1 Introduction

1.1 Background and Motivation

The scarcity of high-quality annotated data remains a notorious challenge in medical image analysis due to the high cost of acquiring expert annotations Castro et al. [2020]. Transfer learning from large models pretrained in a supervised fashion on natural images such as ImageNet has become a de-facto solution for 2D medical imaging tasks in low data regimes Lam et al. [2018], Bayramoglu and Heikkilä [2016], Pardamean et al. [2018], Yang et al. [2018]

. Recently, self-supervised learning shows initial success in building large-scale Deep Learning based applications by leveraging unannotated data for pretraining

Zhou et al. [2019], Chen et al. [2019], Taleb et al. [2020, 2020], Zhuang et al. [2019], Bai et al. [2019], Abbet et al. [2020], Sowrirajan et al. [2021]. However, a bottleneck within self-supervised learning is the demanding requirement of computational resources to train compared to standard supervised learning Chen et al. [2020], Caron et al. [2021, 2021], Grill et al. [2020]. For example, regarding training on ImageNet, SwAV Caron et al. [2021] uses the batch size of 4096 distributed on 64 GPUs and SimCLR Chen et al. [2020] uses varying batch sizes between 256 and 8192 on 32-128 TPU cores. Even when the batch size is small, the author of SimCLR notes that the training time must be extended to provide more negative examples. In pretraining medical datasets, Azizi et al. Azizi et al. [2021] observe the best performance when using the batch size of 1024 on 64 cloud TPU cores to train SimCLR on a chest X-ray dataset. While transfer learning from supervised pretraining on a large labeled dataset such as ImageNet is widely studied Raghu et al. [2019], Ke et al. [2021], the transferability of models pretrained on ImageNet using self-supervised techniques requires further investigation.

This paper reflects on the effectiveness of transfer learning with self-supervised features. We evaluate the performance of four downstream classification tasks using ImageNet pretrained features obtained from supervised and self-supervised techniques. The four distinct tasks concern three modalities with varying data sizes and distributions. The first task is in the domain of digital pathology and aims to detect sentinel axillary lymph node metastases in hematoxylin and eosin (H&E) stained patches extracted from whole-slide images. The second task concerns the severity classification of diabetic retinopathy from colored fundus images. The last two tasks are related to reading X-ray images. One involves identifying whether a patient is suffering from pneumonia and the other involves detecting multiple findings, such as pneumothorax, nodule or mass, opacity, and fracture. In particular, we consider low data regimes ranging from approximately 1% to 10% of the original dataset size for each task (Section 5.2). We evaluate pretrained features of three self-supervised approaches, SimCLR Chen et al. [2020], SwAV Caron et al. [2021], and DINO Caron et al. [2021], on aforementioned tasks by training a linear layer on top of frozen features. We find that DINO consistently outperforms other self-supervised techniques and the supervised baseline by a significant margin.

Additionally, we propose Dynamic Visual Meta-Embeddings

(DVME) - a model-agnostic technique to combine multiple self-supervised pretrained features for downstream tasks. In natural language processing, it has been observed that different word embeddings work well for different tasks and that it is difficult to anticipate the usefulness of a given embedding technique for a certain task at hand. The usage of a meta-embedding mitigates this problem by constructing an ensemble of embedding sets to increase the lexical coverage of vocabulary which leads to improved performance on downstream tasks

Kiela et al. [2018]. Similarly, in vision tasks, we propose to concatenate multiple pretrained embeddings with self-attention for transfer learning. Concatenation expands the embedding space and yields richer representation while self-attention adapts the contribution of individual embedding to a specific downstream task. We show that DVME leads to a further increase in performance across all tasks compared to the best single self-supervised pretrained model baseline.

1.2 Contributions

Overall, the main contributions are as following:

  • Across four distinct medical image classification tasks, we assess the quality of the embeddings obtained from different models which are pretrained on ImageNet using state-of-the-art self-supervised or supervised pretraining techniques.

