1 Introduction

Complex industrial equipment such as engines, turbines, aircrafts, etc., are typically instrumented with a large number of sensors that result in multivariate time series data. Most deep learning approaches model such multivariate time series data using variants of recurrent neural networks (RNNs) and convolutional neural networks (CNNs), e.g. [7, 12, 1, 18, 10]. These approaches often follow an “end-to-end” design philosophy which emphasizes minimal a priori assumptions about the system [9], and therefore, ignore or fail to leverage explicit structures. However, in most industrial setups, a complex equipment has a well-defined and documented structure: it consists of multiple interconnected modules, with the dynamics of one module affecting the dynamics of other modules. Fig. 1 shows an aircraft turbofan engine with several interconnected modules.

Figure 1: Left: Simplified structure of a turbofan engine depicting different modules / components [adapted from [14]]. Right: Observations from sensors installed on an instance of the engine depicting typical degradation trends due to an impending failure.

Existing deep learning approaches fail to leverage the underlying structure of the complex equipment, and do not have the explicit capacity to reason about inter-component relations to make decisions over a structured representation of the sensor data.

Recently, a class of models for modeling and reasoning over graphs have been proposed. These include graph neural networks (GNNs) [15, 11], and their recent generalization in form of graph networks [2]. This class of neural networks operate on graphs, and structure their computations accordingly. GNNs provide the desired relational inductive bias [2, 6] to solve problems with underlying structure. For instance, NerveNet [17] uses Gated GNNs (GGNN) [11]

to learn structured policies by explicitly modeling the structure of the agent, and are better than the policies learned by models such as multi-layer perceptrons (MLPs) that simply concatenate all the observations from the environment.

In this work, we explore the applicability of GGNNs to explicitly model the underlying graph-structured mechanism of IoT-enabled complex equipment. We represent the structure of a particular complex equipment as a directed graph where each node corresponds to a subset of sensors (e.g. those from the same module), and an edge models the relationship or dependency between two nodes or subsets of sensors (e.g. the dependence of a module on another module). Effectively, the multivariate time series of sensor data is then represented in the graph domain to learn a GGNN model. We use remaining useful life (RUL) estimation [16] as a target application to validate our approach.

The key contributions of this work can be summarized as follows:

  • We propose an approach to capture the knowledge of the structure of a complex equipment by using GGNNs. To the best of our knowledge, this is the first study to evaluate the effect of introducing such relational inductive bias into the deep learning approaches for equipment health monitoring.

  • We show the advantage of informed modularized processing of the multi-sensor time series data by grouping the sensors into meaningful subsets guided by the underlying graph structure and modules, rather than the commonly used approach that concatenates the observations from all sensors into one multivariate time series.

  • We provide insights into the working of GGNNs for RUL estimation: we observe that the modularized processing of multivariate time series using GGNNs followed by a simple attention mechanism for aggregating information across modules can potentially allow the network to focus more on the modules with impending failures.

2 Related Work

Recent works in [13, 17] implement an inductive bias for object- and relation-centric representations of complex dynamical systems such as a pendulum, cartpole, toy cheetah, etc. In this work, we draw inspiration from such approaches, and show that leveraging such inductive bias can improve performance in IIoT-enabled health monitoring applications, e.g. RUL estimation. To the best of our knowledge, this is the first attempt to model the time series of multivariate time series data for equipment health monitoring applications while leveraging the underlying structure and semantics of the equipment.

Another line of research focuses on incorporating the semantics of the problem into the structure of deep learning models by using ontologies. For instance, [8] propose using dense layers connected as per the ontology of the manufacturing line, followed by an RNN at the top to capture the temporal dependencies. Similarly, [19] attempt to model an equipment as a graph of sensor nodes: they assume a fully-connected graph where nodes correspond to sensors, and edges capture the dependencies across sensors. However, they do not explicitly model the dependence between various modules of an equipment. Our work can be seen as a generalization of these approaches as it uses the structure of equipment to guide data processing.

Several variants of deep neural networks including CNNs and RNNs have been proposed for equipment health monitoring and RUL estimation, e.g. [7, 12, 1, 10, 5]. However, most of these approaches consider a flat concatenation of readings or observations from all the sensors as a multivari ate input to the neural network, and ignore the structure of the underlying system or mechanism from which the data is generated. In this work, we show that grouping the sensors into meaningful inter-dependent subsets and processing them separately before the final concatenation step yields superior performance.

