositionality over a sentiment treebank. In EMNLP, Cited by: §4.1.
S. Sun, Y. Cheng, Z. Gan, and J. Liu (2019) Patient knowledge distillation for bert model compression. In EMNLP, Cited by: §4.4.
Z. Sun, H. Yu, X. Song, R. Liu, Y. Yang, and D. Zhou (2020) MobileBERT: a compact task-agnostic bert for resource-limited devices. ArXiv abs/2004.02984. Cited by: §1, §3.1, §3.2.2.
I. Sutskever, J. Martens, G. E. Dahl, and G. E. Hinton (2013) On the importance of initialization and momentum in deep learning. In ICML, Cited by: §3.1.
Y. Tian, D. Krishnan, and P. Isola (2020) Contrastive representation distillation. ArXiv abs/1910.10699. Cited by: §2.1.
F. Tung and G. Mori (2019) Similarity-preserving knowledge distillation. 2019 IEEE/CVF International Conference on Computer Vision (ICCV), pp. 1365–1374. Cited by: §3.2.3.
I. Turc, M. Chang, K. Lee, and K. Toutanova (2019) Well-read students learn better: the impact of student initialization on knowledge distillation. ArXiv abs/1908.08962. Cited by: §3.1, §4.2.
A. Vaswani, N. M. Shazeer, N. Parmar, J. Uszkoreit, L. Jones, A. N. Gomez, L. Kaiser, and I. Polosukhin (2017) Attention is all you need. In NIPS, Cited by: §2.2.
A. Wang, A. Singh, J. Michael, F. Hill, O. Levy, and S. R. Bowman (2018) GLUE: a multi-task benchmark and analysis platform for natural language understanding. ArXiv abs/1804.07461. Cited by: §4.1.
P. Wang, A. Yang, R. Men, J. Lin, S. Bai, Z. Li, J. Ma, C. Zhou, J. Zhou, and H. Yang (2022) Unifying architectures, tasks, and modalities through a simple sequence-to-sequence learning framework. arXiv preprint arXiv:2202.03052. Cited by: §1.
W. Wang, H. Bao, S. Huang, L. Dong, and F. Wei (2021) MiniLMv2: multi-head self-attention relation distillation for compressing pretrained transformers. In FINDINGS, Cited by: §3.2.3, §4.4.
W. Wang, F. Wei, L. Dong, H. Bao, N. Yang, and M. Zhou (2020) MiniLM: deep self-attention distillation for task-agnostic compression of pre-trained transformers. ArXiv abs/2002.10957. Cited by: §1, §1, §3.1, §3.2.2, §3.2.3, §4.4.
A. Warstadt, A. Singh, and S. R. Bowman (2019) Neural network acceptability judgments. Transactions of the Association for Computational Linguistics 7, pp. 625–641. Cited by: §4.1.
Z. Wu, Z. Liu, J. Lin, Y. Lin, and S. Han (2020) Lite transformer with long-short range attention. ArXiv abs/2004.11886. Cited by: §4.7.
Z. Yang, Y. Cui, Z. Chen, W. Che, T. Liu, S. Wang, and G. Hu (2020)
TextBrewer: An Open-Source Knowledge Distillation Toolkit for Natural Language Processing
. In Proceedings of the 58th Annual Meeting of the Association for Computational Linguistics: System Demonstrations, pp. 9–16. External Links: Link Cited by: §A.1.2.
J. Yim, D. Joo, J. Bae, and J. Kim (2017) A gift from knowledge distillation: fast optimization, network minimization and transfer learning. 2017 IEEE Conference on Computer Vision and Pattern Recognition (CVPR), pp. 7130–7138. Cited by: §3.2.3, §4.4.
L. Yuan, F. E. H. Tay, G. Li, T. Wang, and J. Feng (2020) Revisiting knowledge distillation via label smoothing regularization. 2020 IEEE/CVF Conference on Computer Vision and Pattern Recognition (CVPR), pp. 3902–3910. Cited by: §2.1, §3.2.1, §4.3, §4.7.
S. Zagoruyko and N. Komodakis (2017)
Paying more attention to attention: improving the performance of convolutional neural networks via attention transfer
. ArXiv abs/1612.03928. Cited by: §3.2.2.
T. Zhang, F. Wu, A. Katiyar, K. Q. Weinberger, and Y. Artzi (2021) Revisiting few-sample bert fine-tuning. ArXiv abs/2006.05987. Cited by: §3.1.
Y. Zhu, R. Kiros, R. S. Zemel, R. Salakhutdinov, R. Urtasun, A. Torralba, and S. Fidler (2015) Aligning books and movies: towards story-like visual explanations by watching movies and reading books. 2015 IEEE International Conference on Computer Vision (ICCV), pp. 19–27. Cited by: §4.2.
I. A. Zualkernan, S. Dhou, J. Judas, A. R. Sajun, B. R. Gomez, and L. A. Hussain (2022)
An iot system using deep learning to classify camera trap images on the edge
. Comput. 11, pp. 13. Cited by: §1.

Checklist

For all authors…
1. Do the main claims made in the abstract and introduction accurately reflect the paper’s contributions and scope?
2. Did you describe the limitations of your work?
3. Did you discuss any potential negative societal impacts of your work?
4. Have you read the ethics review guidelines and ensured that your paper conforms to them?
If you are including theoretical results…
1. Did you state the full set of assumptions of all theoretical results?
2. Did you include complete proofs of all theoretical results?
If you ran experiments…
1. Did you include the code, data, and instructions needed to reproduce the main experimental results (either in the supplemental material or as a URL)?
2. Did you specify all the training details (e.g., data splits, hyperparameters, how they were chosen)?
3. Did you report error bars (e.g., with respect to the random seed after running experiments multiple times)?
4. Did you include the total amount of compute and the type of resources used (e.g., type of GPUs, internal cluster, or cloud provider)?
If you are using existing assets (e.g., code, data, models) or curating/releasing new assets…
1. If your work uses existing assets, did you cite the creators?
2. Did you mention the license of the assets?
3. Did you include any new assets either in the supplemental material or as a URL?
4. Did you discuss whether and how consent was obtained from people whose data you’re using/curating?
5. Did you discuss whether the data you are using/curating contains personally identifiable information or offensive content?
If you used crowd sourcing or conducted research with human subjects…
1. Did you include the full text of instructions given to participants and screenshots, if applicable?
2. Did you describe any potential participant risks, with links to Institutional Review Board (IRB) approvals, if applicable?
3. Did you include the estimated hourly wage paid to participants and the total amount spent on participant compensation?

Appendix A Appendix

a.1 Reproducibility

a.1.1 Settings

In most experiments, we use the following default settings unless otherwise specified:

The hyperparameters of loss weight $β_{k l}$ is set to be 1.
The temperature and hard label weight are tuned by grid search and select the best one in other experiments (See Section 4.3).
The initialization scheme is pre-train (See Section 4.2).

In the experiments about temperature and hard label weight in Section 4.3, no feature-based or relation-based knowledge distillation is used.

a.1.2 Code

We provide source code of this paper in the supplementary material. The main file is main.py. We modified the implementation of BERT in huggingface in custom_bert.py

for the convenience of distillation. In the environment of distributed multi-GPU, we use the DistributedDataParallel (DDP) provided by PyTorch and the main file is

distributed_wrapper.py. For part of the implementations of knowledge distillation, we use the TextBrewer (Yang et al., 2020) under Apache 2.0 license.

a.1.3 Teacher Models

We download the fine-tuned ${BERT}_{base}$ teacher models of different GLUE task in huggingface:

The ${BERT}_{large}$ models are downloaded from https://huggingface.co/yoshitomo-matsubara.

a.2 Knowledge Types

In this subsection, we introduce the definitions of the knowledge used in Section 4.4. $T$ and $S$ denote the teacher model and the student model here. $l$ and $r$ indicate the layer number of $T$ and $S$ respectively. $N_{h}$ is the number of attention heads. $A$ is the attention matrix and $H$ is the hidden state. $W$ indicates the learnable projection matrix.

Attention mse: the mse loss of the sum of attention heads between $T$ and $S$

$L = D_{m s e} (N_{h}^{S} \sum a = 1 A_{a, l}^{S}, N_{h}^{T} \sum a = 1 A_{a, r}^{T})$ (10)
Attention ce: the cross-entropy loss of the mean of attention heads between $T$ and $S$

$L = D_{c e} (\frac{1}{N_{h}^{S}} N_{h}^{S} \sum a = 1 A_{a, l}^{S}, \frac{1}{N_{h}^{T}} N_{h}^{T} \sum a = 1 A_{a, r}^{T})$ (11)
Hidden mse: the mse loss of the hidden states between $T$ and $S$

$L = D_{m s e} (H_{l}^{S}, H_{r}^{T} W_{l r})$ (12)
Cos: the cosine similarity loss between the hidden states between $T$ and $S$

$\begin{matrix} L & = D_{c o s} (H_{l}^{S}, H_{r}^{T} W_{l r}) = 1 - c o s (H_{l}^{S}, H_{r}^{T} W_{l r}) \end{matrix}$ (13)
Pkd: the normalized mse loss of the hidden states between $T$ and $S$

$L = D_{m s e} (\frac{H_{l}^{S}}{| H_{l}^{S} |}, \frac{H_{r}^{T} W_{l r}}{| H_{r}^{T} W_{l r} |})$ (14)
Mmd: the mse loss between the similarity matrices of hidden states. $H_{1}$ and $H_{2}$ are two hidden states in models. $⊤$ indicates the matrix transpose.

$L = D_{m s e} (H_{1}^{T} \cdot H_{2}^{T ⊤}, H_{1}^{S} \cdot H_{2}^{S ⊤})$ (15)
Gram: the mse loss between the similarity matrices of hidden states. The difference between mmd and gram is the order of matrix multiplication.

$L = D_{m s e} (H_{1}^{T ⊤} \cdot H_{2}^{T}, H_{1}^{S ⊤} \cdot H_{2}^{S})$ (16)
Query relation: the KL-divergence loss of the query relation between $T$ and $S$

${V R}_{l, a}^{T} = softmax (\frac{V_{l, a}^{T} \cdot V_{l, a}^{T ⊤}}{\sqrt{d}})$

${V R}_{r, a}^{S} = softmax (\frac{V_{r, a}^{S} \cdot V_{r, a}^{S ⊤}}{\sqrt{d}})$
Key relation: the KL-divergence loss of the key relation between $T$ and $S$ . The definition is similar to the query relation above, just replace $Q$ with $K$ .
Value relation: the KL-divergence loss of the value relation between $T$ and $S$ . The definition is similar to the query relation above, just replace $Q$ with $V$ .