  • We identify a single self-supervised model which consistently outperforms the other approaches on all selected downstream tasks. In particular, this effect is prominently observed in low data regimes.

  • We propose Dynamic Visual Meta-Embeddings (DVME) to fully leverage the collective representations obtained from different self-supervised pretrained models. The representations obtained from the DVME model aggregation outperform all single model approaches on the selected downstream tasks.

2 Related work

Self-supervised learning in medical imaging

Two main self-supervised approaches in medical imaging are in the form of handcrafted pretext tasks and contrastive learning. Early applications design tailored pretext tasks to reconstruct images from transformed or distorted inputs Zhou et al. [2019], Chen et al. [2019], Taleb et al. [2020], Zhuang et al. [2019], Bai et al. [2019], Rivail et al. [2019], Abbet et al. [2020]. For example, Model Genesis Zhou et al. [2019]

applies in-domain transfer learning to various classification and segmentation tasks on CT and X-ray images. The proposed architecture is an autoencoder that reconstructs images from four transformations, namely non-linear, local-shuffling, out-painting, and in-painting. The induced transformations are supposed to enable the encoder to learn features related to appearance, texture, and context.

Chen et al. Chen et al. [2019] propose context restoration as a pretext task applied in three common medical use cases: plane detection on fetal 2D ultrasound images, abdominal organ localization on CT images, and brain tumor segmentation on MRI images. The proposed method generates distorted images with different spatial contexts while maintaining the same intensity distribution by repeatedly swapping two random patches in an input image. Through reconstruction, the model learns useful semantic features transferable in subsequent target classification and segmentation tasks. Alternatively, several works Taleb et al. [2020], Zhuang et al. [2019] tailor the pretext tasks as solving Jigsaw puzzles and Rubik cubes. Taleb et al.Taleb et al. [2020] create puzzles made of patches fused from different modalities, e.g., different MRI modes, of the same structure and trains a construction task to reassemble the shuffled patches. Likewise, in 3D images, Zhuang et al. Zhuang et al. [2019] rearrange and rotate the CT volumes, driving the model to learn features invariant to translation and rotation. The pretrained features are transferred to solve brain hemorrhage classification and tumor segmentation tasks. The limitation of handcrafted pretext tasks is that they are highly task- and domain-specific, and thus cannot generalize well to different tasks. Lately, contrastive learning-based techniques (see Section 3) resolve this issue. Sowrirajan et al. Sowrirajan et al. [2021] use MoCo He et al. [2020] to pretrain on unlabeled CheXpert Irvin et al. [2019] dataset and finetunes with labels on external Shenzhen Hospital X-ray dataset Jaeger et al. [2014] to detect pleural effusion. Azizi et al. Azizi et al. [2021] propose multi-instance contrastive learning that utilizes two crops of the same patient but with different viewpoints or lighting conditions as positive pairs so that the model learns representations invariant to different images of the same pathology.

Transfer learning in medical imaging

Transfer learning with ImageNet pretrained features still incites debates over its actual benefits for downstream medical tasks Raghu et al. [2019], Ke et al. [2021], He et al. [2018]. In a large data regime, Raghu et al. Raghu et al. [2019] show that lightweight models with random initialization can perform on par with large architectures pretrained on ImageNet such as ResNet-50 He et al. [2015] and Inception-v3 Szegedy et al. [2015]. On the contrary, Ke et al. Ke et al. [2021] argue that ImageNet pretraining can significantly boost the performance with newer architectures such as DenseNet Huang et al. [2018] and EfficientNet Tan and Le [2019]. In low data regimes, however, transfer learning with self-supervised approaches has been found particularly helpful in recent works Newell and Deng [2020], Azizi et al. [2021], Chaves et al. [2021]. Azizi et al. Azizi et al. [2021] perform transfer learning with SimCLR Chen et al. [2020] on X-ray and dermatology datasets and show a significant gain compared to a supervised baseline. Chaves et al. Chaves et al. [2021] evaluate self-supervised models on multiple dermatology datasets and find the advantage of self-supervised pretraining when using low training data. Whereas prior works focus on a single self-supervised technique Azizi et al. [2021] and a unique modality, i.e., dermatology Chaves et al. [2021], our work extends the investigation by benchmarking various self-supervised approaches against the supervised baseline across a set of heterogeneous medical imaging tasks. Our primary goal is to compare the richness of feature embeddings of different self-supervised learning techniques in the scope of transfer learning on medical imaging tasks.

