I Introduction
Since the inception of sumproduct networks (SPNs) [1], a multitude of works have emerged with respect to their structure and weight learning, e.g., [2, 3, 4], as well as their application in image completion, speech modeling, semantic mapping and robotics, e.g., [5], just to name a few. An SPN exhibits a clear semantics of mixtures (sum nodes) and features (product nodes).
In short, given a highdimensional dataset (
), an SPN learns and encodes a probability distribution over the data and implicit latent (hidden) variables. Compared to other probabilistic graphical models like Bayesian and Markov networks with #P or NPhard computation, an SPN enjoys a tractable exact inference cost, and its learning is relatively simple and fast.
On the other hand, there has been an exploding number of works on tensors (a multilinear operator rooted in physics) [6] including their connection and utilization in various engineering fields such as signal processing [7]
, and lately also in neural networks and machine learning
[8, 9, 10]. The power of tensors lies in their ability to lift the curse of dimensionality, reducing computational and storage complexity from exponential to linear cost.
In this work, we establish a natural tensor representation of an SPN which we call a tensor SPN (tSPN). By utilizing the tensor notion, we essentially expand the set of tractable SPNs to match that of compact and deep SPNs. We focus on structure compression rather than the learning of SPNs. Indeed, our work leverages on the wealth of existing SPN learning algorithms such as [11, 2, 3], and attempts to turn their inherently wide SPN tree outputs (owing to the intrinsic way of learning through partitioning the data matrix) into a “deep” tree via tensor network techniques subject to a nonnegativity constraint. This is inline with the recent trend on pruning neural networks (NNs) [12], but operates quite differently in the regime of tensor networks with the imposition of a nonnegative constraint not needed in the NN counterparts.
In particular, sparsifying an SPN and transforming it into a tSPN brings about the following advantages:

It automatically enables sharing of weights through the tensor network cores, often resulting in significant parameter compression.

Fewer parameters can facilitate faster computation, lower power consumption, and less stringent cooling requirements in hardware implementations.

