 # Cusum tests for changes in the Hurst exponent and volatility of fractional Brownian motion

In this note, we construct cusum change-point tests for the Hurst exponent and the volatility of a discretely observed fractional Brownian motion. As a statistical application of the functional Breuer-Major theorems by Bégyn (2007) and Nourdin and Nualart (2018, arXive:1808.02378), we show under infill asymptotics consistency of the tests and weak convergence to the Kolmogorov-Smirnov law under the no-change-hypothesis. The test is feasible and pivotal in the sense that it is based on a statistic and critical values which do not require knowledge of any parameter values. Consistent estimation of the break date under the alternative hypothesis is established. We demonstrate the finite-sample properties in simulations and a data example.

## Authors

##### This week in AI

Get the week's most popular data science and artificial intelligence research sent straight to your inbox every Saturday.

## 1 Introduction

The (simplest) definition of fractional Brownian motion (fBm), , is that is a continuous-time Gaussian process with continuous paths which is centered, for all , and with covariance function

 E[BHtBHs]=12(t2H+s2H−|t−s|2H),t,s≥0.

has stationary Gaussian increments and is -self-similar. Except the case , when is Brownian motion, increments are not independent and is not a semi-martingale. We refer to Nourdin (2012) for more information on properties of fBm. We observe a path of fBm , with a volatility (or scaling) parameter , over the unit interval at equidistant discrete observation times, . Denote , the observed increments called fractional Gaussian noise. We establish limit results under infill asymptotics as , .
The self-similarity parameter , called Hurst exponent, determines the persistence and the smoothness regularity of paths of . Modelling data by fBm asks for statistical inference on and . There is a rich literature on estimators for , but local asymptotic normality (LAN) and thus asymptotic efficiency of maximum likelihood (mle) and the whittle estimator under infill asymptotics has been established only recently by Brouste and Fukasawa (2018)

. Since the computation of the mle is infeasible for too large sample sizes due to the inversion of a covariance matrix, method of moment approaches based on power variations are prominent alternative methods which are simple to implement and fast to compute. We first restrict to the more standard case

, For , non-central marginal limit theorems with slower rates are given in Nourdin et al. (2010). We shall use a functional central limit theorem for a sum of squared second-order increments from Bégyn (2007) for the test in this case.

in that the following central limit theorem for the normalized quadratic variation is available:

 √n(n2H−1n∑j=1(ΔnjBH1)2−1)d⟶N(0,2γ), (1)

with given in (5), see, for instance, Nourdin et al. (2010). This setup is covered by the well-known theorem of Breuer and Major (1983). From this convergence, we derive one standard estimator for the Hurst exponent

 ^Hn=12−log(∑nj=1(ΔnjBH1)2)2log(n), (2)

and based on the delta method, when , that . When is unknown, a small modification of this statistic using a ratio of discrete quadratic variations at different sampling frequencies

 ^H(σ)n=12log(2)log(∑n−2j=0(σ(BH(j+2)Δn−BHjΔn))2∑nj=1(ΔnjBHσ)2), (3)

yields a consistent estimator with -rate. More refined related estimation methods have been presented by Coeurjolly (2001) and by Bardet and Surgailis (2011)

using increment ratios. Lower bounds for the convergence rates of unbiased estimators of

are known to be when is known and in case of unknown volatility, see Coeurjolly and Istas (2001) or Brouste and Fukasawa (2018). Hence, the estimators using power variations attain optimal rates. The volatility can be estimated when we plug-in the estimated Hurst exponent. If , these estimators preserve consistency, but the central limit theorems do no longer apply.
While there is a strand of literature that addresses change-point analysis for changes in the mean of fBm or related time-series models, see, for instance, Betken (2017) for a recent contribution, there is scant groundwork on changes points of the Hurst exponent . There are a few works in the time-series literature, see Lavancier et al. (2013) and references therein, which do not include a classical cusum test based on power variations. Although cusum tests are in general very popular because of their appealing asymptotic and finite-sample properties, to the best of the author’s knowledge the presented methods have not yet been discussed in the literature.
A necessary prerequisite for a cusum change-point test is a functional central limit theorem, also referred to as invariance principle. Proving such a result for power variations of fBm is difficult due to the dependence of increments. Nevertheless, exploiting properties of Gaussian processes such results have been established in the last years. Building upon two functional central limit theorems by Bégyn (2007) and Nourdin and Nualart (2018), we construct cusum change-point tests for a change in the Hurst exponent or the volatility parameter of the fBm. We remark that we use the general result from Nourdin and Nualart (2018) only for one simple specific function, while the authors focus on necessary and sufficient conditions under which functional weak convergence holds true.