3 Contrastive Learning

Self-supervised methods can be broadly categorized into handcrafted pretext tasks Jing and Tian [2020]

and contrastive learning. In Layman’s terms, contrastive learning learns the representation by comparing the similarity between images. Given the output embeddings obtained from an encoder, they are either pulled closer (similar) or pushed away (dissimilar) in the embedding space. Most of the approaches are built on the notion of

multi-instance level classification Dosovitskiy et al. [2015], which considers each image as a unique class. Current techniques create so-called positive pairs as data augmented versions of an image and the model learns to contrast them from the rest of images in the batch. A detailed review and taxonomy of contrastive learning can be found in Le-Khac et al. [2020]. Among state-of-the-art contrastive techniques, our main focuses are SimCLR, SwAV, and DINO.

SimCLR

Simple Framework for Contrastive Learning of Visual Representation Chen et al. [2020] maximizes the agreement of two views from the same image. The paper proposes a set of transformations applied to input images to create positive and negative pairs. An encoder takes a transformed batch and forwards it to a projection head that maps images to an embedding space. A contrastive loss on top compares the embeddings to minimize the distance between similar (positive) embeddings. Finally, the projection head is discarded and the encoder can be transferred to downstream tasks.

SwAV

Swapping Assignments between multiple Views of the same image Caron et al. [2021] also contrasts two image views but not in a direct, sample-based fashion as SimCLR. Instead, it compares the cluster to which each view belongs. If two views come from the same image, they should fall on the same cluster assignment and vice versa. Caron et al. Caron et al. [2021] shows that this approach has an advantage over SimCLR in avoiding the need for large batch size and improving the convergence time. In comparison to a prior clustering-based self-supervised technique in Caron et al. [2019]

, the clustering assignment process is online, so gradients can be backpropagated in batch-wise manner.

Dino

Knowledge distillation without labels Caron et al. [2021]

matches the output probability distributions of various image views obtained from two networks. This approach takes inspiration from Bootstrap Your Own Latent (BYOL)

Grill et al. [2020] in the perspective of self distillation task and the architecture of Vision Transformer (ViT) Dosovitskiy et al. [2021]

as the backbone. Instead of passing the views into the same network, DINO passes two transformations of an image into two networks, namely the student and teacher network. The loss compares the probability outputs of both networks and the student’s parameters are updated via backpropagation while the teacher’s parameters is updated via an exponential moving average of the student ones. In addition, compared to using convolutional architectures,

Caron et al.’s study Caron et al. [2021] indicates that ViT-based DINO shows distinct properties in characterizing object boundaries and generates features that perform well using K-Nearest Neighbors without further finetuning in ImageNet classification task.

4 Datasets

The four datasets in our experiments are distinct in terms of modality, dataset size, and class distribution in order to partially reflect the heterogeneity of typical medical imaging tasks. We consider three common modalities in medical image analysis: digital pathology, fundus imaging, and X-ray.

PatchCamelyon (PatchCam)

The dataset contains H&E sentinel axillary lymph node patches extracted from whole-slide image in the study at Ehteshami Bejnordi et al. [2017], Veeling et al. [2018]. All of the slides were annotated by expert pathologists. If the center of a patch contains at least one pixel of tumor tissue, it will be marked as positive. The data version we use is the curated one from Kaggle competition111https://www.kaggle.com/c/histopathologic-cancer-detection that removes all the duplicated patches and comes with a default train/test split. The original train set consists of 220025 patches of size 9696 with binary labels indicating whether there is a tumor or not. For our training task, we randomly select a subset comprising 50000 images. The official test set comprises 57486 images for which no labels are provided. Hence, for all performance evaluations on PatchCam we therefore submit our predictions to Kaggle.