a.3 Detailed Experimental Results

a.3.1 Temperature & Hard Label Weight

Temperature

MRPC

0.1

0.701

0.7181

0.7206

0.701

0.2

0.701

0.7034

0.7083

0.7059

0.5

0.7034

0.701

0.7059

0.7034

0.701

0.7059

0.7132

0.7034

0.7059

0.7083

Hard

Label

Weight

0.701

0.7034

0.7083

0.7059

SST-2

0.1

0.8716

0.8693

0.8681

0.8647

0.2

0.8658

0.8670

0.8658

0.8624

0.5

0.8647

0.8658

0.8681

0.8647

0.8601

0.8647

0.8681

0.8601

0.8635

0.8578

0.8635

0.8624

Hard

Label

Weight

0.8624

0.8601

0.8647

QQP

0.1

0.8925

0.8926

0.8919

0.8894

0.2

0.8901

0.8925

0.8903

0.8877

0.5

0.889

0.89

0.8893

0.8862

0.8903

0.8892

0.8873

0.8855

0.8907

0.8872

0.8869

0.8825

Hard

Label

Weight

0.8864

0.8856

0.8874

0.8846

QNLI

0.1

0.84

0.8433

0.8442

0.844

0.2

0.8433

0.8424

0.8406

0.8428

0.5

0.8439

0.8422

0.8417

0.84

0.5054

0.842

0.8402

0.8406

0.8424

0.8391

0.8398

0.8402

Hard

Label

Weight

0.84

0.8406

0.8382

0.8404

RTE

0.1

0.6751

0.6679

0.6606

0.6751

0.2

0.657

0.6643

0.5

0.6643

0.6679

0.6642

0.657

0.5957

0.6679

0.6643

0.6679

0.6534

0.6643

0.6606

Hard

Label

Weight

0.657

0.6643

CoLA

0.1

0.7373

0.7335

0.2

0.7469

0.7354

0.744

0.7248

0.5

0.7421

0.7277

0.7287

0.7248

0.7402

0.7335

0.7296

0.7172

0.7306

0.7229

0.7191

0.7133

Hard

Label

Weight

0.7229

0.7162

0.7124

0.7229

STS-B

0.1

0.8552

0.8515

0.7434

0.4664

0.2

0.8591

0.84

0.6162

0.4558

0.5

0.8454

0.7454

0.4624

0.4485

0.8379

0.6001

0.4535

0.4459

0.7689

0.4624

0.4485

0.8454

Hard

Label

Weight

0.5345

0.4515

0.4454

0.4438

MNLI-mm

0.1

0.7775

0.7794

0.7811

0.7756

0.2

0.7771

0.7806

0.776

0.7704

0.5

0.7783

0.7761

0.7721

0.7726

0.7757

0.7739

0.7688

0.769

0.7742

0.7709

0.7669

0.7675

Hard

Label

Weight

0.7686

0.7683

0.7667

0.7652

MNLI-m

0.1

0.7664

0.7657

0.7526

0.7608

0.2

0.7531

0.7526

0.7518

0.7637

0.5

0.766

0.7551

0.7539

0.7623

0.7638

0.7533

0.7612

0.7505

0.7533

0.7514

0.758

0.7607

Hard

Label

Weight

0.7604

0.7504

0.7577

0.7587

Table 4: Hyper-parameters experiments about temperature and hard label weight

a.3.2 Single-Match Experiments

MRPC
bert-small	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.7868	0.7672	0.799	0.7917	0.8137
attention_ce_mean	0.7843	0.7819	0.7819	0.7892	0.8015
hidden_mse	0.7598	0.7672	0.7623	0.7917	0.7966
mmd	0.8113	0.7843	0.799	0.7917	0.799
gram	0.8064	0.8162	0.8235	0.799	0.8064
cos	0.7721	0.7598	0.7721	0.8186	0.7868
pkd	0.7525	0.8456	0.8284	0.8284	0.8407
query_relation	0.8137	0.799	0.799	0.799	0.8134
key_relation	0.8088	0.8015	0.8039	0.8137	0.7892
value_relation	0.8015	0.8015	0.8039	0.799	0.8039
bert-mini	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.7941	0.7353	0.7426	0.8088	0.826
attention_ce_mean	0.8088	0.8137	0.7917	0.8186	0.8186
hidden_mse	0.75	0.75	0.7598	0.8088	0.8186
mmd	0.8333	0.8186	0.8431	0.8186	0.8064
gram	0.8333	0.8064	0.8358	0.8064	0.8186
cos	0.7549	0.7451	0.7475	0.8186	0.7721
pkd	0.7426	0.826	0.7941	0.8113	0.8088
query_relation	0.8211	0.8211	0.8235	0.8333	0.8145
key_relation	0.8284	0.8211	0.8235	0.8235	0.777
value_relation	0.8186	0.826	0.8284	0.8162	0.8137
bert-tiny	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.7647	0.7623	0.7623	0.7598	0.7377
attention_ce_mean	0.7672	0.7623	0.7647	0.7647	0.7279
hidden_mse	0.7475	0.7451	0.7475	0.7672	0.723
mmd	0.7549	0.7647	0.7672	0.7574	0.7304
gram	0.7721	0.7647	0.7721	0.7745	0.7206
cos	0.7328	0.723	0.7328	0.7598	0.723
pkd	0.6838	0.723	0.7255	0.7402	0.7328
query_relation	0.7304	0.7279	0.7279	0.7328	0.7347
key_relation	0.7377	0.7304	0.7328	0.7279	0.7206
value_relation	0.7328	0.7328	0.7304	0.7304	0.7402
SST2
bert-small	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.8922	0.8956	0.8922	0.8865	0.8922
attention_ce_mean	0.8968	0.8956	0.8956	0.8865	0.8922
hidden_mse	0.8819	0.8853	0.8842	0.8968	0.8991
mmd	0.8876	0.8979	0.8922	0.8933	0.8933
gram	0.8911	0.8911	0.8922	0.8911	0.8956
cos	0.8807	0.8796	0.8807	0.8899	0.8968
pkd	0.8704	0.8819	0.8796	0.8899	0.8968
query_relation	0.8899	0.8911	0.8899	0.8933	0.8934
key_relation	0.8865	0.8853	0.8876	0.8911	0.8968
value_relation	0.8933	0.8876	0.8911	0.8865	0.8968
bert-mini	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.8612	0.8693	0.8589	0.8635	0.8704
attention_ce_mean	0.8612	0.8681	0.8727	0.8647	0.867
hidden_mse	0.8578	0.8544	0.8544	0.8647	0.8739
mmd	0.8681	0.8716	0.8784	0.8681	0.8739
gram	0.867	0.8658	0.867	0.867	0.867
cos	0.8291	0.8349	0.8337	0.8647	0.867
pkd	0.82	0.8429	0.8452	0.8578	0.8681
query_relation	0.8647	0.8567	0.8693	0.8612	0.8646
key_relation	0.8624	0.8658	0.8647	0.8635	0.8727
value_relation	0.8624	0.8635	0.8578	0.8589	0.8693
bert-tiny	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.8257	0.8257	0.8222	0.82	0.8245
attention_ce_mean	0.8234	0.8222	0.8211	0.8234	0.8234
hidden_mse	0.8234	0.8245	0.828	0.8234	0.8257
mmd	0.8291	0.8234	0.8222	0.8234	0.8257
gram	0.8234	0.8211	0.8245	0.8222	0.8257
cos	0.82	0.8222	0.8268	0.8211	0.8291
pkd	0.82	0.8257	0.8245	0.8245	0.8314
query_relation	0.8222	0.8314	0.8222	0.8234	0.8245
key_relation	0.8314	0.8222	0.8314	0.8245	0.8268
value_relation	0.8245	0.8245	0.8245	0.8245	0.8257
QQP
bert-small	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.9003	0.8999	0.9002	0.901	0.8934
attention_ce_mean	0.9005	0.9007	0.9008	0.9001	0.8955
hidden_mse	0.8983	0.9013	0.9009	0.8995	0.8962
mmd	0.9001	0.9002	0.9021	0.8995	0.895
gram	0.9	0.9028	0.9023	0.9011	0.8953
cos	0.8979	0.9	0.9017	0.9007	0.8977
pkd	0.8953	0.9014	0.9037	0.8987	0.8982
query_relation	0.8941	0.8938	0.8947	0.895	0.8939
key_relation	0.8945	0.8952	0.8938	0.8941	0.8955
value_relation	0.8943	0.8959	0.8948	0.8936	0.8943
bert-mini	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.8909	0.8887	0.889	0.8939	0.8899
attention_ce_mean	0.8914	0.894	0.893	0.8945	0.8895
hidden_mse	0.8896	0.8926	0.8937	0.8918	0.8907
mmd	0.8919	0.8916	0.8917	0.8921	0.8898
gram	0.8928	0.8933	0.8931	0.8928	0.8922
cos	0.8876	0.8874	0.8884	0.8916	0.8925
pkd	0.8857	0.8911	0.8903	0.8919	0.894
query_relation	0.8906	0.8895	0.8911	0.8897	0.8878
key_relation	0.8897	0.8896	0.8901	0.8908	0.8909
value_relation	0.8903	0.8904	0.8911	0.8908	0.8888
bert-tiny	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.8634	0.8644	0.866	0.8663	0.8719
attention_ce_mean	0.8657	0.8645	0.8659	0.8643	0.872
hidden_mse	0.8615	0.8613	0.864	0.8607	0.8707
mmd	0.8665	0.8628	0.8642	0.8655	0.8719
gram	0.8666	0.8657	0.867	0.8659	0.872
cos	0.8626	0.8651	0.8626	0.8606	0.8689
pkd	0.8619	0.8671	0.8685	0.8591	0.8734
query_relation	0.8708	0.8714	0.8714	0.8703	0.8715
key_relation	0.8714	0.8711	0.8716	0.8699	0.8716
value_relation	0.8713	0.8708	0.8716	0.8718	0.874
QNLI
bert-small	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.8602	0.8598	0.8666	0.8697	0.8735
attention_ce_mean	0.8706	0.868	0.8677	0.8666	0.8713
hidden_mse	0.842	0.842	0.8393	0.8675	0.8719
mmd	0.8695	0.8592	0.8658	0.8702	0.8702
gram	0.8666	0.8536	0.8653	0.8695	0.8726
cos	0.8389	0.8278	0.8365	0.8647	0.864
pkd	0.8221	0.8603	0.8534	0.8711	0.8651
query_relation	0.8695	0.8702	0.8708	0.8704	0.8705
key_relation	0.8724	0.8722	0.8722	0.8689	0.8693
value_relation	0.8726	0.8669	0.8708	0.8722	0.8693
bert-mini	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.8378	0.8353	0.8376	0.8431	0.844
attention_ce_mean	0.8417	0.842	0.842	0.8415	0.844
hidden_mse	0.8329	0.8248	0.836	0.8411	0.8426
mmd	0.8418	0.8406	0.8422	0.8422	0.8473
gram	0.8422	0.8343	0.84	0.8433	0.8442
cos	0.8272	0.8135	0.8173	0.8389	0.8426
pkd	0.806	0.8365	0.8395	0.8384	0.8473
query_relation	0.8446	0.844	0.8448	0.842	0.8415
key_relation	0.8475	0.8442	0.8439	0.8433	0.8446
value_relation	0.8431	0.8457	0.8439	0.8424	0.8457
bert-tiny	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.7924	0.7926	0.7919	0.7915	0.7968
attention_ce_mean	0.7983	0.7926	0.7979	0.791	0.7968
hidden_mse	0.7756	0.7741	0.7851	0.7844	0.795
mmd	0.7913	0.7862	0.7939	0.7981	0.797
gram	0.7937	0.7844	0.7891	0.7893	0.7974
cos	0.7803	0.7672	0.7679	0.7822	0.791
pkd	0.7631	0.7829	0.7827	0.7849	0.7908
query_relation	0.7972	0.7919	0.7972	0.7983	0.7984
key_relation	0.7913	0.797	0.7968	0.7979	0.7961
value_relation	0.7926	0.7974	0.7974	0.7926	0.7961
RTE
bert-small	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.6282	0.6318	0.6245	0.6498	0.6679
attention_ce_mean	0.657	0.6534	0.6534	0.6534	0.6787
hidden_mse	0.5957	0.5957	0.574	0.6643	0.6606
mmd	0.6606	0.6462	0.6534	0.657	0.6643
gram	0.6606	0.6859	0.6679	0.6426	0.6859
cos	0.5704	0.5487	0.5523	0.6715	0.6462
pkd	0.5487	0.574	0.5596	0.6462	0.6498
query_relation	0.6643	0.6679	0.6679	0.6751	0.6745
key_relation	0.6751	0.6715	0.657	0.6751	0.6534
value_relation	0.6787	0.657	0.6643	0.6751	0.6787
bert-mini	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.6426	0.5957	0.6065	0.6498	0.6643
attention_ce_mean	0.6498	0.6462	0.6462	0.6643	0.6715
hidden_mse	0.5632	0.556	0.5487	0.6606	0.6426
mmd	0.657	0.657	0.6823	0.657	0.657
gram	0.6859	0.6606	0.6931	0.6643	0.6787
cos	0.5812	0.5957	0.574	0.6715	0.6209
pkd	0.556	0.5776	0.5812	0.657	0.6245
query_relation	0.6859	0.6823	0.6823	0.6787	0.6789
key_relation	0.6715	0.6715	0.6715	0.6751	0.6426
value_relation	0.6823	0.7004	0.6823	0.6715	0.6715
bert-tiny	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.6173	0.5957	0.6029	0.6209	0.6101
attention_ce_mean	0.6173	0.6065	0.6065	0.6173	0.6173
hidden_mse	0.5993	0.6209	0.6101	0.6173	0.5884
mmd	0.6173	0.5957	0.5957	0.6209	0.6137
gram	0.6137	0.6065	0.6209	0.6173	0.6209
cos	0.5921	0.6209	0.6065	0.6065	0.5812
pkd	0.6137	0.6065	0.6245	0.6137	0.5993
query_relation	0.6354	0.6426	0.6426	0.639	0.6354
key_relation	0.639	0.6354	0.6354	0.6354	0.6101
value_relation	0.6245	0.6354	0.6245	0.639	0.6282
CoLA
bert-small	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.767	0.7383	0.7478	0.768	0.7766
attention_ce_mean	0.7718	0.7613	0.7603	0.7632	0.7881
hidden_mse	0.6932	0.6913	0.7066	0.768	0.7804
mmd	0.7574	0.7517	0.7565	0.7603	0.7766
gram	0.7747	0.7603	0.7641	0.7555	0.7804
cos	0.6942	0.6942	0.6989	0.7593	0.7718
pkd	0.6913	0.7066	0.7057	0.7661	0.768
query_relation	0.7709	0.7651	0.7718	0.7718	0.7745
key_relation	0.7718	0.7728	0.7728	0.7728	0.7756
value_relation	0.7689	0.7776	0.7737	0.7728	0.7795
bert-mini	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.6922	0.6989	0.6932	0.7392	0.745
attention_ce_mean	0.7354	0.7354	0.7383	0.744	0.745
hidden_mse	0.6951	0.6951	0.6932	0.7383	0.743
mmd	0.7229	0.698	0.6951	0.744	0.7459
gram	0.7488	0.7354	0.744	0.7363	0.745
cos	0.6942	0.6913	0.6913	0.7248	0.7181
pkd	0.6913	0.6913	0.6913	0.743	0.7335
query_relation	0.7459	0.7469	0.744	0.744	0.7457
key_relation	0.7469	0.7411	0.745	0.745	0.745
value_relation	0.7392	0.7383	0.7469	0.743	0.743
bert-tiny	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.6932	0.6913	0.6913	0.6913	0.6913
attention_ce_mean	0.6913	0.6913	0.6961	0.6913	0.6999
hidden_mse	0.6913	0.6913	0.6913	0.6913	0.6913
mmd	0.6913	0.6913	0.6932	0.6922	0.6989
gram	0.6913	0.6942	0.6913	0.6932	0.6951
cos	0.6951	0.6913	0.6913	0.6951	0.6913
pkd	0.6913	0.6922	0.6913	0.6913	0.6913
query_relation	0.6913	0.6913	0.6913	0.6913	0.6913
key_relation	0.6913	0.6913	0.6913	0.6913	0.6942
value_relation	0.6913	0.6913	0.6913	0.6913	0.6942
STSB
bert-small	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.8717	0.8731	0.8713	0.8728	0.8715
attention_ce_mean	0.8702	0.8699	0.8651	0.8646	0.8724
hidden_mse	0.8689	0.8696	0.8687	0.8597	0.8735
mmd	0.8725	0.8708	0.8693	0.8705	0.8724
gram	0.8726	0.8718	0.873	0.8716	0.8737
cos	0.8726	0.8661	0.8692	0.8626	0.8725
pkd	0.864	0.8672	0.8678	0.8594	0.873
query_relation	0.8697	0.8711	0.87	0.8715	0.8731
key_relation	0.8731	0.8712	0.8704	0.8714	0.8733
value_relation	0.87	0.8708	0.8706	0.8711	0.8718
bert-mini	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.8669	0.865	0.8653	0.8556	0.8652
attention_ce_mean	0.8656	0.8643	0.8645	0.8671	0.8634
hidden_mse	0.8637	0.8613	0.8494	0.8675	0.8636
mmd	0.8574	0.8485	0.866	0.8536	0.8627
gram	0.8651	0.8648	0.8652	0.8585	0.863
cos	0.8634	0.8533	0.8633	0.8598	0.8647
pkd	0.8402	0.8384	0.8595	0.8519	0.865
query_relation	0.862	0.8622	0.8611	0.8627	0.8663
key_relation	0.8631	0.8612	0.8598	0.8624	0.8674
value_relation	0.8615	0.861	0.8604	0.8632	0.8646
bert-tiny	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.7769	0.7822	0.6231	0.7797	0.8165
attention_ce_mean	0.7813	0.7816	0.7871	0.6145	0.8167
hidden_mse	0.7796	0.7848	0.7859	0.6546	0.8166
mmd	0.7879	0.6161	0.6075	0.6266	0.8168
gram	0.7802	0.7758	0.7795	0.6325	0.8166
cos	0.6664	0.7857	0.6735	0.6776	0.8163
pkd	0.6745	0.6911	0.7814	0.6685	0.8156
query_relation	0.7969	0.7969	0.8058	0.8065	0.8155
key_relation	0.804	0.7969	0.7969	0.8065	0.8173
value_relation	0.8065	0.797	0.7989	0.797	0.8166
MNLI-mm
bert-small	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.7861	0.7811	0.787	0.7886	0.8008
attention_ce_mean	0.788	0.7877	0.7916	0.79	0.8011
hidden_mse	0.7764	0.776	0.779	0.7862	0.8003
mmd	0.7895	0.7911	0.7866	0.7876	0.7998
gram	0.7867	0.7881	0.7881	0.79	0.8001
cos	0.7679	0.7735	0.7833	0.7851	0.8014
pkd	0.7483	0.7883	0.7936	0.7872	0.8098
query_relation	0.7916	0.7917	0.7918	0.7918	0.7995
key_relation	0.7926	0.7916	0.7894	0.7923	0.7983
value_relation	0.7912	0.7927	0.7905	0.7922	0.8008
bert-mini	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.761	0.7457	0.7522	0.7717	0.7831
attention_ce_mean	0.7722	0.774	0.7722	0.7736	0.7829
hidden_mse	0.7476	0.7492	0.76	0.7674	0.7833
mmd	0.7724	0.7686	0.773	0.7729	0.782
gram	0.7707	0.7653	0.7727	0.7723	0.7847
cos	0.7388	0.7485	0.7459	0.7632	0.7859
pkd	0.7294	0.7632	0.7645	0.7672	0.7928
query_relation	0.7728	0.7749	0.7726	0.7736	0.7844
key_relation	0.7735	0.7731	0.7733	0.7743	0.7833
value_relation	0.7731	0.7728	0.7743	0.7732	0.7826
bert-tiny	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.7072	0.7013	0.702	0.7036	0.7181
attention_ce_mean	0.702	0.7063	0.7035	0.7024	0.7191
hidden_mse	0.6974	0.7035	0.6995	0.7007	0.7284
mmd	0.7043	0.7063	0.704	0.7053	0.7287
gram	0.7041	0.7002	0.7005	0.7035	0.7175
cos	0.6915	0.6928	0.6961	0.6988	0.7233
pkd	0.5794	0.6989	0.7002	0.6969	0.7321
query_relation	0.711	0.71	0.71	0.7112	0.7282
key_relation	0.709	0.7088	0.7083	0.7104	0.7281
value_relation	0.7097	0.7074	0.7087	0.7089	0.7276
MNLI-m
bert-small	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.7943	0.7877	0.7893	0.7915	0.8047
attention_ce_mean	0.7915	0.7917	0.7946	0.7947	0.7954
hidden_mse	0.7853	0.7818	0.7873	0.7944	0.8004
mmd	0.7911	0.7921	0.7887	0.7885	0.7991
gram	0.7949	0.7912	0.7959	0.7896	0.799
cos	0.781	0.7824	0.787	0.7928	0.8013
pkd	0.7686	0.7905	0.7947	0.7924	0.807
query_relation	0.792	0.7926	0.7926	0.7926	0.793
key_relation	0.7934	0.7929	0.791	0.7938	0.8011
value_relation	0.7936	0.7933	0.7941	0.7917	0.7946
bert-mini	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.7606	0.7532	0.7555	0.7631	0.7785
attention_ce_mean	0.7643	0.7661	0.7627	0.766	0.7787
hidden_mse	0.7575	0.7555	0.761	0.7614	0.7783
mmd	0.7655	0.7628	0.7624	0.7678	0.7788
gram	0.7619	0.7637	0.7669	0.7668	0.7763
cos	0.7493	0.7511	0.7583	0.7578	0.7798
pkd	0.7244	0.7576	0.7588	0.7602	0.7827
query_relation	0.7694	0.7689	0.7698	0.7697	0.7744
key_relation	0.7702	0.767	0.7694	0.7699	0.776
value_relation	0.7691	0.7676	0.7665	0.7693	0.7753
bert-tiny	First	Last	Dilatation	First-1	Last-1
attention_mse_sum	0.7025	0.6977	0.6977	0.7056	0.7172
attention_ce_mean	0.7069	0.7028	0.7043	0.7038	0.7196
hidden_mse	0.7028	0.7049	0.7033	0.7018	0.7252
mmd	0.7083	0.7006	0.702	0.7043	0.726
gram	0.7035	0.7052	0.7042	0.7038	0.7158
cos	0.6977	0.7018	0.6993	0.7016	0.7261
pkd	0.6772	0.6968	0.6975	0.6997	0.7202
query_relation	0.7074	0.7086	0.7075	0.7082	0.70456
key_relation	0.7088	0.7087	0.7087	0.709	0.7242
value_relation	0.709	0.708	0.7092	0.7106	0.7169

