Large-scale knowledge bases (KBs), such as YAGO (Suchanek et al., 2007), Freebase (Bollacker et al., 2008) and DBpedia (Lehmann et al., 2015), are usually databases of triples representing the relationships between entities in the form of fact (head entity, relation, tail entity) denoted as (h, r, t), e.g., (Melbourne, cityOf, Australia). These KBs are useful resources in many applications such as semantic searching and ranking (Kasneci et al., 2008; Schuhmacher and Ponzetto, 2014; Xiong et al., 2017), question answering (Zhang et al., 2016; Hao et al., 2017) and machine reading (Yang and Mitchell, 2017). However, the KBs are still incomplete, i.e., missing a lot of valid triples (Socher et al., 2013; West et al., 2014). Therefore, much research work has been devoted towards knowledge base completion or link prediction to predict whether a triple (h, r, t) is valid or not (Bordes et al., 2011).
Many embedding models have proposed to learn vector or matrix representations for entities and relations, obtaining state-of-the-art (SOTA) link prediction results Nickel et al. (2016a). In these embedding models, valid triples obtain lower implausibility scores than invalid triples. Let us take the well-known embedding model TransE (Bordes et al., 2013) as an example. In TransE, entities and relations are represented by -dimensional vector embeddings. TransE employs a transitional characteristic to model relationships between entities, in which it assumes that if (h, r, t) is a valid fact, the embedding of head entity plus the embedding of relation should be close to the embedding of tail entity , i.e. + (here, , and are embeddings of , and respectively). That is, a TransE score of the valid triple (h, r, t) should be close to and smaller than a score of an invalid triple (h’, r’, t’). The transitional characteristic in TransE also implies the global relationships among same dimensional entries of , and .
Other transition-based models extend TransE to additionally use projection vectors or matrices to translate head and tail embeddings into the relation vector space, such as: TransH (Wang et al., 2014), TransR (Lin et al., 2015b), TransD (Ji et al., 2015), STransE (Nguyen et al., 2016b) and TranSparse (Ji et al., 2016). Furthermore, DISTMULT (Yang et al., 2015) and ComplEx (Trouillon et al., 2016) use a tri-linear dot product to compute the score for each triple. Recent research has shown that using relation paths between entities in the KBs could help to get contextual information for improving KB completion performance (Lin et al., 2015a; Luo et al., 2015; Guu et al., 2015; Toutanova et al., 2016; Nguyen et al., 2016a). See other embedding models for KB completion in Nguyen (2017).
Recently, convolutional neural networks (CNNs), originally designed for computer vision(LeCun et al., 1998)
, have significantly received research attention in natural language processing(Collobert et al., 2011; Kim, 2014). CNN learns non-linear features to capture complex relationships with a remarkably less number of parameters compared to fully connected neural networks. Inspired from the success in computer vision, Dettmers et al. (2018) proposed ConvE—the first model applying CNN for the KB completion task. In ConvE, only and are reshaped and then concatenated into an input matrix which is fed to the convolution layer. Different filters of the same
shape are operated over the input matrix to output feature map tensors. These feature map tensors are then vectorized and mapped into a vector via a linear transformation. Then this vector is computed withvia a dot product to return a score for (h, r, t). See a formal definition of the ConvE score function in Table 1. It is worth noting that ConvE focuses on the local relationships among different dimensional entries in each of or , i.e., ConvE does not observe the global relationships among same dimensional entries of an embedding triple (, , ), so that ConvE ignores the transitional characteristic in transition-based models, which is one of the most useful intuitions for the task.
In this paper, we present ConvKB—an embedding model which proposes a novel use of CNN for the KB completion task. In ConvKB, each entity or relation is associated with an unique -dimensional embedding. Let , and denote -dimensional embeddings of , and , respectively. For each triple (h, r, t), the corresponding triple of -dimensional embeddings (, , ) is represented as a input matrix. This input matrix is fed to the convolution layer where different filters of the same shape are used to extract the global relationships among same dimensional entries of the embedding triple. That is, these filters are repeatedly operated over every row of the input matrix to produce different feature maps. The feature maps are concatenated into a single feature vector which is then computed with a weight vector via a dot product to produce a score for the triple (h, r, t). This score is used to infer whether the triple (h, r, t) is valid or not.