Aptos

The dataset comprises of colored fundus images of diabetic retinopathy patients obtained from diverse clinics with different camera setups. For each image, clinicians grade the severity with a score between 0 and 4 that corresponds to no diabetic retinopathy, mild, moderate, severe, and proliferative diabetic retinopathy. The dataset is part of the challenge held on Kaggle222https://www.kaggle.com/c/aptos2019-blindness-detection. The train and test set contain 3662 and 1928 images respectively. Similar to PatchCam, we submit the inference of the test set to Kaggle to obtain the scores.

Pneumonina chest X-ray

The dataset contains chest X-ray images annotated by two expert radiologists. Each radiologist classifies each image into healthy and pneumonia. We obtain the dataset in Kaggle

333https://www.kaggle.com/paultimothymooney/chest-xray-pneumonia with a default train/test split of 5216/624 images. Each patient can have multiple images, which is taken into consideration for patient stratification during train and validation. Further description of the dataset and acquisition can be found at Kermany et al. [2018].

NIH chest X-ray

The dataset consists of chest X-ray images provided by NIH Clinical Center444https://nihcc.app.box.com/v/ChestXray-NIHCC. The images were manually reviewed by three certified radiologists from the American Board of Radiology. Each radiologist marks the presence of four medical conditions: pneumothorax, nodule or mass, opacity, and fracture. We use two subsets of the original NIH Chest X-ray dataset which are referred as validation and test set in the study at Majkowska et al. [2020]. We use the first subset (2414 images) for training and keep the second subset (1962 images) for evaluation. Since there can be multiple findings per image, for simplicity we exclude such cases in our experiment. In addition, we also add a class called other for when no mentioned conditions are found in the image.

5 Experimental Setup

5.1 Architecture

To assess the transferability of self-supervised features in medical imaging tasks, we choose ResNet-50 He et al. [2015], which is the backbone for many state-of-the-art self-supervised approaches Chen et al. [2020], He et al. [2020], Caron et al. [2021, 2021]. ResNet-50 is used for the supervised baseline (ImageNet and random initialization) and two self-supervised approaches (SwAV and SimCLR). For Dino, the architecture of choice is VisionTransformer (ViT) with patch size 88. The pretrained weights for SimCLR and SwAV are obtained from VISSL555https://vissl.ai/ while for DINO the weights are obtained from the FAIR repository666https://github.com/facebookresearch/dino.

5.2 Dataset sizes and subtasks

For each dataset we consider three different subtasks (Small, Medium, Full) each containing a different fraction of training data, see Table 1. The subtasks are generated by random sampling which is accounting for class imbalances. For each subtask, we generate a split of the training data which is used to conduct a five fold cross validation. Finally, the five models from this cross validation are evaluated on the fixed test set and the final performance is obtained by averaging the individual model scores. For PatchCam and APTOS, we submit the prediction of test set to Kaggle and obtain a final score of which the calculation is presented in Section 5.6.

Dataset Training Testing
Small (S) Medium (M) Full (F)
PatchCam 500 5000 50000 57486 (*)
APTOS 50 500 3662 1928 (*)
Pneumonia Chest X-ray 50 500 5216 624
NIH Chest X-ray 20 200 2414 1962
  • (*) The performance evaluation is obtained by submitting the predictions to Kaggle.