a.3.3 Double-Match Experiments

MRPC
bert-small	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.7696	0.7623	0.7525	0.7917	0.7941
attention_ce_mean,gram	0.8211	0.7966	0.8162	0.799	0.8088
attention_ce_mean,hidden_mse	0.7525	0.75	0.7549	0.7794	0.7966
attention_ce_mean,key_relation	0.7892	0.7696	0.7745	0.8137	0.7941
attention_ce_mean,mmd	0.7966	0.8235	0.8015	0.8039	0.7966
attention_ce_mean,pkd	0.7868	0.8309	0.8162	0.8088	0.8382
attention_ce_mean,query_relation	0.7941	0.7892	0.7819	0.8137	0.7966
attention_ce_mean,value_relation	0.8015	0.8088	0.8015	0.8211	0.8113
attention_ce_mean,value_relation	0.7721	0.7623	0.7672	0.7941	0.8186
attention_mse_sum,gram	0.799	0.7745	0.799	0.799	0.8113
attention_mse_sum,hidden_mse	0.7574	0.7475	0.7647	0.7843	0.8162
attention_mse_sum,key_relation	0.7917	0.7525	0.7794	0.799	0.799
attention_mse_sum,mmd	0.8039	0.8064	0.8088	0.799	0.8113
attention_mse_sum,pkd	0.7745	0.7721	0.8162	0.8137	0.8382
attention_mse_sum,query_relation	0.7966	0.7721	0.7843	0.799	0.8015
attention_mse_sum,value_relation	0.7917	0.7966	0.799	0.8088	0.8137
cos,key_relation	0.7696	0.75	0.7525	0.7966	0.777
cos,query_relation	0.7696	0.7549	0.75	0.799	0.7892
cos,value_relation	0.7574	0.75	0.7598	0.8015	0.7966
gram,key_relation	0.8039	0.7721	0.7672	0.8137	0.7892
gram,query_relation	0.7917	0.7696	0.7794	0.799	0.7917
gram,value_relation	0.8088	0.8064	0.826	0.8015	0.8137
hidden_mse,key_relation	0.75	0.7549	0.7598	0.7794	0.7843
hidden_mse,query_relation	0.7525	0.75	0.7647	0.7794	0.7917
hidden_mse,value_relation	0.7549	0.7549	0.7598	0.7892	0.8039
mmd,key_relation	0.8015	0.7721	0.7868	0.799	0.7966
mmd,query_relation	0.7941	0.7868	0.7868	0.799	0.7843
mmd,value_relation	0.8284	0.8088	0.799	0.799	0.8088
pkd,key_relation	0.777	0.7745	0.7794	0.8162	0.8088
pkd,query_relation	0.7721	0.777	0.7843	0.8088	0.8309
pkd,value_relation	0.7647	0.8211	0.8211	0.8088	0.8358
bert-mini	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.7623	0.7304	0.7451	0.8309	0.7745
attention_ce_mean,gram	0.8431	0.8186	0.8407	0.8211	0.8186
attention_ce_mean,hidden_mse	0.75	0.7475	0.7475	0.8309	0.8088
attention_ce_mean,key_relation	0.799	0.777	0.777	0.826	0.777
attention_ce_mean,mmd	0.8211	0.8162	0.8137	0.8211	0.8039
attention_ce_mean,pkd	0.6838	0.8162	0.777	0.8284	0.8137
attention_ce_mean,query_relation	0.7892	0.7745	0.7794	0.8162	0.7794
attention_ce_mean,value_relation	0.8039	0.8064	0.8137	0.8137	0.8088
attention_mse_sum,cos	0.7623	0.7157	0.7377	0.8235	0.7966
attention_mse_sum,gram	0.8064	0.7328	0.7549	0.8186	0.826
attention_mse_sum,hidden_mse	0.7598	0.723	0.7475	0.8431	0.8211
attention_mse_sum,key_relation	0.8088	0.7304	0.7426	0.8162	0.7966
attention_mse_sum,mmd	0.8113	0.7304	0.7353	0.8333	0.8235
attention_mse_sum,pkd	0.6838	0.7451	0.7574	0.8358	0.8137
attention_mse_sum,query_relation	0.8113	0.7304	0.7377	0.8333	0.7794
attention_mse_sum,value_relation	0.8039	0.7549	0.7574	0.8358	0.8235
cos,key_relation	0.7525	0.7353	0.7451	0.8235	0.7745
cos,query_relation	0.7525	0.7328	0.7525	0.826	0.7549
cos,value_relation	0.75	0.7377	0.7426	0.8309	0.777
gram,key_relation	0.8309	0.7696	0.7672	0.8211	0.777
gram,query_relation	0.7966	0.7574	0.7745	0.826	0.7721
gram,value_relation	0.8137	0.8064	0.8064	0.8235	0.8309
hidden_mse,key_relation	0.7426	0.7377	0.75	0.8235	0.7721
hidden_mse,query_relation	0.7451	0.7353	0.7402	0.8309	0.777
hidden_mse,value_relation	0.75	0.7426	0.7475	0.826	0.799
mmd,key_relation	0.8211	0.7574	0.7794	0.8235	0.7696
mmd,query_relation	0.8064	0.7696	0.7745	0.8186	0.7745
mmd,value_relation	0.8235	0.8186	0.8186	0.826	0.8162
pkd,key_relation	0.6838	0.7696	0.7745	0.8284	0.7868
pkd,query_relation	0.6863	0.7696	0.7672	0.8309	0.7941
pkd,value_relation	0.6863	0.8088	0.7917	0.8284	0.8113
bert-tiny	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.7353	0.7206	0.7108	0.7402	0.7059
attention_ce_mean,gram	0.7206	0.7328	0.7304	0.7304	0.723
attention_ce_mean,hidden_mse	0.7353	0.7304	0.7255	0.7353	0.7206
attention_ce_mean,key_relation	0.7279	0.7157	0.7206	0.723	0.7181
attention_ce_mean,mmd	0.7353	0.7451	0.7475	0.7426	0.7206
attention_ce_mean,pkd	0.6838	0.7475	0.7475	0.7598	0.7328
attention_ce_mean,query_relation	0.7255	0.7279	0.7206	0.7255	0.7279
attention_ce_mean,value_relation	0.7206	0.7377	0.7304	0.723	0.7377
attention_mse_sum,cos	0.7279	0.7206	0.7108	0.7426	0.723
attention_mse_sum,gram	0.7402	0.7255	0.7377	0.7279	0.7304
attention_mse_sum,hidden_mse	0.7328	0.7206	0.7132	0.7353	0.7181
attention_mse_sum,key_relation	0.7451	0.723	0.7279	0.7206	0.7328
attention_mse_sum,mmd	0.7475	0.7353	0.7377	0.7451	0.7304
attention_mse_sum,pkd	0.6838	0.75	0.7647	0.7574	0.7402
attention_mse_sum,query_relation	0.7353	0.7328	0.723	0.7206	0.7328
attention_mse_sum,value_relation	0.7353	0.7328	0.7328	0.723	0.7451
cos,key_relation	0.7353	0.7206	0.7181	0.7426	0.7206
cos,query_relation	0.7353	0.7157	0.7108	0.7402	0.7157
cos,value_relation	0.7279	0.723	0.7206	0.7402	0.723
gram,key_relation	0.723	0.7279	0.7255	0.7279	0.7206
gram,query_relation	0.7279	0.7279	0.7279	0.7279	0.7206
gram,value_relation	0.7255	0.7279	0.7255	0.7353	0.7304
hidden_mse,key_relation	0.7353	0.7304	0.7402	0.723	0.7206
hidden_mse,query_relation	0.7426	0.7304	0.7377	0.7255	0.7206
hidden_mse,value_relation	0.7279	0.7304	0.7255	0.723	0.7328
mmd,key_relation	0.7353	0.7574	0.7451	0.7353	0.7206
mmd,query_relation	0.7353	0.7525	0.7353	0.7304	0.7255
mmd,value_relation	0.7353	0.7525	0.7475	0.7451	0.7328
pkd,key_relation	0.6838	0.7525	0.7451	0.7574	0.7304
pkd,query_relation	0.6838	0.7475	0.7451	0.7549	0.7304
pkd,value_relation	0.6838	0.7426	0.7451	0.7598	0.7426
sst2
bert-small	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.8853	0.8888	0.8865	0.8899	0.8979
attention_ce_mean,gram	0.8956	0.8922	0.8922	0.8979	0.8922
attention_ce_mean,hidden_mse	0.8876	0.8956	0.8968	0.8911	0.8968
attention_ce_mean,key_relation	0.8956	0.8968	0.9014	0.8956	0.8979
attention_ce_mean,mmd	0.8922	0.8956	0.8888	0.8956	0.8945
attention_ce_mean,pkd	0.8739	0.8922	0.8922	0.8911	0.8945
attention_ce_mean,query_relation	0.9002	0.8876	0.8933	0.8979	0.8899
attention_ce_mean,value_relation	0.8979	0.8933	0.8968	0.8888	0.8991
attention_mse_sum,cos	0.8796	0.8899	0.9002	0.8933	0.8899
attention_mse_sum,gram	0.8956	0.9002	0.8956	0.8876	0.8968
attention_mse_sum,hidden_mse	0.8865	0.8945	0.8956	0.8922	0.8979
attention_mse_sum,key_relation	0.8979	0.8979	0.8865	0.8933	0.8979
attention_mse_sum,mmd	0.8991	0.8979	0.8956	0.8945	0.8911
attention_mse_sum,pkd	0.8796	0.8899	0.8876	0.8945	0.9002
attention_mse_sum,query_relation	0.8888	0.8956	0.8933	0.8865	0.8956
attention_mse_sum,value_relation	0.8899	0.8968	0.8945	0.8853	0.8922
cos,key_relation	0.883	0.8876	0.8888	0.8911	0.8911
cos,query_relation	0.8819	0.8899	0.8911	0.8945	0.8956
cos,value_relation	0.8876	0.8922	0.8888	0.9002	0.8933
gram,key_relation	0.8933	0.8933	0.8899	0.8865	0.8888
gram,query_relation	0.8979	0.8979	0.8945	0.8853	0.8979
gram,value_relation	0.8991	0.9014	0.8979	0.8911	0.8922
hidden_mse,key_relation	0.8899	0.8899	0.8865	0.8876	0.906
hidden_mse,query_relation	0.8956	0.8865	0.8876	0.8945	0.9037
hidden_mse,value_relation	0.8922	0.8945	0.8922	0.8979	0.9025
mmd,key_relation	0.8933	0.9002	0.8991	0.8865	0.8956
mmd,query_relation	0.8968	0.8979	0.8979	0.8968	0.8945
mmd,value_relation	0.8888	0.8911	0.8956	0.8979	0.8899
pkd,key_relation	0.8819	0.8888	0.8899	0.8911	0.8956
pkd,query_relation	0.8761	0.8865	0.8876	0.8888	0.8933
pkd,value_relation	0.883	0.8933	0.8899	0.8911	0.8979
bert-mini	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.8544	0.8452	0.8544	0.8704	0.8693
attention_ce_mean,gram	0.8761	0.8727	0.8727	0.8693	0.8693
attention_ce_mean,hidden_mse	0.867	0.8635	0.8704	0.8693	0.8727
attention_ce_mean,key_relation	0.8693	0.8727	0.867	0.867	0.8773
attention_ce_mean,mmd	0.867	0.8727	0.8693	0.8658	0.8704
attention_ce_mean,pkd	0.8314	0.8578	0.8704	0.8647	0.8704
attention_ce_mean,query_relation	0.8704	0.8727	0.8739	0.8739	0.8704
attention_ce_mean,value_relation	0.8693	0.8693	0.8727	0.8739	0.8658
attention_mse_sum,cos	0.8578	0.8463	0.844	0.8704	0.8704
attention_mse_sum,gram	0.8647	0.8761	0.8589	0.8704	0.8739
attention_mse_sum,hidden_mse	0.8635	0.8567	0.8601	0.8704	0.8773
attention_mse_sum,key_relation	0.867	0.8693	0.8658	0.8647	0.8739
attention_mse_sum,mmd	0.8635	0.875	0.8681	0.8658	0.8739
attention_mse_sum,pkd	0.8211	0.8452	0.8486	0.867	0.8716
attention_mse_sum,query_relation	0.8704	0.8796	0.867	0.8681	0.8693
attention_mse_sum,value_relation	0.8658	0.8693	0.8739	0.8681	0.867
cos,key_relation	0.8612	0.8555	0.8635	0.8681	0.867
cos,query_relation	0.8555	0.8532	0.8658	0.8693	0.8704
cos,value_relation	0.8578	0.8498	0.8567	0.8658	0.8716
gram,key_relation	0.8727	0.867	0.8773	0.8716	0.8693
gram,query_relation	0.8739	0.8624	0.8727	0.8704	0.8693
gram,value_relation	0.8716	0.8727	0.8853	0.8704	0.8647
hidden_mse,key_relation	0.867	0.8589	0.8624	0.8693	0.8739
hidden_mse,query_relation	0.867	0.8589	0.867	0.8704	0.8693
hidden_mse,value_relation	0.867	0.8567	0.8681	0.8681	0.8704
mmd,key_relation	0.8693	0.8681	0.8739	0.867	0.8693
mmd,query_relation	0.875	0.8773	0.8716	0.8693	0.8704
mmd,value_relation	0.8624	0.8681	0.8693	0.8761	0.867
pkd,key_relation	0.8349	0.8498	0.8612	0.8612	0.8693
pkd,query_relation	0.8337	0.8417	0.8589	0.8612	0.875
pkd,value_relation	0.8394	0.8624	0.8681	0.8635	0.8704
bert-tiny	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.8234	0.828	0.8314	0.8245	0.828
attention_ce_mean,gram	0.8234	0.8245	0.8234	0.8257	0.828
attention_ce_mean,hidden_mse	0.8257	0.8268	0.828	0.8257	0.8257
attention_ce_mean,key_relation	0.8234	0.8257	0.8234	0.8222	0.8245
attention_ce_mean,mmd	0.8257	0.8257	0.8245	0.8268	0.8245
attention_ce_mean,pkd	0.8291	0.8257	0.8326	0.8268	0.8326
attention_ce_mean,query_relation	0.8222	0.8234	0.8245	0.8245	0.8245
attention_ce_mean,value_relation	0.8234	0.8211	0.8211	0.8291	0.8257
attention_mse_sum,cos	0.8268	0.8291	0.8291	0.8211	0.8245
attention_mse_sum,gram	0.8268	0.8303	0.836	0.8257	0.8268
attention_mse_sum,hidden_mse	0.8257	0.8257	0.828	0.8222	0.8268