The above is crucial in downstream edge computing, which translates into better user privacy, lower reliance on the cloud and lower wireless bandwidth for overtheair network update on edge devices.
To our knowledge, this paper is the first to systematically transform an SPN into a tensor format, specifically, a tensor network counterpart named tSPN. The following sections cover SPN and tensor basics, and then introduce the tSPN conversion. Numerical experiments then demonstrate the remarkable compression in the number of network parameters, with negligible loss in the probabilistic modeling accuracy.
Ii Preliminaries
Iia SPN basics
We use a slightly modified SPN example from [1, 13], shown in Fig. 1(a), to motivate some important concepts and operations of SPNs. Boolean variables are chosen for the ease of illustration, but their generalization to multinominal or continuous variables are straightforward [1]
. To begin with, an SPN is a directed acyclic graph with alternating layers of sum and product (internal) nodes and a root node on top. The edges emanating downwards from sum nodes have nonnegative weights, while the edges emanating downwards from product nodes are all of unit weight. The leaves contain the set of random variables
. For boolean variables, the indicator functions and are 1 when and are 1, respectively, and 0 otherwise. We adopt the abbreviations and for and , respectively.Definition 1
The scope of an SPN is the set of variables appearing in its leaves. The scope of an internal sum or product node is the scope of the corresponding subSPN rooted at that node, as illustrated in Fig. 2.
Definition 2
An SPN is called complete when all children of a sum node have identical scope. It is called decomposable when all children of a product node have disjoint scopes. An SPN is called valid when all its sum nodes are complete and all its product nodes are decomposable. The sum nodes have the semantics of a mixture of components, while product nodes represent features. An SPN is called a normalized SPN when the edges emanating from a sum node have a total weight of one, and is an unnormalized SPN otherwise.
Consequently, the SPN in Fig. 1(a) is a valid and normalized SPN. We use to denote the value of an SPN where
is a vector containing all (nonnegative) weights in the network, and
is the vector of all random variables. A distribution is called tractable if any marginal probability can be computed in linear time.Definition 3
An induced tree [3] is a subtree of an SPN originating from the root following two rules: i) only one edge out of a sum node is selected at a time; ii) all edges out of a product node are selected. It can be readily checked that the total number of induced trees arising from an SPN can be computed by , i.e., by setting and where is the allones vector.
For instance, the bolded edges in Fig. 1(a) denotes an induced tree by selecting the left route out of each sum node. The notion of a network polynomial [14] comes in handy at this point.
Definition 4
Let
be the probability mass function of a set of discrete random variables
. The network polynomial of is the multilinear polynomial , where is the product of evidence indicators that has a value of 1 in the state .Any joint probability function of valued discrete random variables is represented by probabilities. The corresponding network polynomial has therefore terms. For example, the joint probability function of the SPN in Fig. 1 has a network polynomial that consists of terms:
(1)
Therefore an equivalence is drawn between an SPN and its network polynomial representation, which in turn encodes a probability function.
The beauty of an SPN lies in its exact and tractable inference. Equation (IIA) is an instance of a normalized SPN. For an unnormalized SPN, there are two ways to build its probability function. One is to scale the edge weights out of each sum node such that they add up to one, i.e., turning it back into a normalized SPN. Alternatively, we can compute the partition function in one bottomup pass by setting :
such that is a probability function.
Example 1
Assuming a normalized SPN, the probability of a fully specified state (also called a complete evidence) , e.g., , , in Fig. 1(a), is easily computed through a bottomup pass by setting and for and and .
Example 2
Assuming a normalized SPN, the probability of an evidence, e.g., in Fig. 1(a), can be computed by marginalizing over and . This is computed through a bottomup pass by setting and , and and for .
The above two examples are readily verified by comparing with (IIA). Similar operations allow us to compute the conditional probability and most probable explanation (MPE) by replacing sum nodes with max nodes, called a maxproduct network, in a similarly efficient manner [15].
To articulate with tensorbased reformulation of the SPN, we will need to slightly modify the induced tree (Definition 3) by terminating at the leaf nodes, i.e., the bottom nodes of the SPN in Fig. 1(b) instead of down to individual or . With reference to Fig. 1(b), the SPN contains two such induced trees corresponding to the left and right branches originating from the root sum node.
