An Effective Single-Image Super-Resolution Model Using Squeeze-and-Excitation Networks

10/03/2018 ∙ by Kangfu Mei, et al. ∙ Jiangxi Normal University 0

Recent works on single-image super-resolution are concentrated on improving performance through enhancing spatial encoding between convolutional layers. In this paper, we focus on modeling the correlations between channels of convolutional features. We present an effective deep residual network based on squeeze-and-excitation blocks (SEBlock) to reconstruct high-resolution (HR) image from low-resolution (LR) image. SEBlock is used to adaptively recalibrate channel-wise feature mappings. Further, short connections between each SEBlock are used to remedy information loss. Extensive experiments show that our model can achieve the state-of-the-art performance and get finer texture details.

READ FULL TEXT VIEW PDF
POST COMMENT

Comments

There are no comments yet.

Authors

page 9

This week in AI

Get the week's most popular data science and artificial intelligence research sent straight to your inbox every Saturday.

1 Introduction

Single-image super-resolution(SISR) is a popular computer vision problem, which aims to reconstruct a high-resolution (HR) image from a low-resolution(LR) image. However, SISR is still considered as an ill-posed inverse problem due to high-level information loss during image downsampling. To solve this problem, many algorithms have been proposed.

Early methods [17, 19, 21, 20, 15]

, besides bicubic and bilinear interpolation, learned the mapping from LR to HR pairs directly by sacrificing certain accuracy or speed for improvements. Super-Resolution Convolutional Neural Network (SRCNN) proposed by Dong et al.

[3]

was the first successful model that adopted CNN structure to solve SISR problem and obtained great performance improvement. In SRCNN, convolutional neural network was used to learn non-linear mapping from each LR vector to a set of HR vector. Due to the outstanding performance of SRCNN, several deeper and more complicated models has been proposed to follow it, such as VDSR proposed by Kim et al.

[8]. Though VDSR achieved excellence performance, its speed remained slow speed as it use a very deep residual convolutional network and an upscale image preprocess.

To avoid the complexities of feature extraction network and upscale preprocess, Shi et al.

[16] replaced upscale preprocess with sub-pixel convolution layers. The sub-pixel layers could produce HR image from feature maps directly with a set of up-scaling filters. This architecture greatly improved the speed of networks. Therefore, following the strategy of up-sampling layer, Ledig et al. [12] further proposed a SRResNet with a very deep ResNet [5] architecture. Lai et al. [11] proposed the LapSRN, which use learned kernel as up-sampling unit to direct produced SR images.

In spite of great success achieved in the above architectures, the main issue that how to model mapping from LR to HR images better in a fast and flexible way remained unsolved. In this paper, we have proposed a Super-Resolution Squeeze-and-Excitation Network (SrSENet) for SISR. The concept of SEBlock [6] is employed to better modeling interdependencies between channels. Short connections from input to each SEBlock are used to remedy information lost. And different deconvolution layers are used for different scales under the same feature extraction architecture. The proposed method is evaluated on some popular publicly available benchmarks. Extensive experiments show that our proposed model can achieves competitive accuracy in a more accurate and flexible way. It can greatly reduce model’s complexity by using less layers and allow designing more flexible applications.

The contributions of this paper are two folds:

  • We have introduced an effective super-resolution network with SEBlock. It performs dynamic channel-wise feature recalibration to provide a new powerful architecture to improve the representational ability of information extraction part from low-resolution images.

  • We have set up a new state-of-the-art super-resolution method with fast running speed and accurate result in the measurement of PSNR and SSIM without increasing the complexity of the network, especially in case of large upscale rate.

2 Related Work

2.1 Single-Image Super-Resolution

In this section, we are mainly concentrated on reviewing mainstream deep learning based single-image super-resolution methods. Typically, a SISR network could be approximately divided into two parts. The first part could be seen as a feature extraction block, which is composed of many stacked convolutional layers. The second part records up-scaling information from LR images to HR images. Recent works are concentrated on improving the first part by changing the way of skip connections between inputs of each layer. In other words, they focus on changing the proportion of information captured by initial layers.

Figure 1: Comparisons on network architectures of four typical deep learning based SISR categories.

