1 Introduction

Topological data analysis (TDA) seeks to understand and characterize topological features of data. In particular, persistent homology provides a framework for analyzing the topological connectivity of a dataset at different scales. Persistent homology has drawn interest in applied mathematics (Edelsbrunner et al. 2002, Scopiagno & Zorin 2004, Zomorodian 2005, Ghrist 2008, Carlsson 2009)

, computer science and machine learning

(Adams et al. 2017), statistics (Worsley 1996, Adler et al. 2010, Chazal et al. 2014, Fasy et al. 2014, Turner, Mukherjee & Boyer 2014, Bubenik 2015, Chen et al. 2015), and the applied sciences (Sousbie et al. 2011, Van de Weygaert et al. 2011, Cisewski et al. 2014, Singh et al. 2014, Bendich et al. 2016). The interest in persistent homology is due, at least in part, to its ability to extract summaries of data that are otherwise missed by traditional data analysis methods. Persistent homology gives a multi-scaled way to view data. Different features (in particular, the homology generators) are tracked across the scales, resulting in an object known as the persistence diagram

, which is a multi-set of birth-death pairs (indicating the birth and death of the homology generators). While persistence diagrams contain potentially useful information about a dataset, they are not easy objects to use directly in machine learning and statistical settings, so work has been carried out to transform persistence diagrams into one- or two-dimensional functional summaries and vectorized representations. In this article, we review functional summaries of persistence diagrams, develop a unified framework for the functional summaries along with proposing a generalization of a popular functional summary (persistence landscape functions), discuss various ways the functional summaries can be used, and compare the results on simulated and real datasets. Below, we introduce two examples that will be considered in subsequent sections.

Example: Prostate Cancer Histology.
(a) Gleason Grade 3
(b) Gleason Grade 5
Figure 1: Sample ROIs from regions graded Gleason Grade (left) and Gleason Grade (right). The dark purple are nuclei, and can easily be segmented using software such as CellProfiler(Lamprecht et al. 2007). In the lower-Gleason grades, the nuclei form round circles surrounding glands. As the cancer progresses, these circles become irregular in shape and eventually break open, losing all structure.

Prostate cancer (PCa) is the second most common cancer in men worldwide with an estimated 1.1 million cases diagnosed in 2012

(Center et al. 2012, Ferlay et al. 2015). Prostate cancer diagnosis involves histological classification of hematoxylin and eosin (H&E) prepared slides of a prostate biopsy, such as the region of interest (ROI) from a slide scan shown in Fig. 1

. Slides are classified into five grades based on glandular architectural features in the Gleason Grading System; a primary and a secondary grade are assigned, with higher grades corresponding to increasingly poor prognostic outcomes

(Humphrey 2004). Initially developed in the 1960s, the Gleason grading system and its recently introduced refinement, the Grade Groups (Epstein et al. 2016), are the most powerful predictors of prognostic outcome in prostate cancer. However, the system suffers from high intra- and inter-observer variability due to the subjective nature of the grading scheme (Engers 2007, Truesdale et al. 2011, Abdollahi et al. 2012, Goodman et al. 2012, Helpap et al. 2012, Truong et al. 2013, Evans et al. 2016). The Gleason grading system and Grade Groups both rely exclusively on architectural patterns of carcinoma cells for histological classification; these architectural patterns provide an opportunity to use topological data analysis. Through a simulation study (Section 5.1), we present a technique for classification of histology slides based on functional summaries of persistence diagrams so that prevalent patterns can be revealed in order to assist a pathologist or oncologist in finding glandular architectural patterns that can be used to assign a Gleason Score or Grade Group.

Example: Fibrin Network Data.

Complicated spatial structures are common in biological data (e.g., fibrin clots, fibroblasts), but are difficult to quantitatively analyze without losing important information. In particular, the coagulation cascade culminates in the web-like structure of a fibrin network. Fig. 2 displays a sample of a human fibrin network collected using a scanning electron microscope; the image are from Pretorius et al. (2009). Features of these structures have numerous implications for vascular diseases like hemophilia and thrombosis (Campbell et al. 2009, Pretorius et al. 2009).

