Recently, researchers presented deep neural network models for text-to-speech (TTS) synthesis whose results are comparable to the previous approaches such as concatenative models. Among the neural TTS models, Tacotron (Wang et al., 2017) has emerged as an end-to-end TTS model that can be trained from scratch on <text, audio> pairs. The generative model of Tacotron is a sequence-to-sequence (seq-to-seq) model (Sutskever et al., 2014) with an attention mechanism (Bahdanau et al., 2014). The model has many advantages compared to other state-of-the-art neural TTS models, like WaveNet (van den Oord et al., 2016), Deep Voice (Arık et al., 2017), as well as Taigman et al. (2017). No need for separately pre-trained subsections, Tacotron produced natural speech samples which achieved competitive mean opinion score (MOS).
In this paper, we report our experiment on a modified version of the Tacotron architecture to generate emotional speech. We also found that Tacotron had a difficulty to generate a middle part of speech. We resolved it by applying modifications that especially aim facilitating information flow in Tacotron.
2 Emotional speech synthesizer
As a seq-to-seq model, Tacotron contains three parts: 1) an encoder to extract features from the input text, 2) an attention-based decoder to generate Mel spectrogram frames from the attended portion of the input text, and 3) a post-processor to synthesize the waveform of speech. We present the emotional Tacotron to generate speech that carries special specifications such as emotion or personality, so that the model can have variation in the synthesized speech. We implemented emotional Tacotron by injecting a learned emotion embedding as follows:
where , , and are the input, the attention applied context vector, the hidden state of the attention RNN and the hidden state of the decoder RNN at time-step , respectively. Figure 1 depicts architecture of the emotional Tacotron.
2.1 Attention-based emotional decoder
A stack of RNNs is used for the decoder together with a content-based tanh attention mechanism Taigman et al. (2017) in the original Tacotron. The decoder predicts r-frames of Mel spectrogram at every time-step employing a decoder pre-net, one layer attention RNN, as well as two layer residual connection decoder RNN. For every minibatch, the decoder starts with a “GO” frame which is all zero; later, for every time-step, the previous time frame is fed as the decoder pre-net’s input.
Having inspired by Tjandra et al. (2017), we injected the projection of the one-hot emotion label vector to attention RNN by concatenating with the pre-net output and adding one more layer to project it to match the size of the attention RNN input. Same injection is performed at the first layer of the decoder RNN to add the emotional features to the generated spectrogram.
In the original Tacotron, the decoder is trained such that to predict one output at a time by feeding the ground truth information of the previous time-step. However, the ground truth information is not available in the test phase. Hence, the generated output contains some noise for every time-step. As a result, the errors are quickly accumulated and mess the generated wave especially for long wave outputs. The so-called exposure bias problem causes disconnectivity and losing the attention alignment, which shows the messy pattern between decoder time-steps and encoder states. As an example, Figure 2-(a) shows the attention alignment of the original Tacotron, in which and axes belong to the decoder time-step and the encoder time-step, respectively. As can be seen from the figure, the attention works well for the initial time-steps but the model loses the attention at around . We addressed the exposure bias problem by the tricks explained as follows.
Monotonic attention (MA).
Text to speech conversion is basically a monotonic transform. One possible way of handling the non-monotonicity shown in Figure 2-(a) is forcing the attention to follow a monotonic pattern. Recently, Raffel et al. (2017) have presented a differentiable method for this purpose. We have implemented this idea in the emotional Tacotron. Figure 2-(b) shows the attention alignment in the monotonic-attention-added Tacotron, which depicts a clean pattern compared to Figure 2-(a). Furthermore, having listened to the generated outputs, we have figured out that there is correlation between the quality of the generated output and the cleanness and sharpness of the attention alignment.
Semi-teacher-forced Training (STFT).
In the conventional teacher-forced training of seq-to-seq model, the decoder’s input at each time-step is the ground truth output (spectrogram frame in our case) at the previous time-step . Feeding ideal input to the decoder in training phase provokes exposure bias problem because noisy generated output from the previous time-step is used in test phase. Having inspired from Taigman et al. (2017), we decided to add noise in the training phase by feeding the average of and to the decoder as .
We trained our emotional Tacotron on the Korean dataset from Acriil that contains <text, audio, emotion label> pairs. A female actor read news articles in six different emotions: neutral, angry, fear, happy, sad, and surprise. The scripts contain same text except for happy, and we observed that different script does not affect the generated happy speech.