3 Problem Setup

(a) GGNN-based Metric Regression (GNMR)
(b) GRU-based Metric Regression (GRU-MR)
Figure 2: Illustrative process flow for the proposed GGNN-based Metric Regression (GNMR) and the traditional GRU-based Metric Regression. While GRU-MR ingests observations from all sensors at once, GNMR processes observations grouped based on the equipment structure. refers to one or more feedforward layers with leaky ReLUs that capture the influence of node on node . denotes the initial representation of node and denotes the final representation of node after propagation steps. (Best viewed in the electronic version by zooming-in.)

We consider the scenario where a complex equipment consists of multiple modules (sub-systems) connected to each other in a known fashion. Let denote the set of all the sensors installed to monitor various parameters across various modules of the equipment. The dynamical behavior of any module is observed via the multivariate time series corresponding to a fixed and known subset of sensors (parameters) associated with that module. We represent the equipment as a directed graph , where (for ) is a node in the graph that corresponds to a subset of sensors associated with the module indexed by , is a directed edge from node to that models the influence of on . Note that, in general,

, such that a sensor can be associated with more than one node: for example, a sensor measuring the ambient temperature can be associated with all nodes. We consider the supervised learning setting: we are given a fixed graph structure

and a learning set of time series, where is the target value, and denotes the multivariate time series associated with the nodes of . Here, denotes the -dimensional multivariate time series corresponding to node for time , where and denote the number of sensors in .

For the RUL estimation task, the time series are collected from one or more instances (installations) of an equipment with structure , and the target variable corresponds to the RUL value at time , e.g. in terms of remaining cycles of operation or remaining operational hours. RUL estimation is then a metric regression task where the goal is to map to . Let denote the total operational life of an instance till the failure point, s.t. at any time , the target RUL is given by . Furthermore, as in a typical practical setting, we assume that all instances of the equipment have the same underlying graph structure , i.e. the different modules of the equipment are connected to each other in same fashion.

4 Approach

As illustrated in Fig. 1(a), each multivariate time series is processed by a neural network (for

) to obtain a fixed-dimensional initial node representation vector

. This initial representation is then updated using the representations of neighboring nodes defined by using a message passing mechanism to obtain . Finally, an attention mechanism is used to combine the final node representations to obtain an RUL estimate for the equipment. We refer to this approach as GNMR (Gated Graph Neural Networks for Metric R

egression). The entire computation flow of GNMR is differentiable end-to-end and the associated parameters are learned via stochastic gradient descent. Next, we describe these steps in more detail.

Learning Node Representations from Time Series

The -dimensional time series at node is processed by to obtain

. We consider a gated recurrent units (GRU)-based RNN

[3] for processing this time series. In general, is different across the nodes implying that we need to learn and maintain GRU networks. This can pose scalability issues for graphs with large number of nodes. It is, therefore, desirable to use a common GRU, which we refer to as , to process the multivariate time series from all the nodes so as to keep the number of trainable parameters of the network within manageable limits. To this end, any point () at node is first processed via a node-specific feedforward network to obtain a fixed -dimensional vector . Note that is same across nodes allowing us to use the common for further processing of the resulting time series to obtain the initial representation . Effectively, consisting of and maps the input time series to .

Message Passing Across Nodes

While the node-level representation obtained from can capture the dependencies across sensors in , it ignores the dependencies across nodes. It is desirable to leverage the representations of neighboring nodes to capture the dependencies between nodes, and then aggregate them to obtain a representation for the overall dynamics of the system. To achieve this, the representations for each node are iteratively updated by a GGNN using the representations of the neighboring nodes as described next.

Consider two normalized adjacency matrices and corresponding to the incoming and outgoing edges in graph , as illustrated in Fig. 1(a). Let correspond to the th row of matrix , and denote the representation (or embedding) for node after message propagation steps. GGNN takes , , and the initial node representations as input, and returns an updated set of representations after iterations of message propagation across nodes in the graph s.t. , where represents the parameters of the GGNN function . For any node in the graph and message propagation step , the previous representation of the node , and the aggregated representation of its neighboring nodes (as obtained via Eqs. 1-3 below) are used to iteratively update the representation of the node times.