Table 1: Number of samples for different subtasks

5.3 Linear performance and finetuning

The evaluation of linear performance is of the standard methods for assessing feature quality of a pretrained feature extractor. This performance measure is obtained by freezing all layers of the pretrained model and only finetuning a final linear layer, cf. Chen et al. [2020], Caron et al. [2021, 2021], Azizi et al. [2021]. In our experiments we follow the same setup by adding and training linear layers with output dimensions adjusted to the number of classes in the respective downstream tasks. The linear layer is added after the last average pooling layer in ResNet-50 and after the concatenation of class tokens from the last four blocks in ViT, following the implementation of Caron et al. [2021]. In addition to linear evaluation we consider finetuning, where all layers of the pretrained base network as well as the final linear classifier are adapted on the downstream task at hand. To avoid bias learning due to class imbalance, the number of samples per class is maintained balanced across each experiment. However, as the number of samples in the NIH Chest X-ray dataset for the underrepresented class is significantly small compared to other classes, we use oversampling during training.

5.4 Linear evaluation with DVME

Given a set of pretrained feature extractors, it may be difficult to anticipate which pretrained model to choose for a given downstream task at hand. This concern is also shared in natural language processing where there are multiple word embedding techniques trained on different domains, each having its own strengths depending on target tasks. Meta-embedding is an effective technique that takes a union over different word embeddings to tackle the out-of-vocabulary problem and fuse multi-modal information Kiela et al. [2018]. Though there is no multi-modal information in our study, we hypothesize that the pretrained features from different techniques are sufficiently independent from one another and encode certain complementary information. Therefore, we propose Dynamic Visual Meta-Embedding (DVME) for vision tasks which aggregates information by concatenating the embeddings of SimCLR, SwAV and DINO pretrained models. The newly constructed embedding space improves the separability of image features through the complementary effect of each embedding component. For SimCLR and SwAV, the embedding is obtained at the last layer before the classifier and has the dimension of 2048. For DINO, the embedding is obtained by concatenating the class tokens of the last four blocks, resulting in the length of 1536. We project each embedding to a fixed dimension of 512 and concatenate them. A self-attention module is added after the concatenated layer to learn the importance of each embedding component for a specific downstream task. This self-attention module is the same as in the Vision Transformer architecture Dosovitskiy et al. [2021] except that the attention is learned across different components of the meta-embedding instead of image patches. Figure 1

shows a sketch how self-attention is incorporated when fusing the pretrained features. Clearly, the proposed DVME approach is not limited to SimCLR, SwAV or DINO and can be used with other feature extractors. We provide a snippet of DVME implemented in PyTorch in Appendix

E.

Figure 1: Dynamic Visual Meta-Embedding (DVME): The embeddings extracted from each pretrained model are projected to the same dimension and concatenated before feeding to the self-attention module.

5.5 Hyperparameters and Augmentation

All experiments use the Adam optimizer starting with a small learning rate between 1e-3 and 1e-4 and further reducing it when the validation loss does not improve consecutively over five epochs. As our study aims to compare among different initialization and not to outperform the best performance, we do not apply intensive augmentation techniques. Images with an original size larger than 224

224 are resized into 256256, then cropped and applied further flipping or rotation depending on the nature of modality. For PatchCam dataset, we apply directly flipping without resizing or cropping as the size of the images is less than 224224.

5.6 Metrics

The evaluation metric for PatchCam, Pneumonia, and NIH Chest X-ray is the area under the Receiver Operating Characteristic curve (AUC) while it is the Cohen Kappa score for APTOS. We submit the predictions of APTOS and PatchCam test set to Kaggle and obtain two scores for the private and public leaderboard, which are evaluated on two different portions of the test set. We calculate the final score as the weighted average score of the private and public leaderboard. Precisely, the final score is calculated as

where for PatchCam is 0.51 and for APTOS is 0.85. The value of is the portion of test set that Kaggle uses to calculate the score on private leaderboard and it varies depending on the competition.

