ConceptVision: A Flexible Scene Classification Framework

01/03/2014 ∙ by Ahmet Iscen, et al. ∙ Bilkent University 0

We introduce ConceptVision, a method that aims for high accuracy in categorizing large number of scenes, while keeping the model relatively simpler and efficient for scalability. The proposed method combines the advantages of both low-level representations and high-level semantic categories, and eliminates the distinctions between different levels through the definition of concepts. The proposed framework encodes the perspectives brought through different concepts by considering them in concept groups. Different perspectives are ensembled for the final decision. Extensive experiments are carried out on benchmark datasets to test the effects of different concepts, and methods used to ensemble. Comparisons with state-of-the-art studies show that we can achieve better results with incorporation of concepts in different levels with different perspectives.

READ FULL TEXT VIEW PDF
POST COMMENT

Comments

There are no comments yet.

Authors

page 2

page 8

This week in AI

Get the week's most popular data science and artificial intelligence research sent straight to your inbox every Saturday.

1 Introduction

With the advancement of digital cameras and smart phones, billions of images have been stored in personal collections and shared in social networks. Due to the limitation and subjectivity of tags associated with images, methods that can categorize images based on visual information are required to manage such a huge volume of data. On the other hand, it is still a challenge to classify images when the number and the variety of images are large.

Figure 1: While image (a) can be described through semantic categories such as chair, table, floor, wood, image (b) can only be described with the help of low-level features such as color, texture.

Scene categorization has been attacked by many studies in computer vision and multimedia literature. Low-level features extracted over the entire image are commonly used to classify scenes, such as for indoor versus outdoor, or city versus landscape categorization

[1, 2, 3, 4]. Recently, Oliva and Torralba proposed to represent scenes with a set of holistic spatial scene properties, which are referred to as Spatial Envelope, such as degree of naturalness, openness, roughness, etc [5].

Histogram of quantized local descriptors, usually referred to as visual words, is shown as a simple but effective way for representation of scenes [6, 7, 8] as an alternative to global features. Spatial pyramid matching is proposed in [9] where histograms are computed for different levels of image partitions.

On the other direction, with the idea that semantics is not sufficiently captured by low-level features, object detector responses have been used as high-level representations [10, 11]. While the number of objects could reach to hundreds -thanks to recent availability of good detectors that can be generalized for a large variety of objects [12]-, the main drawback of object-based approaches is the requirement for manual labeling to train the object models. Moreover, it may be difficult to describe some image through specific objects.

Recently, use of attributes as mid-level representations has also gained attention [13, 14, 15]. Objects are described through a set of attributes that are shared between object categories, such as object parts (wheels, legs) or adjectives (round, striped). However, these methods also heavily depend on training to model human-defined attributes.

These problems bring us back to the discussion of semantic concepts for classification and retrieval of images and videos [16, 17]. How can we describe scenes through a set of intermediate representations? Should they correspond to only semantic categories? How many of those are required to capture all the details?

Let’s consider the images in Figure 1. The object names such as chair, table, floor, and the attributes such as wood are relatively easier to come up with in describing the scene. On the other hand, how much can we describe the image on the right with nouns or adjectives that can be learned through examples in training? How much information can be captured in both images through only low-level features such as the color or edge distribution?

We argue that, while the advantages of mid- or high-level semantic categories cannot be discarded, because of the high cost of training -even if we do not consider the question of definability-, it could be provided only in limited numbers. Therefore, low-level information, which is less-costly to obtain, should be taken advantage of. The main question is how can we melt representations with different characteristics in the same pool?

In this study, we introduce ConceptVision, in which we use the term concept for any type of intermediate representation, ranging from visual words to attributes and objects. We do not restrict ourselves with only semantic categories that can be described by humans, but consider also low-level representations. We handle the variations between different levels of concepts, by putting them into concept groups. Separate classifiers are trained for each concept group. The contributions of each concept group to the final categorization are provided in the form of confidence values that are ensembled through a set of methods for the final decision.

In the following, first we present our proposed method in Section 2. We describe the datasets used and discuss about the implementation details in Section 3. Section 4 shows our experimental results with ConceptVision and Section 5 provides comparisons with other methods.

