1 Introduction

Pre-training of artificial neural networks on available large-scale datasets offers a mechanism to reduce the need for excessive training data for the application at hand – simply by transferring features from large-scale databases to datasets covering restricted domains with limited data. This allows models with small quantities of data to still fair exceptionally well in objective performance metrics. Pre-training has become increasingly popular in the computer vision community owing to a substantial rise in the availability of large-scale datasets like ImageNet

Russakovsky et al. (2015). Since such natural image datasets have been widely accepted and lead to strong results with natural testing data, we might assume that images most closely resembling natural objects achieve maximum performance. However, since these natural images have to be manually labeled, their production is prone to errors and extremely labor-intensive. Recently, Kataoka et al. (2020)

countered the notion that pre-training can only be performed on natural images and proposed pre-training on 2D fractals. For most datasets, such pre-training led to performance comparable to models pre-trained on ImageNet and for some it even exceeds their performance.

We propose a novel technique for pre-training with a strong 3D inductive bias, which we plan to pursue this by replacing 2D fractals with procedurally generated 3D meshes rendered under various illumination conditions and poses. Rendering multiple images from a single mesh permits determining the type and magnitude of the variation to be implemented on a single object. It paves the way to generate massive numbers of images per class without manual labeling of images and the potential human error accompanying it. The dataset produced will then be used in a classification setting where the training objective is to identify the correct class for a fractal or 3D object independent of deformations or camera and illumination variation. We expect the 3D nature of our generated images to lead to a different inductive bias than the 2D fractals and expect networks pre-trained on 3D objects to generalize better to complex visual tasks, including object detection.

Intermediate features in convolutional neural networks (CNNs) optimized for visual tasks bear a notable resemblance to the hierarchy of neural activity along the primate ventral visual stream, which supports object recognition

Yamins et al. (2014). Since our network will be trained using 3D variations, a thought-provoking question arises: Do models trained on 3D renders better match neural activity along the primate ventral stream than models trained with 2D images? We will pursue experiments to explicitly study this question, comparing the relative linear fits between 2D/3D model features and brain activity from monkeys and humans. In addition, our 3D data generation process enables generation of 2D data (by removing all pose variation) and even enables the removal of 3D cues (by removing all illumination variation), allowing us to disentangle 2D and 3D properties of the primate visual system. Giving precedent to the computer vision aspect of the research which is to achieve better transfer learning performance compared to the 2D approach, we will also study whether an inductive bias towards 3D better predicts brain activity.

Since the natural image formation process is 3D, we hypothesize that our method will learn better low- and high-level features which better generalize for visual learning tasks and also match the brain data better than the 2D fractal work of Kataoka et al. (2020). We propose the following steps to pursue this study:

  1. Generate synthetic object renders based on simple algorithms by attributing few meshes to each class and rendering them under various viewpoints and illumination conditions. We will use various combinations of datasets formed from 2D and 3D data.

  2. Train and evaluate artificial neural networks using 2D and 3D datasets following the protocol of Kataoka et al. (2020) and focus on the transfer learning capabilities on a set of image classification tasks and measure the performance of our models.

  3. Evaluate brain predictability of the networks pre-trained based on those datasets to investigate if a 3D inductive bias produces networks that better resembles brain activity.

2 Related work

2.1 Rendering and procedural meshes

The generation of synthetic data is popular for various computer vision tasks e.g. Gan et al. (2020); Kortylewski et al. (2018). The goal of 3D rendering is usually to simulate the 3D world closely and accurately using high-quality assets (e.g. in Wood et al. (2021)). The idea of domain randomization uses 3D assets, but starts to randomize texture and illumination Tremblay et al. (2018) leading to non-realistic appearance. In contrast, our approach builds on easy to generate assets based on procedural strategies. Today, fractals are the most popular procedural structures for pre-training – most, however, are 2D. Procedural 3D meshes are commonly used in the entertainment industry e.g. to generate landscapes Olsen (2004).

2.2 Pre-training datasets

Conventionally, pre-training of CNNs has been performed on large-scale natural image datasets Krizhevsky et al. ; Deng et al. (2009); Zhou et al. (2017). As noted by Huh et al. (2016), this practice of first training a network to perform image classification on large-scale datasets (i.e. pre-training) and then transferring the extracted features for a completely new work (i.e. fine-tuning) has become the rule of thumb for solving a wide range of computer vision problems. The development of denser and deeper supervised CNN architectures Krizhevsky et al. (2012); He et al. (2016); Huang et al. (2017); Simonyan and Zisserman (2015) has unquestionably impacted pre-training Krizhevsky et al. (2012). While such models function at the mere cost of more computational resources, they have substantially amplified performance metrics since they extract a huge number of perceptive features at various hierarchies and iterations.