Our contributions in this paper are as follows:
We introduce ConvKB—a novel embedding model of entities and relationships for knowledge base completion. ConvKB models the relationships among same dimensional entries of the embeddings. This implies that ConvKB generalizes transitional characteristics in transition-based embedding models.
We evaluate ConvKB on two benchmark datasets: WN18RR (Dettmers et al., 2018) and FB15k-237 (Toutanova and Chen, 2015). Experimental results show that ConvKB obtains better link prediction performance than previous SOTA embedding models. In particular, ConvKB obtains the best mean rank and the highest Hits@10 on WN18RR, and produces the highest mean reciprocal rank and highest Hits@10 on FB15k-237.
|Model||The score function|
2 Proposed ConvKB model
A knowledge base is a collection of valid factual triples in the form of (head entity, relation, tail entity) denoted as such that and where is a set of entities and is a set of relations. Embedding models aim to define a score function giving an implausibility score for each triple such that valid triples receive lower scores than invalid triples. Table 1 presents score functions in previous SOTA models.
We denote the dimensionality of embeddings by such that each embedding triple (, , ) are viewed as a matrix . And denotes the -th row of . Suppose that we use a filter operated on the convolution layer. is not only aimed to examine the global relationships between same dimensional entries of the embedding triple (, , ), but also to generalize the transitional characteristics in the transition-based models. is repeatedly operated over every row of to finally generate a feature map as:
where is a bias term and
Our ConvKB uses different filters to generate different feature maps. Let and denote the set of filters and the number of filters, respectively, i.e. , resulting in feature maps. These feature maps are concatenated into a single vector which is then computed with a weight vector via a dot product to give a score for the triple . Figure 1 illustrates the computation process in ConvKB.
Formally, we define the ConvKB score function as follows:
where and are shared parameters, independent of , and ; denotes a convolution operator; and denotes a concatenation operator.
If we only use one filter (i.e. using ) with a fixed bias term and the activation function or , and fix and during training, ConvKB reduces to the plain TransE model (Bordes et al., 2013). So our ConvKB model can be viewed as an extension of TransE to further model global relationships.
We evaluate ConvKB on two benchmark datasets: WN18RR (Dettmers et al., 2018) and FB15k-237 (Toutanova and Chen, 2015). WN18RR and FB15k-237 are correspondingly subsets of two common datasets WN18 and FB15k (Bordes et al., 2013). As noted by Toutanova and Chen (2015), WN18 and FB15k are easy because they contain many reversible relations. So knowing relations are reversible allows us to easily predict the majority of test triples, e.g. state-of-the-art results on both WN18 and FB15k are obtained by using a simple reversal rule as shown in Dettmers et al. (2018). Therefore, WN18RR and FB15k-237 are created to not suffer from this reversible relation problem in WN18 and FB15k, for which the knowledge base completion task is more realistic. Table 2 presents the statistics of WN18RR and FB15k-237.
|Dataset||#Triples in train/valid/test|
|IRN (Shen et al., 2017)||–||–||–||211||–||46.4|
|KBGAN (Cai and Wang, 2018)||–||0.213||48.1||–||0.278||45.8|
|DISTMULT (Yang et al., 2015) ||5110||0.43||49||254||0.241||41.9|
|ComplEx (Trouillon et al., 2016) ||5261||0.44||51||339||0.247||42.8|
|ConvE (Dettmers et al., 2018)||5277||0.46||48||246||0.316||49.1|
|TransE (Bordes et al., 2013) (our results)||3384||0.226||50.1||347||0.294||46.5|
|Our ConvKB model||2554||0.248||52.5||257||0.396||51.7|
|KB (García-Durán and Niepert, 2017)||–||–||–||209||0.309||49.3|
|R-GCN+ (Schlichtkrull et al., 2017)||–||–||–||–||0.249||41.7|
|Neural LP (Yang et al., 2017)||–||–||–||–||0.240||36.2|
|Node+LinkFeat (Toutanova and Chen, 2015)||–||–||–||–||0.293||46.2|
3.2 Evaluation protocol
In the KB completion or link prediction task (Bordes et al., 2013), the purpose is to predict a missing entity given a relation and another entity, i.e, inferring given or inferring given . The results are calculated based on ranking the scores produced by the score function on test triples.