attention_mse_sum,key_relation	0.8245	0.8291	0.828	0.828	0.8234
attention_mse_sum,mmd	0.8291	0.8211	0.8245	0.8291	0.8245
attention_mse_sum,pkd	0.8211	0.8326	0.8314	0.8268	0.8303
attention_mse_sum,query_relation	0.8268	0.8245	0.8245	0.8245	0.8268
attention_mse_sum,value_relation	0.8245	0.828	0.8291	0.828	0.8257
cos,key_relation	0.8257	0.8268	0.8268	0.828	0.828
cos,query_relation	0.8245	0.8245	0.8268	0.828	0.8291
cos,value_relation	0.8245	0.828	0.8291	0.8234	0.8268
gram,key_relation	0.8245	0.8234	0.8268	0.8268	0.8268
gram,query_relation	0.8303	0.8268	0.8245	0.8268	0.8245
gram,value_relation	0.8268	0.8268	0.8222	0.828	0.828
hidden_mse,key_relation	0.8234	0.8291	0.8257	0.828	0.8245
hidden_mse,query_relation	0.8245	0.828	0.8268	0.8268	0.8291
hidden_mse,value_relation	0.828	0.8268	0.8268	0.828	0.828
mmd,key_relation	0.828	0.82	0.8234	0.8245	0.8268
mmd,query_relation	0.8257	0.8234	0.8257	0.8245	0.8257
mmd,value_relation	0.8222	0.8177	0.8211	0.8234	0.8234
pkd,key_relation	0.8268	0.8337	0.828	0.8268	0.8291
pkd,query_relation	0.8257	0.8314	0.828	0.828	0.8291
pkd,value_relation	0.8234	0.8326	0.8349	0.8234	0.836
qqp
bert-small	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.8936	0.8995	0.8969	0.8946	0.8977
attention_ce_mean,gram	0.8916	0.8953	0.8925	0.8922	0.8925
attention_ce_mean,hidden_mse	0.8946	0.8974	0.8993	0.8936	0.8968
attention_ce_mean,key_relation	0.8956	0.8953	0.8957	0.8923	0.8925
attention_ce_mean,mmd	0.8956	0.8952	0.8955	0.893	0.8922
attention_ce_mean,pkd	0.8921	0.8989	0.899	0.8936	0.8952
attention_ce_mean,query_relation	0.8951	0.8956	0.8947	0.8951	0.8957
attention_ce_mean,value_relation	0.8915	0.8931	0.8907	0.8958	0.8932
attention_mse_sum,cos	0.8916	0.8956	0.8966	0.8951	0.8966
attention_mse_sum,gram	0.892	0.8964	0.894	0.8954	0.8952
attention_mse_sum,hidden_mse	0.8923	0.896	0.8956	0.8953	0.8982
attention_mse_sum,key_relation	0.8945	0.8897	0.8932	0.8922	0.8961
attention_mse_sum,mmd	0.8943	0.8932	0.8933	0.8929	0.8966
attention_mse_sum,pkd	0.8923	0.8978	0.8997	0.8921	0.8969
attention_mse_sum,query_relation	0.8924	0.8916	0.8919	0.8918	0.8955
attention_mse_sum,value_relation	0.8973	0.8919	0.8971	0.8912	0.8961
cos,key_relation	0.8937	0.8958	0.8972	0.8927	0.8987
cos,query_relation	0.8905	0.8968	0.899	0.8956	0.895
cos,value_relation	0.8922	0.8982	0.8969	0.8925	0.8937
gram,key_relation	0.8915	0.8949	0.8937	0.893	0.891
gram,query_relation	0.8926	0.8942	0.8962	0.8918	0.893
gram,value_relation	0.8938	0.8952	0.8935	0.8926	0.8928
hidden_mse,key_relation	0.8938	0.8976	0.8989	0.8918	0.8929
hidden_mse,query_relation	0.8941	0.8985	0.8991	0.8917	0.8937
hidden_mse,value_relation	0.8917	0.8979	0.8965	0.8921	0.8933
mmd,key_relation	0.8922	0.8923	0.8927	0.8914	0.8959
mmd,query_relation	0.8924	0.8926	0.8921	0.8928	0.8932
mmd,value_relation	0.8915	0.8932	0.8945	0.893	0.8926
pkd,key_relation	0.8914	0.8982	0.8987	0.8917	0.896
pkd,query_relation	0.8914	0.8978	0.9002	0.892	0.8948
pkd,value_relation	0.8939	0.8979	0.9005	0.8949	0.8959
bert-mini	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.8885	0.8938	0.8918	0.8904	0.8919
attention_ce_mean,gram	0.8867	0.8912	0.8923	0.8866	0.8868
attention_ce_mean,hidden_mse	0.8879	0.8908	0.8917	0.8882	0.8913
attention_ce_mean,key_relation	0.8904	0.8867	0.8888	0.8901	0.8886
attention_ce_mean,mmd	0.8888	0.8867	0.8869	0.8869	0.8888
attention_ce_mean,pkd	0.8867	0.8932	0.8968	0.887	0.8936
attention_ce_mean,query_relation	0.8886	0.8899	0.8895	0.8882	0.8893
attention_ce_mean,value_relation	0.8895	0.8908	0.887	0.8908	0.8873
attention_mse_sum,cos	0.8884	0.8901	0.8893	0.892	0.8913
attention_mse_sum,gram	0.8876	0.8897	0.8875	0.8903	0.8904
attention_mse_sum,hidden_mse	0.8841	0.8888	0.891	0.8906	0.8888
attention_mse_sum,key_relation	0.8862	0.8892	0.8859	0.8913	0.8909
attention_mse_sum,mmd	0.8885	0.8847	0.8859	0.8907	0.8877
attention_mse_sum,pkd	0.8864	0.8951	0.8949	0.8899	0.8932
attention_mse_sum,query_relation	0.8883	0.8855	0.886	0.8899	0.8887
attention_mse_sum,value_relation	0.8904	0.8881	0.8856	0.8893	0.8904
cos,key_relation	0.8867	0.892	0.8942	0.8909	0.8897
cos,query_relation	0.8848	0.892	0.8924	0.888	0.8891
cos,value_relation	0.8876	0.8898	0.8927	0.8892	0.8925
gram,key_relation	0.8904	0.8926	0.8906	0.8877	0.8878
gram,query_relation	0.8881	0.8927	0.8898	0.8864	0.888
gram,value_relation	0.8874	0.8911	0.8881	0.8858	0.8895
hidden_mse,key_relation	0.8909	0.8923	0.8952	0.887	0.8902
hidden_mse,query_relation	0.8886	0.8931	0.8952	0.8881	0.8891
hidden_mse,value_relation	0.8904	0.8922	0.8908	0.8882	0.8907
mmd,key_relation	0.8884	0.8899	0.8868	0.8906	0.8904
mmd,query_relation	0.8876	0.8904	0.8893	0.8874	0.8919
mmd,value_relation	0.8872	0.8892	0.8889	0.889	0.8877
pkd,key_relation	0.8876	0.8929	0.8943	0.8893	0.8915
pkd,query_relation	0.8856	0.8929	0.8949	0.8889	0.8917
pkd,value_relation	0.8847	0.8942	0.8956	0.8895	0.8926
bert-tiny	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.8645	0.8702	0.868	0.8688	0.8707
attention_ce_mean,gram	0.8701	0.8671	0.8695	0.8691	0.8695
attention_ce_mean,hidden_mse	0.8691	0.8661	0.8681	0.8694	0.8722
attention_ce_mean,key_relation	0.8724	0.8717	0.8718	0.8719	0.8694
attention_ce_mean,mmd	0.8707	0.8683	0.87	0.8712	0.8725
attention_ce_mean,pkd	0.8659	0.871	0.8706	0.8678	0.8733
attention_ce_mean,query_relation	0.869	0.8717	0.871	0.8676	0.8712
attention_ce_mean,value_relation	0.8689	0.8721	0.872	0.8707	0.8688
attention_mse_sum,cos	0.8653	0.864	0.8677	0.8704	0.8712
attention_mse_sum,gram	0.87	0.8697	0.8637	0.8721	0.8715
attention_mse_sum,hidden_mse	0.8678	0.8616	0.865	0.8699	0.8713
attention_mse_sum,key_relation	0.8699	0.869	0.8704	0.8718	0.8708
attention_mse_sum,mmd	0.8689	0.8637	0.8657	0.867	0.8705
attention_mse_sum,pkd	0.8686	0.8696	0.8724	0.869	0.8718
attention_mse_sum,query_relation	0.8692	0.8698	0.8675	0.8724	0.871
attention_mse_sum,value_relation	0.8708	0.8695	0.8684	0.8707	0.8665
cos,key_relation	0.8669	0.8691	0.8656	0.8679	0.8701
cos,query_relation	0.8659	0.8716	0.8648	0.8653	0.8698
cos,value_relation	0.8658	0.8682	0.8667	0.8711	0.8697
gram,key_relation	0.8692	0.8682	0.872	0.8695	0.869
gram,query_relation	0.8681	0.8689	0.8681	0.8726	0.8699
gram,value_relation	0.8696	0.8726	0.867	0.8683	0.87
hidden_mse,key_relation	0.8682	0.8673	0.8682	0.867	0.8705
hidden_mse,query_relation	0.8687	0.8687	0.8676	0.8681	0.8692
hidden_mse,value_relation	0.8693	0.8677	0.8629	0.8697	0.8711
mmd,key_relation	0.8706	0.871	0.8707	0.8681	0.8674
mmd,query_relation	0.8711	0.8726	0.8718	0.8727	0.8721
mmd,value_relation	0.8725	0.8736	0.8716	0.8734	0.8741
pkd,key_relation	0.8689	0.8687	0.8691	0.8697	0.8719
pkd,query_relation	0.8697	0.869	0.8682	0.8652	0.8715
pkd,value_relation	0.8692	0.8678	0.8684	0.8677	0.8723
qnli
bert-small	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.8521	0.8504	0.8574	0.8686	0.868
attention_ce_mean,gram	0.8677	0.857	0.864	0.8717	0.8711
attention_ce_mean,hidden_mse	0.8554	0.8506	0.855	0.8667	0.8662
attention_ce_mean,key_relation	0.872	0.8717	0.8666	0.8724	0.87
attention_ce_mean,mmd	0.8722	0.8656	0.8713	0.8722	0.87
attention_ce_mean,pkd	0.8272	0.8647	0.8627	0.8711	0.8682
attention_ce_mean,query_relation	0.8744	0.8699	0.8678	0.8719	0.8724
attention_ce_mean,value_relation	0.8704	0.8735	0.8752	0.8744	0.8706
attention_mse_sum,cos	0.849	0.8351	0.8534	0.8678	0.871
attention_mse_sum,gram	0.8602	0.8547	0.8708	0.8708	0.8739
attention_mse_sum,hidden_mse	0.8492	0.8444	0.8512	0.8667	0.8735
attention_mse_sum,key_relation	0.8666	0.8651	0.8682	0.8715	0.8742
attention_mse_sum,mmd	0.866	0.8592	0.8728	0.8726	0.8741
attention_mse_sum,pkd	0.8395	0.858	0.8603	0.8728	0.87
attention_mse_sum,query_relation	0.8724	0.8622	0.8717	0.8711	0.8735
attention_mse_sum,value_relation	0.8618	0.8678	0.8699	0.8722	0.8713
cos,key_relation	0.8508	0.8473	0.8554	0.8688	0.8655
cos,query_relation	0.8523	0.8528	0.8552	0.8678	0.8658
cos,value_relation	0.8499	0.8504	0.8558	0.87	0.8622
gram,key_relation	0.871	0.857	0.8684	0.8722	0.8691
gram,query_relation	0.8689	0.8602	0.8651	0.8722	0.871
gram,value_relation	0.8711	0.8569	0.8629	0.8761	0.8717
hidden_mse,key_relation	0.8525	0.8495	0.8563	0.8667	0.8689
hidden_mse,query_relation	0.8541	0.8526	0.8552	0.8673	0.8667
hidden_mse,value_relation	0.8528	0.8514	0.8536	0.8664	0.8656
mmd,key_relation	0.8702	0.8653	0.8726	0.875	0.8719
mmd,query_relation	0.8686	0.8653	0.8669	0.8717	0.8724
mmd,value_relation	0.87	0.8673	0.8695	0.8719	0.8691
pkd,key_relation	0.8312	0.8603	0.8629	0.8684	0.8671
pkd,query_relation	0.8318	0.8633	0.8634	0.8713	0.8653
pkd,value_relation	0.838	0.8625	0.8633	0.8706	0.8678
bert-mini	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.8349	0.8263	0.8351	0.844	0.8422
attention_ce_mean,gram	0.8439	0.8433	0.8406	0.8442	0.8455
attention_ce_mean,hidden_mse	0.8367	0.8358	0.838	0.8444	0.8431
attention_ce_mean,key_relation	0.8448	0.8402	0.8426	0.8439	0.8446
attention_ce_mean,mmd	0.8455	0.8455	0.8415	0.8437	0.8468
attention_ce_mean,pkd	0.8179	0.8426	0.8431	0.8407	0.8479
attention_ce_mean,query_relation	0.8486	0.8409	0.8411	0.8444	0.8428
attention_ce_mean,value_relation	0.845	0.8413	0.8418	0.8433	0.8439
attention_mse_sum,cos	0.8298	0.8188	0.8234	0.8409	0.8439
attention_mse_sum,gram	0.8382	0.8342	0.8356	0.8481	0.845
attention_mse_sum,hidden_mse	0.8309	0.8272	0.8281	0.8462	0.8411
attention_mse_sum,key_relation	0.8373	0.8391	0.8349	0.8435	0.8422
attention_mse_sum,mmd	0.8396	0.8342	0.8331	0.8435	0.8417
attention_mse_sum,pkd	0.8226	0.8384	0.842	0.84	0.8448
attention_mse_sum,query_relation	0.8417	0.8367	0.8378	0.8435	0.8424
attention_mse_sum,value_relation	0.8393	0.8365	0.8362	0.8422	0.8429
cos,key_relation	0.8371	0.8338	0.8384	0.8387	0.8431
cos,query_relation	0.8367	0.832	0.8365	0.8389	0.8415
cos,value_relation	0.8351	0.8321	0.8369	0.8387	0.8431
gram,key_relation	0.8424	0.8411	0.8413	0.8446	0.844
gram,query_relation	0.8435	0.8389	0.8393	0.8439	0.8422
gram,value_relation	0.8411	0.8406	0.8422	0.8457	0.845
hidden_mse,key_relation	0.8413	0.8353	0.8406	0.8387	0.8418
hidden_mse,query_relation	0.8411	0.8386	0.8437	0.8391	0.8411