2 Our Method

Figure 2: A visual representation of ConceptVision. In the training stage, concepts in each concept group are obtained from training images. Then, an individual classifier is trained for each concept group. Also, for each trained individual classifier, we compute a concept-priority value. In testing stage, a test image, represented by concepts, is fed to the individual classifier of each concept group. Class-confidence values of each classifier incorporated with the concept-priority values, are combined in the ensemble stage to make a final prediction.

As depicted in Figure 2

, ConceptVision brings the ability of using different levels of descriptors through the definition of concepts and concept groups. Low-level local or global descriptors could be quantized to obtain concepts in the form of visual words, and then concept group can be represented as Bag-of-Words. On the other hand, each object category could correspond to a concept, and as a whole the concept group could be represented through a vector of confidence values of object detectors.

ConceptVision is designed to allow the integration of different concept groups for classification. Note that our definition does not necessarily require concept groups to have any semantic meaning; we suppose that, with a capable combination technique, each concept group can add a different perspective for classification. Hence, the proposed framework tries to capture the perspective of each concept group and consider it during the final classification.

Our classification has two main parts; individual classification and ensemble of classifiers. Individual classification is applied to each concept group separately, and sequentially each classification result is combined in ensemble of classifiers stage before making a final prediction. Following sub-sections discuss these stages in more detail.

2.1 Individual Classification

To support our hypothesis of trying to examine the different perspectives of each concept group, we consider each group independently in the beginning. That is, we assume that the individual classification performance of a concept group has no effect on another, and should therefore be treated completely separately. This also allows us to have an agnostic classification method that can be used with any type of concepts.

In order to implement this idea, we train a separate, individual probabilistic classifier for each concept group. For a given image query, the role of each individual classifier is to give the probability of the image belonging to each class. In ConceptVision, we use probabilistic SVM as our classifier type. SVM is a popular classifier that is used widely in any area that involves machine learning. While the regular SVM outputs a single prediction class for a given query, a probabilistic SVM gives class-confidences, the probability of the query belonging to each class.

The individual classification phase is simple, and can be summarized in the following steps:

  1. Collect the extracted concepts for each concept group using the training set.

  2. Train a separate multi-class SVM classifier for each concept group.

  3. During the testing phase, apply concepts extracted from test set to the corresponding trained probabilistic SVM model. Output of the model gives the probabilities of query images belonging to each class.

2.2 Ensemble of Classifiers

Ensemble of classifiers is the most important stage of our framework. After training a separate classifier for each concept group, we must be able to combine them properly before making a final decision. Before making any further advancement, we must first answer a simple question. How do we consider each individual classifier? Do we consider them equally, or do we assign more priority to some of them than others? And if latter, what criteria should we use to assign more priority to an individual classifier?

We first examine the first option, not assigning any priorities to individual classifiers and treating them equally. This approach would simply take outputs of each classifier and combine them without making any other operations. However, just after a brief pondering we can intuitionally detect some flaws or misjudgments with this approach. First of all, how can we guarantee that each individual classifier will perform well? In fact, we cannot guarantee anything with unknown data, and a single poor- performing classifier would have the same contribution in the final decision making process as a well-performing classifier. This would include many noisy factors for the final prediction making; therefore we decide to explore the second approach, giving priorities to each individual classifier.

This brings us to the second question, how do we decide which individual classifier gets which priority? To answer this question, we must find a way to have an estimate on how a classifier would work on general unseen data, so we can assign more weight to decisions of those that are expected perform well, and less weight to those that are predicted to perform poorly.

We introduce the notation of concept-priority value. Concept-priority value is a value which serves as an estimate on how each classifier would perform generally. We find this value by performing a k-fold cross-validation on the training set using each each classifier and assigning the average accuracy value as the concept-priority value of the corresponding individual classifier.

Now that we have a generalized estimation for the performance of each individual classifier, we can weigh their outputs accordingly. Probability outputs of each single classifier is multiplied by its concept-priority value. After obtaining the weighted class-confidence probabilities from each classifier, we ensemble them together in the final step. At the end, the class that obtains the highest value is selected as the final prediction. Different techniques considered for the ensembling will be discussed in Section 4.