Most approaches rely on large-scale real world datasets for pre-training. In contrast, Kataoka et al. (2020) proposed to solely train on synthetically generated images which are derived from simple rules (fractals). Their method used one formula to generate one class, and used data augmentation to increase the number of images in the category. This approach performed very well in comparison to pre-training with natural-image datasets. Our method is different from it since we use 3D procedural and morphable models to generate different 3D objects as classes and render them under different viewpoints and illumination conditions to obtain multiple images per class.

2.3 Computational models for biological vision

CNN features explain appreciable variance in monkey and human neural activity, and the layer hierarchy in CNNs maps onto the ventral stream hierarchy, which underlies primate object recognition

Yamins et al. (2014). These general findings have been replicated across species (monkeys, humans), imaging modalities (electrophysiology, fMRI, MEG, EEG), and stimulus types (objects, scenes, faces) Yamins and DiCarlo (2016); Richards et al. (2019). Since we assume that the primate brain’s neural tuning develops to capture the 3D structure of the world, we hypothesize that pre-training with the 3D dataset will produce CNN features that better explain activity in high level brain area than pre-training with 2D datasets like Kataoka et al. (2020).

3 Methodology

Our approach explores different combinations of synthetic datasets. We use FractalDB Kataoka et al. (2020) as a 2D baseline dataset (Fig. 1). Two 3D datasets will be built, namely ProcSynthDB (Fig. 2) and MorphSynthDB (Fig. 3). While the FractalDB uses a 2D fractal-based approach with 2D data augmentation for image generation, our proposed two synthetic 3D datasets build on three-dimensional procedural methods to generate 3D meshes per class and renders them under a variety of viewpoints and illumination conditions. A brief overview of the dataset comparisons can be found in Table 1 We will add results of standard ImageNet trained networks (AlexNet, VGG, ResNet-50) as baseline to our comparison.

Figure 1: Fractal images from Kataoka et al., 2020 Kataoka et al. (2020). This dataset is built using different fractal rules and image-based data augmentation. The dataset provides up to 10k different fractals (classes) and 1k images per class.

3.1 ProcSynthDB

For every class, we start off by creating a base mesh from simple building blocks (sphere, cylinder, cube etc.) and using various wireframes, smootheness, skin on them. Each base mesh should be different enough to visually classified as belonging to a separate class. Our first approach uses perspective to create alterations in renders by changing the 3D viewpoint as well as the illumination conditions it is subjected to. This enables to get multiple images per mesh with a strong 3D-based variation in appearance. In the rendering process, we also change the the size of the mesh twice across one single axis so that it produces natural-looking modifications. We describe the exact procedure to generate the meshes in pseudo-code in Algorithm

1 and examples of resulting shapes are found in Fig. 2.

Figure 2: Example images of ProcSynthDB objects from different classes. In addition to the proceduraly created class, we change the viewpoint and illumination conditions.
input : number of meshes , , ,
output :  synthetic 3D meshes
;
while  do
       /* Add several primitives with random parameters and modifiers */
       ;
       for  to  do
             for  do
                   for  to random(0,w) do
                         add with random parameters to the scene ;
                         randomly modify mesh with wireframe or subdivide modifier or not ;

                   end for

             end for

       end for
      /* Quality Control to remove objects over the maximum size */
       if  then
              save mesh from all objects ;

       end if
      delete all objects ;

end while
Algorithm 1 Generation of ProcSynthDB Meshes

3.2 MorphSynthDB

Our second 3D render dataset builds on ProcSynthDB and explores Gaussian process deformation models Lüthi et al. (2017) for shape and texture variation Sutherland et al. (2021). We will start from the first 100 ProcSynthDB meshes and add random shape and color variation to them to obtain new shapes with additional variation in color. We use the implementation of Sutherland et al. (2021) but with higher strength of the shape variation for the shape Gaussian processes. In particular we changed the magnitude of the following shape and albedo parameters (original value in brackets) . Since this procedure is sensitive to large number of vertices we downsample the meshes before applying the transformations. Examples of resulting shapes are found in Fig. 3.

Figure 3: Example images of MorphSynthDB objects from different classes. In addition to shape variation based on Gaussian processes, this dataset also includes texture variation.
Database View Dimensionality Colored Illumination Variation
ProcSynthDB 3D
MorphSynthDB 3D
FractalDB 2D
Table 1: Overview of database compositions

3.3 Pre-training and subsequent fine-tuning

We will use the ResNet-50 architecture He et al. (2016) for pre-training our models across all dataset combinations. Our process will stay restricted to supervised multi-class classification. We will change the training phase of the model with our dataset leaving the fine-tuning step untampered, as proposed in Kataoka et al. (2020)

. For the sake of maintaining a uniform comparison, we will perform a hyperparameter search based on cross-validation for each set of network and data and will search around the values derived in

Kataoka et al. (2020).

