1 Introduction

In previous work [Parker et al., 2016], a method for designing experiments on social networks was introduced. That paper presented a linear network effects model, which provided a framework for finding the optimal design of experiments when experimental units were connected according to some relationship, which was specified by an adjacency matrix, and treatment effects propagated to experimental units connected to the experimental unit to which the treatments were applied.

Although in that paper the primary application was the design for experiments on social networks, a variety of examples were given showing how these networks could be useful in many applications, for example in agricultural experiments where experimental units were connected by some spatial relationship, and also in crossover trials, where experimental units were connected by temporal networks.

In that paper, some methods were introduced to exploit symmetries in the network in order to improve the speed of finding an optimal design. In this current paper, we expand this argument, and show that there is a wide class of experiments that can be reformulated into a problem of design on the network, and that by presenting the problem in this networked form, we can suggest how to modify existing algorithms to allow optimal designs on the original problems to be found more quickly by exploiting automorphisms of the network. We recap the previous literature, and the paper we base this work on ([Parker et al., 2016]) in what remains of this section. In Section 2 we give a brief overview of algorithms used currently for design, and propose a new algorithm for social networks based on the properties of the graph. We give examples of use of the new algorithm in Section 3, before showing how this algorithm is useful in a wide variety of design problems, even when there is no obvious network structure. We conclude briefly in Section 5.

1.1 Previous literature

Due to the increasing prevalence of (particularly) social networks, the general field of network science, and statistical analysis of networks has shown growth over recent years. [Aral, 2016] provides a review of the importance of statistical inference and design in social networks, describing that although the literature on analysis of networks has increased rapidly in recent years, there is limited research on experimental design on networks. Much of the research tends to relate to large-scale properties of networks, for example [Basse and Airoldi, 2017]

draw inspiration from model-assisted survey sampling to provide a detailed view of how treatments might be chosen when there are structured relationships represented as networks between experimental units, specifically under a normal-sum model where the response of a node is governed by the sum of normally distributed random variables, determined by the responses of the node’s neighbours.

There have been some attempts to make use of graphs as a tool for finding optimal designs, mostly in the context of block designs. [Wit et al., 2005], for the application of designing efficient experiments for dual-channel microarrays, presents a way of representing experiments with blocks of size two, where when a direct comparison is made between two treatments in a block it is represented as a link in a network. Designs (for the -optimality criterion as we refer to it in this paper) were found by simulated annealing for up to nodes (treatments in the representation of [Wit et al., 2005]). [Bailey, 2007] extends this work on microarrays, and presents optimal designs. [Bailey and Cameron, 2009] generalise this concept to more general block designs by considering the concurrence graph of a block design where nodes representing treatments are joined by a number of edges equal to the number of blocks in which the treatments appear together. By considering properties of the concurrence graph thus formed, they present some interesting combinatoric parallels, and methods for finding optimal designs for these blocked experiments. [Bailey and Cameron, 2011] present some parallels between optimal design criteria and well-known properties of graphs using concurrence graphs, in the context of block designs.

The idea of considering isomorphisms of designs - where two or more designs are equivalent- has been used to reduce the search space for finding optimal designs is established: for example [Ma et al., 2001] provide an algorithm for fractional factorial designs which makes use of isomorphisms to reduce the complexity of calculations; [Bulutoglu and Margot, 2008]

provide a way of classifying orthogonal arrays by isomorphisms.

[Colbourn and Colbourn, 1981] show that the problem of finding whether block designs are isomorphic is equivalent in complexity to the graph automorphism problem. Perhaps surprisingly, this result does not seem to have been used in a constructive method to find designs, as we do in this paper.

Most of the results in this present paper extend [Parker et al., 2016], where we present a linear network effects model which describes the response of each node as depending on the treatment given directly to that node, and also depends on the treatments given to the neighbours of that node. This is summarised in Section 1.2 below. Further recent work in this area follows in [Koutra, 2017].

1.2 Recap of design for networks and notation

[Parker et al., 2016] considers networks of experimental units; a network is an undirected graph, a collection of nodes and edges where the nodes represent experimental units on each of which we apply some treatment. The edges represent relationships between the experimental units.