3 Implementation

To demonstrate the ConceptVision idea, it is desired to include concepts at different levels. In order to eliminate effort for the manual labeling of objects or attributes, we take the advantage of two datasets where the semantic categories are already available in some form. We performed our experiments on two different datasets, MIT Indoor [18] and SUN Attribute Dataset [19]. MIT Indoor Dataset is a challenging scene dataset because of its large intra-class variations and cluttered scenes. SUN Attribute Dataset contains a large number of images in a variety of scene categories. MIT Indoor Dataset was an appealing option, because of its pre- trained object models made available by Fei Fei Li et al. [10]. Sun Attribute Dataset meets our demands with its pre-trained 102 discriminative attribute classifiers.

3.1 MIT Indoor Dataset

MIT Indoor dataset contains 15620 images from 67 indoor categories. Categories do not have the same number of images, but each category has at least 100 images. Some of these categories are similar and hard to distinguish, such as kitchen and restaurant kitchen, corridor and lobby etc.

For our implementation in the MIT Indoor Dataset, we split the data into test and training sets using the recommended setup by its authors. We use 80 images from each class for training and 20 images from each class for testing. Our implementation on this dataset consists of using four concept groups.

While our framework supports any number of concept groups, to demonstrate our idea, we have only used four different types of concept groups for the MIT Indoor Dataset. These concept groups are well-known low-level features like PHOW [20], HOG [21], and OPP-PHOW , besides the object detection confidence values obtained using Object Bank [10] detectors.

3.2 SUN Attribute Dataset

Sun Attribute Dataset is a large scale dataset consisting of more than 700 categories and 14,000 images. Most of the categories are very similar to each other with little or no difference. This setup makes it extremely hard for scene recognition, caused by not having enough data for each category, and inter-class category similarity.

In order to make the scene recognition in this dataset more feasible for our task, we have decided not to work with original We have decided to use the images in the second-level hierarchy category that they belong to. Some of the examples of these categories are “indoor sport and leisure”, “outdoor natural water, ice, snow”, and “outdoor man-made sports fields, parks, leisure spaces”.

SUN Attribute Dataset dataset comes with a set of pre-computed visual features that is available on its website. Among these descriptors, we used HOG, SSIM, and Attribute Confidence Vectors. Please refer to the original paper [22] for more details).

4 Experiments

This section discusses our experiments and their results, and is divided into two parts; self-evaluation and comparison with others. In the first sub-section, we discuss our experiments with different configurations of ConceptVision, and show their results. Then in the second part, we compare the results of our method with other methods and discuss the differences.

4.1 Self Evaluation

In order to evaluate ConceptVision thoroughly, see its behavior by making slight changes and find the most efficient and simple version of our method, we experimented with various modifications. In this section, we discuss each modification, and compare their results that we obtained using MIT Dataset. We recommend reader to revisit Figure 2 in order to have a visual representation of our framework before reading this section.

4.1.1 Evaluation Using Different Ensemble Techniques

This section presents the possibilities of using different ensemble methods to combine vectors from different concept groups before using a classifier to make a final decision.

Confidence Summation without Weighted Classifier Ensemble: This version of our framework simply sums the confidence values obtained from classifiers of different concept groups. For the scenario of eliminating the weighted classifier ensemble step, we treat each classifier with equal importance and do not consider any weighting to their results. This approach can be disadvantageous when one or more classifiers do not perform well with the test data, and effect the final prediction in a negative way.

Confidence Summation with Weighted Classifier Ensemble: This scenario is an extended version of the configuration presented in the first bullet of this sub-section. For this configuration, before combining the confidence values of each classifier in the summation step, we multiply each of them by the corresponding class priority value, which is explained in Section 2. Using this approach, classifiers that are expected to perform poorly would have less negative impact on the final decision, and classifiers that are expected to perform well would have more positive impact.

Ranking without Weighted Classifier Ensemble: To experiment with a different ranking method we integrate a classic ranking system [23] to combine different features. Instead of using exact confidence values, we sort the confidence values of each class and rank each class in the order of preference. If we assume there are classes, the class with the highest confidence receives the rank , while the class with the lowest confidence receives 1. This quantizes the rank of each class to a whole number, but some information about the classifier results can be lost by avoiding the exact probabilities of each class. In our experiment, instead of summing up exact confidence values; we sum their ranks to come up with a final decision.