More specifically, the representation of node in the message propagation step is updated as follows:

(1)
(2)
(3)
(4)
(5)
(6)
(7)

where , and denote the -th row of and , respectively. Here, and allow to capture the information from upstream and downstream nodes in the system, respectively.

denotes feedforward ReLU layer(s) with parameters

that computes the contribution (message) from to if there is an incoming edge from to , i.e. when . Then, denotes the message from to corresponding to edge . Similarly, computes the message from to if there is an outgoing edge from to , i.e. when . and denote the matrices that contain the information from the incoming and outgoing edges with as starting and ending node, respectively. For , simply returns . The trainable parameters , , and of appropriate dimensions constitute ,

is the sigmoid function, and

is the element-wise multiplication operator. Eqs. 4-7 are the computations equivalent to a gated recurrent unit (GRU) network.

Note that for large graphs with many nodes and edges, the number of functions and their associated parameters can be large. However, in many practical applications such as a power plant or a water treatment plant [4], nodes typically have an associated type with more than one node belonging to the same type, e.g. multiple water tanks in a water treatment plant. Under such scenarios, it may be suitable to tie the parameters of the edge functions for a given pair of node types.

Attention Mechanism to Aggregate Node-level Representations

The final representations can be aggregated to get a graph-level output (RUL estimate in our case) by using an attention mechanism, e.g. as used in [11]. In this work, we consider a simple variant of this attention mechanism: For each node, we use the concatenated vector as inputs to two parallel feedforward layers and to obtain and . Here, is a one-hot vector of length , and is set to 1 for th position, and 0 otherwise. Also, is used as an additional input for the RUL estimation task as the total life passed can be a useful feature to estimate the wear-and-tear of the system. We apply softmax over the values from to obtain attention weight for node . The final RUL estimate is then given by

(8)

This can be interpreted as assigning a weightage to the node while denotes the RUL estimate as per node .

Given the training set

, the loss function used for training is then given by

, with learning parameters being , parameters of , and the parameters of the feedforward layers (s, , and ) with leaky ReLU units.

5 Experimental Evaluation

Figure 3: Original graph structure used for the experiments. Each node corresponds to a module (in bold) with an associated subset of sensors (in italics). Refer Table 2 in [14] for details of sensor names.

We investigate if GNMR is able to leverage the graph structure to improve upon other strong baselines from literature that consider a simple concatenation of observations as a multivariate input: CNNs [1, 10], LSTMs [20]

, and Deep Belief Networks

[18]. We additionally implement GRU-MR: a GRU-based RUL estimation model on lines of Metric Regression approach proposed in [20] as depicted in Fig. 1(b)

. We ensure comparable hyperparameter settings as well as the same train, validation and test splits for GRU-MR and the proposed GNMR, as detailed later. We further study the sensitivity of the approach to the knowledge of the graph structure by synthetically combining or segregating nodes (modules) in the original graph structure. To study other ways of combining time series of sensors, we also consider reducing the number of input dimensions for GRU via principal components analysis within the GRU-MR framework, and refer to it as

PCA-GRU-MR

. We report results for 5 PCA components (capturing 85% variance in the data), i.e. 5-dimensional input to GRU-MR in Table

1.

Datasets: We use the four publicly available aircraft turbofan engine benchmark datasets111https://ti.arc.nasa.gov/tech/dash/groups/pcoe/prognostic-data-repository/#turbofan FD001-FD004, as introduced in [14]. We use the equipment structure information as depicted in Figs. 1 and 3 (refer [14] for details). Each dataset contains a pre-defined train-test split. We further use a random 80-20 split of the original train split to obtain a train and a validation set. The hold-out validation set is used for hyperparameter tuning.