We assume that if a relationship exists between two experimental units, the response of each experimental unit is dependent on the treatment applied to the other according to a linear network effects model which we specify below.

We have experimental units, and treatments. The relationship between experimental units is specified by the adjacency matrix where if and only if and are related and otherwise. By convention, .

We assume there is a “subject effect” on the response from experimental unit of when treatment is given to that subject, and a “network effect” of if treatment is given to a connected experimental unit (if ). We assume that each experimental unit receives exactly one treatment.

We measure the response for each of our experimental units. Let be the treatment applied to experimental unit ; then our response is modelled as

(1)

We call this model the “Linear Network Effects Model” (LNEM). We assume that errors

are independent and identically distributed with mean 0 and constant variance

. We assume that we wish to estimate the subject and/or network effects, or some contrast of them.

We let

be the indicator vector with

-th element equal to 1 when treatment is applied to subject , and otherwise 0. In matrix form,

(2)

where is our design matrix, and our vector of parameters is

(3)

We calculate the Fisher information matrix as , and choose an optimality criterion: we seek to minimise the average variance of all pairwise differences of treatment effects,

This is defined to be -optimality for estimating the differences in the treatment effects. To ensure estimability, without loss of generality we set .

2 Algorithm

We recap briefly some general properties of design algorithms, which allow us to put our algorithm in context. Let the design space, the set of all possible assignments of treatments to experimental units for our experiment, be . To assess how good a design is we calculate the value of some optimality criterion , and seek to find the design(s) which maximise ; if our optimality criterion is such that we wish to minimise without loss of generality we maximise instead. That is, we wish to find , which we call an optimal design. Typically will be some function of the Fisher information matrix, ; for example A-optimality, a popular criterion, involves taking the average variance of all unknown parameters, which corresponds to , the trace of the inverse of the information matrix. D-optimality, which minimises the joint confidence region for the unknown parameters, can be expressed as . Computationally, is normally hard to evaluate. For example, in A-optimality both the calculation of this information matrix and the resulting inversion of it will be computationally hard.

Typically when finding optimal designs, the design space which we must search over to find a design may be large. For example, if we have experimental units which each take values in some set then the size of the design space will be

, and we suffer from the “curse of dimensionality”. Even if

is the binary set such that each experimental unit may be assigned one of two treatments, then the size of the design space may be . If is a continuous set (e.g. or, a set of equivalent size, the interval , the design space is (infinitely) bigger.

Ideally, we would evaluate the optimality criterion at all possible designs to find the optimal design , but for large design spaces and/or criteria that are difficult to calculate, computational restrictions may mean we can not do this or at least not compute this in a reasonable time. In some cases, analytic results will enable designs to be found exactly without a search algorithm. However, in general we seek some algorithm that enables us to find the optimal design (or a design which is near optimal). In overview, existing algorithms for design seek to do one or both of the following:

  • reduce the complexity of the calculation of the optimality criterion

  • evaluate a subset of such that the overall number of calculations of is smaller.

Many algorithms exist within these categories. The first category includes emulation, used extensively within computer designs, where instead of evaluating a complicated function , we evaluate an emulator , a function which is simpler to evaluate but we believe has similar properties such that for all . Updating formula can also be used in some problems, where we know that for some easy-to-calculate function .

The second category of algorithms include space-filling designs, where a representative sample of designs that “fill” the space are evaluated. There are also many optimisation algorithms, which use the previously evaluated designs and their optimality criterion function evaluations , to choose which design should be evaluated next. Fedorov exchange algorithms, coordinate exchange algorithms, simulated annealing, particle swarm optimisation, many stochastic search algorithms such as Nelder-Mead, are the subject of research. Some of these algorithms are deterministic, in that the choice of is mandated, others are stochastic in that is chosen randomly. To guard against designs which are local maxima, the initial is often chosen randomly, even if the rest of the algorithm is deterministic, and the algorithm repeated with many random chosen as starting designs.

Much of the literature in experimental design revolves around trying to find better algorithms for particular problems. In this work, we do not seek to find new algorithms, but to know how mapping the optimisation problem to a network domain allows us to vastly reduce the number of designs evaluated in order to allow us to find better designs. We can use many existing algorithms with small modifications in this new network framework.

