1 Introduction

With the growing demands of surveillance systems and the booming market of Internet of Things, sensors have become an imperative part of everyday life. Thus, the reliability on sensors is increasing with each passing day. However, traditional single sensor systems have not really been able to match up to the sensor performance. For instance, if with three sensors it is attempted to detect the fault in a machine, where the first one shows a temperature of C, second one C and the third one , the machine is considered as faulty if the temperature is above

C. So, it is difficult to judge from the sensor values if the machine can be considered as faulty. If information from only one sensor is taken into account, then there is high probability of information loss and further varied decision results will be acquired. This can be attributed to the conflicting results of the sensors. In reality, the information from different sensors may be inaccurate, fuzzy and conflicting, resulting in a difficult decision making. To mitigate these problem, Bayesian theory

[CAI], fuzzy sets [islam] , Z-numbers [Jiang], D-numbers [LIUChen], evidence theory etc. have been put forth. In [CAI]

, to build a fault diagnosis model, the authors have used a Bayesian network with two layers namely a fault layer and a fault symptom layer. In

[islam], fuzzy set theory has been applied for fault diagnosis. To combat data uncertainty, [Jiang] has used Z-number to combine the data from different sensors. The authors have used D-number theory in [LIUChen] to handle uncertain information for risk analysis. This work has shown that D-number is effective in combining data from different sensors. But for the error in the sensor data, the information may result in high conflict, thus culminating in error prone fusion result. Dempster-Shafer evidence theory can deal with this conflicting information.

Dempster-Shafer theory of evidence (DSTE) [Dempster2008, shafer197] is a mathematical concept for combinining data from different sensors. It is a generalisation of Bayesian method and offers better fusion result than most of the aforementioned methods. Thus, evidence theory has been incorporated in many applications to deal with incomplete and uncertain information. An agent-oriented intelligent fault diagnosis system has been proposed in [LUO2012]. Belief entropy has been used in [yuan2016] by considering sensor reliability and assigning different weights using a distance function. The authors in [jiang2016] have used Deng’s entropy to measure and modify the evidence by using discounting coefficients. Finally, Dempster’s Combination Rule (DCR) has been used to fuse the modified evidence to detect fault in a motor rotor. A novel fault diagnosis method of proton exchange membrane fuel cell (PEMFC) system has been proposed in [Liu]

which combines Extreme Learning Machine (ELM) and Dempster-Shafer theory of evidence. The failure diagnosis model is taken care of by ELM and the diagnostic output is combined by DSTE. Support vector machine (SVM)-evidence theory model has been used in

[HUI2017] to solve information gathered by every SVM model to increase the accuracy of classification. The resulting model has been shown to improve the accuracy by removing all conflicting information from the original SVM model. Thus, it can be easily concluded that evidence theory can be successfully used for fault diagnosis. Keeping this into consideration, this work proposes an effective method to improve traditional DCR for information fusion.

In this work, information gathered from different sensors are considered as diagnosis evidence and the fault diagnosis model is based on evidence fusion and the corresponding decision. Also, an improved DCR has been put forward to deal with uncertainity in the data expressed by weighted Deng entropy. The rest of the paper is organised as follows: Section 2 gives an overview of the relevant literature pertaining to improved DCR. In Section 3, some concepts of DSTE and weighted Deng entropy are elaborated. Section 4 presents the proposed method to deal with conflicting and uncertain information followed by Section 5 which illustrates an application of fault diagnosis system. Finally, the paper is concluded in Section 6.

2 Related Study

A lot of methods have come up in the past to deal with the uncertainty and the conflict in the data. The idea is to redistribute the conflict factor which was attempted by Yager in [yager]. In this work, the value has been reallocated to an unknown domain and also a modified DCR has been proposed. However, this method was not very capable to reduce the uncertainty of the fused result. Jiang et al[jiang2018] modified [yager] to fuse the basic probability assignment (BPA). Sun et al[Sun] used valid coefficients to consider partial conflicts of the evidence. Li et al[li2001efficient] considered equality of each of group of evidence to distribute the conflict factor and used weighted average support degree to achieve the same. Frame of Discernment (FD) (explained in Section 3) was extended in [Smarandache2005] to mitigate the conflicting behaviour of information. Martin et al[Martin] used a combination rule to propose a discounting procedure to deal with partial conflicts. Reliability of evidence was calculated in [LiangX] to modify the combination model. Li and Gou [WLLi] extended [Sun] and [li2001efficient] by taking into consideration the conflict distribution of the proposition.