Figure 2: Sample of human fibrin network from Figure 1a of Pretorius et al. (2009), where the white scale bar is 1 m.

One of the primary goals of Pretorius et al. (2009) was to compare platelet and fibrin networks of humans and eight other animal species, and carry out an inference procedure to determine if the differences are statistically significant. They focused their comparisons on the thickness of the fibrin fibers and grouped them into thin, intermediate, and thick fibers, requiring measurements of individual fibers within the collection of fibrin networks. To measure the fibers, they randomly selected 100 fibers within the sampled and imaged fibrin networks, and then measured the diameters of the fibers. Next, they assigned the 100 fibers from each fibrin network into one of the three clusters based on the measured diameter, and then did comparisons between the fiber classes of the different species. While they focused on fiber thickness, we compare the topological structure of the fibrin networks using functional summaries of persistence diagrams. In Section 5.2.1, we develop a data-generating model that mimics some of the characteristics of these spatially complex data, including allowing for varying thicknesses of the strands, which we call the Pickup Sticks Simulator (STIX). Before carrying out the hypothesis tests on the real fibrin data, we run a simulation study on the STIX data where we know the ground truth and can verify the methodology.

Additional Applications.

Though we focus on classification and hypothesis tests for prostate cancer histology slides and fibrin networks, the methods we propose can have analogous use in other areas of science. For example, the complicated spatial structure of fibrin networks is similar to the distribution of matter in the Universe, often referred to as the Cosmic Web (Worsley 1996, Sousbie et al. 2011, Van de Weygaert et al. 2011, Wu et al. 2018), and to brain artery trees (Bendich et al. 2016, Biscio & Møller 2016).

Main Contributions.

First, a review is provided of the functional summaries from the literature. Then, we propose a unified framework for the functional summaries and generalize the definition of one popular type of persistence functional summary, the persistence landscape function, to a broader class of functions that allows for different kernels and bandwidths providing additional flexibility for the practitioner. Theoretical properties of the persistence functional summaries are established, putting these functional summaries on a solid foundation for various types of statistical inference and methodology. Then, several of the popular functional summaries, along with the proposed generalized landscape function, are used in two different applications in order to compare their performance. The first is using simulated prostate cancer histology data, where the data are classified according to simulated architectural morphology. The second application carries out two-sample hypothesis tests comparing human and monkey fibrin images, which is particularly challenging because the data have a complicated, web-like, spatial structure. In order to evaluate the performance in a more controlled setting, we develop a new data-generating mechanism, STIX. STIX generates images that have similar features to the fibrin data, but are also interesting objects of study on their own.

2 Functional Summaries of Persistence Diagrams

Before introducing functional summaries of persistence diagrams, we provide an introduction to persistence diagrams themselves, along with some examples of the types of inference one may want to do with a set, or sets, of persistence diagrams.

2.1 Persistence Diagrams

In TDA, persistence diagrams (Cohen-Steiner et al. 2007, Edelsbrunner & Morozov 2012, Wasserman 2016) provide a useful way to summarize the topological structure of a point-cloud of data or a function111Actually, as long as we have a filtration, we can define a persistence diagram. . In this introduction, we focus on the function-based filtrations for persistence diagrams, but other types of filtrations can be used. For more details on filtrations over point clouds, we suggest Zhu (2013) or Ghrist (2014). Given a function , where is a topological space, we define the upper222Some literature considers the lower level set

. Both definitions are valid and here we use upper level sets because they yield a very straight forward definition when we consider the image data or certain functions estimated from a point cloud, such as kernel density estimates

(Wasserman 2006). -level set of as

For any two level thresholds , the corresponding level sets satisfy . Thus, the collection of level sets forms a filtration with the level as the index set.