## 2 Statistical application of functional central limit theorems for power variations

The result by Nourdin and Nualart (2018) applied with the Hermite polynomial of rank 2 provides for a functional limit theorem for the normalized discrete quadratic variation

 √n(n2H−1⌊nt⌋∑j=1(ΔnjBHσ)2−tσ2)⟶√2γσ2Wt, (4)

as , weakly in the Skorokhod space of cádlág functions with a standard Brownian motion independent of

. The limit process being continuous, convergence holds with respect to the uniform topology. The long-run variance is determined by

 γ=14∑r∈Z(|r+1|2H+|r−1|2H−2|r|2H)2=12(1+∞∑r=2(D2((⋅)2H,r))2), (5)

where for some function , the second-order increment operator is . The estimate , , , shows the convergence of the series, while the sum of squared increments exhibits long-range dependence for . By continuous mapping, (4) readily implies that

 (6)

that is, the convergence of the cusum process to a Brownian bridge. This functional central limit theorem can be exploited for a change-point test with the help of the next simple lemma.

###### Lemma 0.

Let and be real-valued cádlág functions defined on . For any , there exists a , such that

 ∥X−Y∥∞=sup0≤t≤1|Xt−Yt|≤δ  ⇒  ∣∣sup0≤t≤1Xt−sup0≤t≤1Yt∣∣≤ϵ.
###### Proof.

If , there exists , such that

 Xs−Ys≥Xs−sup0≤t≤1Yt>ϵ   or    Ys−Xs ≥Ys−sup0≤t≤1Xt>ϵ,

and thus . Hence, for and , we obtain the claimed continuity. ∎

Based on Lemma 1 and continuous mapping, we obtain the weak convergence of the supremum of the absolute left-hand side in (6), multiplied with , to the law of the supremum of the absolute value of a standard Brownian bridge, referred to as the Kolmogorov-Smirnov law. In the vein of Phillips (1987), this weak convergence can be exploited to test for structural breaks in the observed path of . Depending, however, on , and , this statistic is yet infeasible and we thus propose the following modification

 Tn =sup1≤m≤n∣∣Sn,m∣∣, with (7) Sn,m =1√n∑mj=1((ΔnjBHσ)2−1n∑nj=1(ΔnjBHσ)2)(n−1∑k=−n+11n(n−k)∧n∑j=1∧(1−k)((ΔnjBHσ)2−∑nj=1(ΔnjBHσ)2n)((Δnj+kBHσ)2−∑nj=1(ΔnjBHσ)2n))12,

where we write . is a cusum process of squared increments standardized with the empirical long-run variance, that is, a sum over empirical autocovariances for different lags. It holds that

 Tnd⟶sup0≤t≤1∣∣Wt−tW1∣∣,   as n→∞, (8)

with the Kolmogorov-Smirnov limit law. The standardization with the empirical long-run variance thus takes out the factor in (4). Moreover, we do not rescale squared increments by in (7). Multiplying numerator and denominator with , the squared denominator consistently estimates the long-run variance as , and it is positive definite by standard results from time series analysis. Slutsky’s lemma in combination with the weak convergence for the infeasible statistic based on (6) thus gives the stated asymptotic distribution of . In the next paragraph, we work out statistical properties of and construct a change-point test. Let us recall that (8) holds true only in the case . Instead of considering functional non-central limit theorems when , if they were available at all, and the law of the supremum of a Rosenblatt limit process, a simpler solution to address the general case, , is to use an analogous statistic as (7) with second-order increments. For observations , set

 T(2)n =sup1≤m≤n−1∣∣S(2)n,m∣∣, with (9) S(2)n,m

where are second-order increments. A normalized sum of squared second-order increments of fBm satisfies a (functional) central limit theorem for any , see Section 3.1 of Bégyn (2007) and we thus readily derive weak convergence of to the Kolmogorov-Smirnov limit law for any .