In fact, prevailing SPN learning algorithms or alike, e.g, LearnSPN, SPNB and SPNBT [11, 2], all produce SPN trees terminating at leaf nodes. Although SPN illustrations often utilize networks with shared weights (e.g., the two top branches in Fig. 1 are shared among many induced trees), conventional learning algorithms are all based on the “slice” and “chop” operations on the dataset matrix [4], or their variants with additional regularization constraints. A toy example illustrates the basic learnSPN flow. Referring to Fig. 3
(a), the slicing operation constructs children of a sum node by clustering similar sample instances. This is often done via kmeans or expectationmaximization (EM) for Gaussian mixture models (GMMs). In Fig.
3(b), the chopping operation constructs children of a product node by grouping dependent variables. This is often done by the Gtest or mutual information methods wherein a scoring formula is used to determine variables belonging to the same group, if any. These socalled hierarchical divisive clustering steps are surprisingly simple and effective, but they never look back and this leads to inherently wide SPN tree structures. For example, in the standard NLTCS benchmark, learnSPN (with default hyperparameters) generates an SPN with 19 layers and 1420 leaf nodes, even though there are only 16 variables. This demonstrates that existing learning algorithms do not readily produce shared edges (and weights) across different induced trees, and do not generate SPNs that can otherwise be represented compactly.
IiB Tensor basics
In this article, tensors are highdimensional arrays that generalize vectors and matrices to higher orders. A way or order tensor is an array where each entry is indexed by indices . We use the convention for . When the tensor is called cubical. MATLAB notation is used to denote entries of tensors. Boldface capital calligraphic letters are used to denote tensors, boldface capital letters denote matrices, boldface letters denote vectors, and Roman letters denote scalars. A set of tensors, like that of a tensor train (TT), is denoted as . The notion of a rank1 matrix is generalized to tensors in the following manner.
Definition 5
[6, p. 460] For a given set of vectors , the corresponding rank1 tensor is defined such that
Alternatively, this is written as
where denotes the outer product.
A rank tensor is then defined as the sum of rank1 tensors. The generalization of the matrixvector multiplication to tensors involves a multiplication of a vector with a way tensor along one of its modes.
Definition 6
The proposed method also requires the knowledge of the matrix KhatriRao product as defined below.
Definition 7
If and , then their KhatriRao product is the matrix
where denotes the standard Kronecker product.
The storage of a way tensor with dimensions requires elements. Tensor decompositions are crucial in reducing the exponential storage requirement of a given tensor. In this article we will make use of the tensor train (TT) decomposition [16], which is a particular kind of tensor network.
Definition 8
[16, p. 2296] A tensor train (TT) representation of a tensor is a set of 3way tensors such that can be computed from
The dimensions are called the TTranks, and the threeway tensors are called the TTcores.
When , the TT is said to have periodic boundary conditions and is called a tensor loop or tensor ring. In this article, we will always set , i.e., a standard TT structure. The key idea now is to represent the network polynomial of any joint probability function by a lowrank TT. In this way, all (if ) probabilities can be computed from numbers, where is the maximal TTrank. Without loss of generality, we consider only boolean variables from now on.
Definition 9
For a given network polynomial of binary random variables we define the corresponding TT consisting of 3way tensors such that the evaluation of for a given state can be computed from
Note that the and factors are a column and row vector, respectively. The other factors are matrices, such that the whole product results in the scalar . Small TTranks for then imply small matrix factors, and a massive reduction in the required number of parameters can be achieved.
Iii Putting an SPN on a tSPN
The key motivation of this work comes from the important observation that an SPN induced tree terminated at leaf nodes is in fact a rank1 tensor. Using Fig. 1(b) again as an example, there are two such induced trees that can be regarded as the addition of two rank1 tensor terms with mode products onto their th mode, as shown in Fig. 4. Consequently, summing all the rank1 terms (gray shaded terms in Fig. 4) produces a way cubical tensor of dimension . This tensor can then hopefully be sufficiently approximated by a lowrank TT as a particular kind of tSPN. We aim at building a tSPN based on the TT structure, depicted in Fig. 5, that satisfies the following constraints:

The TTcores have nonnegative entries.

There is a mixed core, whose position is arbitrary, with all its entries summing up to 1.

Every core to the left of the mixed core is a left normalized core, which means that each of its vertical slices sums up to 1.

Every core to the right of the mixed core is a right normalized core, which means that each slice sums up to 1.

When we encounter a slice that contains all zeros, then it means the two slices (one vertical and one horizontal) in two adjacent cores corresponding to the same can be removed and the dimension is shrunk by one.
The first constraint ensures that a tSPN has nonnegative weights. The remaining constraints ensure that the partition function when for all ’s. A tSPN obeying the above constraints is called a normalized tSPN in analogy to a normalized SPN. The left/right normalized cores and the mixed core are strongly analogous to the mixedcanonical form of a TT which consists of left/right orthogonalized cores and a mixed core. We remark that a tSPN having a TT structure automatically enforces the desired weight parameter sharing as well as a deep network. This is because each scalar (viz. probability) evaluation of a TTbased tSPN, when contracted with onto its th mode, , results in a matrix product using all TTcores (cf. Definition 9).
Recalling from Fig. 4, a tSPN is fully captured by a way cubical tensor through summing all rank1 terms (induced trees) extracted from the learned SPN. The conversion of such a fulltensor tSPN into a TTbased tSPN then boils down to converting into its TT format .
A direct way to obtain the TT form of is by regarding each rank1 tensor term, corresponding to an induced tree, as a rank1 TT and sum them all up into a new TT [16]. However, in this case, the TT ranks
equal the number of rank1 terms and are therefore impractically high. Although TTrounding by singular value decomposition (SVD) between successive cores may reduce the TTranks, it will generally destroy the nonnegativity of weights and result in cores with negative values. Similar issues arise when we use nonnegative tensor factorization (NTF) algorithms
[17] on which also produce a large number of rank1 tensor terms. In fact, constructing the full tensor explicitly is computationally prohibitive when the number of variables go beyond 17 on our computers. This motivates us to develop an SPNtotSPN construction algorithm, called spn2tspn, through a recently proposed tensornetwork based nonlinear system identification method [18] elaborated below.Iiia Algorithm: spn2tspn
Starting from a learned SPN trained by a given dataset, we compute the probabilities of a set of training input samples as well as nonsamples through exact inference. This step has linear complexity due to the SPN nature, and generates a set of multiinput singleoutput (MISO) data used for the identification of the underlying TT. On the one hand, training samples are meaningful data (positive samples) used in the SPN learning and therefore correspond to higher probabilities. On the other hand, we randomly generate some nonsamples (negative samples) outside the dataset and feed them into the SPN for their probabilities which are mostly close to zero. We then utilize these MISO data to identify a TTbased tSPN by adapting the approach in [18].
Now having a set of training samples and nonsamples together with their probabilities, the goal is to obtain a tensor in a TT format such that the probability distribution inferred from this TTbased tSPN closely tracks that of the SPN. We first collect the column vectors into the matrix for . Next, we formulate the optimization problem
(2)
such that is a TT with nonnegative cores , and is computed from
(3)
and is the collection of probabilities of samples and nonsamples.
Following from [18], (2) is broken into leastsquares subproblems of small sizes solved by the alternating linear scheme (ALS). To obtain nonnegative ’s, we further impose a nonnegative constraint into each subproblem which is then solved by the nonnegative leastsquares (NNLS) method [19] within each ALS iteration. This problem formulation also resembles that of a tensor completion work that employs a TT format [20] but without the nonnegativity constraint in place. We therefore refer the reader to the paper for details. In short, to solve for , one solves the following leastsquares subproblem by NNLS
(4)
where denotes the th column of , whereas and are auxiliary notations defined as:
The proposed algorithm is summarized in Algorithm 1.
Dataset name  # variables  # layers  # leaf nodes  # weights  # parameters  # parameters  reduction  TV