For each level set , its topological features are captured through the generators of its homology groups. Informally, the -th order homology groups (-th order topological feature) capture the connected components, the -st order homology groups capture regions forming a loop structure, and -nd order homology groups capture regions forming a void structure. For the formal definition of homology groups, we refer readers to Edelsbrunner & Harer (2008) and Edelsbrunner & Morozov (2012). When we decrease the level , new generators for the homology groups may be created (e.g., the formation of new components), existing generators may merge together (e.g., two connected components joining together), and existing generators may be eliminated (e.g., a loop getting filled in). The level at which a generator is created is called its birth time and the level at which a generator is eliminated, or merges with another generator that has an earlier birth time, is called its death time. Thus, for every generator in , there are three characteristics: homology order, birth time, and death time.

The persistence diagram is the collection of all these triplets of the filtration formed by the given function . Thus, if a function’s filtration has generators, then its persistence diagram is

where and are the homology order, birth time, and death time of the -th generator, respectively, and the norm denotes the number of off-diagonal elements in the persistence diagram .

2.1.1 Example: constructing a persistence diagram from a dataset

There are many ways of constructing a persistence diagram from a dataset. If the data are images, functions, or fields evaluated on a grid, then the construction of the corresponding persistence diagrams is straight forward – we just consider the pixels, or grid points, whose value is above a given level and vary such level to construct a filtration.

When the data are a collection of points, the construction of a persistence diagram depends on how the function that generates the underlying filtration is constructed. Here we illustrate the construction using an estimator of the underlying density function. We use a kernel density estimate (KDE) to estimate the underlying probability density function that generates this data and construct the filtration using the (upper) level set of the KDE

(Fasy et al. 2014, Wasserman 2016). This procedure is summarized in Fig. 3, where we obtain a persistence diagram for the estimated density function of the given 2D point clouds. Formally, let be the observed values for a single dataset. The KDE is where is a smooth function called the kernel function (e.g. a Gaussian kernel) and is a quantity called the smoothing bandwidth that controls the amount of smoothing (Wasserman 2006). Using and its level sets, we then construct the persistence diagram which contains topological information about the underlying density function.

(a) Dataset
(b) KDE
(c) Level Set
(d) PD
Figure 3: The construction of a persistence diagram from the single dataset (points) displayed in (a). We construct the persistence diagram (PD, d) using level sets (e.g., c) of its kernel density estimator (b).

2.2 Modeling multiple persistence diagrams

In this paper, we focus on the case where multiple persistence diagrams, are observed and we want to perform statistical analysis (e.g., estimating population quantities, classification, hypothesis testing) over these diagrams. In addition to the prostate cancer histology data and fibrin network data mentioned previously, there are many other situations where this framework is useful, such as when analyzing brain artery trees (Bendich et al. 2016, Biscio & Møller 2016), investigating the large-scale structure of the Universe using cosmological simulations (Wu et al. 2018), or studying shape data (Turner, Mukherjee & Boyer 2014, Crawford et al. 2016). A common assumption in these examples is that the persistence diagrams, , are generated from the same population. Thus, we can model this procedure as the case where there exists a distribution of persistence diagrams (Mileyko et al. 2011) such that are independent and identically distributed from .

Unfortunately, persistence diagrams are not easy objects to work with. Even if a sample of persistence diagrams are from the same distribution, each of them may have different numbers of topological features, and those features have a complicated covariance. This makes it difficult to carry out common algebraic operations such as addition, division, and multiplication, hence computing statistical summaries such as means and medians is challenging (Turner 2013, Turner, Mileyko, Mukherjee & Harer 2014). In the multiple diagram setting, a simple but elegant approach is to summarize each diagram by a function and then analyze the diagrams by comparing their corresponding functions. Because functions are well-defined objects, and statistical analysis over functions are well-studied, analyzing these functional summaries is a much easier task than directly studying the diagrams.