hidden_mse,value_relation	0.838	0.838	0.8411	0.8387	0.8413
mmd,key_relation	0.842	0.84	0.8439	0.8444	0.8442
mmd,query_relation	0.8437	0.8429	0.8415	0.8437	0.8435
mmd,value_relation	0.8422	0.8413	0.8413	0.8426	0.8437
pkd,key_relation	0.8212	0.8415	0.8415	0.8413	0.8477
pkd,query_relation	0.8234	0.8437	0.8428	0.8418	0.8462
pkd,value_relation	0.8213	0.8426	0.8415	0.8429	0.847
bert-tiny	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.7829	0.7798	0.7809	0.7917	0.7899
attention_ce_mean,gram	0.7946	0.7889	0.7972	0.7954	0.7963
attention_ce_mean,hidden_mse	0.7838	0.7818	0.7825	0.7895	0.7939
attention_ce_mean,key_relation	0.7966	0.7959	0.7975	0.7964	0.7974
attention_ce_mean,mmd	0.7981	0.7924	0.7959	0.7959	0.7963
attention_ce_mean,pkd	0.7778	0.7911	0.7893	0.7866	0.7913
attention_ce_mean,query_relation	0.7981	0.7974	0.7968	0.799	0.7955
attention_ce_mean,value_relation	0.7952	0.7924	0.7941	0.7944	0.7946
attention_mse_sum,cos	0.7822	0.7811	0.7759	0.7853	0.7878
attention_mse_sum,gram	0.7959	0.7921	0.7939	0.793	0.7952
attention_mse_sum,hidden_mse	0.7866	0.7833	0.7827	0.7866	0.791
attention_mse_sum,key_relation	0.7943	0.7966	0.7952	0.7937	0.7946
attention_mse_sum,mmd	0.7974	0.791	0.7955	0.7941	0.7974
attention_mse_sum,pkd	0.7747	0.7932	0.788	0.7911	0.7932
attention_mse_sum,query_relation	0.7957	0.7955	0.7935	0.7948	0.7943
attention_mse_sum,value_relation	0.7913	0.7933	0.7922	0.793	0.7952
cos,key_relation	0.7844	0.782	0.7822	0.7908	0.7886
cos,query_relation	0.7844	0.7838	0.782	0.793	0.7871
cos,value_relation	0.7873	0.7814	0.7818	0.7886	0.7878
gram,key_relation	0.7983	0.7902	0.7957	0.7966	0.7957
gram,query_relation	0.797	0.7924	0.7964	0.8005	0.7952
gram,value_relation	0.7957	0.7884	0.7922	0.7966	0.7932
hidden_mse,key_relation	0.7895	0.7902	0.7913	0.7911	0.7917
hidden_mse,query_relation	0.7906	0.7849	0.7827	0.7937	0.7933
hidden_mse,value_relation	0.786	0.7864	0.7908	0.7893	0.79
mmd,key_relation	0.7979	0.7904	0.7977	0.7964	0.7972
mmd,query_relation	0.797	0.7944	0.7977	0.7977	0.7946
mmd,value_relation	0.7941	0.7932	0.7933	0.7948	0.795
pkd,key_relation	0.7838	0.7933	0.7911	0.7933	0.7919
pkd,query_relation	0.7849	0.7917	0.7904	0.7888	0.7922
pkd,value_relation	0.7811	0.7917	0.79	0.7926	0.7915
rte
bert-small	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.5704	0.556	0.5523	0.6606	0.6534
attention_ce_mean,gram	0.6715	0.6715	0.6751	0.6895	0.6895
attention_ce_mean,hidden_mse	0.5596	0.556	0.5596	0.6534	0.6354
attention_ce_mean,key_relation	0.6534	0.6462	0.6498	0.6751	0.6534
attention_ce_mean,mmd	0.6643	0.657	0.6534	0.6859	0.6751
attention_ce_mean,pkd	0.5848	0.6245	0.6137	0.657	0.639
attention_ce_mean,query_relation	0.6751	0.6606	0.6498	0.6751	0.6643
attention_ce_mean,value_relation	0.6534	0.6606	0.6534	0.6643	0.6679
attention_mse_sum,cos	0.574	0.5487	0.5596	0.6606	0.6534
attention_mse_sum,gram	0.6534	0.639	0.6426	0.6751	0.6751
attention_mse_sum,hidden_mse	0.5668	0.5523	0.5668	0.657	0.657
attention_mse_sum,key_relation	0.657	0.6354	0.6354	0.6715	0.657
attention_mse_sum,mmd	0.6679	0.657	0.6606	0.6715	0.6715
attention_mse_sum,pkd	0.556	0.5921	0.6173	0.639	0.639
attention_mse_sum,query_relation	0.6679	0.6534	0.657	0.6751	0.6534
attention_mse_sum,value_relation	0.6462	0.6534	0.6498	0.6751	0.6606
cos,key_relation	0.574	0.5776	0.5668	0.6787	0.6426
cos,query_relation	0.5704	0.5596	0.5776	0.6643	0.6606
cos,value_relation	0.5668	0.5596	0.5632	0.6787	0.6354
gram,key_relation	0.657	0.6534	0.6606	0.6751	0.6715
gram,query_relation	0.657	0.6643	0.6462	0.6751	0.657
gram,value_relation	0.657	0.657	0.6643	0.6859	0.6679
hidden_mse,key_relation	0.5704	0.5704	0.574	0.6534	0.6426
hidden_mse,query_relation	0.574	0.574	0.574	0.6534	0.6751
hidden_mse,value_relation	0.5884	0.574	0.5776	0.6534	0.6426
mmd,key_relation	0.657	0.6354	0.6534	0.6895	0.6643
mmd,query_relation	0.6679	0.6462	0.6751	0.6643	0.6643
mmd,value_relation	0.6643	0.6679	0.6679	0.6859	0.6679
pkd,key_relation	0.5812	0.6029	0.6065	0.6534	0.6354
pkd,query_relation	0.5884	0.6173	0.6137	0.6498	0.6318
pkd,value_relation	0.5632	0.5993	0.6065	0.6354	0.6462
bert-mini	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.5884	0.5596	0.5704	0.6679	0.6065
attention_ce_mean,gram	0.6679	0.6534	0.6498	0.6787	0.6751
attention_ce_mean,hidden_mse	0.5993	0.556	0.5596	0.657	0.6498
attention_ce_mean,key_relation	0.6462	0.6209	0.6282	0.6787	0.639
attention_ce_mean,mmd	0.6462	0.6715	0.657	0.6751	0.6606
attention_ce_mean,pkd	0.5596	0.5884	0.6029	0.6534	0.6209
attention_ce_mean,query_relation	0.6426	0.6209	0.6354	0.6787	0.639
attention_ce_mean,value_relation	0.6426	0.6498	0.6426	0.6895	0.6606
attention_mse_sum,cos	0.5921	0.5415	0.5415	0.6426	0.6245
attention_mse_sum,gram	0.6245	0.6209	0.6245	0.6643	0.6643
attention_mse_sum,hidden_mse	0.5632	0.5451	0.5848	0.6498	0.6426
attention_mse_sum,key_relation	0.6282	0.6065	0.5812	0.6787	0.6462
attention_mse_sum,mmd	0.6462	0.6173	0.6137	0.6643	0.6534
attention_mse_sum,pkd	0.5523	0.6245	0.6137	0.6426	0.6282
attention_mse_sum,query_relation	0.6426	0.6137	0.5812	0.6751	0.6354
attention_mse_sum,value_relation	0.6318	0.6282	0.6209	0.6751	0.6534
cos,key_relation	0.5921	0.5596	0.5812	0.657	0.6173
cos,query_relation	0.5921	0.5523	0.5668	0.6498	0.6101
cos,value_relation	0.5848	0.574	0.5704	0.6462	0.6101
gram,key_relation	0.657	0.6245	0.6318	0.6787	0.639
gram,query_relation	0.6679	0.639	0.6462	0.6787	0.6209
gram,value_relation	0.6498	0.6426	0.6498	0.6787	0.6643
hidden_mse,key_relation	0.5884	0.5632	0.5776	0.6606	0.6354
hidden_mse,query_relation	0.5921	0.5596	0.5848	0.657	0.6173
hidden_mse,value_relation	0.5884	0.5884	0.5921	0.6715	0.6426
mmd,key_relation	0.6534	0.639	0.6426	0.6787	0.6318
mmd,query_relation	0.657	0.6462	0.6498	0.6715	0.6354
mmd,value_relation	0.6354	0.6534	0.657	0.6751	0.6643
pkd,key_relation	0.556	0.6029	0.639	0.6498	0.6354
pkd,query_relation	0.556	0.5993	0.6137	0.6534	0.6318
pkd,value_relation	0.556	0.6101	0.6065	0.6534	0.6209
bert-tiny	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.6282	0.5776	0.6173	0.6101	0.5776
attention_ce_mean,gram	0.6209	0.6137	0.6209	0.6101	0.6173
attention_ce_mean,hidden_mse	0.5921	0.5921	0.5921	0.6137	0.5957
attention_ce_mean,key_relation	0.6173	0.6173	0.6137	0.6173	0.6065
attention_ce_mean,mmd	0.6354	0.5993	0.6173	0.6282	0.6209
attention_ce_mean,pkd	0.5523	0.5921	0.5993	0.574	0.5957
attention_ce_mean,query_relation	0.6137	0.5957	0.5921	0.6173	0.5957
attention_ce_mean,value_relation	0.6209	0.6245	0.6318	0.6245	0.6245
attention_mse_sum,cos	0.5993	0.5596	0.5848	0.6209	0.5848
attention_mse_sum,gram	0.6101	0.6029	0.6245	0.6173	0.6065
attention_mse_sum,hidden_mse	0.5993	0.5884	0.5921	0.6137	0.5921
attention_mse_sum,key_relation	0.6137	0.6029	0.6101	0.6245	0.6065
attention_mse_sum,mmd	0.6354	0.6245	0.6245	0.6282	0.6065
attention_mse_sum,pkd	0.556	0.5921	0.5884	0.5812	0.5957
attention_mse_sum,query_relation	0.6173	0.6029	0.6101	0.6245	0.6029
attention_mse_sum,value_relation	0.6101	0.6029	0.6245	0.6137	0.6173
cos,key_relation	0.6173	0.5957	0.6173	0.6137	0.5812
cos,query_relation	0.6137	0.5848	0.6029	0.6173	0.5848
cos,value_relation	0.6173	0.5884	0.5884	0.6101	0.5776
gram,key_relation	0.6209	0.6245	0.6209	0.6282	0.5993
gram,query_relation	0.6029	0.6029	0.5993	0.6245	0.5957
gram,value_relation	0.6245	0.639	0.6245	0.6209	0.6245
hidden_mse,key_relation	0.5957	0.5812	0.5884	0.6137	0.5848
hidden_mse,query_relation	0.5921	0.5848	0.5921	0.6065	0.5812
hidden_mse,value_relation	0.6029	0.5993	0.5993	0.6173	0.5921
mmd,key_relation	0.6318	0.6101	0.6245	0.6318	0.6137
mmd,query_relation	0.6318	0.6065	0.6101	0.6318	0.6065
mmd,value_relation	0.6462	0.6101	0.6209	0.6354	0.6245
pkd,key_relation	0.5523	0.6029	0.6029	0.5812	0.5921
pkd,query_relation	0.5451	0.5993	0.5957	0.5848	0.5993
pkd,value_relation	0.5487	0.6065	0.5993	0.5704	0.5957
cola
bert-small	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.7181	0.7018	0.7133	0.7747	0.7728
attention_ce_mean,gram	0.7747	0.7804	0.7785	0.7747	0.7795
attention_ce_mean,hidden_mse	0.7565	0.72	0.7402	0.7728	0.768
attention_ce_mean,key_relation	0.7747	0.7613	0.767	0.7833	0.7728
attention_ce_mean,mmd	0.7804	0.7709	0.7689	0.7776	0.7747
attention_ce_mean,pkd	0.7143	0.7469	0.7296	0.7756	0.768
attention_ce_mean,query_relation	0.7747	0.7728	0.768	0.7747	0.7824
attention_ce_mean,value_relation	0.7785	0.7814	0.7814	0.7776	0.7756
attention_mse_sum,cos	0.7277	0.7124	0.7306	0.7766	0.7689
attention_mse_sum,gram	0.7737	0.767	0.7689	0.7766	0.7776
attention_mse_sum,hidden_mse	0.7651	0.7287	0.7392	0.7737	0.7689
attention_mse_sum,key_relation	0.7766	0.7641	0.7709	0.7747	0.7689
attention_mse_sum,mmd	0.7766	0.7718	0.7718	0.7804	0.7737
attention_mse_sum,pkd	0.7181	0.7344	0.743	0.7728	0.7709
attention_mse_sum,query_relation	0.7766	0.768	0.7737	0.7728	0.7766
attention_mse_sum,value_relation	0.7776	0.7574	0.7718	0.7766	0.7709
cos,key_relation	0.7296	0.7085	0.721	0.7737	0.7641
cos,query_relation	0.7354	0.7152	0.7191	0.7737	0.767
cos,value_relation	0.7191	0.7028	0.7162	0.7747	0.767
gram,key_relation	0.7747	0.7651	0.768	0.7756	0.7728
gram,query_relation	0.7737	0.7718	0.7661	0.7766	0.7709
gram,value_relation	0.7728	0.7766	0.7766	0.7747	0.7795
hidden_mse,key_relation	0.7584	0.72	0.7421	0.7766	0.767
hidden_mse,query_relation	0.7661	0.7296	0.743	0.7747	0.7718
hidden_mse,value_relation	0.7536	0.7152	0.7373	0.7718	0.7709
mmd,key_relation	0.7824	0.767	0.7709	0.7804	0.7709
mmd,query_relation	0.7756	0.7709	0.7814	0.7737	0.7737
mmd,value_relation	0.7728	0.7737	0.7766	0.7756	0.7804
pkd,key_relation	0.7076	0.7277	0.7306	0.7766	0.7661
pkd,query_relation	0.7114	0.7421	0.7315	0.7766	0.7689
pkd,value_relation	0.7306	0.7411	0.7344	0.7728	0.7728
bert-mini	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.698	0.6922	0.6951	0.7536	0.7239
attention_ce_mean,gram	0.7459	0.7469	0.7488	0.7517	0.7488
attention_ce_mean,hidden_mse	0.7066	0.7037	0.7105	0.7469	0.743
attention_ce_mean,key_relation	0.7421	0.7392	0.7536	0.7402	0.7383
attention_ce_mean,mmd	0.7421	0.7335	0.7392	0.7411	0.7507
attention_ce_mean,pkd	0.6913	0.697	0.6922	0.7469	0.7373