There have been other works as well which did not modify the traditional DCR. Rather, they worked with preprocessing of original evidence. To deal with conflicting evidence, Murphy [Murphy] used average of BPA, but failed to consider the relationship between the evidences. In [JOUSSELME], the authors proposed a new method of distance measurement (Jousselme’s distance) which proved to be an effective method for finding the correlation among the evidence. But, if all the elements of FDs are a part of Focal Elements (FE) (explained in Section 3), the calculation will get a bit tricky due to the rise in cardinality. Pignistic probability distance was used by [ChenY] to preprocess the original BPA and calculate the weighted evidence. Similarity measurements were used by Zhang et al[ZhangYing] to calculate support degree and weighted factor of each evidence. Zhang et al[Zhang2014] further used -dimensional Pignistic probability vector based on cosine theorem and the weight factor was determined by considering the angle measurements between the evidences. Classification algorithms for ensemble learning along with evidence theory was used by [TABASSIAN2012]

to deal with the uncertainty in the information. BPA based on normal distribution was put forth by Xu

et al. in [XU2013]. In this work, training data was used to construct the normal distribution and then a BPA function was determined by considering the relation between the normal distribution model and the test data. Zhang et al[ZHANGChen] determined BPA from the distance between the core data samples and the selected data. Lu et al[RLu] used Mahalanobis distance to propose a combination rule which worked well for highly conflicting evidences. Supporting probability distance was used by [YuCholo] to work with the combination rule. In [YLin] Lin et al. used Euclidean distance measurement to distinguish between different evidences. Wang et al[ZWang] have used belief entropy to reduce the uncertainty on the evidences, Though, many methods have been applied to mitigate the high conflict results, scope for improvement still persists as has been shown in this work.

3 Preliminaries

Before delving deep into the methodology, some preliminaries are outlined:

3.1 Dempster-Shafer Evidence Theory

Uncertain reasoning method, popularly known as Evidence Theory, has found its applications in a lot of areas like fault diagnosis [YLin, ZWang], uncertainty modelling, decision making etc. Dempster-Shafer Evidence Theory, also referred to as theory of belief functions, has been greatly used in the field of uncertainty modelling. The basic concepts of DS theory are introduced next.

Frame of discernment is the complete set of all hypotheses where the elements are mutually exclusive and the set is exhaustive. It is represented by:


For fault diagnosis syatem, the fault types in this work are represented by and the number of elements in the power set of is . As an example, if there are three fault types , and , then the frame of discernment is and the power set is given as: . Here, shows that the fault has occurred, shows that either of the fault has occurred and represents no fault has occurred.

Basic probability assignment (BPA) represented by is responsible for mapping each hypotheses (faults in this work) of frame of discernment that is to with the conditions that:


This reflects the support degree of . As an example, if and , then if and happen, the support degrees are 0.6, 0.3 and 0.1 respectively.

is called the focal element (FE) if . The FEs for fault types , and are .

In Dempster-Shafer Theory, BPA can be generated from multiple sensors based on frame of discernment. These BPA can be combined together using Dempster’s Combination Rule (DCR):


where is the severity of the conflict; larger the value of K, greater is the conflict between the different evidences.

3.2 Weighted Deng Entropy

In Dempster-Shafer Evidence Theory, both BPA and frame of discernment are the reasons which attribute to uncertainties. The existing belief entropy like Deng entropy [DENG2016] and Dubois and Prade’s weighted Hartley entropy [DUBOIS] consider only mass functions but not the frame of discernment. Weighted Deng entropy [TangY] was formulated to address these uncertainties. The scale of frame of discernment denoted as and the relative scale of the proposition or focal element with respect to the frame of discernment is . Thus, the modified belief entropy can be given by:


where, is a proposition or focal element of mass function and is the cardinality of proposition .