(SPN)  (tSPN)  ()  distance
NLTCS
MSNBC
KDDCup2K
Plants
Audio
Jester
Retail
Pumbstar
DNA
Kosarek
MSWeb
EachMovie
Reuters52
20Newsgroup
Ad
Algorithm 1
SPNtotSPN Conversion (spn2tspn)
Input: A trained SPN and training samples and nonsamples.
Output: A compressed TTbased tSPN.
Once a tSPN is built, a purposedly reserved portion of the dataset input samples (not used in the SPN learning) are used as test inputs and their SPN probability outputs are used as test outputs to check the quality of the tSPN. As will be shown later in experiments, almost exact matches are observed between the probabilities derived from the learned SPN and its tSPN couterparts, with the latter having substantially fewer parameters.
We note that SPN operations such as inference and most probable explanation (MPE) etc. can be easily mapped to the tSPN scenario which, being not central to the theme and also due to space limitation, are put into the Supplemental Material of this paper.
Iv Experiments
We use fifteen benchmarking datasets from publicly available website^{1}^{1}1https://github.com/arranger1044/spyn/tree/master/data and learn their corresponding SPNs by using the methods proposed in [2]. The Python implementation^{2}^{2}2https://github.com/arranger1044/spyn of the algorithms are used throughout our experiments. We then apply Algorithm 1 to transform the SPNs into tSPNs, and the results are summarized in Table I. All experiments were run on a desktop computer with an Intel i5 quadcore processor at 3.2GHz and 16GB RAM. Implementations of the proposed algorithm, together with necessary data files for reproducing experimental results will be made publicly available after the peer review. To measure the “closeness” of the probability distributions between an SPN and its tSPN counterpart, we use the total variation (TV) distance [21]. However, we stress that this metric (essentially an L1 norm) is only handy when the size of the problem is relatively small, say, # variables . When there are more variables like , our desktop computer fails to construct a tensor and compute the TV distance. That said, to still evaluate the tSPN conversion, we plot the probability profiles of training and testing data both in an SPN and its corresponding tSPN to visually compare their similarity.
As shown in Table I, the number of parameters in tSPNs are significantly fewer than those in the original SPNs, while excellent match is still observed in their probability distributions as indicated by the TV distances and as depicted in Figs. 6 and 7. In the first two experiments, the number of variables are both no bigger than , thus we are still able to compute the TV distances from reference SPNs to tSPNs. Among other experiments, we highlight that when converting the SPN of the 20Newsgroup dataset into a tSPN, a storage reduction is witnessed. Although explicitly computing probabilities for the TV distance evaluation is prohibitive, we can compare the probabilities of only parts of the samples and nonsamples. In particular, in each of Figs. 6 and 7, we plot the probabilities of four sets of input samples, namely, training/testing samples/nonsamples. Comparing the upper and lower figures, we observe essentially indistinguishable difference between the probability outputs of the SPN and tSPN, and similarly for other examples not plotted here. It is interesting to note that the testing samples/nonsamples are never used in the spn2tspn conversion, but the resultant tSPN still manages to well capture the probabilities for these unseen data. This demonstrates the success of putting SPNs on tSPNs, which leads to substantial reduction in modeling parameters while having virtually no loss in accuracy.
Apparently, other tensor factorizations such as the CANDECOMP/PARAFAC canonical polyadic decomposition or Tucker decomposition [6] may be used for tSPN, but according to our tests these are not as effective as the TT decomposition in preserving the depth and width semantics of SPNs. Furthermore, the identification algorithms for other tensor formats are not as simple and scalable as spn2tspn, and are therefore omitted.
Backed by the experimental results, we highlight some additional advantages of TTbased tSPNs further to those already stated in the introduction:

They often have small sizes via controlling the TT ranks, which translates into smaller network sizes and faster inference.

Depth of a tSPN is inherently high (corresponding to the number of TTcores), while its width (corresponding to TTranks) is usually set to be low. In terms of neural network language, this means higher expressive efficiency.

The structural simplicity of a tSPN acts as a regularizer. In terms of neural network language, this implies a better inductive bias.
Of course, a natural question is whether data learning can be directly carried out on the tSPN structure, rather than going through the SPN learning followed by tSPN conversion. Research is underway along this direction and results will be reported in our upcoming work.
V Conclusions
This paper is the first to propose a tensor implementation of an SPN called tSPN. An equivalence is drawn between an SPN with boolean variables to a way cubical tensor of dimension 2. The transformation of the latter into a tensor train (TT) representation then allows inherent sharing of originally distributed weights in an SPN tree, thereby leading to an often dramatic reduction of the number of network parameters as seen in various numerical experiments, at little or negligible loss of modeling accuracy. The TTbased tSPN also automatically guarantees a deep and narrow neuralnetwork architecture. These promising new results have demonstrated tSPN to be a more natural form for realizing an SPN compared to its conventional tree structure.
References