Ranking with Weighted Classifier Ensemble: This variety of ensemble methods weighs the class ranks from classifier by its concept-priority value, in order to avoid the possible issues that can rise from treating each classifier equally. As described in confidence summation with weighting, this approach hopes to assign appropriate weights to the classifiers that are expected to behave well or poorly.

Two-Layer Classifier as Ensemble: Another approach to combine results of individual classifiers is using another classifier as the ensemble method. The input of this classifier would be the output of the previous classifiers concatenated together. This approach has a danger of over-fitting on the second classifier.

Figure 3: The Results of Different Ensemble Techniques in Sun Attribute Dataset
Figure 4: The Results of Different Ensemble Techniques for MIT Indoor Dataset

The comparison of these approaches for SUN Attributes Dataset and MIT Indoor Dataset can be seen in Figure 3 and Figure 4 respectively. We can see that although changing the ensemble method did not have much effect in the Sun Attribute Dataset, the results of the MIT Indoor Dataset are more distinct. In MIT Indoor, ensembling concept groups using confidence summation and weighted methods is clearly more advantageous than using a ranking system or a non-weighted system. Using confidence- based methods reduces the probability of losing information classifier information, and class-priorities give each classifier their assumed generalized performance rate. We can argue for the same trend in SUN Attribute Dataset, but the difference of accuracies in SUN Attribute Dataset is much less. Two-layer Classifiers gives us the worst results for both datasets, because the second level classifier is extremely prone to over-fitting the output of the first layer classifier during the training stage, hence not working well in the testing stage.

4.1.2 Evaluation Using Different Number of Concept Groups

(a) MIT Indoor Dataset - Weighted Confidence Method
(b) SUN Attribute Dataset - Weighted Confidence Method
(c) MIT Indoor Dataset - Weighted Ranking Method
(d) SUN Attribute Dataset - Weighted Ranking Method
Figure 5: Experimental results for comparing ConceptVision with different numbers of concept groups.

The second different set of experiments we performed on ConceptVision was done by changing the number of different concepts used in each dataset. For individual classifiers, we use probabilistic SVM, and for ensemble of classifiers phase, we use the weighted versions of methods discussed in Section 4.1.1. SVM parameters are set using cross-validation on training data. Results for both datasets are reported in Figure 5.

Based on our experiments, we can also observe that the accuracy of the classifier also generally increases as we add more concept groups to our system. For both datasets, we obtain the best results by using the highest amount of concept groups. This can serve as a proof that the combination features from completely different concept groups can be beneficial to the overall classifier, and that our method makes use of this relation in a meaningful way.

4.1.3 Evaluation Using Different Classifiers

For this set of experiments, we used a fixed ensemble configuration and changed the type of our classifier in order to observe any different behaviors. We originally designed ConceptVision considering the popular Support Vector Machine classifier, however we believe it would also be necessary to see the performance of our framework using different classifiers. To test our framework, we also use Random Forests

[24] and Ada- Boost [25].

Ada-boost is a famous ensemble method relying on the ensemble of weak classifiers (ID3, Decision Stumps). Each weak classifier is weighted iteratively with respect to its classification accuracy compared to preceding ones, and they are trained with a weighted boosting approach where the probability of an instance being selected is proportional to its hardness of classification. Random Forests [24]

is a descendant of Ada-boost that also uses the group of different Decision Trees. Each decision tree is branched up to leaves by a randomly chosen subsample of the training data and each node is selected by any measure that considers randomly sampled features from the whole feature space.

Confidence Ranking
Random Forests 37.3% 32.3%
Ada-Boost 35.8% 33.9%
SVM 43.6% 43.2%
Table 1: Comparison of different classifiers on MIT Indoor Dataset.

For these two experiments, ensemble of SVMs gives better accuracy for the given datasets, as seen on Table 1 and 2. These results underline the fact that, LIBSVM’s [26] implementation of SVM outperforms the other two classifiers with its capability of constructing non-linear decision boundaries. Random Forests and Ada-Boost methods are based on weak classifiers dividing the decision space with linear boundaries.