attention_ce_mean,query_relation	0.744	0.7459	0.744	0.7488	0.7498
attention_ce_mean,value_relation	0.7478	0.7478	0.7565	0.744	0.745
attention_mse_sum,cos	0.6913	0.6913	0.6932	0.7498	0.7267
attention_mse_sum,gram	0.7383	0.7028	0.697	0.7459	0.7421
attention_mse_sum,hidden_mse	0.698	0.6942	0.6922	0.7507	0.7402
attention_mse_sum,key_relation	0.7421	0.721	0.7066	0.7411	0.7402
attention_mse_sum,mmd	0.7306	0.7018	0.7085	0.745	0.745
attention_mse_sum,pkd	0.6913	0.6942	0.6922	0.7469	0.7354
attention_mse_sum,query_relation	0.7469	0.7191	0.7066	0.7421	0.7411
attention_mse_sum,value_relation	0.7459	0.7315	0.72	0.7402	0.7383
cos,key_relation	0.6932	0.6989	0.6999	0.7488	0.7172
cos,query_relation	0.6961	0.6942	0.6913	0.7584	0.7267
cos,value_relation	0.6989	0.6932	0.698	0.743	0.7277
gram,key_relation	0.745	0.7392	0.7478	0.745	0.7507
gram,query_relation	0.745	0.7267	0.7383	0.745	0.7469
gram,value_relation	0.7565	0.7421	0.7469	0.7488	0.743
hidden_mse,key_relation	0.7133	0.7018	0.7037	0.7478	0.7402
hidden_mse,query_relation	0.7066	0.697	0.6989	0.7478	0.7383
hidden_mse,value_relation	0.7009	0.7037	0.7028	0.7507	0.7402
mmd,key_relation	0.7478	0.7363	0.7383	0.7421	0.7459
mmd,query_relation	0.7507	0.7143	0.7335	0.743	0.7469
mmd,value_relation	0.7507	0.7277	0.7296	0.7411	0.7402
pkd,key_relation	0.6913	0.7018	0.697	0.7488	0.7315
pkd,query_relation	0.6932	0.6999	0.697	0.7402	0.7344
pkd,value_relation	0.697	0.7009	0.7057	0.743	0.7383
bert-tiny	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.6913	0.6913	0.6913	0.6913	0.6913
attention_ce_mean,gram	0.6932	0.6961	0.6932	0.6913	0.697
attention_ce_mean,hidden_mse	0.6913	0.6913	0.6932	0.6913	0.6913
attention_ce_mean,key_relation	0.6922	0.6913	0.6951	0.6989	0.6913
attention_ce_mean,mmd	0.697	0.6922	0.6922	0.6913	0.6942
attention_ce_mean,pkd	0.6913	0.6913	0.6922	0.6913	0.6913
attention_ce_mean,query_relation	0.6989	0.698	0.6951	0.6999	0.6942
attention_ce_mean,value_relation	0.6913	0.698	0.6942	0.697	0.6913
attention_mse_sum,cos	0.6942	0.6913	0.6913	0.6913	0.6913
attention_mse_sum,gram	0.6913	0.6913	0.6922	0.6913	0.6913
attention_mse_sum,hidden_mse	0.6913	0.6932	0.6913	0.6922	0.6913
attention_mse_sum,key_relation	0.6922	0.6913	0.6913	0.6961	0.6913
attention_mse_sum,mmd	0.6922	0.6913	0.6913	0.6913	0.6913
attention_mse_sum,pkd	0.6913	0.6913	0.6913	0.6913	0.6932
attention_mse_sum,query_relation	0.6913	0.6922	0.6913	0.6961	0.6913
attention_mse_sum,value_relation	0.6913	0.6913	0.6913	0.6913	0.6942
cos,key_relation	0.6913	0.6913	0.6913	0.6913	0.6913
cos,query_relation	0.6913	0.6913	0.6913	0.6913	0.6913
cos,value_relation	0.6913	0.6913	0.6913	0.6922	0.6913
gram,key_relation	0.6913	0.6913	0.6913	0.7028	0.6913
gram,query_relation	0.6913	0.6922	0.6922	0.6951	0.6913
gram,value_relation	0.6961	0.6951	0.6989	0.6913	0.697
hidden_mse,key_relation	0.6932	0.6913	0.6913	0.6913	0.6961
hidden_mse,query_relation	0.6913	0.6913	0.6961	0.6913	0.6913
hidden_mse,value_relation	0.6913	0.6913	0.6913	0.6913	0.6951
mmd,key_relation	0.6951	0.6951	0.6932	0.6951	0.6989
mmd,query_relation	0.6932	0.6913	0.6922	0.6913	0.6913
mmd,value_relation	0.6942	0.6932	0.6942	0.6913	0.6913
pkd,key_relation	0.6913	0.6951	0.6913	0.6913	0.6913
pkd,query_relation	0.6913	0.6951	0.6913	0.6913	0.6913
pkd,value_relation	0.6913	0.6913	0.6922	0.6913	0.6922
stsb
bert-small	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.8722	0.8715	0.8712	0.874	0.8721
attention_ce_mean,gram	0.8732	0.8717	0.8731	0.8724	0.8745
attention_ce_mean,hidden_mse	0.8723	0.8703	0.8695	0.8736	0.872
attention_ce_mean,key_relation	0.8748	0.8724	0.8721	0.8741	0.8735
attention_ce_mean,mmd	0.8721	0.8748	0.8737	0.8726	0.8736
attention_ce_mean,pkd	0.8665	0.869	0.8694	0.8727	0.8726
attention_ce_mean,query_relation	0.8722	0.8729	0.8731	0.8738	0.8721
attention_ce_mean,value_relation	0.8735	0.872	0.8737	0.8717	0.8735
attention_mse_sum,cos	0.87	0.8686	0.8695	0.8748	0.8739
attention_mse_sum,gram	0.8719	0.8745	0.8744	0.8745	0.8749
attention_mse_sum,hidden_mse	0.8684	0.8703	0.8706	0.8724	0.8728
attention_mse_sum,key_relation	0.8734	0.8732	0.875	0.8731	0.8737
attention_mse_sum,mmd	0.874	0.8726	0.872	0.873	0.8735
attention_mse_sum,pkd	0.8666	0.8686	0.8685	0.8706	0.8738
attention_mse_sum,query_relation	0.8722	0.8724	0.8734	0.8727	0.8749
attention_mse_sum,value_relation	0.8727	0.8727	0.8748	0.8732	0.8753
cos,key_relation	0.8727	0.87	0.87	0.8729	0.8708
cos,query_relation	0.8721	0.8697	0.8698	0.873	0.8718
cos,value_relation	0.8722	0.8704	0.8685	0.8751	0.8728
gram,key_relation	0.8732	0.8722	0.8712	0.8725	0.8754
gram,query_relation	0.8728	0.8732	0.8723	0.8729	0.8724
gram,value_relation	0.8727	0.8717	0.8729	0.873	0.8721
hidden_mse,key_relation	0.8716	0.8697	0.8695	0.8736	0.8717
hidden_mse,query_relation	0.8724	0.8718	0.8712	0.8751	0.8723
hidden_mse,value_relation	0.8707	0.8711	0.8707	0.8712	0.8726
mmd,key_relation	0.8742	0.8729	0.8736	0.8753	0.8745
mmd,query_relation	0.8721	0.8717	0.8723	0.8756	0.8734
mmd,value_relation	0.8733	0.8752	0.8731	0.8731	0.8741
pkd,key_relation	0.8672	0.8693	0.8677	0.8716	0.8733
pkd,query_relation	0.8678	0.8708	0.8684	0.8719	0.8742
pkd,value_relation	0.8664	0.8694	0.8689	0.8708	0.8742
bert-mini	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.8648	0.8541	0.8566	0.8661	0.8661
attention_ce_mean,gram	0.865	0.8646	0.8635	0.8624	0.8636
attention_ce_mean,hidden_mse	0.8667	0.8605	0.8625	0.8648	0.8638
attention_ce_mean,key_relation	0.8659	0.866	0.8652	0.8644	0.8643
attention_ce_mean,mmd	0.8652	0.8674	0.8672	0.8655	0.8634
attention_ce_mean,pkd	0.8568	0.8567	0.8549	0.8615	0.862
attention_ce_mean,query_relation	0.8652	0.8635	0.8655	0.8643	0.8645
attention_ce_mean,value_relation	0.8653	0.8654	0.8645	0.8657	0.8629
attention_mse_sum,cos	0.8649	0.8455	0.8436	0.8659	0.8661
attention_mse_sum,gram	0.8652	0.8525	0.86	0.8626	0.8665
attention_mse_sum,hidden_mse	0.8654	0.8488	0.847	0.8651	0.8636
attention_mse_sum,key_relation	0.8653	0.8618	0.8642	0.8653	0.8666
attention_mse_sum,mmd	0.8654	0.8626	0.8639	0.8656	0.8652
attention_mse_sum,pkd	0.8541	0.8534	0.8497	0.8621	0.8638
attention_mse_sum,query_relation	0.8662	0.8625	0.8635	0.8662	0.8639
attention_mse_sum,value_relation	0.8641	0.8573	0.8601	0.8623	0.864
cos,key_relation	0.8661	0.8533	0.857	0.8671	0.8651
cos,query_relation	0.8663	0.8534	0.856	0.8665	0.8655
cos,value_relation	0.8666	0.8577	0.8558	0.8647	0.8662
gram,key_relation	0.8636	0.864	0.8645	0.864	0.8666
gram,query_relation	0.8662	0.8619	0.8646	0.8662	0.8654
gram,value_relation	0.8646	0.8641	0.8645	0.8652	0.8638
hidden_mse,key_relation	0.8652	0.8643	0.8639	0.8667	0.8623
hidden_mse,query_relation	0.8653	0.8648	0.8673	0.8679	0.8612
hidden_mse,value_relation	0.8658	0.8633	0.8628	0.867	0.866
mmd,key_relation	0.8665	0.8705	0.8665	0.8636	0.8648
mmd,query_relation	0.8673	0.8673	0.8675	0.8661	0.8644
mmd,value_relation	0.8654	0.8667	0.866	0.8648	0.8626
pkd,key_relation	0.8568	0.8612	0.8568	0.8574	0.8638
pkd,query_relation	0.8559	0.8592	0.8555	0.8598	0.8643
pkd,value_relation	0.8556	0.8571	0.8555	0.8585	0.8624
bert-tiny	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.8178	0.8189	0.8154	0.8175	0.8166
attention_ce_mean,gram	0.8165	0.814	0.816	0.8168	0.8164
attention_ce_mean,hidden_mse	0.8174	0.8175	0.8172	0.8171	0.8161
attention_ce_mean,key_relation	0.8153	0.8157	0.8157	0.8167	0.8158
attention_ce_mean,mmd	0.8164	0.8163	0.8162	0.8166	0.8167
attention_ce_mean,pkd	0.817	0.8158	0.8148	0.8155	0.8156
attention_ce_mean,query_relation	0.8156	0.8155	0.8155	0.8149	0.8155
attention_ce_mean,value_relation	0.8155	0.8153	0.8153	0.8155	0.8157
attention_mse_sum,cos	0.8169	0.8155	0.8174	0.8171	0.8154
attention_mse_sum,gram	0.8172	0.8146	0.8173	0.8169	0.8161
attention_mse_sum,hidden_mse	0.8173	0.8147	0.8142	0.8144	0.8156
attention_mse_sum,key_relation	0.8155	0.8154	0.8155	0.8154	0.8156
attention_mse_sum,mmd	0.8168	0.8161	0.8145	0.8168	0.8165
attention_mse_sum,pkd	0.8154	0.814	0.8152	0.815	0.8159
attention_mse_sum,query_relation	0.817	0.8152	0.8151	0.817	0.8163
attention_mse_sum,value_relation	0.8169	0.816	0.8167	0.8167	0.8149
cos,key_relation	0.8174	0.8159	0.8184	0.8174	0.8168
cos,query_relation	0.8177	0.8156	0.8152	0.8175	0.8169
cos,value_relation	0.8178	0.8158	0.818	0.8173	0.8142
gram,key_relation	0.8167	0.8171	0.8151	0.8142	0.8154
gram,query_relation	0.8154	0.8171	0.817	0.8168	0.817
gram,value_relation	0.8158	0.816	0.8149	0.8153	0.8156
hidden_mse,key_relation	0.8154	0.8142	0.8164	0.8141	0.8143
hidden_mse,query_relation	0.8173	0.8143	0.8138	0.8167	0.8144
hidden_mse,value_relation	0.8138	0.8149	0.8148	0.8142	0.8148
mmd,key_relation	0.8164	0.8146	0.815	0.8147	0.8156
mmd,query_relation	0.8155	0.8145	0.8149	0.8152	0.8172
mmd,value_relation	0.8162	0.816	0.8142	0.8152	0.8152
pkd,key_relation	0.8129	0.8144	0.8128	0.8145	0.8164
pkd,query_relation	0.8163	0.8147	0.8132	0.8145	0.8169
pkd,value_relation	0.814	0.8141	0.8101	0.8144	0.8155
mnli_mismatched
bert-small	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.7888	0.8099	0.8111	0.7968	0.8063
attention_ce_mean,gram	0.801	0.8037	0.8027	0.8017	0.8012
attention_ce_mean,hidden_mse	0.79	0.8067	0.8094	0.7984	0.8018
attention_ce_mean,key_relation	0.7988	0.7952	0.8034	0.803	0.7987
attention_ce_mean,mmd	0.7981	0.7992	0.804	0.7986	0.8016
attention_ce_mean,pkd	0.7855	0.8128	0.8164	0.8009	0.8063
attention_ce_mean,query_relation	0.8001	0.7988	0.7986	0.7988	0.8004
attention_ce_mean,value_relation	0.7971	0.7977	0.8003	0.7986	0.8007
attention_mse_sum,cos	0.7884	0.8082	0.8131	0.7972	0.8066
attention_mse_sum,gram	0.7977	0.8039	0.8013	0.799	0.8013
attention_mse_sum,hidden_mse	0.7866	0.8056	0.8086	0.7981	0.8027
attention_mse_sum,key_relation	0.7986	0.7924	0.7989	0.8032	0.8002
attention_mse_sum,mmd	0.7964	0.7974	0.7986	0.8036	0.8007
attention_mse_sum,pkd	0.7874	0.8094	0.8155	0.8	0.8076
attention_mse_sum,query_relation	0.7988	0.7914	0.7962	0.8001	0.8003
attention_mse_sum,value_relation	0.7987	0.7924	0.7994	0.8005	0.8009
cos,key_relation	0.7917	0.8118	0.8123	0.7981	0.8038
cos,query_relation	0.7922	0.8111	0.8119	0.7977	0.8044