6 Results and Discussion

6.1 Evaluation of self-supervised and supervised pretrained features

(a) Supervised ImageNet
(b) DINO
(c) DVME
(d) Supervised ImageNet
(e) DINO
(f) DVME
Figure 2: t-SNE visualization of embeddings obtained using different pretrained feature extractors (supervised ImageNet, DINO, proposed method DVME). Top row: PatchCam dataset, bottom row: APTOS dataset

For each task and each self-supervised pretrained initialization, Table 2

contains the linear evaluation performance obtained on small (S), medium (M), and full (F) sized subsets. As additional baselines we compare against the linear performance of features extracted by a ResNet-50 supervisedly pretrained on ImageNet and the features extracted by a Kaiming randomly initialized ResNet-50. The latter constitutes a lower bound for all other methods. In first order, the linear performance of the differently initialized feature extractors measures the separability of the dataset embeddings by a hyperplane.

Table 2 shows that SwAV and SimCLR pretrained features yield inconsistent patterns across all downstream tasks. For example, while SwAV and SimCLR intializations perform on par with each other on PatchCam and NIH Chest X-ray, they are different by approximately 10% in Kappa score and 3.7% in AUC on the S subsets of APTOS and Pneumonia Chest X-ray, respectively. Notably, DINO initialization consistently outperforms all the other initializations across all tasks by a significant margin. For example on NIH Chest X-ray S and M subtasks, DINO pretrained features yield an improvement of approximately 5-6% in AUC over SimCLR and SwAV. The single exception is the APTOS S subtask, where SwAV outperforms DINO by 3.3% in AUC. However, DINO still yields an improvement over SimCLR and ImageNet supervised initialization by 7% and 11.2% in Kappa score, respectively. We refer to Appendix B.1 for more detailed results on the performance obtained by the competing initialization methods for different dataset sizes. In comparison to ImageNet supervised pretrained features, we observe that self-supervised features are more effective in improving the performance across all downstream tasks. This suggests that the representation generated by self-supervised methods are of higher quality, leading to better performance on the test set and reducing the performance variability between folds in low data regimes, similar to the observation made in Chaves et al. [2021]. Figure 2 (a,b,d,e) visualizes the t-SNE embeddings of the features extracted by the supervised pretrained ResNet-50 and DINO on the PatchCam (binary classification) and APTOS (multi-class) downstream tasks. In Figure 2 (a,b) an improved separation in t-SNE space can be seen clearly when comparing the supervised pretrained embedding to the DINO embedding. We refer to Appendix D for the embedding visualization of other datasets.

We extend our comparison by finetuning all different model initializations separately on all downstream tasks. As our study primarily concerns assessing the quality of different pretrained features, no extensive hyperparamter tuning is conducted in the finetuning setting. Table 3 summarizes the finetuning results across all datasets and each subtasks. We refer to Appendix B.2

for more detailed results on different subset sizes as well as hyperparameters. Similar to the linear evaluation results, we consistently observe a higher performance for all self-supervised pretrained initializations compared to the supervised pretrained and randomly initialized baselines in the low data regimes (S, M), which supports the observation made by

Azizi et al. [2021], Chaves et al. [2021]. DINO pretrained features outperform those from other self-supervised methods in 2/4 S subtasks and 3/4 M subtasks. When using full data for fine-tuning, all self-supervised pretrained initializations consistently outperform the baseline methods on PatchCam, APTOS and Pneumonia Chest X-ray. On full data of the NIH Chest X-ray task, only SwAV exceeds the supervised baseline performance.

Moreover, we note that finetuning can result in slightly lower performance than linear evaluation in some of the initializations when the number of training samples falls less than a hundred due to overfitting effects. This can been observed for the S subtasks of APTOS, Pneumonia Chest X-ray, and NIH Chest X-ray dataset where there are 50 samples or less, see Table 1. For example, while DINO achieves the highest AUC of 0.6323 on the S subtask of NIH Chest X-ray in linear evaluation, the best performance for finetuning is obtained by SwAV and reaches only 0.5903 AUC.