Confidence Ranking
Random Forests 32.7% 33.3%
Ada-Boost 33.2% 34.7%
SVM 40.9% 39.6%
Table 2: Comparison of different classifiers on SUN Attribute Dataset.

4.2 Comparison with Other Studies

In this section we compare the results of ConceptVision from Section 4.1 with some of the other methods used in literature. Since the Sun Attribute Dataset is relatively recent and there are not many experimental results with it in the literature, we make our comparisons using the results obtained from MIT Indoor Dataset. You can see the comparisons on Table 3, and see the detailed explanations of the compared methods in the following sub-sections.

Method Accuracy
Feature Concatenation 9.48%
OB-LR [10] 37.6%
ConceptVISION 40.9%
Table 3: Comparison of ConceptVision with feature concatenation and Object Bank [10] in MIT Indoor Dataset.

For comparing with other methods, we designate the feature concatenation method as our baseline, and also compare ConceptVision with Object Bank [10], which we consider the state-of-art.

4.2.1 Object Bank

Object Bank [10] is a well known method with the idea of having a higher semantic level description of images, exposing scene’s semantic structure similar to human understanding of views. Although ObjectBank provides a good interpretation of the image, it produces a very high dimensional vectors, such as 42588 dimensions with the configuration in the original paper.

4.2.2 Feature Concatenation

Lastly, classical method to combine different concepts or features is to just concatenate them horizontally. This method is extremely simple and widely used, but it can have many disadvantages, such as resulting features being in very high dimensions. Also, combining features from very different concepts, such as low- level and high-level features, does not necessarily add any meaning for classification purposes, and can provide low results.

4.2.3 Results Comparison

When comparing our results with those of Object Bank and feature concatenation on MIT Indoor Dataset, we can see that our method performs better than Object Bank. Results of the comparison can be seen Table 2. The results of feature concatenation performing poorly are not surprising, as we had expected a large concatenation of features from different levels not to perform well. In the second comparison, our method performs actually better than Object Bank on this dataset, without having an as complex object representation as Object Bank does. This shows us that, when combining different concept groups from different levels, their resulting accuracy can be higher than using one of the concepts groups.

5 Discussion and Feature Work

We proposed ConceptVision as a framework for combining concept groups from many different levels and perspective for the purpose of scene categorization. The proposed framework provides flexibility for supporting any type of concept groups, such as those that have semantic meanings like objects and attributes, or low-level features that have no meanings semantically but can provide important information about the structure of an image. There is no limit in the definition of concepts, and it is easy to be expanded through inclusion of any other intermediate representation describing the whole or part of the image in content or semantics.

Although our work can be further improved in many ways, the experimental results from Section 4 look very promising. We show that individual concept group classification accuracies are lower compared to their combination with ConceptVision framework. Furthermore, as we improve the number of concept groups that are used, we also obtain higher accuracies. This can be seen especially in the MIT dataset, where even a concept group like the object representation, which has a poor accuracy overall, increases the overall accuracy when combined with the other low- level features.

Another conclusion we can derive from our experiments is that weighting the results of each individual classifier by its class- priority value also improves the overall accuracy. This can also be seen by our experiments, where the weighted versions of both ensemble methods provide better results than their non-weighted version for both datasets.

Although we are encouraged by its results, we must also express that ConceptVision is far from perfect and there are many improvements that can be made on top of it. Our framework examines each concept group on the same level, by assuming that their classification models are completely independent from each other. We can extend our framework by modifying this idea, and establishing dependence between each concept group by their semantic meanings. This way, we would still be able to incorporate all kinds of concepts groups from different levels, but we would use them in different hierarchical levels in more meaningful way.