Dataset FD001 FD002 FD003 FD004 Average Rank
Method RMSE S RMSE S RMSE S RMSE S RMSE S
CNN-MR [1] 18.45 1,287 30.29 13,570 19.82 1596 29.16 7,886 8 7.75
LSTM-MR [20] 16.14 338 24.49 4,450 16.18 852 28.17 5,550 6.5 5.25
MODBNE [18] 15.04 334 25.05 5,585 12.51 422 28.66 6,558 4.75 5.25
CNN + FNN [10] 12.61 274 22.36 10,412 12.64 284 23.31 12,466 3.25 4.5
GRU-MR (ours) 15.36 481 22.43 3,391 12.52 339 22.96 2,964 3.75 3.75
PCA-GRU-MR (ours) 15.60 469 22.92 3,916 13.37 860 22.41 2,637 5 4.5
GNMR (proposed, ) 12.73 302 21.38 3,148 13.06 366 21.81 3,414 2.75 2.75
GNMR (proposed) 12.14 212 20.85 3,196 13.23 370 21.34 2,795 2 2.25
Table 1: Performance comparison in terms of RMSE and S. Best performance is shown in bold and second-best is underlined.
Dataset FD001 FD002 FD003 FD004 Average Rank
Method RMSE S RMSE S RMSE S RMSE S RMSE S
Original Graph 8 12.14 212 20.85 3,196 13.23 370 21.34 2,795 1.25 1.5
One node for all sensors 1 13.20 321 22.36 4,072 13.65 378 22.04 2,747 4.25 3
Reduced Nodes 4 12.41 299 22.85 4,798 15.26 981 21.87 3,034 4.25 4.5
Increased Nodes 13 12.15 214 22.20 4,512 13.63 623 20.95 3,813 2.25 3.75
One node per sensor 21 13.86 293 21.99 3,317 13.39 431 21.48 2,562 3 2.25
Table 2: Effect of varying the graph structure.

Performance Metrics: We use the standard metrics RMSE and Timeliness Score (S) as introduced in [14]. Let = denote the error in RUL estimate for th test instance, then and , is the number of test instances, if , else . Usually, such that late predictions are penalized more compared to early predictions. We consider and as used in all the baselines. Lower values of RMSE and indicate better performance.

Hyperparameters: We use batch size of 32, and a dropout rate of 0.2 for all feedforward (leaky ReLU) layers. We use 2 leaky ReLU layers for each and in GNMR as well as for the pre-final leaky ReLU layers of GRU-MR (refer Fig. 2

). We use Adam optimizer with initial learning rate of 0.001 which is reduced every 10 epochs by a factor of

. The number of hidden units, same as , for all feedforward and recurrent layers is chosen from {30,60}. We use message propagation steps for GGNN. The number of hidden layers for in GNMR and for GRU-MR is chosen from {2,3,4}. All hyperparameters are selected via grid search based on validation RMSE.

Results and Observations

(1) Comparison with baselines: From Table 1, we observe that GGNN performs better than GRU-MR, PCA-GRU-MR as well as other baselines across most datasets. GNMR has the highest average rank of 2.0 based on both RMSE and S. Furthermore, the special case of GNMR with no message propagation across nodes, i.e. , also compares favorably to GRU-MR and other baselines. These results suggest that meaningful grouping of the sensors into nodes based on the knowledge of the modular graph structure of the equipment is advantageous over methods that consider a concatenated vector of all the sensors as one input. Also, allowing for message propagation across nodes gives further improvement in results indicating the advantage of modeling the dependencies between modules.

(2) Effect of varying the graph structure: We consider two scenarios to study the sensitivity of results to the exact knowledge of graph structure: for the Increased Nodes scenario, any original node in with is split into two nodes, say and , by randomly distributing the sensors in to the two nodes such that each new node gets half the sensors. Furthermore, the nodes and thus created are connected to each other. Also, if , then both and are additionally connected to the new nodes and obtained from . For the Reduced Nodes scenario, when combining two neighboring nodes and into a new node, say , we have , and an edge exists between any two new nodes if there was an edge between the original nodes from which the new nodes were created. We also consider the limiting cases of One node per sensor and One node for all sensors for the Increased Nodes and Reduced Nodes scenarios, respectively.

From Table 2, we observe that the performance degrades as we reduce the nodes in the graph, with Reduced Nodes and One node for all sensors being the worst models. On the other hand, the graph with Increased Nodes performs the same as the Original Graph for FD001 while being better on FD004. Nevertheless, the Original Graph still gives best performance on average across datasets. Increased Nodes and One node per sensor have the second-best performance. However, it is to be noted that the models with increased nodes have a much larger number of MLPs for message propagation (refer Eqs. 1-2) due to increased number of edges, making it computationally more expensive when compared to the original graph.

(a) FD001
(b) FD002
Figure 4: Average attention weight and RUL estimates w.r.t ground truth RUL for the HPC node with impending failure versus other nodes.