Dataset Method Small (S) Medium (M) Full (F)
PatchCam Random 0.6594 0.0319 0.6994 0.0079 0.7990 0.0021
Supervised ImageNet 0.7517 0.0136 0.7863 0.0063 0.7975 0.0032
SwAV 0.7834 0.0112 0.8043 0.0072 0.8088 0.0025
SimCLR 0.7895 0.0091 0.8053 0.0069 0.8084 0.0026
DINO 0.8058 0.0100 0.8359 0.0053 0.8487 0.0014
APTOS (*) Random 0.0324 0.0602 0.0624 0.0459 0.1550 0.116
Supervised ImageNet 0.4851 0.0811 0.6822 0.0257 0.7331 0.0124
SwAV 0.6330 0.0204 0.7274 0.0095 0.7617 0.0128
SimCLR 0.5305 0.0539 0.6500 0.0138 0.6989 0.0084
DINO 0.6003 0.0691 0.7372 0.0167 0.7790 0.0083
Pneumonia Chest X-ray Random 0.6899 0.0339 0.8258 0.0237 0.8907 0.0144
Supervised ImageNet 0.8789 0.0234 0.8954 0.0151 0.9397 0.0033
SwAV 0.8808 0.0222 0.9215 0.0252 0.9709 0.0047
SimCLR 0.9168 0.0006 0.9346 0.0072 0.9665 0.0027
DINO 0.9492 0.0170 0.9718 0.0055 0.9868 0.0008
NIH
Chest X-ray
Random 0.5212 0.0344 0.5317 0.0176 0.5392 0.0346
Supervised ImageNet 0.5383 0.0392 0.6688 0.0148 0.7109 0.0084
SwAV 0.5785 0.0258 0.6889 0.0089 0.7225 0.0139
SimCLR 0.5792 0.0435 0.6645 0.0067 0.6983 0.0231
DINO 0.6323 0.0131 0.7373 0.0112 0.7438 0.0228
  • (*) The evaluation metric for APTOS is Cohen-Kappa score while for others is AUC score.

Table 2: Linear evaluation performance of different self-supervised initializations, supervised pretraining and random initialization on different scales (small, medium, full) of the data.
Dataset Method Small (S) Medium (M) Full (F)
PatchCam Random 0.7355 0.0282 0.7660 0.0223 0.8515 0.0023
Supervised ImageNet 0.7897 0.0162 0.8274 0.0051 0.8483 0.0097
SwAV 0.7895 0.0336 0.8399 0.0142 0.8619 0.0090
SimCLR 0.8021 0.0138 0.8329 0.0085 0.8553 0.0110
DINO 0.8366 0.0092 0.8440 0.0172 0.8517 0.0158
APTOS (*) Random 0.0177 0.0954 0.3233 0.0822 0.5927 0.0545
Supervised ImageNet 0.4817 0.0991 0.7369 0.0310 0.8057 0.0149
SwAV 0.4928 0.0378 0.7594 0.0246 0.8293 0.0133
SimCLR 0.5916 0.0570 0.7603 0.0249 0.8264 0.0103
DINO 0.6601 0.0447 0.7945 0.0079 0.8365 0.0213
Pneumonia Chest X-ray Random 0.6895 0.0512 0.9183 0.0186 0.9820 0.0043
Supervised ImageNet 0.8649 0.0442 0.9698 0.0066 0.9910 0.0015
SwAV 0.9289 0.0291 0.9814 0.0087 0.9927 0.0016
SimCLR 0.9197 0.0168 0.9781 0.0085 0.9950 0.0013
DINO 0.9256 0.0235 0.9867 0.0051 0.9948 0.0010
NIH
Chest X-ray
Random 0.5015 0.0253 0.6404 0.0165 0.6616 0.0345
Supervised ImageNet 0.5251 0.0238 0.6816 0.0429 0.7618 0.0116
SwAV 0.5903 0.0384 0.6973 0.0227 0.7737 0.0212
SimCLR 0.5570 0.0450 0.7228 0.0287 0.7358 0.0295
DINO 0.5552 0.0546 0.6652 0.0114 0.7404 0.0240
  • (*) The evaluation metric for APTOS is Cohen-Kappa score while for others is AUC score.