The proposed functional summaries use either a univariate or a bivariate function function to summarize the persistence diagram, but, in general, functions with more variables can be used. A brief review of the existing functional summaries of persistence diagrams is provided next, before giving more details on the proposed functional summaries. Let be a collection of functions. Then, a functional summary of a persistence diagram, , is a map between and . i.e.,

Using a functional summary , the random diagrams become random functions . Moreover, since these random diagrams are from the same distribution, the corresponding functional summaries also come from the same distribution (of functions), :

(1)

The above characterizes the statistical model for using functional summaries to analyze persistence diagrams. Except where noted, we focus on topological features of the same homological dimension.

2.3 Review: Functional Summaries

We review several functional summaries that have been proposed in existing literature.

2.3.1 Persistence Landscape

The persistence landscape function is a popular univariate functional summary of a persistence diagram (Chazal et al. 2014, Bubenik 2015). To produce a persistence landscape function, or simply referred to as a landscape function, the persistence diagram is rotated clockwise 45 degrees, and then isosceles right triangles are drawn from each feature of a particular homology dimension (where the right angle vertex is the homology feature). From the collection of isosceles right triangles, individual functions are traced out where the first landscape function is the point-wise maximum of all the triangles drawn. More specifically, a persistence landscape is a collection of univariate functional summaries such that for each ,

(2)

where , is a function selecting the -th largest value, and the norm denotes the number of off-diagonal elements in the persistence diagram . An illustration of this is displayed in Fig. 4.

Figure 4: Illustration of a persistence landscape function. The left plot is a persistence diagram and the right plot is its corresponding persistence landscape function; each color and line style represents a different with as the solid black line, as the dashed red line, etc.

2.3.2 Persistence Silhouette

Persistence silhouette functions were introduced in Chazal et al. (2014) as a modification of the persistence landscape function. The persistence silhouette function maps the persistence diagram to a function , as opposed to with landscape functions, by combining all the layers of the landscapes functions into a single, average function. The persistence silhouette is a function such that

where is a weight function based on the persistence of the features. For example, the weight function could be used, where is a tuning parameter that has to be selected. Larger values of put more weight on the features with longer lifetimes, and smaller values of emphasize the features with shorter lifetimes.

2.3.3 Accumulative Persistence Function

The accumulative persistence function (APF), introduced in Biscio & Møller (2016), is a univariate functional summaries such that

The APF behaves like a cumulative distribution function in that it is a non-decreasing function.

2.3.4 Persistence Intensity and Image

The persistence intensity is a bivariate functional summary (Chen et al. 2015), where is a map to a bivariate function defined as

(3)

where is a weight function and is a kernel function with smoothing parameter . The persistence intensity replaces points on the persistence diagrams by a smooth localized function that is determined by the kernel function (the amount of smoothing is determined by the parameter ) and apply a weighted sum over all points to form an intensity function such that, for example, points far away from the diagonal (features that are more persistent) are given higher weights. This leads to a bivariate function that summarizes a persistence diagram.

Note that if we evaluate the bivariate functional summary on a grid and view it as an image, we obtain the persistence image introduced in Adams et al. (2017). The persistence image framework of Adams et al. (2017) includes vectorizing the image making it suitable for many machine learning and statistical methods.333Adams et al. (2017) also presented conditions under which persistence images are stable with respect to changes in the corresponding persistence diagrams.

Remark 1

When we can have an extra scale parameter for each persistence diagram, we can construct a special bivariate functional summary called the persistence flamelet. The persistence flamelet (Padellini & Brutti 2017) is a bivariate functional summary that combines the persistence landscape and the scale parameter. For instance, the persistence diagram may be constructed from a KDE of a point could making the smoothing bandwidth in the KDE the scale parameter. In this case, the persistence landscape also depends on the scale parameter . The persistence flamelet is a bivariate function of such that for each fixed , the persistence flamelet is the persistence landscape.