(3) Preliminary Analysis of Attention Mechanism (refer Eq. 8): For FD001 and FD002 datasets, the faults in all instances are known to originate in the HPC module222For FD003 and FD004, the ground truth information about the faulty node is not available, hence not analyzed. (refer Fig. 3). It is therefore expected that as the degradation increases, the behavior of sensors associated with the HPC module will depict signatures for detecting the impending failure, and in turn, estimating the RUL. We observe that GNMR implicitly tends to capture and leverage this behavior in some cases: we analyze the attention weights s and the corresponding contribution to the RUL estimate from the HPC node versus the remaining nodes. As shown in Fig. 4(b), we observe that for FD002 dataset, the attention for the faulty node (HPC module) increases as the target RUL decreases (i.e. as the engines approach failure), while the attention tends to decrease for the remaining nodes. However, this trend is not observed in FD001 Fig. 4(a). In future, it will be interesting to see if this can be explicitly ensured: while other modules may provide additional information to track the health degradation of a particular module, it may be useful to bias the attention to the module-of-interest.

6 Conclusion and Future Work

We have proposed an approach to incorporate the readily available information about the modularized structure of complex equipment into deep learning models via gated graph neural networks (GNNs). To the best of our knowledge, our work provides a first set of results for leveraging GNNs in the increasingly important area of automated equipment health monitoring. We analyze the heavily-benchmarked aircraft turbofan engine dataset through the lens of structure-aware deep learning, potentially bridging the gap between deep learning and the domain-knowledge aware approaches. We hope that this work inspires future research in leveraging equipment structure to model the behavior of complex systems (such as power plants) with interesting applications like optimization and anomaly detection. While the graph structure is readily available in most practical applications as part of domain knowledge, it may not be optimal in terms of reflecting the dependencies between sensors at a node or between sensors across nodes. It will be interesting to explore if the optimal graph structure can itself be learned starting from the domain knowledge-based initial graph structure.

References

  • [1] G. S. Babu, P. Zhao, and X. Li (2016) Deep convolutional neural network based regression approach for estimation of remaining useful life. In International conference on database systems for advanced applications, pp. 214–228. Cited by: §1, §2, Table 1, §5, Datasets and Pre-processing Details.
  • [2] P. W. Battaglia, J. B. Hamrick, V. Bapst, A. Sanchez-Gonzalez, V. Zambaldi, M. Malinowski, A. Tacchetti, D. Raposo, A. Santoro, R. Faulkner, et al. (2018) Relational inductive biases, deep learning, and graph networks. arXiv preprint arXiv:1806.01261. Cited by: §1.
  • [3] K. Cho, B. Van Merriënboer, C. Gulcehre, D. Bahdanau, F. Bougares, H. Schwenk, and Y. Bengio (2014) Learning phrase representations using rnn encoder-decoder for statistical machine translation. arXiv preprint arXiv:1406.1078. Cited by: §4.
  • [4] J. Goh, S. Adepu, K. N. Junejo, and A. Mathur (2016) A dataset to support research in the design of secure water treatment systems. In International Conference on Critical Information Infrastructures Security, pp. 88–99. Cited by: §4.
  • [5] N. Gugulothu, V. TV, P. Malhotra, L. Vig, P. Agarwal, and G. Shroff (2017) Predicting remaining useful life using time series embeddings based on recurrent neural networks. arXiv preprint arXiv:1709.01073. Cited by: §2.
  • [6] J. B. Hamrick, K. R. Allen, V. Bapst, T. Zhu, K. R. McKee, J. B. Tenenbaum, and P. W. Battaglia (2018) Relational inductive bias for physical construction in humans and machines. arXiv preprint arXiv:1806.01203. Cited by: §1.
  • [7] F. O. Heimes (2008) Recurrent neural networks for remaining useful life estimation. In Prognostics and Health Management, 2008. PHM 2008., pp. 1–6. Cited by: §1, §2.
  • [8] X. Huang, C. Zanni-Merk, and B. Crémilleux (2019) Enhancing deep learning with semantics: an application to manufacturing time series analysis. Procedia Computer Science 159, pp. 437–446. Cited by: §2.
  • [9] Y. LeCun, Y. Bengio, and G. Hinton (2015) Deep learning. nature 521 (7553), pp. 436–444. Cited by: §1.
  • [10] X. Li, Q. Ding, and J. Sun (2018) Remaining useful life estimation in prognostics using deep convolution neural networks. Reliability Engineering & System Safety 172, pp. 1–11. Cited by: §1, §2, Table 1, §5, Datasets and Pre-processing Details.
  • [11] Y. Li, D. Tarlow, M. Brockschmidt, and R. Zemel (2015) Gated graph sequence neural networks. arXiv preprint arXiv:1511.05493. Cited by: §1, §4.
  • [12] P. Malhotra, L. Vig, G. Shroff, and P. Agarwal (2015) Long Short Term Memory Networks for Anomaly Detection in Time Series. In