We group mainstream deep learning based SISR models into four categories, as shown in Figuree 1. The (a) category contains feature extraction, such as network in [3]. The (b) category like [8] introduces short connection as residual-learning. The (c) category like accepts input in each feature extraction layer. Our proposed model could be categorized into the last category (d). The difference from the other three categories is that each extraction layer block receives input before channel-wise modeling. In this way, network could better learn mapping between LR-HR images.

2.2 Squeeze-and-Excitation Channel

Different from works on enhancing spatial encoding, SENet [6] was proposed to fully capture channel-wise dependencies through adaptive recalibration. The SENet was separated into two steps, squeeze and excitation, to explicitly model channel interdependencies.

Figure 2: Our proposed Network architectures of SrSENet in upscale of 4x. Blue blocks represent a Convolutional layer. Yellow blocks represent a LeakRelu layer. Green Blocks represent a Transposed Convolutional layer.

After initial images were input into the first convolution layer, the output feature

was passed to a SEBlock to do squeeze and excitation operator. The squeeze operator was used to embed information from global receptive field into a channel descriptor in each layer. Then a sigmoid activation function and FC layer were later used to gain nonlinear interaction between each layers. The squeeze operator produced a sequence S in

which represented the correlations of each layer. The excitation operator later was employed to perform feature recalibration through reweighting the original feature mappings

where refers to the parameters of the -th filter and denotes the element of -th channel descriptor. This architecture can help feature extaction parts better caputre the information from input to output. In our work, we combined SEBlock with ResNet for feature extraction.

2.3 Transposed Convolutional Layer

In order to obtain super-resolution images, a simple idea is to upscale original image first, then final HR image is directly generated from the resulted scaled image. It is not difficult to find that this kind of strategy wastes much time on preprocessing without any obvious advantage.

Shi et al. [16] first proposed to use sub-pixel convolution layer to produce HR images directly. It upscale a LR image by periodic shuffling the elements of a tensor to a tensor of shape . However, it didn’t make full use of the correspondence information from LR to HR. LapSRN [11] was proposed by to use a multiple transposed convolutional layer to deal with different upscale rate in a progressive way. Without any preprocessing step like upscale, LapSRN achieved more accurate information between LR and HR in a fast way.

Following previous works, we use transposed convolutional layer with different parameters for different upscale rate, which can keep network simple and improve the power of networks to record reconstruction information.

3 Proposed Method

The proposed method aims to extract information from the LR image and learn mapping function from feature maps to HR images . We describe with channels in size of . With upscale rate , is in size of . Our ultimate goal is to minimize the loss between the reconstructed images and the corresponding ground truth HR images. In the following, we will describe the details of the proposed method.

3.1 Network Architecture

Our proposed method is inspired from SRResNet [12] and LapSRN [11]. Following LapSRN, our model contains two parts: residual learning stage and image reconstruction stage, as shown in Figure 2.

Unlike SRResNet and LapSRN, in the residual learning stage, we introduced SrSEBlock to extract features from LR images. The SrSEBlock structure integrates ResNet and SENet, which can better capture information from inputs and better modeling interdependencies between channels.

As VDSR [8] suggested, in the SR ill-posed problem, surrounding pixels were useful to correctly infer center pixel. With larger receptive field a SR model has, it could use more contextual information from LR to better learn correspondences from LR to HR. In our proposed network, the filters of SrSEBlock is in size of . Therefore, in case of depth D layer, its receptive field could be seen as in the original image space. The bigger receptive field means our network can use more context to reconstruct images.

As we know, with the increase of network depth, gradient disappearance or explosion will occur during training and the high-frequency information will also disappear. So, we introduce a short connection between SrSEBlocks which can receive input information before channel-wise modeling.

In the proposed network, we employ 8 SrSEBlocks to generate a feature mapping, and then we employ a transposed layer to transform the resulted mapping directly into a residual image by applying a deconvolutional layer. On different upscale rates, we don’t increase the number of deconvolution layers, just directly change parameters such as the kernel size, stride and padding steps, to obtain corresponding residual image. In image reconstruction stage, the up-sampled LR image feature mappings and the learned residual feature mappings are added together to reconstruct HR image. By using residual image learning, network converges efficiently. The final feature mapping is output directly as the SR image.

Figure 3: The architecture of SELayer.