2.1 Using networks for reducing the state space

We show in this section how we can use the network representation of the problem as an advantage when we consider algorithms for design. [Parker et al., 2016] introduced some ideas of how we might improve our algorithms, and we recap these here briefly before expanding these ideas and presenting a new algorithm.

2.1.1 Symmetry of labels

For many optimality criteria we are only interested in differences between treatments, the treatment effects themselves are irrelevant, and treatments are equivalent up to relabelling. For example, designs and are equivalent. We can thus reorder any design so that we only evaluate designs where the first occurrence of label must come before the first occurrence of label . Without loss of generality, we can assign treatment 1 to experimental unit 1.

2.1.2 Symmetry of networks

Figure 1: Example of an automorphism. Subgraphs 1 and 2 can be exchanged, so an automoporphism exists.

In Figure 1, subgraphs 1 and 2 are exchangeable; i.e. if we consider subdesign A on subgraph 1, and subdesign B on subgraph 2 (call this [A1,B2]), we need not also consider [A2,B1] as by symmetry this design has the same criterion function value.

We can thus reduce our design space greatly if we can identify subgraphs where the designs are exchangeable. This is equivalent to finding an automorphism of our network, a relabelling or permutation of the set such that the edges are preserved. This is known as the Graph Automorphism Problem, and finding efficient algorithms to solve this problem has been the topic of much research [Conte et al., 2004]. Until recently, the general case of this problem was thought to be not solvable in polynomial time, that is no algorithm existed that could find a solution for a graph with nodes in time for some constant . (Recently, an algorithm has been found that claims a solution exists in quasi-polynomial time ([Babai, 2015], although this result has not yet been peer-reviewed.).

Whatever the theoretical complexity, in practice fast algorithms exist already that can effectively and quickly find automorphisms in most cases, for example the VF2 algorithm[Cordella et al., 2001], which in the general case finds isomorphisms between two graphs and . This algorithm is based on a tree search, where a set of nodes corresponding to a partial match between subgraphs of and is maintained, and then nodes connected to these subgraphs are considered to see if they can extend the matching subgraphs. This algorithm is fast, and implemented by the popular igraph package (http://igraph.org/) available in many programming languages, including R. Here, we find automorphisms by setting . Many algorithms exist, but we chose VF2 as it was fast enough for our purposes, and was readily incorporated in the software made available with tis paper.

2.2 New framework for design algorithm

We present below a general algorithm:

  1. Rewrite original problem in graph form.

  2. Find the automorphisms isos of the graph using the VF2 algorithm. This is a set such that for any labelling of the graph corresponding to design , all designs will be automorphisms of .

  3. Set , and pick an initial candidate design .

    1. Check whether , i.e. if is the first design in the lexicographical order of automorphisms of . If so,

      • evaluate the optimality criterion

      • increment by 1.

    2. Set . Pick next candidate design according to algorithm of choice next based on and , so that .

    3. If we have reached a stopping criterion, i.e if for some stopping criterion stop, then stop, otherwise repeat from 3a.

Typical choices of the next algorithm might be the Fedorov exchange algorithm, an exhaustive search, etc. Typical choices of the stop criterion might be that or representing some fixed budget on the number of design points examined or function evaluations made, or that , i.e. we have not seen an improvement in the last steps.

2.2.1 Treatment Structure

In this paper we restrict ourselves to designs on unstructured treatments; that is our design space is such that . We do this for clarity of exposition of our method, but the general ideas extend to factorial and other treatment structures.

2.2.2 Illustrative example

Consider the network represented by 3-1-2, where we have three nodes such that nodes 3 and 2 are each connected to node 1 and there are no other connections. It is clear that the network is automorphic to 2-1-3. Let , and let a design be represented by where is the treatment given to node . In other words means we give treatment A to node 1, B to node 2, and B to node 3. Note that where the elements of the design space are clearly in lexicographical order. Let, , and we let next be the next design lexicographically, and let our stopping criterion be stop if . Then the automorphisms allow us to show that two pairs of designs are equivalent (, ); thus in step 3a, we do not evaluate for designs or . We have therefore reduced the number of designs we must consider from 8 to 6..