3.4 Comparing models to brain data

To assess the similarity between features in the procedural 2D and 3D models and brain activity, we will use linear regression to predict neural responses from monkeys and humans from model features

Kay et al. (2008). The general procedure is as follows: 1.) model features are computed for the images used to measure neural responses, 2.) using 10-fold cross-validation, partial least squares regression will be used to learn a linear mapping from model features to neural activity, and 3.) using the held-out data, the overall fit between a given model and neural responses will be quantified as the correlation between the predicted and true neural responses Yamins et al. (2014). This final correlation between true and predicted responses constitutes the neural predictivity of a given model for the targeted brain region. We will also perform Representational Similarity Analysis (RSA) to measure the similarity between our computational model and brain activity.

4 Experimental protocol

4.1 Combinations of the pre-training datasets

For our experiments, we pre-train our models using the two 3D render databases we produced i.e. the ProcSynthDB and MorphSynthDB; and the third 2D baseline FractalDB. We will carry out our experiments on varied combinations achieved by incorporating these three datasets by utilizing six permutations of our them, as shown in Table 2.

Dataset combinations for pre-training No. classes from each subdataset
FractalDB 1000
ProcSynthDB 1000
MorphSynthDB 1000
ProcSynthDB + FractalDB 500
ProcSynthDB + MorphSynthDB 500
ProcSynthDB + MorphSynthDB + FractalDB 333
Table 2: Combinations of the three datasets to be used during pre-training. We aim at a total of 1000 classes for each combination and will mix them uniformly. For each class we will generate 1000 images following the protocol of FractalDB Kataoka et al. (2020).

Kataoka et al. (2020) re-iterated the well-established fact that the performance achieved by pre-training models is in proportion to an increase in the number of classes and the number of objects or images per class. Therefore, for the sake of uniform recordings and to maintain a category-instance ration, we use 1000 category × 1000 instances per category for all datasets and combinations.

4.2 Transfer learning

We will pre-train ResNet-50 He et al. (2016) using all dataset combinations defined in Table 2. Then, we will fine-tune the models on secondary tasks (natural image datasets, Table 3) to assess their transfer learning performance. For the transfer learning experiments we will closely follow the protocol of Kataoka et al. (2020). Better transfer performance after pre-training on any of our 3D object datasets relative to the 2D fractal datasets would support our hypothesis that pre-training with a strong 3D inductive bias will more closely capture the statistics of natural images. In addition to this quantitative evaluation we will also visualize the learned features of the resulting models similar as in Kataoka et al. (2020) and compare them to features derived from ImageNet trained models.

Test datasets CIFAR 10 CIFAR 100 ImageNet 1K Places 365 Pascal VOC 2012 Omniglot
Table 3: We will use these datasets for our transfer learning evaluation of the models trained with the datasets in Table 2. Those testing datasets are also used in the FractalDB work Kataoka et al. (2020).

4.3 Comparing models to brain data

The monkey neural responses Majaj et al. (2015) were measured for a set of 2560 images of rendered objects with multi-array electrophysiology from areas V4 (an intermediate visual area) and IT (a late-stage ventral stream area that represents high-level object properties). For this data, we predict that 2D models will better predict V4 responses, while 3D models will better predict IT responses.

The human neural responses Allen et al. (2021) were measured for a large set of 10k+ natural images per subject with functional Magnetic Resonance Imaging (fMRI). For these analyses, we will target early (V1, V2), mid (V3, V4), and late (LO, PfS) stages of the ventral stream. We predict that the 2D models will best predict responses in early- and mid-level regions, while the 3D models will best predict responses in late regions.

4.4 Ablation study

One of the key concerns of our method could be that the observed differences could be caused by the different techniques to generate the datasets. To overcome this limitation we will generate a 3D based dataset that has all the 3D variation removed - it will not contain illumination and pose variation and will therefore be a 2D dataset based on 3D data. For this ablation study we will ablate the best performing 3D dataset and build such a 2D variant and name it FlatWorldDB.

5 Conclusion

We propose a strategy to perform supervised classification using synthetic images rendered from 3D meshes. We will investigate the influence of 3D vs. 2D inductive bias via varying the set of fully synthetic databases. Additionally, we will compare the effects of the data-generation methods on a CNN’s performance after transfer learning, on brain predictivity, and their similarity to each other. The goal of this research is not to outperform ImageNet trained models but to measure relative differences resulting from 2D vs. 3D pre-training.