[1]
H. Poon and P. Domingos, “Sumproduct networks: A new deep architecture,” in
Proc. Uncertainty in Artificial Intelligence (UAI)
, 2011, pp. 337–346.  [2] A. Vergari, N. D. Mauro, and F. Esposito, “Simplifying, regularizing and strengthening sumproduct network structure learning,” in Proc. European Conference on Machine Learning and Principles and Practice of Knowledge Discovery in Databases (ECMLPKDD), 2015, pp. 343–358.
 [3] H. Zhao, P. Poupart, and G. J. Gordon, “A unified approach for learning the parameters of sumproduct networks,” in Proc. Advances in Neural Information Processing Systems (NIPS), 2016, pp. 433–441.
 [4] C. J. Butz, J. S. Oliveira, and A. E. dos Santos, “On learning the structure of sumproduct networks,” in Proc. IEEE Symposium Series on Computational Intelligence (SSCI), 2017, pp. 1–8.
 [5] K. Zheng, A. Pronobis, and R. P. N. Rao, “Learning graphstructured sumproduct networks for probabilistic semantic maps,” in Proc. AAAI Conference on Artificial Intelligence, 2018, pp. 4547–4555.
 [6] T. Kolda and B. Bader, “Tensor decompositions and applications,” SIAM Review, vol. 51, no. 3, pp. 455–500, 2009.
 [7] A. Cichocki, D. Mandic, L. De Lathauwer, G. Zhou, Q. Zhao, C. Caiafa, and H. A. PHAN, “Tensor decompositions for signal processing applications: From twoway to multiway component analysis,” IEEE Signal Processing Magazine, vol. 32, no. 2, pp. 145–163, March 2015.
 [8] N. Cohen, O. Sharir, Y. Levine, R. Tamari, D. Yakira, and A. Shashua, “Analysis and design of convolutional networks via hierarchical tensor decompositions,” CoRR, vol. abs/1705.02302, 2017.

[9]
V. Khrulkov, A. Novikov, and I. Oseledets, “Expressive power of recurrent neural networks,” in
Proc. Intl. Conf. Learning Representations (ICLR), 2018.
[10]
Z. Chen, K. Batselier, J. A. K. Suykens, and N. Wong, “Parallelized tensor train learning of polynomial classifiers,”
IEEE Trans. Neural Networks and Learning Systems, pp. 1–12, 2018.  [11] R. Gens and P. Domingos, “Learning the structure of sumproduct networks,” in Proc. Int. Conf. Machine Learning (ICML), 2013, pp. 873–880.
 [12] S. Han, J. Pool, J. Tran, and W. Dally, “Learning both weights and connections for efficient neural network,” in Proc. Advances in Neural Information Processing Systems (NIPS), 2015, pp. 1135–1143.
 [13] R. Gens and P. Domingos, “Discriminative learning of sumproduct networks,” in Proc. Advances in Neural Information Processing Systems (NIPS), 2012, pp. 3239–3247.

[14]
A. Darwiche, “A differential approach to inference in bayesian networks,”
J. ACM, vol. 50, no. 3, pp. 280–305, May 2003.  [15] R. Peharz, R. Gens, F. Pernkopf, and P. Domingos, “On the latent variable interpretation in sumproduct networks,” IEEE Trans. Pattern Analysis and Machine Intelligence, vol. 39, no. 10, pp. 2030–2044, Oct 2017.
 [16] I. V. Oseledets, “Tensortrain decomposition,” SIAM Journal on Scientific Computing, vol. 33, no. 5, pp. 2295–2317, 2011.
 [17] J. Kim, Y. He, and H. Park, “Algorithms for nonnegative matrix and tensor factorizations: a unified view based on block coordinate descent framework,” Journal of Global Optimization, vol. 58, no. 2, pp. 285–319, Feb 2014.
 [18] K. Batselier, Z. Chen, and N. Wong, “Tensor Network alternating linear scheme for MIMO Volterra system identification,” Automatica, vol. 84, pp. 26–35, 2017.
 [19] C. L. Lawson and R. J. Hanson, Solving least squares problems. Siam, 1995, vol. 15.
 [20] C. Y. Ko, K. Batselier, W. Yu, and N. Wong, “Fast and accurate tensor completion with tensor trains: A system identification approach,” CoRR, vol. abs/1804.06128, 2018. [Online]. Available: http://arxiv.org/abs/1804.06128
 [21] A. L. Gibbs and F. E. Su, “On choosing and bounding probability metrics,” International statistical review, vol. 70, no. 3, pp. 419–435, 2002.