References

  • [1] M. Szummer and R. W. Picard, “Indoor-outdoor image classification,” in In IEEE Intl. Workshop on Content-Based Access of Image and Video Databases, 1998.
  • [2] A. Vailaya, A. Member, M. A. T. Figueiredo, A. K. Jain, H.-J. Zhang, and S. Member, “Image classification for content-based indexing,” IEEE Transactions on Image Processing, vol. 10, pp. 117–130, 2001.
  • [3] A. Payne and S. Singh, “Indoor vs. outdoor scene classification in digital photographs,” Pattern Recogn., vol. 38, pp. 1533–1545, Oct. 2005.
  • [4] N. Serrano, A. E. Savakis, and J. Luo, “A computationally efficient approach to indoor/outdoor scene classification.,” in ICPR (4), 2002.
  • [5] A. Oliva and A. Torralba, “Modeling the shape of the scene: A holistic representation of the spatial envelope,” Int. J. Comput. Vision, vol. 42, pp. 145–175, May 2001.
  • [6] P. Quelhas, F. Monay, J. M. Odobez, D. Gatica-Perez, and T. Tuytelaars, “A thousand words in a scene,” IEEE Trans. Pattern Anal. Mach. Intell., vol. 29, pp. 1575–1589, Sept. 2007.
  • [7] F.-F. Li and P. Perona, “A bayesian hierarchical model for learning natural scene categories,” in CVPR, 2005.
  • [8] A. Bosch, A. Zisserman, and X. Muñoz, “Scene classification using a hybrid generative/discriminative approach,” IEEE Trans. Pattern Anal. Mach. Intell., vol. 30, pp. 712–727, Apr. 2008.
  • [9] S. Lazebnik, C. Schmid, and J. Ponce, “Beyond bags of features: Spatial pyramid matching for recognizing natural scene categories,” in CVPR, 2006.
  • [10] E. P. X. Li-Jia Li, Hao Su and L. Fei-Fei, “Object bank: A high-level image representation for scene classification & semantic feature sparsification,” in NIPS, 2010.
  • [11] L.-J. Li, H. Su, Y. Lim, and L. Fei-Fei, “Objects as attributes for scene classification,” in ECCV, 2012.
  • [12] A. Farhadi, I. Endres, D. Hoiem, and D. Forsyth, “Describing objects by their attributes,” in CVPR, 2009.
  • [13] C. H. Lampert, H. Nickisch, and S. Harmeling, “Learning to detect unseen object classes by betweenclass attribute transfer,” in In CVPR, 2009.
  • [14] L. Torresani, M. Szummer, and A. Fitzgibbon, “Efficient object category recognition using classemes,” in ECCV’10, 2010.
  • [15]

    J. Vogel and B. Schiele, “Semantic modeling of natural scenes for content-based image retrieval,”

    Int. J. Comput. Vision, vol. 72, pp. 133–157, Apr. 2007.
  • [16] A. Hauptmann, R. Yan, W.-H. Lin, M. Christel, and H. D. Wactlar, “Can high-level concepts fill the semantic gap in video retrieval? a case study with broadcast news.,” IEEE Transactions on Multimedia, vol. 9, no. 5, pp. 958–966, 2007.
  • [17] J. Smith, M. Naphade, and A. Natsev, “Multimedia semantic indexing using model vectors,” in ICME, 2003.
  • [18] A. Quattoni and A. Torralba, “Recognizing indoor scenes,” 2009.
  • [19] G. Patterson, “Sun attribute database: Discovering, annotating, and recognizing scene attributes,” in CVPR, 2012.
  • [20] A. Bosch, A. Zisserman, and X. Muñoz, “Image classification using random forests and ferns,” in ICCV, 2007.
  • [21] N. Dalal and B. Triggs, “Histograms of oriented gradients for human detection,” in CVPR, 2005.
  • [22] J. Xiao, J. Hays, K. A. Ehinger, A. Oliva, and A. Torralba, “Sun database: Large-scale scene recognition from abbey to zoo,” in CVPR, 2010.
  • [23] T. K. Ho, J. J. Hull, and S. N. Srihari, “Decision combination in multiple classifier systems,” IEEE Trans. Pattern Anal. Mach. Intell., vol. 16, pp. 66–75, Jan. 1994.
  • [24] L. Breiman, “Random forests,” Mach. Learn., vol. 45, pp. 5–32, Oct. 2001.
  • [25] Y. Freund and R. E. Schapire, “A decision-theoretic generalization of on-line learning and an application to boosting,” in EuroCOLT, 1995.
  • [26] C.-C. Chang and C.-J. Lin, “LIBSVM: A library for support vector machines,” ACM Transactions on Intelligent Systems and Technology, vol. 2, pp. 27:1–27:27, 2011.