2.2.3 Rationale

For many designs, evaluating the optimality criterion function requires (sometimes substantial) computational time, and by reducing the number of evaluations required, we can reduce the computational time required. Alternatively, for the same computational time, we can search more of the design space and hope to find a better design.

There is some computational overhead in the new algorithm; evaluating the automorphisms initially can be slow, however this needs to be done just once for each network, so for large designs this time is not a large proportion of the total computation time. There is also some overhead in step 3(a), as checking whether a design is lowest in lexicographical ordering of all automorphisms of that design requires some computation. However, we show that this overhead is substantially lower than the cost of evaluating in some simple examples, so our algorithm can lead to substantial improvements in finding designs. For particular networks, for example networks with a large number of automorphisms relative to the size of the network, the overhead may be prohibitive. This may be the case for dense or highly regular networks. We investigate the computational complexity of the algorithm in 4.3.

3 Examples of use of automorphisms in finding designs

Figure 2: A social network (Example 1 in [Parker et al., 2016]. Top nodes are node numbers and bottom nodes are optimal design for treatments for estimating difference in treatment effects allowing for network effects under Linear Network effects model.

We return to a small example which was Example 1 in [Parker et al., 2016] and represents a social network. This is shown in Figure 2, together with the optimal design for estimating with minimal variance the difference between the treatment effects, , under the LNEM (1). The list of edges is shown in the Appendix.

The optimal design was evaluated using exhaustive search. For each candidate design in our design space (there are designs), the information matrix must be calculated (this a 4 by 4 matrix with columns representing , recalling we can omit the column corresponding to ). This matrix must be inverted, and the inversion is responsible for much of the computational effort in finding the optimal design. In practice, we can note that as we are only interested in differences between subject effects, we can appeal to symmetry of labels to fix the treatment for experimental unit 1 as the first treatment.

In [Parker et al., 2016] we did not use the symmetries of the network, but found the design under exhaustive search; here we use an exhaustive search (so that our next design calculates the lexicographically subsequent design), but will only evaluate designs which are first lexicographically amongst all designs which are automorphisms of the current considered design. We will thus evaluate fewer designs, and stop when one design from each automorphism class has been evaluated.

We naturally find the same optimal design, but evaluate the information matrix 236 times as opposed to 507 times, and use a processing time of 0.02 seconds as opposed to 0.04 seconds.

Example n Number of automorphisms Evaluations without automorphisms Evaluations with automorphisms Time without automorphisms Time with automorphisms
1. Small social network 10 8 507 236 0.04 0.02
2. Small social network 10 1 511 511 0.04 0.04
3. Larger social network 20 8 524287 221183 58.58 31.56
4. Block design with neighbour effects 12 384 535008 18766 108.52 33.68
5. Non-rectangular field trial 15 2 2368741 1581572 279.6 197.58
6. Crossover trial with dropouts 15 6 2262800 904555 283.86 134.26
Table 1: Comparison of exhaustive search algorithms with and without automorphisms

We can repeat this evaluation for all the networks in [Parker et al., 2016], the edge list for each of which is shown in the Appendix. We chose these networks as they represent a variety of different types of network structures, which relate to a variety of different applications. The results are shown in Table 1, and indicate that the number of function evaluations is greatly reduced for all the networks (except network 2, where there are no non-trivial automorphisms) and that the time taken to perform the exhaustive search is greatly reduced, even when taking into account the time needed for calculating automorphisms and lexicographical ordering checking as described above.

We include the computational time as a guide; this will vary greatly between implementations in different software for these small networks, but gives an idea of how effective computationally the use of automorphisms is for finding designs on network problems, even for small networks.

3.1 Implementing a simple coordinate exchange algorithm

We demonstrate how the framework can be combined with a non-trivial design algorithm by showing as an example the cyclic coordinate descent algorithm described fully in[Meyer and Nachtsheim, 1995].