Remark 2

In addition to functional summaries of persistence diagrams, one might want vector-valued summaries for input to machine learning algorithms, for instance. In Adcock et al. (2016), the authors define an algebra of functions on the space of persistence bar codes. Furthermore, they identify the generators of this algebra, and show the utility of these functions through applications of classification of data using machine learning. In addition, using the maximum persistence alone has proven successful in certain settings (Khasawneh & Munch 2014, Perea & Harer 2015).

3 Generalized Landscape Functions

As noted previously, landscape functions result from a persistence diagram that is rotated, and then each feature on the diagram produces an isosceles right triangle, . However, one need not be restricted to these special triangles when computing one-dimensional functional summaries of persistence diagrams. We propose an expanded class of persistence landscape functions, called generalized persistence landscape functions. With these generalized landscapes, one can substitute different kernels (e.g. tricube, Epanechnikov) and different bandwidths in order to better adapt to the details in the persistence diagram. (See Wasserman (2006) for a general discussion about kernel functions and bandwidth selection.) The triangle kernel used in the original landscape function definition can also be used, except the width of the base of the triangle can be adjusted, which could be analogously thought of as adjusting the angles of the triangle.

More specifically, the change is in the form of from Equation (2), where the generalized landscapes use

where is the kernel function with as the bandwidth, is the rotated feature corresponding to from the persistence diagram, with and , and the ensures that goes through . For example, the Epanechnikov kernel would have for . Using the new definitions of , the generalized landscapes are defined in the same manner as landscapes:

(4)

Illustrations of several generalized landscape functions are displayed in Fig. 5 using the triangle kernel. As with general nonparametric smoothing methods, a smaller bandwidth results in a rougher function and a larger bandwidth results in a smoother function. In Sections 5.1 and 5.2, we consider both generalized landscapes and original landscapes in a classification problem and in two sample hypothesis tests. Although the generalized landscapes and the landscape functions ultimately contain the same information, a benefit of using the generalized landscapes is that more features of the persistence diagram can be isolated to fewer function layers.

Figure 5: Generalized persistence landscape functions. The left plot is the persistence diagram used to produce the functional summaries in the right plot. In the right plot, the black circles are the rotated persistence diagram features, the solid black line is the first generalized landscape using the triangle kernel with a bandwidth (half the triangle base) of , the second and third generalized landscapes are plotted in red dashes and green dots, respectively. As a comparison, the first landscape function is plotted in gray as lines and dots.

4 Methodology

All functional summaries defined in the previous section map a persistence diagram to a function. The problem of analyzing random persistence diagrams becomes the problem of analyzing random functions, which is a topic that has been studied for decades in statistics (Van der Vaart 2000). Next, we describe some analysis methods that can be done using the statistical model characterized in (1).

4.1 Population quantities

Using the statistical model of (1), we can define various population quantities associated to the functional summaries such as the mean functional summary (Chazal et al. 2014, Chen et al. 2015, Biscio & Møller 2016). When averaging functional summaries of diagrams, we obtain a sample mean functional summary. This quantity can be used as an estimator of the population mean functional summary. In more detail, the population mean functional summary is a function

where the expectation is with respect to the distribution . The sample estimator is then the pointwise estimator

and the convergence of toward can be studied using notions of convergence of functions (Chazal et al. 2014, Chen et al. 2015).

Let be the set of all possible functions formed by a given functional summary, and let be a compact set such that we are interested in the population mean functional summary within . To simplify the problem, we define for all for every . Throughout the paper, we assume that the functional summary is uniformly bounded by a constant . Namely,

(5)

The following is a simple convergence theorem of the estimator , which shows that as long as the functional summary is continuous, the sample mean function summary uniformly converges to almost surely, as expressed in the following proposition.

Proposition 1 (Pointwise Convergence)

Assume Equation (5) holds. If  is equicontinuous, then

As a result, if there exists a constant such that any is -Lipschitz, then

The proof is presented in Appendix B. Persistence intensity, persistence landscapes and generalized landscapes, and persistence scoring all satisfy the condition in Proposition 1 as long as the number of homological features and the lifetime of the features are uniformly bounded. Thus, averaging these functional summaries yields a consistent estimate of the corresponding population mean functional summary.