## 3 A cusum test for changes in the Hurst exponent

We consider the statistical hypothesis test

 H0:We observe a discretization of a path of BHσ with σ>0, H∈(0,3/4) constant vs. H1:There is one θ∈(0,1) and we have BHσ on [0,θ) and B~Hσ,|H−~H|>0, on [θ,1].

It is standard in the theory of statistics for high-frequency data to address such questions path-wise. This means that and are formulated for the one observed path of , and the statistical decision is based on the discretization of the given path. It is not important here how the inter-dependence structure evolves under around . One can think for instance of two independent fBms intertwined at the change, but a gradual change of persistence in a vicinity of is possible as well.

Consistency of the test is implied by the following lower bound for under . A standard decomposition in the expectation and a bound for the stochastic deviation by Markov’s inequality yield with an almost surely finite constant and an almost surely positive constant that

 Tn≥|Sn,⌊nθ⌋| ≥∣∣1√n∑⌊nθ⌋j=1(n−2H−θn−2H−(1−θ)n−2~H)∣∣Cn−2(H∧~H)−OP(1) ≥cθ(1−θ)√n(1−n−2(H∨~H−H∧~H))−OP(1),

where we write and . Hence, when and are fix, with rate . Naturally, the power of the test decreases for closer to one boundary of the observation interval or for smaller . Considering a null sequence , an expansion of yields the speed . We have proved the following main result of this note.

###### Theorem 3.1.

The sequence of tests with critical regions

 Cn={Tn>q1−α}, (10)

where denotes the -fractile, that is, the (1-

)-quantile, of the Kolmogorov-Smirnov law, provides an asymptotic distribution-free test for the null hypothesis

against the alternative hypothesis , which has asymptotic level and asymptotic power 1. The consistency is valid for decreasing sequences of in , as long as .

Consistency of the test directly extends to the case of more than one change in . Further, a locally bounded drift term added to will not affect the results, which follows with standard estimates for high-frequency data provided by Jacod and Protter (2012). In case of additional nuisance jumps, truncation methods can be used to obtain a robust version.
Using (9), we can drop the restriction under .

###### Corollary 3.2.

The sequence of tests with critical regions , provides an asymptotic distribution-free test for , for any , against with asymptotic level and asymptotic power 1. The consistency is valid for decreasing sequences of in , as long as .

For the lower bound of under , we use that are centered and

 E[(D2(Zj))2]=σ2(4−22H)Δ2Hn=cHσ2Δ2Hn, (11)

with , and decreasing in . Analogously as for , if without loss of generality , a lower bound is thus given by

 T(2)n≥|S(2)n,⌊nθ⌋| ≥cθ(1−θ)√n(cH−c~HΔ2(~H−H)n)−OP(1) ≥c(4−22H)θ(1−θ)√n(1−Δ2(~H−H)n)−OP(1),

with an almost surely positive constant . This proves Corollary 3.2.

## 4 A cusum test for changes in the volatility

We prove that reacts as well to a change of and thus provides a statistical hypothesis test for

 H0:We observe a discretization of a path of BHσ with σ>0, H∈(0,3/4) constant vs. Hσ1:There is one θ∈(0,1) and we have BHσ on [0,θ) and BH~σ,|σ2−~σ2|>0, on [θ,1].

A related lower bound for under as in Section 3 yields with an almost surely finite constant and an almost surely positive constant that

 Tn≥|Sn,⌊nθ⌋| ≥∣∣1√n∑⌊nθ⌋j=1(σ2n−2H−θσ2n−2H−(1−θ)~σ2n−2H)∣∣Cn−2Hmax(σ2,~σ2)−OP(1) ≥cθ(1−θ)√n(1−min(σ2,~σ2)max(σ2,~σ2))−OP(1).

We obtain the following corollary to Theorem 3.1.

###### Corollary 4.1.

The sequence of tests with critical regions (10), provides an asymptotic distribution-free test for the null hypothesis against the alternative hypothesis , which has asymptotic level and asymptotic power 1. The consistency is valid for decreasing sequences of in , as long as .