4 Proposed Method based on Weighted Deng Entropy

The steps for the proposed improved Dempster Combination Rule (iDCR) are given as follows:

If there is an evidence set in frame of discernment with focal elements , then the average value can be defined as:


where, and .

Next, the Euclidean distance () between the original BPA and the average BPA is calculated by:


The dimension distance vector can thus be represented as:

The similarity between two evidences can be derived from the previously calculated distance and is given by:


So, the dimension similarity vector can be represented as:

Now, if the similarity between two evidences shows a higher mutual support degree, it indicates that the conflict is less. The support degree of evidence can thus be evaluated by:


Next, the weighted Deng entropy [TangY] is calculated as follows:


In this step, based on the support degree and weighted Deng entropy , the reliability/credibility degree or the weight of is given by:


Here, is the weight of the evidence. Thus, the modified BPA can be given as:


Finally, Dempster’s combination rule is applied to combine the modified BPA.


Here, m(F) is the final fusion result. A diagrammatic representation of the steps is given in Fig. 1.

Figure 1: Flowchart of the proposed method

4.1 Examples

Example 1.

A frame of discernment of a fault diagnosis system is . The BPAs ( and ) from two different sensors are given in Table 1.

0.99 0.01 0
0 0.01 0.99
Table 1: BPA from two sensors

From Table 1, it can be seen that the support degree of from the first sensor is 0.99 and that from the second sensor is 0. For on the other hand, the reverse is true. The support degree is thus clearly conflicting. Again, for the support degree for both the sensors is 0.01 which indicates that this fault is not very likely to occur. But the fusion result from the classical DCR is , , and . Thus, the support degree according to classical DCR is 1 indicating that fault will definitely happen which is of course not supported by the actual condition. So, it can be easily concluded that if there is a conflict between evidences, classical DCR shows paradoxical result.

Now, that the flaw in the traditional method has been established, the calculation for Example 1 for the proposed method is given in details as follows:

First, the average values are calculated:

In this step, the Euclidean distances are calculated:

Next, the similarity degrees between the evidences are calculated:

From the similarity degrees, support degrees are evaluated:

The weighted Deng entropy is calculated next:

The credibility degree or the weight and the modified BPA are deduced in this step:

Finally, DCR is applied to calculate the fusion result: , and . This result is a clear indication that the faults and are much more likely to happen than fault , thus supporting the real condition, making the proposed method more feasible.

Example 2.

A frame of discernment has 7 elements, of which and are three different faults. The BPAs (, and ) are given in Table 2.

0.70 0.05 0.05 0.05 0.05 0.05 0.05
0.05 0.70 0.05 0.05 0.05 0.05 0.05
0.75 0.05 0 0.05 0.05 0.05 0.05
Table 2: BPA from three sensors
Rules Evidence
0.4579 0.8381
Wang et. al [ZWang] 0.4579 0.1431
0.0399 0.0114
0.0133 0.0023
0.0133 0.0023
0.0133 0.0023
0.0044 0.0005
0.4787 0.9542
iDCR 0.4787 0.0430
0.0085 0.0001
0.0085 0.0006
0.0085 0.0006
0.0085 0.0006
0.0085 0.0006
Table 3: Fusion Results

It can be deduced from Table 3 that, though there is huge conflict in the data, for both [ZWang] and the proposed method the fusion result of is the highest when all the three sensors are combined. Though both the methods give the correct judgement, the support degree of for the proposed method is higher, proving its superiority over [ZWang].

Example 3.

A frame of discernment of a fault diagnosis system is and the BPA is given as follows:

0.70 0.15 0.15 0
0.40 0.20 0.40 0
0.65 0.35 0 0
0.75 0 0.25 0
0 0.20 0.80 0
Table 4: BPA from three sensors
Rules Evidence
0.7568 0.9455 1 NaN
DS [LIUChen] 0.0811 0.0545 0 NaN
0.1621 0 0 NaN
0 0 0 NaN
0.2800 0.1820 0.1365 0
Yager [yager] 0.0300 0.0105 0 0
0.0600 0 0 0
0.6300 0.8075 0.8635 1
0.6265 0.6531 0.6762 0.5000
Li et al[li2001efficient] 0.1403 0.1989 0.1511 0.1800
0.2332 0.1480 0.1727 0.3200
0 0 0 0
0.4645 0.4412 0.4457 0.2594
Sun et al[Sun] 0.0887 0.1142 0.0866 0.0934
0.1523 0.0814 0.0989 0.1660
0.2945 0.3632 0.3688 0.4812
0.6265 0.6475 0.6669 0.5445
Li and Gou [WLLi] 0.1403 0.2036 0.1553 0.1757
0.2332 0.1489 0.1778 0.2798
0 0 0 0
0.7401 0.9190 0.9854 0.9443
Lin et al[YLin] 0.0749 0.0556 0.0054 0.0040
0.1850 0.0245 0.0093 0.0517
0 0 0 0
0.7084 0.9020 0.9764 0.9495
Wang et al[ZWang] 0.0793 0.0528 0.0074 0.0045
0.2123 0.0452 0.0162 0.0465
0 0 0 0
0.7081 0.9043 0.9773 0.9637
iDCR 0.0797 0.0520 0.0072 0.0039
0.2122 0.0437 0.0155 0.0324
0 0 0 0
Table 5: Fusion Results

From Table 4, it can be seen that sensors 1,2,3 and 4 support the fault whereas fault is supported by the sensor 5. Additionally, according to the data from sensor 5, fault does not happen. This shows that there is high conflict in the sensor data. Also, as no other sensor supports fault other than sensor 5, when fusion rule is applied, the values of should be higher than both and . From Table 5 and Fig. 2 it is evident that as the number of evidences increases, also increases but and decrease. Though traditional DCR follows this trend, but it becomes useless when there is high conflict, that is, when the fifth evidence is introduced. Yager’s method is unable to resolve the high conflict situation as well as it removes the normalisation process in DCR and also assigns the conflict to an unknown domain. To allocate the conflict in evidence, Li et al. has set up a model whereas Sun et al. has considered only partial evidences leading to strong uncertainty in results. By modifying the model, Li and Gou distributed the conflict resulting conservative fusion result. So, from the results it can be deduced that most of the methods adhere to the view that the second evidence is the most credible while the reverse is true for the fifth evidence. The proposed method (iDCR) performs better while dealing with information with high conflict; fusion result of fault has a slight decrease from 0.9773 to 0.9637, as opposed to Lin et al. and Wang et al. where the decrease is from 0.9854 to 0.9443 and 0.9764 to 0.9495 respectively.

Figure 2: (a) Combination results for , (b) Combination results for , (c) Combination results for

5 Application of Fault Diagnosis Method

The fault diagnosis architecture of a multi sensor fusion system used in this work is described below:

5.1 Fault Diagnosis Architecture

Data from multiple sensors (which are distributed in the system) have been used in this work to improve the accuracy of the system in terms of fault diagnosis. The sensors can generate their own evidences for different faults when they are working. Later, DCR is used to combine all these evidences as have been discussed earlier. Finally, decision rules are applied to make the final decision about the system.

The system is divided into five levels to achieve its goals, they being:

  1. Data Level: In this level, data is collected from the different sensors and the frame of discernment is built.

  2. Feature Level: Different fault features are extracted in this level to monitor the system status.

  3. Evidence Level: Depending on the extracted features, BPA of different sensors are generated at this level.

  4. Fusion Level: As the name suggests, different BPAs are combined in this level.

  5. Decision Level: Finally, in this level feasible decision rule is applied to derive the final conclusion.

5.2 Testing

A rotating machinery [YLin] is used in this work to verify the performance of the system. The faults in the system have been categorised into four types: = “Imbalance”, = “Shaft crack”, = “Misalignment” and = “Bearing loose”. Thus, the frame of discernment is .

In the data level five sensors have been used to monitor the status of the system. Next, in feature level the fault features considered are: = “Power spectrum entropy”, = “Wavelet energy spectrum entropy”, = “Wavelet space spectral entropy” and = “Singular spectrum entropy”. The reference fault feature vector is as procured from the training data. In evidence level, the distance between the reference and the measurement fault feature vector for five sensors is:


where, .

