Computationally Efficient Modulation Level Classification Based on Probability Distribution Distance Functions

12/24/2010 ∙ by Paulo Urriza, et al. ∙ 0

We present a novel modulation level classification (MLC) method based on probability distribution distance functions. The proposed method uses modified Kuiper and Kolmogorov-Smirnov distances to achieve low computational complexity and outperforms the state of the art methods based on cumulants and goodness-of-fit tests. We derive the theoretical performance of the proposed MLC method and verify it via simulations. The best classification accuracy, under AWGN with SNR mismatch and phase jitter, is achieved with the proposed MLC method using Kuiper distances.



There are no comments yet.


page 1

page 2

page 3

This week in AI

Get the week's most popular data science and artificial intelligence research sent straight to your inbox every Saturday.

I Introduction

Modulation level classification (MLC) is a process which detects the transmitter’s digital modulation level from a received signal, using a priori knowledge of the modulation class and signal characteristics needed for downconversion and sampling. Among many modulation classification methods [1], a cumulant (Cm) based classification [2] is one of the most widespread for its ability to identify both the modulation class and level. However, differentiating among cumulants of the same modulation class, but with different levels, i.e. 16QAM vs. 64QAM, requires a large number of samples. A recently proposed method [3] based on a goodness-of-fit (GoF) test using Kolmogorov-Smirnov (KS) statistic has been suggested as an alternative to the Cm-based level classification which require lower number of samples to achieve accurate MLC.

In this letter, we propose a novel MLC method based on distribution distance functions, namely Kuiper (K) [4] [5, Sec. 3.1]

and KS distances, which is a significant simplification of methods based on GoF. We show that using a classifier based only on K-distance achieves better classification than the KS-based GoF classifier. At the same time, our method requires only

additions in contrast to additions for the KS-based GoF test, where is the number of distinct modulation levels, is the sample size and is the number of test points used by our method.

Ii Proposed MLC Method

Ii-a System Model

Following [3], we assume a sequence of discrete, complex, i.i.d. and sampled baseband symbols, , drawn from a modulation order

, transmitted over AWGN channel, perturbed by uniformly distributed phase jitter and attenuated by an unknown factor

. Therefore, the received signal is given as , where , and . The task of the modulation classifier is to find , from which was drawn, given . Without loss of generality, we consider unit power constellations and define SNR as .

Ii-B Classification based on Distribution Distance Function

The proposed method modifies MLC technique based on GoF testing using the KS statistic [3]

. Since the KS statistic, which computes the minimum distance between theoretical and empirical cumulative distribution function (ECDF), requires

all CDF points, we postulate that similarly accurate classification can be obtained by evaluating this distance using a smaller set of points in the CDF.

Let where is the chosen feature map and is the number extracted features. Possible feature maps include (magnitude, ) or the concatenation of and (quadrature, ). The theoretical CDF of given and , , is assumed to be known a priori (methods of obtaining these distributions, both empirically and theoretically, are presented in [3, Sec. III-A]). The CDFs, one for each modulation level, define a set of test points


with the distribution distances given by


for , , and , corresponding to the maximum positive and negative deviations, respectively. Note the symmetry in the test points such that . Thus, there are test points for a order classification.

The ECDF, given as


is evaluated at the test points to form , . Here, equals to one if the input is true, and zero otherwise. By evaluating only at the test points in (1), we get


which are then used to find an estimate of the maximum positive and negative deviations


of the ECDF to the true CDFs. The operation of finding the ECDF at the given testpoints (4) can be implemented using a simple thresholding and counting operation and does not require samples to be sorted as in [3]. The metrics in (5) are used to find the final distribution distance metrics


which are the reduced complexity versions of the KS distance (rcKS) and the K distance (rcK), respectively111Note, that other non-parametric distances used in hypothesis testing exist (see introduction in e.g. [4]), although for brevity they are not addressed here. We note, however, that our approach is easily applied to any assumed distance metric.. Finally, we use the metrics in (6) as substitutes to the true distance-based classifiers with the following rule: choose such that


In the remainder of the letter, we define and , where .

Ii-C Analysis of Classification Accuracy

Let denote the set of test points, , sorted in ascending order. For notational consistency, we also define the following points, and . Given that these points are distinct, they partition into regions. An individual sample, , can be in region , such that , with a given probability, determined by .

Assuming are independent of each other, we can conclude that given , the number of samples that fall into each of the regions,

, is jointly distributed according to a multinomial PMF given as


where , and is the probability of an individual sample being in region . Given that is drawn from , , for .

Now, with particular , the ECDF at all the test points is


Therefore, we can analytically find the probability of classification to each of the classes as


for the rcK classifier. A similar expression can be applied to rcKS, replacing with in (10).

Ii-D Complexity Analysis

Given that the theoretical CDFs change with SNR, we store distinct CDFs for SNR values for each modulation level (impact of the selection of on the accuracy is discussed further in Section III-B.) Further, we store theoretical CDFs of length each. For the non-reduced complexity classifiers that require sorting samples, we use a sorting algorithm whose complexity is . From Table I, we see that for rcK/rcKS tests use less addition operations than K/KS-based methods [3] and Cm-based classification [2]. For , the rcK method is more computationally efficient when implemented in ASIC/FPGA, and is comparable to Cm in complexity when implemented on a CPU. In addition, the processing time would be shorter for an ASIC/FPGA implementation, which is an important requirement for cognitive radio applications. Furthermore, their memory requirements are also smaller since has to be large for a smooth CDF. It is worth mentioning that the authors in [3] used the theoretical CDF, but used as the number of samples to generate the CDF in their complexity figures. The same observation favoring the proposed rcK/rcKS methods holds for the magnitude-based (mag) classifiers [3, Sec III-A].

Method Multiply Add Memory
rcKS/rcK (mag)
KS/K (mag)
TABLE I: Number of Operations and Memory Usage

Iii Results

As an example, we assume that the classification task is to distinguish between M-QAM, where . For comparison we also present classification result based on maximum likelihood estimation (ML).

Iii-a Detection Performance versus SNR

In the first set of experiments we evaluate the performance of the proposed classification method for different values of SNR. The results are presented in Fig. 1. We assume fixed sample size of , in contrast to [3, Fig. 1] to evaluate classification accuracy for a smaller sample size. We confirm that even for small sample size, as shown in [3, Fig. 1], Cm has unsatisfying classification accuracy at high SNR. In (10,17) dB region rcK clearly outperforms all detection techniques, while as SNR exceeds 17 dB all classification methods (except Cm) converge to one. In low SNR region, (0,10) dB, KS, rcKS, rcK perform equally well, with Cm having comparable performance. The same observation holds for larger sample sizes, not shown here due to space constraints. Note that the analytical performance metric developed in Section II-C for rcK and rcKS matches perfectly with the simulations. For the remaining results, we set  dB, unless otherwise stated.

Fig. 1: Effect of varying SNR on the probability of classification with =50; (an.) – analytical result using (10).