We pick a random starting design. Each node is considered in turn, and for each node we cycle through all possible treatments for that node to see if changing the treatment allocated to that node can improve the design. If we find an improvement, we fix that design, and start again. If after checking all treatments we find that changing the treatment on this node does not improve the design, we move to the next node. When we have cycled through all nodes without improvement, we stop.

In the language of our general algorithm above, we pick

where is the unit vector with all elements zero except the -th, which is 1, and is the maximum design so far discovered such that . for design . The stopping criterion is chosen such that

i.e. if we have evaluated all designs resulting from changing one coordinate and not seen an improvement.

Example n Number of automorphisms Evaluations (CD) Evaluations (ES) Efficiency of design found with CD
1. Small social network 10 8 77 236 1
2. Small social network 10 1 145 511 0.944
3. Larger social network 20 8 127 221183 0.989
4. Block design with neighbour effects 12 384 14 18766 0.873
5. Non-rectangular field trial 15 2 82 1581572 0.931
6. Crosover trial with dropouts 15 6 93 90455 1
Table 2: Comparison of coordinate descent (CD) and exhaustive search (ES) algorithms, both methods using automorphisms.

We perform 100 random starts to mitigate the algorithm finding local maxima. To demonstrate how this algorithm can work with automorphisms, we apply this algorithm to the same 6 networks as in Table 1 above. We present the results as Table 2. We can see that even this simple algorithm is compatible with the network framework of taking automophisms into account, and a very small number of function evaluations are made, with generally highly efficient designs being found.

4 Block designs as networks

We seek to generalise the framework developed to include a wider class of models. We start with a simple example.

Suppose we have four blocks, each of four experimental units. Let us suppose we wish to allocate treatments labelled with corresponding unknown effects to the experimental units to maximise some optimality criterion; for example we may wish to estimate

This is defined to be -optimality for estimating the differences in the treatment effects. We call this criterion function .

A typical schematic for the structure of the experiment might be written down as in the left of Figure 3. It is clear that experimental units 1,2,3, and 4 are contained within block 1, and so on. We might choose to represent the experiment pictorially as in the right of Figure 3.

Block Experimental Units 1 1 2 3 4 2 5 6 7 8 3 9 10 11 12 4 13 14 15 16
Figure 3: Left: A traditional representation of a simple block design with 16 units in four blocks. Right: A representation of a blocked experiment as a network design. Experimental units numbered 1 to 16 are in black circles, and blocks are indicated by with red circles.

Why is this useful? Let us now imagine that the 20 nodes are experimental units that are connected according to the relationship shown in Figure 3. We forget that the nodes have any special meaning now, save that we may assign treatments only to the first 16 nodes, and that node B1 is assigned treatment , node B2 assigned treatment , B3 assigned and finally B4 assigned .

In order to find the -optimal design, we can write the model for our blocked experiment as

(4)

where A is the adjacency matrix where whenever there is a link as shown in the Figure (e.g. , and otherwise).

By writing as , we can see immediately that this is equivalent to

a more familiar representation of a blocked experiment, where is block effect of experimental unit in block . As if and only if node is linked to node , and this only happens when experimental unit is in block for , we can replace , , and so on.

Perhaps more simply, the network effects of the special nodes representing blocks in the linear network effects model are replaced by the block effects. We can think of the block effects as propagating like network effects from the special nodes B1, B2, B3, B4. We will normally wish to estimate some function of the treatment effects only (block effects are often not of interest but it is important to account for them in the design), and as the treatment effects for nodes B1, B2, B3, B4 are irrelevant (we cannot measure the experiment units B1, B2, B3, B4 directly as they are not real units!), we ignore them and use the same optimality criterion as before. As we are not estimating all effects, strictly this is now optimality rather than A optimality.

The properties of the two designs can be summarised in Table 3 .

Original Problem Network Problem
No of Treatments
Experimental Units
Wish to estimate Average pairwise variance of for all Average pairwise variance of for all
Optimality criterion A
Restrictions Can apply any treatment to any unit. Can apply treatments 1,…,m to units , and treatments 3,4,5,6 to units B1-B4.
Table 3: Comparison of original and augmented network design for treatments.