Following Bordes et al. (2013), for each valid test triple , we replace either or by each of other entities in to create a set of corrupted triples. We use the “Filtered” setting protocol (Bordes et al., 2013)
, i.e., not taking any corrupted triples that appear in the KB into accounts. We rank the valid test triple and corrupted triples in ascending order of their scores. We employ three common evaluation metrics: mean rank (MR), mean reciprocal rank (MRR), and Hits@10 (i.e., the proportion of the valid test triples ranking in top 10 predictions). Lower MR, higher MRR or higher Hits@10 indicate better performance.
3.3 Training protocol
We use the common Bernoulli trick (Wang et al., 2014; Lin et al., 2015b) to generate the head or tail entities when sampling invalid triples. We also use entity and relation embeddings produced by TransE to initialize entity and relation embeddings in ConvKB. We employ a TransE implementation available at: https://github.com/datquocnguyen/STransE
. We train TransE for 3,000 epochs, using a grid search of hyper-parameters: the dimensionality of embeddings, SGD learning rate , -norm or -norm, and margin . The highest Hits@10 scores on the validation set are when using -norm, learning rate at , = 5 and = 50 for WN18RR, and using -norm, learning rate at , = 1 and k = 100 for FB15k-237.
To learn our model parameters including entity and relation embeddings, filters and the weight vector , we use Adam (Kingma and Ba, 2014) and select its initial learning rate . We use ReLU as the activation function . We fix the batch size at 256 and set the -regularizer at 0.001 in our objective function. The filters
are initialized by a truncated normal distribution or by. We select the number of filters . We run ConvKB up to 200 epochs and use outputs from the last epoch for evaluation. The highest Hits@10 scores on the validation set are obtained when using = 50, , the truncated normal distribution for filter initialization, and the initial learning rate at on WN18RR; and k = 100, , for filter initialization, and the initial learning rate at on FB15k-237.
3.4 Main experimental results
Table 3 compares the experimental results of our ConvKB model with previous published results, using the same experimental setup. Table 3 shows that ConvKB obtains the best MR and highest Hits@10 scores on WN18RR and also the highest MRR and Hits@10 scores on FB15k-237.
ConvKB does better than the closely related model TransE on both experimental datasets, especially on FB15k-237 where ConvKB gains significant improvements of in MR (which is about 26% relative improvement) and in MRR (which is 34+% relative improvement), and also obtains % absolute improvement in Hits@10. Previous work shows that TransE obtains very competitive results Lin et al. (2015a); Nickel et al. (2016b); Trouillon et al. (2016); Nguyen et al. (2016a). However, when comparing the CNN-based embedding model ConvE with other models, Dettmers et al. (2018) did not experiment with TransE. We reconfirm previous findings that TransE in fact is a strong baseline model, e.g., TransE obtains better MR and Hits@10 than ConvE on WN18RR.
ConvKB obtains better scores than ConvE on both datasets (except MRR on WN18RR and MR on FB15k-237), thus showing the usefulness of taking transitional characteristics into accounts. In particular, on FB15k-237, ConvKB achieves improvements of in MRR (which is about 25% relative improvement) and % in Hits@10, while both ConvKB and ConvE produce similar MR scores. ConvKB also obtains 25% relatively higher MRR score than the relation path-based model KB on FB15k-237. In addition, ConvKB gives better Hits@10 than KB, however, KB gives better MR than ConvKB. We plan to extend ConvKB with relation path information to obtain better link prediction performance in future work.
In this paper, we propose a novel embedding model ConvKB for the knowledge base completion task. ConvKB applies the convolutional neural network to explore the global relationships among same dimensional entries of the entity and relation embeddings, so that ConvKB generalizes the transitional characteristics in the transition-based embedding models. Experimental results show that our model ConvKB outperforms other state-of-the-art models on two benchmark datasets WN18RR and FB15k-237. Our code is available at: https://github.com/daiquocnguyen/ConvKB.
We also plan to extend ConvKB for a new application where we could formulate data in the form of triples. For example, inspired from the work by Vu et al. (2017) for search personalization, we can also apply ConvKB to model user-oriented relationships between submitted queries and documents returned by search engines, i.e. modeling triple representations (query, user, document).
This research was partially supported by the Australian Research Council (ARC) Discovery Grant Project DP160103934.