cos,value_relation	0.7892	0.8108	0.8111	0.7988	0.8059
gram,key_relation	0.8007	0.7961	0.8024	0.8019	0.8011
gram,query_relation	0.7972	0.7974	0.7995	0.8	0.7991
gram,value_relation	0.799	0.8037	0.8002	0.8017	0.7986
hidden_mse,key_relation	0.7932	0.8053	0.8056	0.7999	0.8007
hidden_mse,query_relation	0.7935	0.8095	0.8069	0.8011	0.8009
hidden_mse,value_relation	0.7909	0.8067	0.8082	0.797	0.8016
mmd,key_relation	0.7971	0.7997	0.7976	0.8022	0.7991
mmd,query_relation	0.801	0.7975	0.7987	0.8036	0.8027
mmd,value_relation	0.7978	0.7986	0.7995	0.803	0.8005
pkd,key_relation	0.7869	0.8104	0.8116	0.8	0.8037
pkd,query_relation	0.7888	0.8081	0.8115	0.8032	0.8009
pkd,value_relation	0.7847	0.8103	0.8154	0.8002	0.8046
bert-mini	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.7754	0.792	0.7944	0.7846	0.7891
attention_ce_mean,gram	0.7874	0.7856	0.787	0.782	0.7836
attention_ce_mean,hidden_mse	0.7803	0.7942	0.7894	0.7816	0.7823
attention_ce_mean,key_relation	0.7819	0.7844	0.7839	0.7859	0.7807
attention_ce_mean,mmd	0.7852	0.7834	0.7845	0.7829	0.7854
attention_ce_mean,pkd	0.7697	0.7919	0.796	0.7841	0.7917
attention_ce_mean,query_relation	0.7853	0.7859	0.7857	0.7818	0.7819
attention_ce_mean,value_relation	0.7803	0.779	0.7821	0.783	0.7828
attention_mse_sum,cos	0.772	0.7789	0.7845	0.7826	0.7885
attention_mse_sum,gram	0.7788	0.7651	0.7714	0.7825	0.7861
attention_mse_sum,hidden_mse	0.7755	0.7748	0.778	0.7828	0.7835
attention_mse_sum,key_relation	0.7784	0.7664	0.7699	0.7812	0.7838
attention_mse_sum,mmd	0.7791	0.7646	0.7677	0.7813	0.7843
attention_mse_sum,pkd	0.7711	0.777	0.788	0.7833	0.792
attention_mse_sum,query_relation	0.7769	0.7591	0.7705	0.783	0.7848
attention_mse_sum,value_relation	0.7785	0.765	0.772	0.7817	0.7831
cos,key_relation	0.7792	0.792	0.7921	0.7822	0.7904
cos,query_relation	0.7771	0.7942	0.7882	0.7818	0.7867
cos,value_relation	0.7765	0.792	0.7937	0.7796	0.787
gram,key_relation	0.7817	0.7858	0.788	0.7828	0.7832
gram,query_relation	0.7836	0.7852	0.7857	0.7836	0.7839
gram,value_relation	0.7854	0.7859	0.7863	0.7825	0.7839
hidden_mse,key_relation	0.7797	0.7947	0.7879	0.7822	0.7854
hidden_mse,query_relation	0.7771	0.7952	0.7935	0.7831	0.7849
hidden_mse,value_relation	0.7796	0.7928	0.7889	0.7807	0.783
mmd,key_relation	0.7812	0.784	0.7847	0.7836	0.7809
mmd,query_relation	0.7851	0.7845	0.7845	0.7852	0.7869
mmd,value_relation	0.7818	0.7823	0.7824	0.7832	0.7835
pkd,key_relation	0.7694	0.7954	0.8001	0.7834	0.7892
pkd,query_relation	0.7704	0.7911	0.7971	0.7833	0.791
pkd,value_relation	0.7709	0.7957	0.7965	0.7846	0.7903
bert-tiny	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.7203	0.7337	0.7297	0.7281	0.7289
attention_ce_mean,gram	0.7289	0.7307	0.7286	0.7253	0.7301
attention_ce_mean,hidden_mse	0.7294	0.7317	0.7328	0.7271	0.7285
attention_ce_mean,key_relation	0.7298	0.7235	0.7279	0.7241	0.7257
attention_ce_mean,mmd	0.7256	0.7231	0.7312	0.728	0.729
attention_ce_mean,pkd	0.7174	0.7295	0.731	0.7264	0.727
attention_ce_mean,query_relation	0.7307	0.7252	0.7271	0.7295	0.7267
attention_ce_mean,value_relation	0.7227	0.7237	0.725	0.729	0.7229
attention_mse_sum,cos	0.7231	0.7155	0.7237	0.7315	0.7271
attention_mse_sum,gram	0.7227	0.7257	0.7279	0.7286	0.7255
attention_mse_sum,hidden_mse	0.7259	0.7194	0.7258	0.723	0.7257
attention_mse_sum,key_relation	0.7257	0.7272	0.7257	0.7252	0.7262
attention_mse_sum,mmd	0.7249	0.7242	0.7266	0.7251	0.7262
attention_mse_sum,pkd	0.7032	0.7319	0.73	0.7216	0.7262
attention_mse_sum,query_relation	0.7264	0.7269	0.7247	0.7245	0.7281
attention_mse_sum,value_relation	0.7269	0.7252	0.7233	0.7282	0.7282
cos,key_relation	0.7257	0.7304	0.7299	0.7259	0.7289
cos,query_relation	0.7224	0.7283	0.7307	0.7255	0.727
cos,value_relation	0.7215	0.7317	0.7286	0.7267	0.7301
gram,key_relation	0.7263	0.7259	0.7277	0.7303	0.7251
gram,query_relation	0.7246	0.7249	0.7301	0.7309	0.7291
gram,value_relation	0.7242	0.7277	0.7271	0.7293	0.728
hidden_mse,key_relation	0.7227	0.7238	0.7264	0.722	0.7253
hidden_mse,query_relation	0.7215	0.7321	0.7255	0.7206	0.7295
hidden_mse,value_relation	0.7273	0.7249	0.7257	0.7217	0.7262
mmd,key_relation	0.7257	0.7235	0.7225	0.728	0.7244
mmd,query_relation	0.7248	0.7231	0.729	0.726	0.7283
mmd,value_relation	0.725	0.7198	0.727	0.7242	0.7241
pkd,key_relation	0.7147	0.7303	0.7306	0.7213	0.7261
pkd,query_relation	0.7135	0.727	0.7253	0.7257	0.7313
pkd,value_relation	0.716	0.7275	0.7299	0.7216	0.731
mnli_matched
bert-small	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.7985	0.8022	0.8039	0.7985	0.7984
attention_ce_mean,gram	0.8034	0.8049	0.8046	0.8021	0.8008
attention_ce_mean,hidden_mse	0.7945	0.8015	0.8038	0.8022	0.7992
attention_ce_mean,key_relation	0.8009	0.7987	0.7964	0.8016	0.7985
attention_ce_mean,mmd	0.8001	0.7987	0.7996	0.7988	0.8013
attention_ce_mean,pkd	0.7862	0.8071	0.8115	0.7989	0.807
attention_ce_mean,query_relation	0.8007	0.8017	0.798	0.8003	0.8005
attention_ce_mean,value_relation	0.7999	0.7992	0.8008	0.7999	0.8013
attention_mse_sum,cos	0.7911	0.8019	0.8038	0.7984	0.8041
attention_mse_sum,gram	0.7979	0.7978	0.8025	0.7982	0.8021
attention_mse_sum,hidden_mse	0.7944	0.8015	0.8041	0.7981	0.802
attention_mse_sum,key_relation	0.7995	0.7962	0.7987	0.799	0.8005
attention_mse_sum,mmd	0.8008	0.8004	0.7986	0.8011	0.8038
attention_mse_sum,pkd	0.7941	0.8072	0.8146	0.7958	0.8058
attention_mse_sum,query_relation	0.8019	0.7982	0.7992	0.8011	0.8014
attention_mse_sum,value_relation	0.7983	0.7964	0.7972	0.8019	0.7996
cos,key_relation	0.7933	0.8059	0.8063	0.7971	0.8011
cos,query_relation	0.794	0.8029	0.8051	0.7986	0.8018
cos,value_relation	0.7938	0.8034	0.8046	0.7962	0.7985
gram,key_relation	0.8037	0.8015	0.8024	0.8001	0.8005
gram,query_relation	0.7993	0.8041	0.8034	0.8001	0.8005
gram,value_relation	0.8033	0.7995	0.7992	0.8015	0.8008
hidden_mse,key_relation	0.7956	0.8035	0.8044	0.7975	0.7966
hidden_mse,query_relation	0.7969	0.8046	0.8048	0.8005	0.8031
hidden_mse,value_relation	0.7952	0.8011	0.8015	0.8008	0.7988
mmd,key_relation	0.7995	0.7996	0.8017	0.8006	0.7996
mmd,query_relation	0.7979	0.7986	0.7993	0.8005	0.802
mmd,value_relation	0.7996	0.8029	0.7998	0.7991	0.7998
pkd,key_relation	0.7945	0.8036	0.8111	0.7982	0.7999
pkd,query_relation	0.7893	0.8078	0.8106	0.7978	0.8058
pkd,value_relation	0.7912	0.8073	0.8138	0.7987	0.8055
bert-mini	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.7751	0.7826	0.7826	0.7749	0.7797
attention_ce_mean,gram	0.7745	0.7768	0.778	0.7751	0.7778
attention_ce_mean,hidden_mse	0.7751	0.7792	0.7806	0.777	0.778
attention_ce_mean,key_relation	0.7749	0.7722	0.7735	0.7775	0.7806
attention_ce_mean,mmd	0.7771	0.777	0.7773	0.7748	0.7744
attention_ce_mean,pkd	0.7701	0.7856	0.7861	0.78	0.7823
attention_ce_mean,query_relation	0.7773	0.7732	0.7742	0.7749	0.7806
attention_ce_mean,value_relation	0.777	0.7735	0.7766	0.7777	0.7747
attention_mse_sum,cos	0.7707	0.7738	0.7768	0.7763	0.7747
attention_mse_sum,gram	0.7768	0.7689	0.774	0.7779	0.7788
attention_mse_sum,hidden_mse	0.7782	0.7688	0.7707	0.7761	0.7808
attention_mse_sum,key_relation	0.7739	0.7689	0.7737	0.7803	0.7759
attention_mse_sum,mmd	0.7734	0.7717	0.7729	0.7781	0.7788
attention_mse_sum,pkd	0.765	0.7788	0.784	0.7776	0.7842
attention_mse_sum,query_relation	0.7768	0.7704	0.7737	0.7771	0.7768
attention_mse_sum,value_relation	0.7751	0.7675	0.7735	0.7783	0.7803
cos,key_relation	0.7737	0.7806	0.781	0.7753	0.7798
cos,query_relation	0.7734	0.78	0.7815	0.7767	0.7793
cos,value_relation	0.7751	0.781	0.78	0.7781	0.7789
gram,key_relation	0.7775	0.7762	0.7778	0.7777	0.7806
gram,query_relation	0.7792	0.7766	0.7776	0.7753	0.7738
gram,value_relation	0.7727	0.7786	0.7784	0.7765	0.7738
hidden_mse,key_relation	0.7743	0.7812	0.7823	0.7774	0.7799
hidden_mse,query_relation	0.7752	0.7797	0.7813	0.776	0.7762
hidden_mse,value_relation	0.7761	0.7817	0.7796	0.7766	0.7793
mmd,key_relation	0.7787	0.7782	0.7789	0.7758	0.7815
mmd,query_relation	0.7748	0.7735	0.7739	0.7752	0.7735
mmd,value_relation	0.7753	0.7745	0.7748	0.7745	0.7777
pkd,key_relation	0.7695	0.7862	0.7855	0.7795	0.7832
pkd,query_relation	0.7722	0.7859	0.7874	0.7764	0.7825
pkd,value_relation	0.7683	0.7879	0.7874	0.7758	0.7824
bert-tiny	First	Last	Dilatation	First-1	Last-1
attention_ce_mean,cos	0.7223	0.7258	0.7237	0.7219	0.7239
attention_ce_mean,gram	0.7251	0.7259	0.7233	0.7253	0.7246
attention_ce_mean,hidden_mse	0.7226	0.7252	0.7243	0.7236	0.7259
attention_ce_mean,key_relation	0.7241	0.725	0.7257	0.7223	0.7248
attention_ce_mean,mmd	0.7246	0.7274	0.7266	0.7258	0.7242
attention_ce_mean,pkd	0.7117	0.7207	0.7261	0.72	0.7257
attention_ce_mean,query_relation	0.7235	0.7235	0.7232	0.7222	0.7236
attention_ce_mean,value_relation	0.7263	0.7226	0.7219	0.7238	0.7219
attention_mse_sum,cos	0.7214	0.7203	0.721	0.7199	0.7227
attention_mse_sum,gram	0.7233	0.7218	0.7194	0.7229	0.7231
attention_mse_sum,hidden_mse	0.7201	0.7221	0.7211	0.722	0.7251
attention_mse_sum,key_relation	0.7235	0.7213	0.7196	0.7237	0.721
attention_mse_sum,mmd	0.7236	0.721	0.7205	0.7239	0.7223
attention_mse_sum,pkd	0.7109	0.7214	0.725	0.7203	0.7231
attention_mse_sum,query_relation	0.7239	0.7213	0.7193	0.7226	0.7194
attention_mse_sum,value_relation	0.7232	0.7201	0.7195	0.7241	0.7228
cos,key_relation	0.7203	0.7256	0.7234	0.7225	0.724
cos,query_relation	0.7204	0.7251	0.7237	0.7238	0.726
cos,value_relation	0.7193	0.7254	0.7234	0.7212	0.7242
gram,key_relation	0.7246	0.7259	0.7231	0.7231	0.724
gram,query_relation	0.7246	0.7246	0.7248	0.7219	0.7238
gram,value_relation	0.7241	0.7208	0.7228	0.7266	0.7227
hidden_mse,key_relation	0.7211	0.7251	0.7225	0.7241	0.7273
hidden_mse,query_relation	0.722	0.7233	0.7238	0.7223	0.7265
hidden_mse,value_relation	0.722	0.7256	0.7221	0.7241	0.7228
mmd,key_relation	0.7245	0.7245	0.7231	0.7237	0.7245
mmd,query_relation	0.7243	0.726	0.7255	0.7235	0.7253
mmd,value_relation	0.7257	0.7217	0.7223	0.7234	0.7221
pkd,key_relation	0.7096	0.7213	0.7247	0.72	0.7257
pkd,query_relation	0.7099	0.723	0.7225	0.7219	0.7268
pkd,value_relation	0.7107	0.7206	0.7249	0.7201	0.7249