The difference

is tightly related to a normal distribution. In what follows, we show that it converges to a normal distribution in various ways. Let

such that for each be the mapping from the persistence diagram to a functional summary as displayed in Equation (1). Let be a probability measure over  and define be the norm for functions and be the -covering number of .

Proposition 2

Let and . Assume Equation (5) holds, then

Moreover, if

(6)

where is the upper bound of the functional summary and the supremum is taken over all finitely discrete probability measures on the space of persistence diagrams 444 A finitely discrete probability measure puts probability mass only finitely many points in ., then converges in distribution to , where is a Gaussian process over with a covariance function

for . Futhermore, if there exists a constant such that any is -Lipschitz, then the above three convergences hold.

The proof is presented in Appendix B. Proposition 2 presents the asymptotic normality of the sample mean functional summary. The assumptions are from the Donsker theorem; see, e.g., page 18 of Kosorok (2007). The convergence toward a Gaussian process further implies the convergence of the supremum, i.e.,

by the continuous mapping theorem; see page 16 of Kosorok (2007) for more detailed discussion.

The assumption (6) is quite mild. If the functional summary is -Lipschitz, then Equation (6) holds and thus converges to a Gaussian process. A good news is that many functional summaries, such as the persistence landscapes, persistence silhouette, persistence image, and persistence intensity are all -Lipschitz functional summaries under a very mild assumption (the number of features in the persistence diagrams is finite almost surely). For the generalized landscape, as long as the kernel function is Lipschitz (which is true for most of the common kernel functions), the functional summary is also Lipschitz.

4.2 Confidence Bands

Confidence bands provide a way to assess and visualize the uncertainty in the sample mean functional summary, which can be constructed using a bootstrapping procedure (Chazal et al. 2014). Specifically, given a confidence level , the bootstrap can be employed to find a fixed bandwidth upper envelope function and a lower envelope function such that

for some regions . See Proposition 3 below for more details.

The following are the details of the construction of a confidence band. Note that we assume the functional summary is a univariate function for simplicity; one can easily generalize the following for multivariate functions.

  1. The initial estimate. First, compute the sample mean functional summary, for , a given interval.

  2. The bootstrap procedure. Sample diagrams with replacement and compute the corresponding functional summaries and the sample mean functional summary, denoted as . Namely, generate by sampling randomly (with replacement) from in a way such that each diagram has an equal probability of being selected. Then compute the the corresponding functional summaries , and calculate the sample mean functional summary, .

  3. Replication. Repeat the bootstrap procedure times, leading to bootstrap realizations of the sample mean functional summary, denoted as

  4. Width of band. For a given significance level , choose

    where is the quantile of the -distance between the bootstrap realizations and the initial estimate.

  5. Output. The upper and lower bound of the confidence band is

The following proposition shows that the confidence band is consistent under mild assumptions.

Proposition 3 (Functional Bands)

If the assumptions in Proposition 2, including Equation (6), hold, then

The proof is presented in Appendix B. Proposition 3 shows that the confidence band is asymptotically valid. Note that if a slightly stronger assumption is made,

(7)

for some constants , then we can replace the in proposition 3 by ; see the derivation of Chazal et al. (2014).

The above procedure provides a fixed bandwidth confidence band. A variable-bandwidth confidence band can also be constructed using a simple modification in Step 4 and 5. First, compute a variance estimator of the functional summaries

(8)

Then, in Step 4, choose

And, in Step 5, we construct the band via

Using a similar derivation as Chazal et al. (2014), one can prove that such a confidence band is also valid

Note that both equations (6) and (7) hold if the functional summaries are -Lipschitz. Therefore, we have the following result for the generalized landscapes.