Thus, rejects the null hypothesis under both types of changes. There are opportunities to discriminate the two types of changes based on the different behavior of the ratio of expected squared increments before and after the break at time . We present one in the next paragraph. With (11) we obtain an analogous result for the test based on (9) for any under as well. In view of the rates in the LAN result by Brouste and Fukasawa (2018), we can see that our tests attain asymptotic minimax-optimal rates. This means that parameter differences smaller than the orders stated in Theorem 3.1 and Corollary 4.1 are impossible to detect and determine the minimax detection boundary.

## 5 Estimation of the change point and discriminating the type of change

If a change-point test rejects the null hypothesis of no change, the estimation of the time of a change, referred to as the break date, becomes of interest. We prove consistency of the argmax-estimator associated with our statistic (7) under the alternative hypothesis with one break in at time . The result analogously extends to a break in , and using an iterative algorithm it may be extended to multiple changes.

###### Proposition 5.0.

Under the alternative hypothesis , the estimator

 ^θn=Δnargmax1≤m≤n∣∣Sn,m∣∣ (12)

satisfies that .

###### Proof.

Without loss of generality, we consider observations , with

 E[(ΔnjZ)2]={σ2n−2H,1≤j≤i∗nσ2n−2~H,i∗n+1≤j≤n,

where and , . Generalizations of the proof to , and when one increment is affected by and are obvious. Define , a piecewise constant function with

 f(t)=n∑m=1E[m∑j=1((ΔnjZ)2−1nn∑j=1(ΔnjZ)2)]1((m−1)Δn,mΔn](t),

and . We obtain for , that

 f(mΔn) ={σ2δHm(1−i∗nn),0≤m≤i∗nσ2δHi∗n(1−mn),i∗n

We see that is non-negative and increasing for , and decreasing for , with a unique maximum at . is the expectation of the numerator of the cusum process in (7). Thus, uniformly in . For , it holds that

, with a probability tending to 1, and the leading term is larger than the

-term with a probability tending to 1. Hence, the convergence rate is implied by the relation

 1√n(f(i∗nΔn)−f(i∗nΔn−γn))=σ2δH√nγn(1−i∗nn)→∞,

as long as . More precisely, we apply Lemma 1 from page 45 of Bibinger and Madensoy (2018) to the function , which yields for that with a probability converging to 1 we have that

 i∗nΔn≥^θn≥i∗nΔn−γn.

An analogous application of the same lemma to the function , yields that with a probability converging to 1 it holds that

 i∗nΔn≤^θn≤i∗nΔn+γn.

One opportunity to distinguish which type of change occurs when the test rejects the null hypothesis uses the estimator .

###### Corollary 5.1.

With from (12), for and observations , set

 Qn=1^θnn∑^θnnj=1(ΔnjZ)21(n−^θnn)∑nj=^θnn+1(ΔnjZ)2, (13)

and , else. It holds that

 QnP⟶⎧⎪ ⎪⎨⎪ ⎪⎩∞, under H1 with H<~H,σ2~σ2, under Hσ1,0, under H1 with H>~H, (14)

as .

###### Proof.

We have by definition and since , almost surely for sufficiently large. By Proposition 2, , as . Thus, we obtain that

 Qn =1θn∑θnj=1(ΔnjZ)21(n−θn)∑nj=θn+1(ΔnjZ)2(1+Oa.s.(1))

Analogous results can be proved for statistics based on (9) along the same lines.

## 6 Simulations and data example Figure 1: Left: Empirical size of the test under H0. Middle: Boxplot comparing performances of three estimators of the Hurst exponent. Right: Empirical type II error rates for the test under H1.

We simulate discretizations of using the code by Coeurjolly (2000) with the Cholesky method. First, the plot in the middle of Figure 1 compares the performance of three related estimators for the Hurst exponent:

1. from (2).

2. from (3).

3. The increments ratio estimator from Bardet and Surgailis (2011) using second-order increments.

The parameter configuration is and . The boxplots based on 10,000 Monte Carlo iterations reveal that has a much smaller finite sample variance compared to the two other estimators for . The robustification for general from (3) has a much larger variance. The more sophisticated increments ratio estimator has a better performance, but still cannot keep up with . According to Brouste and Fukasawa (2018) the mle, which can be computed for moderate sample sizes, allows to attain a smaller variance for general .