Table 3: Finetuning performance of different self-supervised initializations, supervised pretraining and random initialization on different scales (small, medium, full) of the data.

6.2 Evaluation of DVME performance

Table 4 summarizes the results obtained from fusing SwAV, SimCLR and DINO with the DVME approach on each dataset and for each subtask. We evaluate DVME similar to the linear performance evaluation from Section 6.1 by training only the meta-embedding on top of the three frozen feature extractors, cf. Section 5.4. As a performance benchmark, we selected for each dataset and each fraction of data the self-supervised initialization that leads to the best linear evaluation performance, cf. Table 2

. DVME outperforms this benchmark in 4/4 of the S subtasks, in 3/4 of the M subtasks and in 2/4 F subtasks. For the subtasks where DVME is not exceeding the benchmark performance, the performance difference lies within one standard deviation of the DVME linear evaluation score. The improvement of DVME over the benchmark is particularly pronounced for the APTOS and NIH Chest X-ray tasks. For example, DVME helps gain roughly 6% in Kappa score over the best individual baseline for the S and M subtask of the APTOS dataset.

The t-SNE visualizations of the DVME embeddings in Figure 2 (c,f) qualitatively indicate that the clusters are better separated, particularly in the case of multiclass classification. When analyzing the attention matrix, we find that SwAV and SimCLR pay little attention to each other but firmly into DINO, suggesting the representation from SwAV and SimCLR could be more similar and thus not so informative compared to DINO.

In order to better understand the effect of self-attention on the model fusion, we conduct an ablation study on DVME in Appendix C. In the setting without self-attention, the meta-embedding is directly connected to the linear classifier. Without self-attention, the feature fusion still yields an significant improvement over the baseline, which supports our hypothesis in Section 5.4 that each embedding contains complementary information. However, self-attention is particularly beneficial to certain tasks. For example, on APTOS the Kappa scores increase by 5.6%, 4.4% and 4.8% for the S, M and F subtask, respectively.

Dataset Method Small (S) Medium (M) Full (F)
PatchCam DVEM 0.8227 0.0148 0.8399 0.0059 0.8467 0.0094
Best single baseline 0.8058 0.0100 0.8359 0.0100 0.8487 0.0014
APTOS (*) DVME 0.6913 0.0575 0.7925 0.0265 0.8242 0.0279
Best single baseline 0.6330 0.0204 0.7372 0.0167 0.7790 0.0083
Pneumonia Chest X-ray
DVME 0.9539 0.0025 0.9696 0.0101 0.9842 0.0029
Best single baseline 0.9492 0.0170 0.9718 0.0055 0.9868 0.0008
NIH
Chest X-ray
DVME 0.6566 0.0564 0.7601 0.0146 0.7538 0.0234
Best single baseline 0.6323 0.0131 0.7373 0.0112 0.7438 0.0228
  • (*) The evaluation metric for APTOS is Cohen-Kappa score while for others is AUC score.

Table 4: Linear evaluation performance of Dynamic Visual Meta-Embedding (DVME) in comparison with the best score obtained using a single pretrained model on different downstream tasks on different scales (small, medium, full) of the data.

7 Conclusion

In this study, we assess the quality of ImageNet self-supervised pretrained features in four selected medical image classification tasks. We demonstrate that feature extractors which were pretrained using SwAV, SimCLR or DINO consistently yield richer embeddings on the downstream tasks compared to a superviesed pretrained baseline model. Among all self-supervised techniques, DINO outperforms the other methods on the majority of datasets and subtasks. Furthermore, we show that the representations from each individual pretrained model encode complementary information which can be fused to yield even more meaningful features. To that end we propose Dynamic Visual Meta-Embedding (DVME), a model-agnostic meta-embedding approach. Our experiments indicate that DVME outperforms the best single model baseline on numerous tasks. As a model-agnostic approach, DVME is not limited to SwAV, SimCLR or DINO. With slight modifications other models can be combined using DVME to generate enriched representations.