As, the distance function and the similarity degree are reciprocal to each other, thus to transform the distance function to similarity degree, an inverse function has been used. Then the BPA of the sensor can be calculated by normalising the similarity degree. Next in the fusion level, the proposed method is used to fuse the different pieces of evidence. Finally, in the decision level if satisfy:


and are the two thresholds of decision and is the final decision if:

Example 4.

Reference fault features of four mechanical faults are given in Table 6 according to [YLin].

Fault Types
43.5828 30.8859 10.6806 53.7373
74.3605 72.1393 17.8107 74.1857
63.9286 58.6064 21.7660 67.5529
49.8858 46.8183 14.998 52.6699
Table 6: Reference Fault Feature Vector
Sensor 1 66.2913 57.3129 22.8701 65.0923
Sensor 2 62.3361 55.3681 22.8297 66.1382
Sensor 3 73.4274 69.8329 16.5621 72.5824
Sensor 4 65.8638 61.5325 24.2016 69.2899
Sensor 5 51.4154 48.3248 15.4123 50.3624
Table 7: Fault Feature of Five Sensors
0.1469 0.2057 0.4660 0.1813
0.1521 0.1935 0.4631 0.1914
0.1278 0.5008 0.2221 0.1493
0.1459 0.2396 0.4395 0.1750
0.2068 0.1399 0.1755 0.4777
Table 8: BPA of five sensors
Rules Results
DS 0.0714 0.1273 0.6902 0.1110
Lin et al[YLin] 0.0715 0.1274 0.6903 0.1111
Wang et al[ZWang] 0.0715 0.1274 0.6900 0.1110
iDCR 0.0715 0.1274 0.6901 0.1111
DS 0.0376 0.2626 0.6315 0.0683
Lin et al[YLin] 0.0315 0.2675 0.6431 0.0579
Wang et al[ZWang] 0.0314 0.2594 0.6490 0.0578
iDCR 0.0315 0.2540 0.6565 0.0585
DS 0.0153 0.1758 0.7755 0.0334
Lin et al[YLin] 0.0125 0.1692 0.7906 0.0276
Wang et al[ZWang] 0.0126 0.1643 0.8026 0.0278
iDCR 0.0124 0.1571 0.8029 0.0275
DS 0.0176 0.1368 0.7570 0.0886
Lin et al[YLin] 0.0109 0.1258 0.7874 0.0759
Wang et al[ZWang] 0.0108 0.1204 0.7941 0.0747
iDCR 0.0103 0.1148 0.8011 0.0692
Table 9: Fusion Results

Table 7 provides the fault feature of the five sensors. Table 8 gives the BPA of the five sensors at the evidence level from which it can be seen that the fault should happen. But the conflict information says otherwise. Like, the informations from sensors 1,2 and 4 show that the fault is , whereas sensor 3 and sensor 5 indicate that the fault is and respectively.

Figure 3: Fusion results of

In Table 9, the calculations using the traditional DCR, some existing methods [YLin, ZWang] and the proposed method have been shown. Now, considering , from Table 9, it can be seen that all the methods confirm fault . Though, when combining sensors 1, 2 and 3, there is a slight decrease in the support degree because of the conflicting information from sensor 3, fault prevails. The support degree again increases for fault when sensor 4 is fused. Finally, when all the five sensors are combined, fault is prevails. So, it can be concluded that the fault diagnosis system can be used to make the correct decision. Moreover, the superiority of the proposed method (iDCR) is evident from Table 9 and Fig. 3, as they show that iDCR has a higher support degree for fault as compared to classical DCR and existing methods.

6 Conclusion

Multiple sensors are used for monitoring many systems where data from a single sensor is not enough or adequate. But the data collected from these multiple sensors may show conflicting results or may be uncertain, fuzzy or even incomplete, resulting in misleading conclusions when data from the multiple sensors are fused. In this work, a multisensor fault diagnosis method has been put forward considering the evidence theory. The proposed method (iDCR) considers weighted Deng entropy to improve upon the traditional Dempster’s combination rule. The superiority of the proposed method has been shown through numerical examples and simulations taking different situations into account. As a future work, this work can be extended for more dynamic and complex environments and also the focus will be on further improving the fusion result.