Next, we illustrate the empirical size and power of the test by plotting the relative amount of realizations of from (7) smaller or equal to the percentiles of the Kolmogorov-Smirnov law against those percentiles. The results are given in the left and right plots of Figure 1 under the null hypothesis and alternative hypotheses, respectively.

For and constant and , the left plot in Figure 1 confirms a highly accurate fit under by the Kolmogorov-Smirnov limit law based on 10,000 Monte Carlo iterations. For other values of , we obtain as well a high accuracy of the fit. Figure 2 shows histograms of 10,000 Monte Carlo iterations under , for , and , and different alternative hypotheses, when for and , and when for and . As expected, the power increases with increasing and with larger sample sizes. The left histogram under closely tracks the asymptotic Kolmogorov-Smirnov law. The factors between medians (or quantiles close to the center) for the same changes , and for the two different sample sizes, are close to the expected factors determined by the rate we have found in Section 3. For the large sample sizes, the histograms under show fat tails which, however, barely reduce the power of the test in these cases. The right plot in Figure 1 depicts the percentage type II error rates. The testing levels of interest are located on the right of the x-axis, that is, the x-axis gives the percentage values of when is the testing level. For sample size , we basically have a power of one at all reasonable testing levels in both considered cases. The power curves for in the two different scenarios are hence more informative. The ordering of the different curves is clear as we have larger power for larger and larger (compare to the histograms). Using instead of , we obtain analogous empirical distributions under the alternative hypotheses while the size under the null hypothesis is a bit better for . However, when under the null hypothesis, the left plot of Figure 3 shows that the empirical distribution of is not close to the Kolmogorov-Smirnov law any more, while the empirical distribution of attains a good size. Under alternative hypotheses with a change of large Hurst exponents, both statistics show similar empirical distributions again. Overall, a very good power for moderate finite sample sizes of our tests is confirmed. This is in line with classical findings in change-point theory for parametric cusum tests. Figure 2: Left: Histogram for realizations of Tn from (7) under H0 and H1 for n=100 with ~H=0.3 and ~H=0.4, and for n=1,000 with ~H=0.3 and ~H=0.4 (left to right).

For a real data example, we use the daily total sunspot numberSource: WDC-SILSO, Royal Observatory of Belgium, Brussels, http://www.sidc.be/silso/datafiles, accessed on April 3, 2019. from 1848/12/23 to 2019/03/31 having daily observations. Time series of sunspots are often analyzed using fBm models, see, for instance, Shaikh et al. (2008). Estimator (3) and the second-order increments ratio estimator from Bardet and Surgailis (2011) applied to all data both yield . However, , such that we clearly reject the hypothesis that is constant. A classical R/S estimate from the increments yields a different value of ca. 0.32 for . This method is often used in the applied literature. We do not rely on this R/S method, however, since Bardet (2018) notes that “a convincing asymptotic study of such an estimator” does not exist, and Taqqu et al. (1995) have demonstrated that the obtained estimates are in general not accurate. Sunspots have a periodic behavior with at least one cycle of about 11 years, compare Figure 3. Especially for non-stationary time series, we obtained inaccurate R/S Hurst exponent estimates also in simulation experiments.
The right-plot of Figure 3 shows 21 point estimates for the Hurst exponent on time blocks with 3,000 days. Since more than 10,000 daily increments and around 2,000 second-order increments are zero, we need to adjust the increments ratio estimator and we see some relevant differences between both estimators. Nevertheless, the empirical findings allow to conclude that a multifractional Brownian motion model is better suited and that the Hurst exponent is not constant and has larger values in a period after 1950 than before. Looking at sub-samples of the time series, we find that for 3-years block length the test does not reject the hypothesis of a constant Hurst exponent in these blocks at 10%-level in 7 of the 63 blocks with a minimum value of . For 1-year block length it is not rejected for 81 from 170 years. This indicates that within smaller time intervals fBm may be used as a suitable model. Figure 3: Left: Empirical size of tests based on T(2)n (black dots) and Tn under H0 with H=0.85. Middle: Sunspot daily increments. Right: Estimated Hurst exponents on blocks by (3) (back dots) and increment ratios.