a.3.4 Best Practices Experiments

#para (M)

SST-2

STS-B

QQP

MRPC

RTE

MNLI

QNLI

average

{BERT}_{base}

109

0.923

0.88

0.909

0.877

0.725

0.845

0.848

0.915

0.8715

Previous SOTA

(ELECTRA-small)

0.912

0.875

0.89

0.88

0.667

0.813

0.884

0.8513

Ours (

{BERT}_{mini}

)

0.91

0.873

0.903

0.874

0.7003

0.797

0.805

0.872

0.8554

Table 7: Best Practice for

{BERT}_{mini}

a.3.5 Weighted Single-Match Experiments

MRPC
bert-small	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.8015	0.7868	0.8162	0.7966	0.8284
attention_ce_mean	0.799	0.799	0.8088	0.799	0.799
hidden_mse	0.75	0.7328	0.7377	0.7745	0.7892
mmd	0.7966	0.8407	0.8407	0.8113	0.8235
gram	0.7843	0.7157	0.7402	0.826	0.8186
cos	0.7696	0.7549	0.7574	0.7941	0.7941
pkd	0.777	0.8211	0.8211	0.8162	0.8407
query_relation	0.8137	0.7745	0.7794	0.826	0.8015
key_relation	0.8431	0.75	0.777	0.8211	0.7819
value_relation	0.8382	0.8039	0.826	0.8162	0.8456
bert-mini	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.7892	0.723	0.7402	0.8333	0.8137
attention_ce_mean	0.8211	0.8137	0.8235	0.826	0.8137
hidden_mse	0.723	0.7108	0.7181	0.8015	0.777
mmd	0.7647	0.8113	0.7892	0.826	0.799
gram	0.6863	0.7206	0.7157	0.8431	0.8113
cos	0.7525	0.7402	0.7402	0.8309	0.7721
pkd	0.6838	0.8186	0.7745	0.8309	0.8137
query_relation	0.799	0.7794	0.777	0.8235	0.7819
key_relation	0.8162	0.7623	0.777	0.8235	0.7819
value_relation	0.8186	0.7892	0.799	0.826	0.8015
bert-tiny	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.7426	0.7157	0.7279	0.7255	0.7475
attention_ce_mean	0.7255	0.7279	0.7255	0.7328	0.7255
hidden_mse	0.723	0.723	0.7255	0.7304	0.7157
mmd	0.7353	0.723	0.7328	0.7377	0.7623
gram	0.7181	0.7059	0.7206	0.7157	0.7059
cos	0.7328	0.7255	0.7181	0.7402	0.7181
pkd	0.6838	0.7475	0.7451	0.7598	0.7328
query_relation	0.7402	0.7549	0.75	0.7402	0.7672
key_relation	0.7525	0.7623	0.7598	0.7377	0.7525
value_relation	0.7353	0.7549	0.7475	0.7402	0.7549
SST-2
bert-small	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.8933	0.8888	0.8922	0.8876	0.8911
attention_ce_mean	0.8899	0.8899	0.8865	0.8888	0.8956
hidden_mse	0.8761	0.8853	0.883	0.8922	0.8991
mmd	0.8899	0.8979	0.9025	0.8933	0.906
gram	0.8807	0.8842	0.8956	0.8979	0.8991
cos	0.8807	0.8899	0.8888	0.8899	0.8933
pkd	0.8819	0.8933	0.8888	0.8865	0.8876
query_relation	0.8922	0.8945	0.8922	0.8933	0.9002
key_relation	0.8911	0.8876	0.8945	0.8865	0.8888
value_relation	0.8876	0.8842	0.8853	0.8876	0.8796
bert-mini	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.8693	0.8704	0.8555	0.8704	0.8727
attention_ce_mean	0.8716	0.8681	0.8716	0.8716	0.875
hidden_mse	0.8394	0.8509	0.8647	0.8819	0.875
mmd	0.8658	0.8727	0.8635	0.8761	0.8819
gram	0.8601	0.8291	0.8555	0.8601	0.8819
cos	0.8647	0.8612	0.8567	0.8693	0.8716
pkd	0.8291	0.8704	0.8681	0.8635	0.8761
query_relation	0.8716	0.8589	0.8727	0.8658	0.875
key_relation	0.8704	0.8647	0.8681	0.8681	0.867
value_relation	0.8716	0.875	0.8727	0.8761	0.8681
bert-tiny	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.8257	0.8314	0.8349	0.8291	0.8291
attention_ce_mean	0.828	0.828	0.828	0.8257	0.828
hidden_mse	0.8291	0.8268	0.8291	0.8303	0.8337
mmd	0.8257	0.8314	0.8257	0.8257	0.8291
gram	0.8268	0.8314	0.836	0.8326	0.8234
cos	0.8257	0.8268	0.8303	0.8245	0.8291
pkd	0.8188	0.8303	0.8326	0.8245	0.8349
query_relation	0.828	0.8245	0.8291	0.828	0.8245
key_relation	0.8326	0.828	0.8268	0.8337	0.828
value_relation	0.8234	0.8245	0.8314	0.8257	0.8268
QQP
bert-small	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.8932	0.8899	0.8937	0.8915	0.8953
attention_ce_mean	0.8922	0.891	0.8918	0.8913	0.8929
hidden_mse	0.8887	0.899	0.8982	0.8916	0.8961
mmd	0.8925	0.8935	0.8951	0.8922	0.895
gram	0.8926	0.8972	0.8994	0.8914	0.8967
cos	0.8918	0.8963	0.8965	0.893	0.8953
pkd	0.8909	0.8971	0.8975	0.8922	0.8972
query_relation	0.8755	0.8756	0.8758	0.8774	0.8801
key_relation	0.8763	0.8811	0.8801	0.8756	0.8795
value_relation	0.881	0.8765	0.8737	0.8787	0.8775
bert-mini	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.8865	0.8768	0.882	0.8861	0.888
attention_ce_mean	0.8881	0.8883	0.8855	0.8864	0.8897
hidden_mse	0.8842	0.8893	0.8927	0.8886	0.8906
mmd	0.8897	0.8825	0.892	0.8856	0.8918
gram	0.8888	0.8829	0.8949	0.8884	0.8923
cos	0.8874	0.8921	0.8933	0.8881	0.8893
pkd	0.8863	0.8939	0.8959	0.8886	0.8936
query_relation	0.8742	0.8751	0.8749	0.8733	0.8743
key_relation	0.8754	0.878	0.8763	0.8762	0.877
value_relation	0.8775	0.8757	0.8752	0.8762	0.8743
bert-tiny	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.8688	0.8651	0.8657	0.8684	0.8689
attention_ce_mean	0.8699	0.8682	0.8687	0.8682	0.8699
hidden_mse	0.8633	0.8666	0.8624	0.8656	0.871
mmd	0.8657	0.8471	0.8633	0.8651	0.8684
gram	0.8662	0.8664	0.8712	0.8657	0.8734
cos	0.8696	0.8694	0.8686	0.8681	0.8707
pkd	0.869	0.8718	0.8698	0.8618	0.8687
query_relation	0.8644	0.8618	0.8602	0.8619	0.8633
key_relation	0.8597	0.8642	0.857	0.8612	0.8569
value_relation	0.8619	0.8564	0.8588	0.864	0.8602
QNLI
bert-small	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.8592	0.8627	0.8717	0.8722	0.8742
attention_ce_mean	0.8728	0.8728	0.8704	0.8722	0.8704
hidden_mse	0.8287	0.8256	0.842	0.8508	0.8612
mmd	0.8583	0.8592	0.8634	0.8715	0.8744
gram	0.8514	0.8298	0.8426	0.8739	0.8741
cos	0.8528	0.8528	0.8572	0.8693	0.864
pkd	0.8298	0.8678	0.8605	0.8717	0.8651
query_relation	0.8726	0.8689	0.8742	0.8719	0.8715
key_relation	0.8691	0.864	0.8644	0.8686	0.8667
value_relation	0.8662	0.8667	0.864	0.8684	0.8684
bert-mini	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.8369	0.8272	0.8298	0.8455	0.8442
attention_ce_mean	0.8437	0.844	0.844	0.8442	0.8439
hidden_mse	0.8045	0.7884	0.8105	0.838	0.8391
mmd	0.8356	0.816	0.8371	0.8422	0.8457
gram	0.831	0.6447	0.8133	0.8446	0.844
cos	0.8334	0.827	0.8354	0.8387	0.8426
pkd	0.8195	0.8428	0.8439	0.8418	0.8473
query_relation	0.8473	0.8437	0.8444	0.8475	0.8477
key_relation	0.8448	0.8424	0.8402	0.8459	0.845
value_relation	0.8459	0.8387	0.8386	0.8424	0.8418
bert-tiny	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.7932	0.7924	0.7877	0.7915	0.7946
attention_ce_mean	0.7968	0.7977	0.797	0.7966	0.797
hidden_mse	0.7728	0.7712	0.7712	0.7877	0.7825
mmd	0.7871	0.78	0.7867	0.791	0.7917
gram	0.7752	0.7593	0.7748	0.7922	0.7899
cos	0.7833	0.7811	0.7816	0.7913	0.791
pkd	0.7791	0.79	0.7899	0.7941	0.7904
query_relation	0.8089	0.8076	0.8083	0.8089	0.8098
key_relation	0.8062	0.7988	0.7977	0.8069	0.8018
value_relation	0.8052	0.7985	0.801	0.804	0.8025
RTE
bert-small	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.639	0.6065	0.5957	0.6751	0.6643
attention_ce_mean	0.6787	0.6787	0.6751	0.6787	0.6823
hidden_mse	0.5451	0.5596	0.556	0.6245	0.6354
mmd	0.6173	0.6245	0.6245	0.6643	0.6498
gram	0.5921	0.5596	0.574	0.6643	0.6643
cos	0.5632	0.5668	0.556	0.6787	0.6354
pkd	0.5776	0.6209	0.6065	0.6462	0.6426
query_relation	0.6751	0.6462	0.6534	0.6643	0.6498
key_relation	0.6498	0.6282	0.6137	0.6715	0.657
value_relation	0.639	0.6823	0.6859	0.6606	0.6751
bert-mini	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.6282	0.5632	0.5921	0.657	0.6534
attention_ce_mean	0.6679	0.6679	0.6643	0.6787	0.6787
hidden_mse	0.5776	0.5632	0.556	0.6462	0.6209
mmd	0.6282	0.6354	0.6462	0.6498	0.6282
gram	0.574	0.5415	0.5596	0.6895	0.6354
cos	0.5884	0.5632	0.5668	0.6679	0.6209
pkd	0.5632	0.5921	0.5993	0.657	0.6245
query_relation	0.6462	0.639	0.6426	0.6679	0.6354
key_relation	0.6534	0.6282	0.639	0.6679	0.6173
value_relation	0.6462	0.6354	0.6282	0.6498	0.6498
bert-tiny	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.6101	0.6137	0.6065	0.6282	0.5957
attention_ce_mean	0.6318	0.6209	0.6137	0.6173	0.6209
hidden_mse	0.5921	0.5812	0.5812	0.6101	0.5957
mmd	0.6101	0.6173	0.6029	0.6173	0.639
gram	0.5812	0.5704	0.5812	0.6137	0.5848
cos	0.6065	0.5884	0.6065	0.6101	0.5884
pkd	0.5451	0.5993	0.5957	0.574	0.5993
query_relation	0.6354	0.6101	0.6029	0.6282	0.6029
key_relation	0.6426	0.6245	0.6173	0.6209	0.6245
value_relation	0.6245	0.6029	0.5921	0.6426	0.6065
CoLA
bert-small	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.7747	0.7574	0.7747	0.7747	0.7737
attention_ce_mean	0.7766	0.7747	0.7776	0.7766	0.7728
hidden_mse	0.697	0.6961	0.6961	0.7824	0.7584
mmd	0.745	0.7459	0.767	0.7795	0.767
gram	0.7306	0.7018	0.7114	0.7689	0.7728
cos	0.7181	0.7114	0.7133	0.7776	0.7718
pkd	0.7095	0.7373	0.7277	0.7709	0.768
query_relation	0.7766	0.7699	0.7689	0.7785	0.7747
key_relation	0.7709	0.7603	0.7709	0.7824	0.7603
value_relation	0.7776	0.7756	0.7689	0.7814	0.7689
bert-mini	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.6922	0.697	0.7057	0.7469	0.7335
attention_ce_mean	0.745	0.7421	0.7469	0.7478	0.743
hidden_mse	0.6932	0.6961	0.6951	0.7344	0.7229
mmd	0.6942	0.7152	0.7162	0.7517	0.7354
gram	0.6942	0.6913	0.6913	0.745	0.7344
cos	0.6932	0.6942	0.698	0.7478	0.7181
pkd	0.6913	0.6999	0.6942	0.7392	0.7335
query_relation	0.7555	0.7325	0.7488	0.7555	0.743
key_relation	0.7507	0.7277	0.7507	0.7565	0.7421
value_relation	0.7593	0.7411	0.7392	0.7507	0.7546
bert-tiny	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.6942	0.6913	0.6913	0.6932	0.6913
attention_ce_mean	0.697	0.6913	0.6951	0.6961	0.697
hidden_mse	0.6913	0.6913	0.6922	0.6913	0.6913
mmd	0.6922	0.6922	0.6922	0.6913	0.6913
gram	0.6913	0.6932	0.6913	0.6913	0.6932
cos	0.6922	0.6913	0.6922	0.6913	0.6913
pkd	0.6913	0.6913	0.6961	0.6913	0.6913
query_relation	0.6913	0.6922	0.6922	0.6913	0.6951
key_relation	0.6942	0.6913	0.6913	0.6913	0.6913
value_relation	0.6932	0.6913	0.6951	0.6961	0.6951
STS-B
bert-small	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.8731	0.8705	0.8727	0.8739	0.8745
attention_ce_mean	0.8731	0.8735	0.8727	0.8732	0.8725
hidden_mse	0.8656	0.8646	0.8642	0.8718	0.8717
mmd	0.8727	0.8678	0.8685	0.8752	0.8748
gram	0.8715	0.8458	0.862	0.8728	0.8723
cos	0.8724	0.8708	0.8694	0.874	0.8733
pkd	0.8663	0.8698	0.8693	0.8726	0.873
query_relation	0.8773	0.8772	0.876	0.8762	0.8753
key_relation	0.8766	0.8734	0.8748	0.8772	0.8744
value_relation	0.8745	0.8757	0.8741	0.877	0.8752
bert-mini	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.8674	0.8249	0.8431	0.8655	0.8638
attention_ce_mean	0.865	0.8641	0.8629	0.8627	0.8656
hidden_mse	0.8549	0.8455	0.8511	0.8665	0.8675
mmd	0.8657	0.8608	0.8654	0.8678	0.866
gram	0.8551	0.7472	0.8283	0.8677	0.8643
cos	0.8626	0.8552	0.8568	0.8684	0.8667
pkd	0.8558	0.8591	0.855	0.8607	0.865
query_relation	0.8693	0.8686	0.8679	0.8688	0.8684
key_relation	0.869	0.8689	0.8683	0.8688	0.8697
value_relation	0.8696	0.869	0.8693	0.8688	0.8701
bert-tiny	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.8164	0.8139	0.8171	0.8163	0.8161
attention_ce_mean	0.8168	0.8168	0.8168	0.8156	0.8168
hidden_mse	0.8176	0.8191	0.8169	0.8192	0.8165
mmd	0.8095	0.812	0.8123	0.8119	0.8187
gram	0.8185	0.8046	0.8105	0.8149	0.8176
cos	0.8181	0.8185	0.8184	0.8175	0.8163
pkd	0.8146	0.8156	0.8145	0.8151	0.8126
query_relation	0.8229	0.823	0.8231	0.8227	0.823
key_relation	0.8187	0.8213	0.821	0.8194	0.822
value_relation	0.8212	0.8167	0.8169	0.8203	0.8214
MNLI-mm
bert-small	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.7965	0.7938	0.8004	0.8001	0.8036
attention_ce_mean	0.7991	0.7993	0.8003	0.8008	0.8027
hidden_mse	0.784	0.8166	0.814	0.7944	0.8087
mmd	0.7947	0.802	0.8034	0.7975	0.8049
gram	0.7859	0.7966	0.8043	0.8002	0.8064
cos	0.7908	0.8086	0.8102	0.7974	0.8037
pkd	0.7903	0.8135	0.8127	0.7992	0.8098
query_relation	0.7973	0.7957	0.7952	0.7994	0.7984
key_relation	0.8012	0.7912	0.7957	0.7982	0.7971
value_relation	0.7957	0.7915	0.7931	0.7956	0.7937
bert-mini	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.7651	0.7367	0.7555	0.7822	0.784
attention_ce_mean	0.7816	0.7823	0.7819	0.7819	0.7844
hidden_mse	0.7729	0.7893	0.7955	0.7816	0.7876
mmd	0.7752	0.7743	0.784	0.7831	0.7891
gram	0.771	0.7648	0.7858	0.785	0.7899
cos	0.7755	0.794	0.7965	0.7808	0.7883
pkd	0.7688	0.7944	0.7977	0.7848	0.7936
query_relation	0.7798	0.7782	0.7798	0.7805	0.7851
key_relation	0.7762	0.7775	0.7775	0.7788	0.7823
value_relation	0.7731	0.7729	0.7733	0.7799	0.7794
bert-tiny	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.7249	0.7156	0.7079	0.7236	0.7248
attention_ce_mean	0.7272	0.724	0.7275	0.7231	0.7281
hidden_mse	0.7189	0.7304	0.7288	0.7228	0.729
mmd	0.7234	0.6882	0.7191	0.724	0.7269
gram	0.7224	0.7023	0.7245	0.7253	0.7316
cos	0.7234	0.7273	0.7297	0.7252	0.7317
pkd	0.7148	0.7268	0.7306	0.7254	0.7321
query_relation	0.7246	0.7266	0.7243	0.7248	0.723
key_relation	0.7265	0.72	0.723	0.7259	0.721
value_relation	0.7248	0.7165	0.7145	0.727	0.7215
MNLI-m
bert-small	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.7942	0.7923	0.8001	0.8015	0.8043
attention_ce_mean	0.7978	0.8003	0.8006	0.801	0.8021
hidden_mse	0.7912	0.8057	0.8093	0.7955	0.8017
mmd	0.7963	0.8016	0.8056	0.8012	0.802
gram	0.7977	0.8025	0.8098	0.7996	0.8059
cos	0.796	0.8016	0.8052	0.7981	0.8021
pkd	0.7902	0.8095	0.8084	0.7961	0.807
query_relation	0.7911	0.7874	0.7905	0.791	0.7954
key_relation	0.7909	0.7927	0.7934	0.7894	0.7943
value_relation	0.7878	0.7925	0.7907	0.79	0.7927
bert-mini	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.767	0.7513	0.7617	0.775	0.7801
attention_ce_mean	0.7779	0.7776	0.7748	0.7749	0.7789
hidden_mse	0.7723	0.7869	0.7851	0.7785	0.7819
mmd	0.775	0.7787	0.7836	0.7805	0.7779
gram	0.7754	0.7763	0.7882	0.7764	0.7823
cos	0.7752	0.7815	0.7826	0.7764	0.7794
pkd	0.7715	0.7858	0.7863	0.7769	0.7828
query_relation	0.7682	0.7705	0.7721	0.7679	0.7705
key_relation	0.7693	0.7725	0.7686	0.7689	0.7721
value_relation	0.7697	0.7658	0.7686	0.771	0.771
bert-tiny	First	Last	Dilatation	First1	Last1
attention_mse_sum	0.7224	0.7166	0.7174	0.7226	0.7218
attention_ce_mean	0.7252	0.7244	0.7253	0.725	0.7238
hidden_mse	0.7187	0.7215	0.7194	0.7188	0.7243
mmd	0.7178	0.7047	0.7222	0.7208	0.7203
gram	0.7202	0.7208	0.7231	0.7245	0.7253
cos	0.7211	0.7259	0.7227	0.7228	0.7246
pkd	0.7112	0.7227	0.7241	0.7205	0.7256
query_relation	0.7261	0.7242	0.7231	0.7261	0.7223
key_relation	0.7246	0.7271	0.7264	0.7251	0.7283
value_relation	0.7285	0.7148	0.7244	0.7279	0.7261

Table 8: Weighted Single Match Experiments

	${V R}_{l, a}^{T} = softmax (\frac{V_{l, a}^{T} \cdot V_{l, a}^{T ⊤}}{\sqrt{d}})$
	${V R}_{r, a}^{S} = softmax (\frac{V_{r, a}^{S} \cdot V_{r, a}^{S ⊤}}{\sqrt{d}})$

Knowledge Distillation of Transformer-based Language Models Revisited

Related Research

KroneckerBERT: Learning Kronecker Decomposition for Pre-trained Language Models via Knowledge Distillation

RoSearch: Search for Robust Student Architectures When Distilling Pre-trained Language Models

Knowledge Distillation For Recurrent Neural Network Language Modeling With Trust Regularization

TinyMBERT: Multi-Stage Distillation Framework for Massive Multi-lingual NER

Linking Common Vulnerabilities and Exposures to the MITRE ATT CK Framework: A Self-Distillation Approach

Extreme Compression for Pre-trained Transformers Made Simple and Efficient

Knowledge Distillation of Russian Language Models with Reduction of Vocabulary

1 Introduction

2 Preliminary

2.1 Distillation

2.2 Transformer

Self-attention Module

Feed-forward Network

3 The framework of Distillation

3.1 Initialization

3.2 Knowledge

3.2.1 Response-Based Knowledge

3.2.2 Feature-Based Knowledge

3.2.3 Relation-Based Knowledge

3.3 Matching Strategy

3.4 Objective Function

4 Empirical Results And Analyses

4.1 Dataset & Settings

4.2 Initialization

4.3 Temperature and Hard Label

4.4 Layer Match

Knowledge Type

Matching Strategy

4.5 Deeper or Wider

4.6 Larger Teacher Teach Better?

4.7 Best Practices of Distilling Extremely Small Models for On-device Application

Constraints

5 Conclusion

References

Checklist

Appendix A Appendix

a.1 Reproducibility

a.1.1 Settings

a.1.2 Code

a.1.3 Teacher Models

a.2 Knowledge Types

a.3 Detailed Experimental Results

a.3.1 Temperature & Hard Label Weight

a.3.2 Single-Match Experiments

a.3.3 Double-Match Experiments

a.3.4 Best Practices Experiments

a.3.5 Weighted Single-Match Experiments