We used sequences of less than 200 characters and wav files of shorter than 8.7s after silence trimming. We trimmed silence from the wav files using the WebRTC Voice Activity Detector (Google, )
because we found that silence trimming is crucial for training. After this process, the dataset contains 21 hours of speech. We did not use masking for the padded zeros at the end of sentences to let the model to train the ending silence. We borrowed the details of the original Tacotron for the common part of our model. In addition, we projected the six categories of the one-hot emotion vector using a fully connected layer with 64 hidden units and 0.5 dropout ratio.
4 Discussion on prediction of attention alignment
When we train the original Tacotron on a non-emotional dataset with same pre-processing, the model had a problem to generate speech. We used a Korean dataset from ETRI, which contains 17 hours of drama scripts recorded by a female actor with natural tone. With the model trained on this dataset, the attention alignment showed irregularities in the middle part. Based on our conjecture that there is correlation between sharpness of attention alignment and the quality of the generated speech, we decided to improve prediction of attention alignment and paid attention to the flow of information in the Tacotron. There are two sources of information for predicting attention alignment. One comes from the hidden state of attention RNN and the other comes from the text encodings from the encoder. Based on these two sources, we propose the following ideas for improving the alignments.
4.1 Utilization of Context Vector
The attention part in the original Tacotron model often attends to similar part of a text input for several decoder time-steps because pronunciation of one character usually requires more than one frame of spectrogram. Even when the model should change the attention weight, the next part to be attended will be an adjacent part of the currently attended text. Therefore, when deciding attention weights, the model can benefit from having information of previously attended text , which is a weighted sum of text encodings. However, the original Tacotron does not utilize that information; attention RNN takes only spectrogram of the previous time-step, which hardly contain the information of . Based on this idea, we concatenated to the attention RNN’s input . Now, the attention RNN takes one more input as follows:
4.2 Residual Connections in CBHG
For the second idea to improve attention prediction, we change the way of encoding a text input, which is also a source of information for deciding attention alignment. The encoding is generated by the CBHG module (Convolution Bank + Highway + bi-GRU) (Lee et al., 2016) shown in Figure 1. The CBHG contains convolutional filter banks, in which each filter explicitly extracts local and contextual information. At the last stage of the CBHG, there is a bi-directional RNN to capture long-term dependency in the text input. Long-term dependency is accumulated in the hidden state of RNN as the RNN reads the input sequentially. One problem here is that the size of hidden state is fixed. If a sequence is long enough, the hidden state will not be able to contain whole information of the sequence. Furthermore, the bi-directional RNN in the CBHG must contain information of current time-step’s text input as well as the information of long-term dependency. This puts more of the burden on the hidden state. In Figure 3-(a), attention alignments have gaps or blurry parts in the middle of the sequence when the input sentence is long in the original Tacotron. We speculate these irregularities comes from the insufficient capacity of the bi-directional RNN’s hidden state in the CBHG; hence, we decided to add a residual connection that connects the input and the output of the bi-directional RNN. We changed the output of the CBHG to have additional term as follows:
where , and are input, hidden state and output of the bi-directional RNN. Now, the residual connection conveys the information of current time-step, so the hidden state of the bi-directional RNN does not need to contain information of current time-step. This connection made the hidden state less congested and helped encoding text information.
By applying residual connection with the method proposed in Section 4.1, we observed sharper and clearer attention alignments as shown in Figure 3. More examples of alignments and results can also be found on our Github page.
We have proposed a modified Tacotron, as an end-to-end emotional speech synthesizer that takes the character sequence and the desired emotion as input and generates the corresponding wave signal. In our experiments, we have figured out that the quality of the generated speech is highly correlated with the sharpness and the cleanness of the attention alignment; hence, we presented some tricks to improve the attention alignments and therefore quality of the generated wave. We are still investigating more improvement in the model by either improving the quality or speeding up generation. Currently, the model does not care about the phase of the spectrogram which may affect the intelligibility of the emotional wave (Broussard et al., 2017). On the other hand, the synthesizing process suffers from the low speed of the Griffin-Lim reconstruction. Furthermore, our final goal is to produce a dynamic TTS that is capable of generating speech with different personalities.