    ESANN, 23rd European Symposium on Artificial Neural Networks, Computational Intelligence and Machine Learning

    ,
    pp. 89–94. Cited by: §1, §2.
  • [13] A. Sanchez-Gonzalez, N. Heess, J. T. Springenberg, J. Merel, M. Riedmiller, R. Hadsell, and P. Battaglia (2018) Graph networks as learnable physics engines for inference and control. arXiv preprint arXiv:1806.01242. Cited by: §2.
  • [14] A. Saxena, K. Goebel, D. Simon, and N. Eklund (2008) Damage propagation modeling for aircraft engine run-to-failure simulation. In IEEE International Conference on Prognostics and Health Management, 2008. PHM 2008., pp. 1–9. Cited by: Figure 1, Figure 3, §5, §5.
  • [15] F. Scarselli, M. Gori, A. C. Tsoi, M. Hagenbuchner, and G. Monfardini (2008) The graph neural network model. IEEE Transactions on Neural Networks 20 (1), pp. 61–80. Cited by: §1.
  • [16] X. Si, W. Wang, C. Hu, and D. Zhou (2011) Remaining useful life estimation–a review on the statistical data driven approaches. European journal of operational research 213 (1), pp. 1–14. Cited by: §1.
  • [17] T. Wang, R. Liao, J. Ba, and S. Fidler (2018) Nervenet: learning structured policy with graph neural networks. Cited by: §1, §2.
  • [18] C. Zhang, P. Lim, A. K. Qin, and K. C. Tan (2016) Multiobjective deep belief networks ensemble for remaining useful life estimation in prognostics. IEEE transactions on neural networks and learning systems 28 (10), pp. 2306–2318. Cited by: §1, Table 1, §5.
  • [19] W. Zhang, Y. Zhang, L. Xu, J. Zhou, Y. Liu, M. Gu, X. Liu, and S. Yang (2019) Modeling iot equipment with graph neural networks. IEEE Access 7, pp. 32754–32764. Cited by: §2.
  • [20] S. Zheng, K. Ristovski, A. Farahat, and C. Gupta (2017) Long short-term memory network for remaining useful life estimation. In Prognostics and Health Management (ICPHM), 2017 IEEE International Conference on, pp. 88–95. Cited by: Table 1, §5, Datasets and Pre-processing Details.

Datasets and Pre-processing Details

The datasets contain time series of readings for 24 sensors (21 sensors and 3 operating condition variables), such that each cycle in the life of an engine provides a 24-dimensional vector. The sensor readings in the training set are available from beginning of usage of the engine till the end of life, while those in the test split are clipped at a random time prior to the failure such that the instances are operational at the last available cycle, and the goal is to estimate the RUL for these test instances. Refer Table 3 for details of the datasets.

Dataset FD001 FD002 FD003 FD004
Instances (training set) 80 208 80 199
Instances (validation set) 20 52 20 50
Instances (test set) 100 259 100 248
Operating conditions 1 6 1 6
Fault Modes 1 1 2 2
Table 3: Basic statistics of the four datasets used.

As commonly used in RUL estimation approaches [20, 1, 10], we also consider an upper bound on the possible values of target RUL during training as, in practice, it is not possible to predict too far ahead in future. So if , we clip the value of to . The targets are then normalized to , such that the targets in training are in the range 0-1. We use min-max normalization technique to normalize input time series sensor wise using the minimum and maximum value of each sensor (in the range of -1 to 1) from the training set. The time series for each engine instance is then divided into windows of length with window-shift of 5, refer Table 4

for details of the number of resulting time series after windowing. We use suitable pre-padding with mean value of sensor readings to ensure same length for each time series for both GRU-MR and GGNN.

Dataset FD001 FD002 FD003 FD004
Training 1,875 4,688 2,129 5,383
Validation 411 1,287 533 1,451
Test 100 259 100 248
Table 4: Number of time series windows.