We have thus shown (at least for this simple example) an equivalence between a traditional design (in this case a block design) and a network design as found in the paper [Parker et al., 2016]. A major advantage of writing a block design in this way is that we can now find optimal designs for block designs in the same way as for network designs, and that we can use the automorphisms found from the network representation of the experimental framework in order to find optimal designs faster. The network setting allows us to develop one set of effective algorithms, rather than regarding blocked experiments as a special class with its own method for finding optimal designs.

4.1 Other block designs as networks

C1 C2 C3 R1 1 2 3 R2 4 5 6 R3 7 8 9
Figure 4: A Row Column Design in (left) a traditional representation and (right) a network diagram.

In a similar method to the one-way block design, it is possible to represent a variety of block designs as networks. For all blocking factors each block can be written as a new network node, linked to all experimental units within that block. We present examples for a double-blocked experiment (a row-column design) as Figure 4. This is readily extendable to more than two blocking factors.

Period P1 P2 P3 Subject a 1 2 3 b 4 5 6 c 7 8 9
Figure 5: A Crossover Design in (left) a traditional representation and (right) a network diagram.

In a crossover design, subjects receive treatments sequentially over several time periods, and an experimenter wishes to account for the treatment possibly still having some effect in a later time period than that for which it is applied. We can represent a crossover-design similarly to a row-column design as Figure 5. Experimental units are subject-period combinations, and we assume that subjects behave similarly, so subject is a blocking factor, and periods may be a blocking factor, so we add extra block nodes as we did for the row-column designs. In addition, we assume a treatment applied to a subject may affect the subject in the next time period, so there may be a carryover effect from experimental unit 1 to 2, 2 to 3, 4 to 5, etc. We represent this carryover effect by the network effect of the treatment given to the experimental unit preceding in time, but note this carryover effect only extends to the next time period, so links in the network are directed. This is similar to Example 6 in [Parker et al., 2016].

4.2 Advantages of changing design space

The argument explained in 2.2.3 applies: by evaluating only one design from each class of automorphic designs, we can make significant savings in the amount of time to evaluate candidate design.

We evaluate several experimental structures to demonstrate this in practice, for which the experimental designs are well-known:

  1. 3 blocks of size 3 (), with 3 treatments. (The optimal designs are randomised complete block designs.)

  2. 4 blocks of size 3 (), with i) 3 and ii) 4 treatments. (The optimal designs are i) randomised complete block designs and ii) balanced incomplete block designs.)

  3. A row-column structure with 3 rows and 3 columns, each row-column intersection containing a single experimental unit, with 3 treatments. (The optimal designs are Latin Squares of size 3.)

  4. A row-column structure with 4 rows and 4 columns, each row-column intersection containing a single experimental unit, with i)3 and ii)4 treatments. (The optimal designs in ii) are Latin Squares of size 4.)

Example n m Number of automorphisms Evaluations without automorphisms Evaluations with automorphisms Time without automorphisms Time with automorphisms
1. 3x3 Blocks 9 3 1296 2925 94 2.52 1.54
2i. 4x3 Blocks 12 3 82944 86126 379 55.44 310.02
2ii. 4x3 Blocks 12 4 82944 605960 1808 378.82 1051.54
3. 3x3 Row Column 9 3 241 72 2807 1.9 0.48
4i. 4x4 Row Column 16 3 1152 7123656 34873 6051.12 493.32
4ii. 4x4 Row Column 16 4 1152 170863644 1610909 141456.6 14123.94
Table 4: Designs for various block designs. Number of evaluations of optimality criterion and computational time with and without automorphisms

We do not claim that these designs would be sensibly found via this method, as the solutions are known analytically, but we seek to demonstrate the benefits of using automorphisms in reducing computational time.

The results are presented as Table 4. Clearly the number of optimality function evaluations is vastly reduced for networks a large number of automorphisms. However, for some networks, such as 2i and 2ii, the overhead in the implementation caused by searching for automorphisms and then checking the lexicographical order of the candidate designs might make the use of automorphisms inefficient.

For larger designs, such as 4i, with a moderate number of automorphisms, we see a more than tenfold reduction in processing time and a hundred-fold reduction in number of evaluations, suggesting that this method works better for networks with a moderate number of automorphisms.