Corollary 1

Assume that is compact and the number of topological features of a persistence diagram is bounded by a constant almost surely. If the functional summaries are constructed by a generalized persistence landscape with a Lipschitz kernel function and a fixed , then the conclusions in proposition 1, 2, and 3 are true.

Corollary 1 is a direct result from the three propositions when the kernel function is Lipschitz. Most common kernel functions such as the triangle kernel and the Gaussian kernel satisfy this condition. Thus, this corollary implies that the generalized landscape function is a stable functional summary for data analysis.

4.3 Prediction Bands

A sample mean functional summary can be used to predict the outcome of a future persistence functional summary. Let be a metric for functional summaries. For every functional summary, say , we first compute the residual, and then pick to be the -quantile of . Then a -prediction set is

(9)

The following Proposition 4 proves that the prediction set in Equation (9) is a valid prediction set in our setting.

Proposition 4

Let be a metric for functional summaries such that

Moreover, assume that the function

has a finite derivative bounded away from at an open neighborhood containing , where solves . Let be as defined in Equation (9). Then

The proof is presented in Appendix B. Note that the assumption is very mild requiring that our estimator is consistent under the metric . The second assumption, the continuity of  at

, is also very weak; if the random variable

has a density function that takes non-zero value around , then this assumption holds. Just as other propositions, Proposition 4 also applies to the generalized landscape when the kernel function is Lipschitz.

There are many possible metrics , and common choices are

(10)

where is a weight function and is a positive number. When , becomes the -metric for functions and we often write for simplicity. and are popular choice in data analysis. However, the prediction set from or (or any other for ) is hard to visualize. The metric leads to a prediction set that is easy to visualize, but can be too sensitive to small perturbations.

To obtain a stable metric with a simple visualization property, we consider the metric with

, the estimated standard deviation of

from Equation (8). This leads to a variable-width prediction band. The prediction band can be constructed by first computing for each . Given a prediction level , let

Then the -prediction band is

(11)

where

(12)

Thus, a simple way to visualize the prediction set is to plot a band governed by the lower envelope and the upper envelope .

Remark 3 (Conformal prediction band)

The above prediction bands have coverage asymptotically. If we want to obtain a prediction band with exact coverage, we may use the conformal prediction approach (Vovk et al. 2005, Shafer & Vovk 2008, Lei et al. 2015). Lei et al. (2015) proposed two methods of constructing a prediction band for functional data combining the data splitting and conformal prediction, which can be used to construct an exact prediction band for functional summaries.

4.4 Two-Sample Test

Because functional summaries can be averaged, two-sample tests of two groups of persistence diagrams can be carried out (Chen et al. 2015, Biscio & Møller 2016). This scenario is common in biomedical applications where one set of diagrams comes from a control group and another set from a treatment group.

There are many ways to carryout two-sample tests, but here we consider a permutation test approach. Assume we observe two sets of diagrams

then the goal is to test the null hypothesis

(13)

Namely, we want to see if there is evidence suggesting the two sets of diagrams were sampled from different populations.

Let be the functional summaries of the corresponding persistence diagrams for set , and let

denote the sample mean functional summary of each group. To perform a permutation test, we first choose a metric of functions, such as one from Equation (10), and then define

as the test statistic. To compute the permutation p-value, the functional summaries from both samples are combined and then randomly split into two groups, one group with

functions and the other with functions. New sample mean functional summaries of both groups are computed along with the test statistic using the new averages. Assume the above procedure is repeated times, then realizations of the test statistic are obtained. The p-value is the proportion of that are greater than or equal to the original test statistic , i.e.,

The idea of permutation test is that when is true, permuting the diagrams or their corresponding functions does not change the distribution significantly. A powerful feature of the permutation test is that it is test; namely, the significance level can be controlled at any level exactly (Wasserman 2006).