In practice, by taking into account network structure, practitioners may be able to make a very large saving in time to find optimal designs with very little modification to existing algorithms, meaning designs found using stochastic algorithms in fixed computing time may be better.

4.3 Computational Justification

Recall that for unstructured treatments. For our optimality criterion, and indeed most common optimality criteria, when calculating we must calculate the Fisher information matrix and invert it to find a variance-covariance matrix, then make some calculation of this final matrix. We assess the typical computational complexity for each design we consider.

  • The complexity for calculation of the Fisher information matrix from where is an matrix is typically .

  • The Fisher information matrix in our model (1) is of size . Inverting the matrix depends on the algorithm used, but is where .

  • Calculating the optimality criterion from the variance-covariance matrix depends on what criterion is used; the trace (A-optimality) is , taking the determinant (D-optimality) will typically be where .

Thus for each design evaluated, and assuming a simple optimality criterion, as (in general we have many more experimental units than treatments) the limiting step is the first step above and therefore calculating has computational complexity of .

The complexity of the overhead in the new framework algorithm involves i) the initial time to calculate automorphisms originally, and ii) the computational cost of checking whether each design is lowest lexicographically amongst all possible automorphic designs.

Let us assume the size of isos is . i.e. there are automorphisms for our network. We map each design of length to an automorphism of itself which reorders the design, each time this operation is . We must do this times (once for each automorphism), and then sort the resulting list of automorphic designs to find the smallest, which can be done in for a good sorting algorithm. Thus the overall computational complexity of checking whether a design is first lexicographically is .

Thus the computational complexity involved in the proposed algorithm where we first check that a design is valid, and if it is calculate the design, is , where the in the denominator in the second term arises because we must calculate for one design in every .

Evaluating one design for the algorithm without automorphisms is ; for the new method is . The ratio of the new to the old is

Thus the effectiveness of our new algorithm depends on the relative sizes of , , and . We find must be small compared to but not too small. This is supported by the results in Table 4, which show the computational time to be reduced significantly for moderate , but actually increased for very large , as the overhead in finding and ordering automorphisms is high here.

5 Conclusions

We have shown that the use of automorphisms for reducing the number of evaluations required of an optimality criterion function is effective on designs where experimental units have a network structure. Moreover, we have shown that we can take block designs with no apparent network structure, such as one-way blocked experiments, row-column experiments, and crossover designs, and add block nodes to induce a network structure. Using automorphisms on these experiments with induced networks is also effective at reducing the complexity of experimental design algorithms.

From a practical point of view, many algorithms for design exist in isolation; we must program an algorithm for split-plot designs differently, perhaps, to how we program row-column designs. We argue that a framework such as we suggest with this paper may promote general purpose algorithms, neggating the need to maintain different algorithms for particular designs. Although algorithms for design can take into account automorphic designs to avoid recalculation of for an automorphic design, in general they do not, and this network representation allows automorphisms to be found readily by algorithms that are quick and available in existing software. We believe that this work may lead to standardisation of algorithms across seemingly different classes of experiment.

References

  • [Aral, 2016] Aral, S. (2016). Networked experiments. The Oxford Handbook of the Economics of Networks.
  • [Babai, 2015] Babai, L. (2015). Graph isomorphism in quasipolynomial time. CoRR, abs/1512.03547.
  • [Bailey, 2007] Bailey, R. (2007). Designs for two-colour microarray experiments. Journal of the Royal Statistical Society: Series C (Applied Statistics), 56(4):365–394.
  • [Bailey and Cameron, 2011] Bailey, R. and Cameron, P. J. (2011). Using graphs to find the best block designs. arXiv preprint arXiv:1111.3768.
  • [Bailey and Cameron, 2009] Bailey, R. A. and Cameron, P. J. (2009). Combinatorics of optimal designs. Surveys in Combinatorics, 365(19-73):3.
  • [Basse and Airoldi, 2017] Basse, G. W. and Airoldi, E. M. (2017). Preprint: Model-assisted design of experiments in the presence of network correlated outcomes. ArXiv e-prints.
  • [Bulutoglu and Margot, 2008] Bulutoglu, D. A. and Margot, F. (2008). Classification of orthogonal arrays by integer programming. Journal of Statistical Planning and Inference, 138(3):654–666.
  • [Colbourn and Colbourn, 1981] Colbourn, M. J. and Colbourn, C. J. (1981). Concerning the complexity of deciding isomorphism of block designs. Discrete Applied Mathematics, 3(3):155–162.
  • [Conte et al., 2004] Conte, D., Foggia, P., Sansone, C., and Vento, M. (2004).

    Thirty years of graph matching in pattern recognition.

    International journal of pattern recognition and artificial intelligence

    , 18(03):265–298.
  • [Cordella et al., 2001] Cordella, L. P., Foggia, P., Sansone, C., and Vento, M. (2001). An improved algorithm for matching large graphs. In 3rd IAPR-TC15 workshop on graph-based representations in pattern recognition, pages 149–159.
  • [Koutra, 2017] Koutra, V. (2017). Designing Experiments on Networks. PhD thesis, University of Southampton.
  • [Ma et al., 2001] Ma, C.-X., Fang, K.-T., and Lin, D. K. (2001). On the isomorphism of fractional factorial designs. journal of complexity, 17(1):86–97.
  • [Meyer and Nachtsheim, 1995] Meyer, R. K. and Nachtsheim, C. J. (1995). The coordinate-exchange algorithm for constructing exact optimal experimental designs. Technometrics, 37(1):60–69.
  • [Parker et al., 2016] Parker, B. M., Gilmour, S. G., and Schormans, J. (2016). Optimal design of experiments on connected units with application to social networks. Journal of the Royal Statistical Society: Series C (Applied Statistics), 66(3):455–480.
  • [Wit et al., 2005] Wit, E., Nobile, A., and Khanin, R. (2005). Near-optimal designs for dual channel microarray studies. Journal of the Royal Statistical Society: Series C (Applied Statistics), 54(5):817–830.

Appendix

The following lists the edges for the six examples shown in this paper. These are also shown visually in examples in [Parker et al., 2016]. “i-j” means an edge exists between and , and the corresponding entry in the adjacency matrix . If no edge it shown then . Examples 1 to 5 are undirected networks. In Examples 6, the network is directed, such that “i->j” means that , but note that .

Example 1: 1-7, 2-7, 3-6, 4-5, 6-9, 9-10

Example 2: 1-5, 1-8, 1-10, 2-3, 2-4, 2-7, 2-8, 2-9, 2-10, 3-4, 3-7, 3-9,
4-6, 4-7, 4-8, 4-9, 4-10, 5-9, 6-7, 7-10, 8-10, 9-10

Example 3: 1-2, 1-4, 2-3, 2-5, 2-9, 2-14, 2-17, 3-4, 3-8, 3-12, 3-13, 3-16,
4-6, 4-7, 4-9, 4-10, 4-11, 4-15, 4-20, 5-6, 5-7, 5-10, 5-14, 6-18, 7-19,
9-11, 9-13, 9-16, 9-20, 10-15, 10-17, 10-18, 15-19

Example 4: 1-2, 2-3, 4-5, 5-6, 7-8, 8-9, 10-11, 11-12

Example 5: 1-2, 1-4, 2-3, 2-4, 2-5, 3-5, 4-7, 4-8, 4-9, 5-9, 5-10,
6-7, 6-11, 6-12, 7-8, 7-11, 7-12, 7-13, 8-9, 8-12, 8-13, 8-14,
9-10, 9-13, 9-14, 9-15, 10-14, 10-15, 11-12, 12-13, 13-14, 14-15,

Example 6: 2->1, 3->2, 4->3, 6->5, 9->8, 10->9, 11->10, 13->12,
14->13, 15->14

Software

A draft package to find designs for networks, including the augmented networks for block designs, is available at https://www.dropbox.com/s/fgfn2f2my4yqlzr/networkDesign_0.0.0.9001.tar.gz?dl=0. Scripts are provided to allow the reader to reproduce many of the results in this paper, as well as those in [Parker et al., 2016].