4.5 Classification

Using the statistical model (1), the problem of classification of persistence diagrams can be studied (Biscio & Møller 2016). We consider the binary classification for simplicity, which can be generalized to multiple classes. The problem of classification is as follows. Suppose a collection of diagrams with labels are observed as

where each denotes the class label of

-th diagram. Statistical classification addresses how to predict the class label of a new persistence diagram,

. Using functional summaries, the goal is to predict the class label for . This can be solved by techniques from classifying functional data (Wang et al. 2016).

Here, we provide a simple approach based on the

-nearest neighbor (kNN) classifier. First a metric

is chosen, possibly from Equation (10), and then a new functional summary , is used to compute the distances . Let denotes the -th closest functional summary to and be its corresponding class label. The kNN classifier is then

Namely, if more than half of ’s neighborhoods have a class label , the label of is ; otherwise the label of is . In practice, one can choose  by minimizing the classification errors using cross-validation.

4.6 Clustering and Visualization

There are two major approaches for clustering diagrams based on functional summaries. The first approach is to directly cluster functional summaries using clustering techniques from functional data analysis. For instance, one can use functional k-means clustering

(Wang et al. 2016) or mode clustering (Ciollaro et al. 2014) to separate functional summaries into clusters and partition diagrams accordingly.

The other approach is based on a pairwise distance matrix. A metric is chosen, possibly from Equation (10

), and then a pairwise distance matrix of functional summaries is computed. Based on the distance matrix, clustering can be carried out using ideas similar to spectral clustering or hierarchical clustering to partition the functions into several clusters

(Von Luxburg 2007, Jacques & Preda 2014).

An extra advantage of the second approach is that it automatically provides a way to visualize the distance/similarity between diagrams. Using the distance matrix, the classical multidimensional scaling (or other approaches) can be performed to see how each diagram is related to one another (Chen et al. 2015, Biscio & Møller 2016).

Remark 4 (Connection to Functional Data Analysis)

In all the above analyses, a number of statistical approaches are available from functional data analysis (Ferraty & Vieu 2006, Ramsay 2006, Wang et al. 2016). This is because the functional summaries of (1) map the persistence diagrams into functions that provide a link between the two fields. Because of this mapping, one can apply the tools from functional data analysis to analyze the persistence diagrams (Biscio & Møller 2016) and the current research along this direction has yielded many fruitful results (Chazal et al. 2014, Adams et al. 2017, Chen et al. 2015, Biscio & Møller 2016).

5 Experimental Evaluation

Next we consider the two applications introduced in Section 1: the Gleason data and the fibrin network data. These datasets are considered because they highlight two different types of persistence diagrams. The Gleason data has an underlying loop structure with topological randomness due to sampling and to variability around the shape of the loop (indicating a spectrum from benign to cancerous) with a persistence diagram containing fewer features. While the spatially complex fibrin data has a complicated persistence diagram with many features. Classification and two-sample tests are carried out using functional summaries of the persistence diagrams to investigate their effectiveness.

5.1 Simulated Gleason Data

Preliminary analysis has shown that clustering regions of interest (ROIs) correlates with the Gleason grades for purely-graded regions (Lawson et al. 2017, 2018). In an effort to both better understand the progression of cancer and to curate a larger data set with known / controlled grading, and because obtaining digital slides is both expensive and time-consuming, we are developing a mock slide synthesizer (Fasy et al. 2018). The data we study in this paper are obtained from the gland synthesizer used in the mock slide synthesizer, where a benign gland would be one that is round, with a diameter about -m (similar to glands found in Grade ROIs). The unhealthy

state is one where the gland and cribriform are indistinguishable, leaving what looks like a sheet of cells (i.e., the nuclei appear to be uniformly distributed). With a tuning parameter, we create cells that range from

benign (Type A) to less and less healthy (Types B and C, respectively) to unhealthy (Type D); see Fig. 6. Note that we refer to these as Types A–D, rather than using the usual Gleason grading scheme of, for example, grades 1–5, to emphasize that our data is computationally generated and the types have not been verified by a pathologist to correspond to particular Gleason grades.
